PVED-CL Communication Protocol, version 1.38 Technical Information
A typical successful valve auto-calibration message sequence:
MMI.StartValveAutoCalibration → PVED-CL
PVED-CL.ValveAutoCalibrationStatus.auto-calibration in progress → MMI
PVED-CL.ValveAutoCalibrationStatus.auto-calibration in progress → MMI
...
PVED-CL.ValveAutoCalibrationStatus.auto-calibration in progress → MMI
PVED-CL.SetParameterResponse.right dead-band value (index 738) → MMI
PVED-CL.ValveAutoCalibrationStatus.auto-calibration in progress → MMI
PVED-CL.SetParameterResponse.left dead-band value (index 737) → MMI
PVED-CL.ValveAutoCalibrationStatus.auto-calibration in progress → MMI
PVED-CL.SetParameterResponse.right maximum value (index 747) → MMI
PVED-CL.ValveAutoCalibrationStatus.auto-calibration in progress → MMI
PVED-CL.SetParameterResponse.left maximum value (index 729) → MMI
PVED-CL.CommitDataResponse.Commit operation has just begun → MMI
PVED-CL.ValveAutoCalibrationStatus.Commit process has started → MMI
PVED-CL.CommitDataResponse.Commit succeeded → MMI
PVED-CL.ValveAutoCalibrationStatus.auto-calibration completed → MMI
Used for requesting the program change for a defined steering device.
CAN message
Priority
PGN
XID
Occurrence
Modes
Sent by
Sent to
Data field
Bytes Encoding
1, 2 UNSIGNED16
3 UNSIGNED8
11079551 • Rev BA • July 2014
6
61184
0x0FAE (MSB first)
when required
operational, reduced
MMI
PVED-CL
Value/Range Description
0x0FAE (MSB first) extended message identifier (XID)
program number for:
0 – 9 – steering wheel
20 – 24 – high priority steering device
25 – 29 – low priority steering device
30 – 34 – high priority external set-point controller
