AK-CC55 Connect menu (SW ver. 2.1x)

Start / Stop

Table 23: Start / Stop
Function Description
Main switch Start / stop of refrigeration. With this setting refrigera-
tion can be started, stopped or a manual override of
the outputs can be allowed. (For manual control the
value is set at -1. Then the outputs can be force con-
trolled. Start / stop of refrigeration can also be accom-
plished with the external switch function connected
to a DI input.Stopped control will give a "Main switch
OFF" alarm.
Delay of outputs at Delay of output signal after start-up After start-up or a
power up power failure the controller's functions can be de-
layed so that overloading of the electricity supply net-
work is avoided. Here you can set the time delay.

Configuration

Table 24: Configuration
Function Description
Main switch Start / stop of refrigeration. With this setting refrigera-
tion can be started, stopped or a manual override of
the outputs can be allowed. (For manual control the
value is set at -1. Then the outputs can be force con-
trolled. Start / stop of refrigeration can also be accom-
plished with the external switch function connected
to a DI input.Stopped control will give a "Main switch
OFF" alarm.
Application mode Selection of application The controller covers several
applications for control of a refrigerated case. Here
you set which of the possible applications is re-
quired.This menu can only be set when regulation is
stopped, i.e. "r12 Main Switch" is set to 0.
DO2 Configuration Select the function of the digital output
DO3 Configuration Select the function of the digital output
DO4 Configuration Select the function of the digital output
AO1 Configuration Select the function of the analogue output
DI1 Configuration Select the function of the digital input
DI2 Configuration Select the function of the digital input
Refrigerant Select the type of refrigerant. If the required refriger-
ant is not part of the list, the user defined option can
be used. Please contact Danfoss for detailed informa-
tionWarning: Wrong selection of refrigerant may
cause damage to the system.
Refrigerant factor K1 Refrigerant factor for a custom refrigerant - please
contact Danfoss for detailed information
© Danfoss | Climate Solutions | 2022.08
Values
-1=Manual, 0=Stop, 1=Start
Values
-1=Manual, 0=Stop, 1=Start
1=1. Comp/Alarm/Fan/Defrost, 2=2. Comp/Light/Fan/
Defrost, 3=3. Comp/Railheat/Fan/Defrost, 4=4. Comp/
Custom, 5=5. EEV/Comp/Fan/Defrost, 6=6. EEV/
Alarm/Fan/Defrost, 7=7. EEV/Light/Fan/Defrost, 8=8.
EEV/Rail/Fan/Defrost, 9=9. EEV/Custom
0=None, 1=Fans, 2=Fan ECO, 3=Defrost, 4=Rail heat,
5=Alarm, 6=Light, 7=Blinds, 8=Compressor/LLSV,
9=Compressor 2, 10=Air heater
0=None, 1=Fans, 2=Fan ECO, 3=Defrost, 4=Rail heat,
5=Alarm, 6=Light, 7=Blinds, 8=Compressor/LLSV,
9=Compressor 2, 10=Air heater
0=None, 1=Fans, 2=Fan ECO, 3=Defrost, 4=Rail heat,
5=Alarm, 6=Light, 7=Blinds, 8=Compressor/LLSV,
9=Compressor 2, 10=Air heater
0=None, 1=Rail heat PWM
0=None, 1=DI status, 2=Door function, 3=Door alarm,
4=Defrost start, 5=Main switch, 6=Night setback,
7=Thermostat band, 8=Alarm at closed, 9=Alarm at
open, 10=Case cleaning, 11=Forced cooling,
12=Open blinds, 13=Coordinated defrost, 14=Forced
closing, 15=Shutdown, 16=Light control, 20=Leak de-
tection, 21=Adaptive liquid control, 29=Door fan stop
0=None, 1=DI status, 2=Door function, 3=Door alarm,
4=Defrost start, 5=Main switch, 6=Night setback,
7=Thermostat band, 8=Alarm at closed, 9=Alarm at
open, 10=Case cleaning, 11=Forced cooling,
12=Open blinds, 13=Coordinated defrost, 14=Forced
closing, 15=Shutdown, 16=Light control, 20=Leak de-
tection, 21=Adaptive liquid control, 29=Door fan stop
0=Not seleted, 6=R13, 7=R13b1, 2=R22, 8=R23,
14=R32, 11=R114, 3=R134a, 12=R142b, 24=R170,
15=R227, 25=R290, 16=R401A, 18=R402A, 19=R404A,
21=R407A, 22=R407B, 20=R407C, 37=R407F,
49=R407H, 23=R410A, 32=R413A, 30=R417A,
31=R422A, 33=R422D, 34=R427A, 35=R438A,
40=R448A, 41=R449A, 48=R449B, 43=R450A,
44=R452B, 45=R454B, 9=R500, 4=R502, 10=R503,
17=R507, 36=R513A, 26=R600, 27=R600a, 5=R717,
28=R744, 46=R1233zdE, 38=R1234ze, 39=R1234yf,
47=R1234zeZ, 29=R1270, 42=R452A, 1=User defined,
13=User defined display
Code Short name
r12 r12 Main switch
o01 o01 DelayOfOutp.
Code Short name
r12 r12 Main switch
o61 o61 Appl. mode
q02 q02 DO2 Config.
q03 q03 DO3 Config.
q04 q04 DO4 Config.
q09 q09 AO1 Config.
o02 o02 DI1 Config.
o37 o37 DI2 Config.
o30 o30 Refrigerant
P83 P83 RfgFac.K1
BC365212986197en-000201 | 45
