CAPTURING SCREENSHOT USING THE REMOTE CONTROL

To capture a screenshot on GVC3200/GVC3202, the users can press the red shortcut key
blue shortcut key
internal storage of GVC3200/GVC3202. The users can access the screenshot in GVC3200/GVC3202
LCD menu->Applications->File Manager->Internal Storage->Pictures->Screenshot.
Please note the screenshot captured here doesn't have the image captured from the camera in the
background. If you would like the image captured from camera, you can press the CAMERA button on the
remote control and then press the blue shortcut key.

USING THE REMOTE CONTROL

GVC3200/GVC3202 remote control is connected to GVC3200/GVC3202 via Bluetooth, and it's already
pre-paired when the user receives GVC3200/GVC3202 packages. Before using the remote control,
please make sure:
1. A pair of AAA batteries are correctly installed on the back of the remote control.
2. The remote control needs to be placed within the Bluetooth effective range, i.e., 10m from
GVC3200/GVC3202.
After powering up GVC3200/GVC3202, pressing "OK" key on the remote control, it will initiate connection
and the remote control can be used right away.
If the remote control fails to pair and connect to GVC3200/GVC3202, please follow the steps below to
troubleshoot:

Check the battery polarity when placed into the battery case. Make sure the batteries are placed in
the correct direction in the remote control.

Check the battery power.
If GVC3200/GVC3202 remote control still does not work with the diagnosis above, please try another
remote control or contact the device provider.
USING MOUSE & KEYBOARD
When the USB mouse is plugged into GVC3200/GVC3202, users could make the following operations
with the mouse.
Firmware Version 1.0.1.65
at the same time for about 3 seconds. The screenshot picture will be saved in the
GVC3200/GVC3202 User Guide
and
Page 35 of 145
