Status

GetCurrentMode

GetCurrentModeResponse

StartStopStatus

22
PVED-CL Communication Protocol, version 1.38 Technical Information
Used to get the information about the current PVED-CL mode.
CAN message
Priority
PGN
XID
Occurrence
Modes
Sent by
Sent to
Data field
Bytes Encoding
1, 2 UNSIGNED16
Information about the current mode.
CAN message
Priority
PGN
XID
Occurrence
Modes
Sent by
Sent to
Data field
Bytes Encoding
1, 2 UNSIGNED16
3 UNSIGNED8
This command is used to make PVED-CL start/stop sending status information. Power-on state: status
disabled.
11079551 • Rev BA • July 2014
6
61184
0x0FA9 (MSB first)
when required
operational, reduced, calibration, fault
configuration tool
PVED-CL
Value/Range Description
0x0FA9 (MSB first) extended message identifier (XID)
6
61184
0x0FAA (MSB first)
200 ms after claiming an address (if no address arbitration lost) and upon
request
operational, reduced, calibration, fault
PVED-CL
configuration tool
Value/Range Description
0x0FAA (MSB first) extended message identifier (XID)
0x55 current mode:
0x0AA – calibration
0x0AF – operational
0x0FF – reduced
– fault
