Diagnostics - Danfoss PVED-CL Technical Information

Technical Information
Communications
PVED-CL Communication Protocol, version 1.38 Technical Information
Flags available in status messages (guidance machine status)
State Request Reset
Command Status
1 No status message transmitted
2 00 – reset not required
01 – reset required
3
4 00 – reset not required
5 00 – reset not required
6 00 – reset not required
1)
Error indication is reported if the steering wheel disengage ability check (if enabled) has failed. This means that too
much time has passed since a steering wheel position change has last exceeded the defined position change
threshold. Both the position change threshold and the timeout value can be configured as required by the
application.
To allow removable set-point controllers to be used, vehicle specific data can be stored in the PVED-CL's
configuration memory. For further details refer to PVED-CL User Manual, 11079550.

Diagnostics

Although PVED-CL supports J1939 diagnostic protocol [J1939-73], there exists a proprietary way of
informing about errors. The configuration/diagnostic tool has an access to the event logs maintained by
PVED-CL's software, which is intended to make the debugging easier as well as to help an OEM or a
support team to tune the system. Detailed information about the interface is provided in the chapter
Diagnostics (proprietary) on page 35.
11079551 • Rev BA • July 2014
Steering Input Position Machine can Execute
Status Commands
11 – not available 11 – not available
01 – correct position or 00 – system is not ready
1)
10 – error indication
01 – correct position or 00 – system is not ready
1)
10 – error indication
01 – system is ready
01 – correct position
00 – incorrect position
00 – system is not ready
Mechanical System
Lockout
01 – active
00 – inactive
00 – inactive
00 – inactive
00 – inactive
13
