CommitDataResponse

EnterCalibrationMode

20
PVED-CL Communication Protocol, version 1.38 Technical Information
CAN message (continued)
Sent by
Sent to
Data field
Bytes Encoding
1, 2 UNSIGNED16
3 UNSIGNED8
Sent back to signal any change in the commit process status.
This means the CommitData command may result in several responses, e.g. ready > in progress >
succeeded.
The minimum delay between responses is set to 40 ms.
CAN message
Priority
PGN
XID
Occurrence
Modes
Sent by
Sent to
Data field
Bytes Encoding
1, 2 UNSIGNED16
3 UNSIGNED8
4, 5 UNSIGNED16
This command is used to force PVED-CL to enter the calibration mode, for further information see PVED-
CL User Manual, 11079550 and shall be sent within 200ms after PVED-CL transmits its Address Claimed
message.
Once the system state changes to Calibration, a response – GetCurrentModeResponse with a proper
mode identifier – will be sent back.
11079551 • Rev BA • July 2014
configuration tool
PVED-CL
Value/Range Description
0x0FA6 (MSB first) extended message identifier (XID)
0x5A check value
6
61184
0x0FA7 (MSB first)
upon request
operational, reduced, calibration
PVED-CL
configuration tool
Value/Range Description
0x0FA7 (MSB first) extended message identifier (XID)
Commit status:
0x00 – ready to perform commit operation
0x01 – commit operation has just begun
0x02 – the operation succeeded
0x03 – the operation failed
0x04 – parameter cross-check failed
0x05 – commit is already in progress
Commit error code If commit operation failed, an error code on the
particular parameter cross-check is issued.
If commit operation succeeded, the value is 0.
Please refer to Commit Error Code on page 37.
