Technical Information

Diagnostics (proprietary)

GetErrorEntry

GetErrorEntryResponse

PVED-CL Communication Protocol, version 1.38 Technical Information
The command is used to retrieve the data stored in error buffers.
CAN message
Priority
PGN
XID
Occurrence
Modes
Sent by
Sent to
Data field
Bytes Encoding
1, 2 UNSIGNED16
3 UNSIGNED8
4 UNSIGNED8
The message presents data available in the error log.
CAN message
Priority
PGN
XID
Occurrence
Modes
Sent by
Sent to
Data field (error identification data)
Bytes Encoding
1, 2 UNSIGNED16
3 UNSIGNED8
4 UNSIGNED8
5 UNSIGNED8
11079551 • Rev BA • July 2014
3
61184
0x0FB3 (MSB first)
when needed
operational, reduced, calibration and fault
configuration tool
PVED-CL
Value/Range Description
0x0FB3 (MSB first) extended message identifier (XID)
1 – 16 buffer index (the oldest error at index 1)
0 Request details
1 – error code
2 – timestamp when error occurred since power on
– PVED-CL PCB temperature when error occurred
6
61184
0x0FB4 (MSB first)
upon request
operational, reduced, calibration and fault
PVED-CL
configuration tool
Value/Range Description
0x0FB4 (MSB first) extended message identifier (XID)
1 – 16 buffer index (the oldest error at index 1)
0 error code details
error severity:
0 – caution
0x55 – nominal
0xAA – critical
0xFF – wrong index or no information available
35
