Danfoss PVED-CL Technical Information page 21

Technical Information
Configuration
PVED-CL Communication Protocol, version 1.38 Technical Information
CAN message
Priority
PGN
XID
Occurrence
Modes
Sent by
Sent to
Data field
Bytes Encoding
1, 2 UNSIGNED16
3 UNSIGNED8
11079551 • Rev BA • July 2014
6
61184
0x0FA8 (MSB first)
if required, within 200ms after PVED-CL's Address Claim
only during start-up
configuration tool
PVED-CL
Value/Range Description
0x0FA8 (MSB first) extended message identifier (XID)
0x58 check value
21
