Grandstream Networks GVC3200 User Manual page 101

Max Hits
Search Timeout (ms)
LDAP Lookup When Dialing
Search LDAP For Incoming
Call
Here is an example configuration on GVC3200/GVC3202 LDAP settings in web UI. The LDAP server is
the built-in LDAP server in Grandstream UCM61xx.
Firmware Version 1.0.1.65
It is used to configure the maximum number of results to be returned
by the LDAP server. If set to 0, server will return all search results. The
default setting is 50.
It is used to configure the interval (in seconds) for the server to
process the request and client waits for server to return. The default
setting is 4000 seconds.
It is used to set if allow the phone system to do the LDAP number
searching when making outgoing calls. The default setting is "No".
It is used to set if allow the phone system to do LDAP number
searching for incoming calls. The default setting is "No".
GVC3200/GVC3202 User Guide Page 100 of 145
