Table 6: Gvc3200/Gvc3202 Optional Equipment List - Grandstream Networks GVC3200 User Manual

Device Name
1 (minimum),
HDMI Display
2 or
Device
3 (supported on GVC3200)
VGA Input Optional
HDMI Input Optional
USB Mouse Optional
USB
Optional
Keyboard
Please connect GVC3200/GVC3202 according to the following procedures:
1. Connect the primary video output device (e.g., high-definition TV) to HDMI output interface 1 on
GVC3200/GVC3202 with HDMI cable.
2. (Optional) Connect additional video output devices to HDMI output interface 2 and HDMI output
interface 3 (supported on GVC3200) with HDMI cable.
3. Connect input device (e.g., a laptop or GXV3275) to GVC3200/GVC3202 VGA IN/HDMI IN port with
VGA/HDMI cable.
4. Connect the external speakerphone GAC2500 to the USB speaker interface on GVC3200/GVC3202.
5. Connect to Ethernet or LAN with Ethernet cable for network access. It is recommended to use
Gigabit network to assure audio and video quality of video conference.
6. Plug in the power adapter into the power supply interface to power up GVC3200/GVC3202.
Firmware Version 1.0.1.65

Table 6: GVC3200/GVC3202 Optional Equipment List

Number
To display video conference view, for example,
high definition TV. The HDMI display device is
connected to HDMI output interface 1/2 for
GVC3202 or 1/2/3 for GVC3200.
For presentation
For presentation
If both HDMI input and VGA input are plugged in,
HDMI input has higher priority, it means VGA input
will not be displayed.
It can be used to help navigate and operate the
GVC3200/GVC3202 besides using remote control.
For example, when viewing a web page, USB
mouse can be used to control the cursor.
It can be used to help input characters when
operating
remote control. For example, typing in username
and password to log in Skype app installed on
GVC3200/GVC3202.
GVC3200/GVC3202 User Guide
Explanation
GVC3200/GVC3202 besides using
Page 27 of 145
