NO.
Name
1 VGA Input Interface
2 HDMI Input Interface
3
HDMI Output Interface
Firmware Version 1.0.1.65

Figure 2: GVC3200 Back Panel

4:
Table GVC3200 Back Panel
Connect to VGA input devices.
Connect to HDMI input devices.
Note:
The HDMI input interface has higher priority than the VGA
interface when both interfaces are connected.
Connect to HDMI display devices.
Note:
There are 3 HDMI output ports. The interface marked with
number "1" is the primary interface to output primary video.
Please make sure to follow the port order when connecting HDMI
port 1, 2 and 3. When there is only 1 HDMI output, it has to use
HDMI output 1. Connect HDMI port 2 and then HDMI port 3 if
you have additional display devices. GVC3200 will not work
correctly if connecting HDMI port 2 or 3 without HDMI port 1
connected.
GVC3200/GVC3202 User Guide
Explanation
