HIKVISION UD02330B User Manual

Thermometric network bullet camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Thermometric Network Bullet Camera User Manual
Thermometric Network Bullet Camera

User Manual

UD02330B
1

Advertisement

Table of Contents
loading

Related Manuals for HIKVISION UD02330B

Summary of Contents for HIKVISION UD02330B

  • Page 1: User Manual

    Thermometric Network Bullet Camera User Manual Thermometric Network Bullet Camera User Manual UD02330B...

  • Page 2: About This Manual

    Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.

  • Page 3: Regulatory Information

    LOSS DATA DOCUMENTATION, CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL...
  • Page 4 Thermometric Network Bullet Camera User Manual with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

  • Page 5: Safety Instruction

    Thermometric Network Bullet Camera User Manual Safety Instruction These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss. The precaution measure is divided into ‘Warnings’ and ‘Cautions’: Warnings: Serious injury or death may be caused if any of these warnings are neglected.
  • Page 6 Thermometric Network Bullet Camera User Manual Cautions:  Make sure the power supply voltage is correct before using the camera.  Do not drop the camera or subject it to physical shock.  Do not touch sensor modules with fingers. If cleaning is necessary, use a clean cloth with a bit of ethanol and wipe it gently.

  • Page 7: Table Of Contents

    Thermometric Network Bullet Camera User Manual Table of Contents Chapter 1 System Requirement ................10 Chapter 2 Network Connection ................11 Setting the Network Camera over the LAN ............11 2.1.1 Wiring over the LAN ....................... 11 2.1.2 Activating the Camera ....................12 Setting the Network Camera over the WAN ............
  • Page 8 Thermometric Network Bullet Camera User Manual 5.5.1 Configuring Display Settings ................... 55 5.5.2 Configuring OSD Settings ....................58 5.5.3 Configuring Text Overlay Settings ................... 59 5.5.4 Configuring Privacy Mask....................60 5.5.5 Configuring Picture Overlay .................... 61 5.5.6 Configuring DPC (Defective Pixel Correction) ..............62 Configuring and Handling Alarm Events ............
  • Page 9 Thermometric Network Bullet Camera User Manual 9.7.1 Rebooting the Camera ....................109 9.7.2 Restoring Default Settings..................... 109 9.7.3 Exporting/Importing Configuration File ............... 110 9.7.4 Upgrading the System ....................111 RS-485 Settings .................... 111 Service Settings .................... 112 Appendix ......................113 Appendix 1 SADP Software Introduction ...............

  • Page 10: Chapter 1 System Requirement

    Thermometric Network Bullet Camera User Manual Chapter 1 System Requirement Operating System: Microsoft Windows XP SP1 and above version/Vista/Win7/Server 2003/Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024× 768 resolution or higher Web Browser: Internet Explorer 6.0 and above version, Apple Safari 5.02 and above version, Mozilla Firefox 3.5 and above version and Google Chrome8 and above version.

  • Page 11: Chapter 2 Network Connection

    Thermometric Network Bullet Camera User Manual Chapter 2 Network Connection Note:  You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection. If the product does not work properly, please contact with your dealer or the nearest service center.

  • Page 12: Activating The Camera

    Thermometric Network Bullet Camera User Manual  Refer to the Figure 2-2 to set network camera over the LAN via a switch or a router. Figure 2-1 Connecting Directly Figure 2-2 Connecting via a Switch or a Router 2.1.2 Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera.
  • Page 13 Thermometric Network Bullet Camera User Manual Figure 2-3 Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 14 Thermometric Network Bullet Camera User Manual Figure 2-4 SADP Interface 3. Create a password and input the password in the password field, and confirm the password. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 15 Thermometric Network Bullet Camera User Manual Figure 2-5 Modify the IP Address 6. Input the password and click the Save button to activate your IP address modification.  Activation via Client Software The client software is versatile video management software for multiple kinds of devices.
  • Page 16 Thermometric Network Bullet Camera User Manual Figure 2-6 Control Panel 2. Click the Device Management icon to enter the Device Management interface, as shown in the figure below. Figure 2-7 Device Management Interface...
  • Page 17 Thermometric Network Bullet Camera User Manual 3. Check the device status from the device list, and select an inactive device. 4. Click the Activate button to pop up the Activation interface. 5. Create a password and input the password in the password field, and confirm the password.

  • Page 18: Setting The Network Camera Over The Wan

    Thermometric Network Bullet Camera User Manual Figure 2-9 Modifying the Network Parameters 8. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. 9. Input the password to activate your IP address modification. 2.2 Setting the Network Camera over the WAN Purpose: This section explains how to connect the network camera to the WAN with a static IP...

  • Page 19: Dynamic Ip Connection

    Thermometric Network Bullet Camera User Manual 2. Assign a LAN IP address, the subnet mask and the gateway. Refer to Section 2.1.2 for detailed IP address configuration of the network camera. 3. Save the static IP in the router. 4. Set port mapping, e.g., 80, 8000, and 554 ports. The steps for port mapping vary according to the different routers.
  • Page 20 Thermometric Network Bullet Camera User Manual 1. Connect the network camera to the router. 2. In the camera, assign a LAN IP address, the subnet mask and the gateway. Refer to Section 2.1.2 for detailed IP address configuration of the network camera. 3.
  • Page 21 Thermometric Network Bullet Camera User Manual Figure 2-13 Normal Domain Name Resolution Steps: 1. Apply a domain name from a domain name provider. 2. Configure the DDNS settings in the DDNS Settings interface of the network camera. Refer to Section 6.3.4 Configuring DDNS Settings for detailed configuration.

  • Page 22: Chapter 3 Access To The Network Camera

    Thermometric Network Bullet Camera User Manual Chapter 3 Access to the Network Camera 3.1 Accessing by Web Browsers Steps: 1. Open the web browser. 2. In the browser address bar, input the IP address of the network camera, and press the Enter key to enter the login interface.
  • Page 23 Thermometric Network Bullet Camera User Manual 6. Install the plug-in before viewing the live video and operating the camera. Please follow the installation prompts to install the plug-in. Figure 3-2 Download and Install Plug-in Figure 3-3 Install Plug-in (1) Figure 3-4 Install Plug-in (2)

  • Page 24: Accessing By Client Software

    Thermometric Network Bullet Camera User Manual Note: You may have to close the web browser to install the plug-in. Please reopen the web browser and log in again after installing the plug-in. 3.2 Accessing by Client Software The product CD contains the iVMS-4200 client software. You can view the live video and manage the camera with the software.
  • Page 25 Thermometric Network Bullet Camera User Manual Figure 3-6 iVMS-4200 Main View Note: For detailed information about the software, please refer to the user manual of the iVMS-4200.

  • Page 26: Chapter 4 Live View

    Thermometric Network Bullet Camera User Manual Chapter 4 Live View 4.1 Live View Page Purpose: The live view page allows you to view the real-time video, capture images, realize PTZ control, set/call presets and configure video parameters. Log in the network camera to enter the live view page, or you can click Live View on the menu bar of the main page to enter the live view page.

  • Page 27: Starting Live View

    Thermometric Network Bullet Camera User Manual Click each button to adjust the layout and the stream type of the live view. You can click the drop-down to select the layout for display. For IE (internet explorer) user, webcomponents and quick time are selectable. And for Non-IE user, webcomponents, quick time, VLC or MJPEG is selectable if they are supported by the web browser.

  • Page 28: Recording And Capturing Pictures Manually

    Thermometric Network Bullet Camera User Manual Window division Manually capture the picture. Manually start/stop recording. Audio on and adjust volume /Mute. Start/stop two-way audio. Enable/disable e-PTZ function. 4.3 Recording and Capturing Pictures Manually In the live view interface, click on the toolbar to capture the live pictures or click to record the live view.

  • Page 29: Chapter 5 Network Camera Configuration

    Thermometric Network Bullet Camera User Manual Chapter 5 Network Camera Configuration 5.1 Configuring Local Parameters Note: The local configuration refers to the parameters of the live view, record files and captured pictures and clips. The record files, captured pictures and clips are the ones you record and captured using the web browser and thus the saving paths of them are on the PC running the browser.
  • Page 30 Thermometric Network Bullet Camera User Manual  Live View Parameters: Set the protocol type and live view performance. ● Protocol Type: TCP, UDP, MULTICAST and HTTP are selectable. TCP: Ensures complete delivery of streaming data and better video quality, yet the real-time transmission will be affected. UDP: Provides real-time audio and video streams.

  • Page 31: Configuring Time Settings

    Thermometric Network Bullet Camera User Manual information on the captures.  Record File Settings: Set the saving path of the recorded video files. Valid for the record files you recorded with the web browser. ● Record File Size: Select the packed size of the manually recorded and downloaded video files to 256M, 512M or 1G.
  • Page 32 Thermometric Network Bullet Camera User Manual Figure 5-2 Time Settings 2. Select the Time Zone. Select the Time Zone of your location from the drop-down menu. 3. Set Time Synchronization. You can synchronize the time through NTP, or you can do it manually. ●...

  • Page 33: Configuring Network Settings

    Thermometric Network Bullet Camera User Manual ● Synchronizing Time Manually Enable the Manual Time Sync function and then click to set the system time from the pop-up calendar. Note: You can also check the Sync with computer time checkbox to synchronize the time of the camera with that of your computer.
  • Page 34 Thermometric Network Bullet Camera User Manual Configuration > Basic Configuration > Network > TCP/IP Or Configuration > Advanced Configuration > Network > TCP/IP Figure 5-6 TCP/IP Settings 2. Configure the basic network settings, including the NIC Type, IPv4 or IPv6 Address, IPv4 or IPv6 Subnet Mask, IPv4 or IPv6 Default Gateway, MTU settings and Multicast Address.

  • Page 35: Configuring Port Settings

    Thermometric Network Bullet Camera User Manual 5.3.2 Configuring Port Settings Purpose: You can set the port No. of the camera, e.g. HTTP port, RTSP port, HTTPS port and server port. Steps: 1. Enter the Port Settings interface: Configuration > Basic Configuration > Network > Port Or Configuration >...

  • Page 36: Configuring Ddns Settings

    Thermometric Network Bullet Camera User Manual Ethernet (PPPoE) function. Steps: 1. Enter the PPPoE Settings interface: Configuration >Advanced Configuration > Network > PPPoE Figure 5-8 PPPoE Settings 2. Check the Enable PPPoE checkbox to enable this feature. 3. Enter User Name, Password, and Confirm password for PPPoE access. Note: The User Name and Password should be assigned by your ISP.
  • Page 37 Thermometric Network Bullet Camera User Manual Registration on the DDNS server is required before configuring the DDNS settings of the camera.  For your privacy and to better protect your system against security risks, we strongly recommend the use of strong passwords for all functions and network devices.
  • Page 38 Thermometric Network Bullet Camera User Manual (4) Enter the User Name and Password registered on the DynDNS website. (5) Click Save to save the settings. Figure 5-10 DynDNS Settings  IP Server: Steps: (1) Enter the Server Address of the IP Server. (2) Click Save to save the settings.

  • Page 39: Configuring Snmp Settings

    Thermometric Network Bullet Camera User Manual Figure 5-12 NO-IP Settings (2) Enter the Server Address as www.noip.com (3) Enter the Domain name you registered. (4) Enter the Port number, if needed. (5) Enter the User Name and Password. (6) Click Save and then you can view the camera with the domain name. ...
  • Page 40 Thermometric Network Bullet Camera User Manual You can set the SNMP function to get camera status, parameters and alarm related information and manage the camera remotely when it is connected to the network. Before you start: Before setting the SNMP, please download the SNMP software and manage to receive the camera information via SNMP port.

  • Page 41: Configuring 802.1X Settings

    Thermometric Network Bullet Camera User Manual Figure 5-14 SNMP Settings 2. Check the corresponding version checkbox (Enable SNMPv1, Enable SNMPv2c, and Enable SNMPv3) to enable the feature. 3. Configure the SNMP settings. Note: The settings of the SNMP software should be the same as the settings you configure here.
  • Page 42 Thermometric Network Bullet Camera User Manual The IEEE 802.1X standard is supported by the network cameras. When the feature is enabled, the camera data is secured and user authentication is needed when connecting the camera to the network protected by the IEEE 802.1X. Before you start: The authentication server must be configured.

  • Page 43: Configuring Qos Settings

    Thermometric Network Bullet Camera User Manual Note: A reboot is required for the settings to take effect. 5.3.7 Configuring QoS Settings Purpose: QoS (Quality of Service) can help solve the network delay and network congestion by configuring the priority of data sending. Steps: 1.

  • Page 44: Email Sending Triggered By Alarm

    Thermometric Network Bullet Camera User Manual and the camera is connected to the Wide Area Network via the router. Steps: 1. Enter the UPnP™ settings interface. Configuration >Advanced Configuration > Network > UPnP™ 2. Check the checkbox to enable the UPnP™ function. The name of the device when detected online can be edited.
  • Page 45 Thermometric Network Bullet Camera User Manual Figure 5-18 Email Settings 3. Configure the following settings: Sender: The name of the email sender. Sender’s Address: The email address of the sender. SMTP Server: The SMTP Server IP address or host name (e.g., smtp.263xmail.com).

  • Page 46: Configuring Nat (Network Address Translation) Settings

    Thermometric Network Bullet Camera User Manual name and password.  For your privacy and to better protect your system against security risks, we strongly recommend the use of strong passwords for all functions and network devices. The password should be something of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product.

  • Page 47: Configuring Ftp Settings

    Thermometric Network Bullet Camera User Manual Figure 5-19 Configure NAT Settings 3. Click Save to save the settings. 5.3.11 Configuring FTP Settings Purpose: You can configure the related FTP server information to enable the uploading of the captured pictures to the FTP server. The captured pictures can be triggered by events or a timing snapshot task.

  • Page 48: Https Settings

    Thermometric Network Bullet Camera User Manual have the option to use the Device Name, Device Number or Device IP for the name of the directory; and when the Child Directory is selected, you can use the Camera Name or Camera No. as the name of the directory. Upload type: To enable uploading the captured picture to the FTP server.
  • Page 49 Thermometric Network Bullet Camera User Manual 1. Enter the HTTPS settings interface. Configuration > Advanced Configuration > Network > HTTPS Figure 5-21 HTTPS Settings 2. Check the checkbox of Enable HTTPS to enable the function. 3. Create the self-signed certificate or authorized certificate. Create the self-signed certificate ...
  • Page 50 Thermometric Network Bullet Camera User Manual Figure 5-23 Create a Certificate 3) Click OK to save the settings. Note: If you already have a certificate installed, the Create Self-signed Certificate is grayed out. Create the authorized certificate  1) Click Create button to create the certificate request. 2) Download the certificate request and submit it to the trusted certificate authority for signature.

  • Page 51: Configuring Video And Audio Settings

    Thermometric Network Bullet Camera User Manual 5.4 Configuring Video and Audio Settings 5.4.1 Configuring Video Settings Steps: 1. Enter the Video Settings interface: Configuration >Basic Configuration > Video/Audio > Video Or Configuration > Advanced Configuration > Video/Audio > Video Figure 5-25 Video Settings 2.
  • Page 52 Thermometric Network Bullet Camera User Manual audio signal can be recorded only when the Video Type is Video & Audio. Resolution: Select the resolution of the video output. Bitrate Type: Select the bitrate type to constant or variable. Video Quality: When bitrate type is selected as Variable, 6 levels of video quality are selectable.

  • Page 53: Configuring Audio Settings

    Thermometric Network Bullet Camera User Manual is insufficient. Smoothing: It refers to the smoothness of the stream. The higher value of the smoothing, the better fluency of the stream, though, the video quality may not be so satisfied. The lower value of the smoothing, the higher quality of the stream, though it may appear not fluent.

  • Page 54: Configuring Roi Encoding

    Thermometric Network Bullet Camera User Manual 3. Click Save to save the settings. 5.4.3 Configuring ROI Encoding Purpose: ROI (Region of Interest) encoding helps to discriminate between the ROI and background information in video compression, which means the technology assigns more encoding resource to the region of interest, thus to increase the quality of the ROI whereas the background information is less focused.

  • Page 55: Configuring Image Parameters

    Thermometric Network Bullet Camera User Manual Figure 5-27 Region of Interest Settings 7. Input the region name for ROI as desired. 8. Click Save to save the settings. 5.5 Configuring Image Parameters 5.5.1 Configuring Display Settings Purpose: You can set the image quality of the camera, including brightness, contrast, etc. Note: The display parameters vary according to the different camera models.
  • Page 56 Thermometric Network Bullet Camera User Manual 1. Enter the Display Settings interface: Configuration > Basic Configuration> Image> Display Settings Or Configuration > Advanced Configuration> Image> Display Settings 2. Set the image parameters of the camera. Figure 5-28 Configuring Display Settings for Camera 2 •...
  • Page 57 Thermometric Network Bullet Camera User Manual cover is recommended) and click the Manual Background Correction button, and then the camera adjusts the image according to the current environment. Manual Shutter Correction: Click the Manual Shutter Correction button and then the camera adjusts the image according to the temperature of the camera itself.

  • Page 58: Configuring Osd Settings

    Thermometric Network Bullet Camera User Manual 5.5.2 Configuring OSD Settings Purpose: You can customize the camera name and time on the screen. Steps: 1. Enter the OSD Settings interface: Configuration > Advanced Configuration > Image > OSD Settings Figure 5-29 OSD Settings 2.

  • Page 59: Configuring Text Overlay Settings

    Thermometric Network Bullet Camera User Manual Figure 5-30 Font Color-Custom 6. You can use the mouse to click and drag the text frame 35mm Camera in the live view window to adjust the OSD position. Figure 5-31 Adjusting OSD Location 7.

  • Page 60: Configuring Privacy Mask

    Thermometric Network Bullet Camera User Manual Figure 5-32 Text Overlay 2. Check the checkbox in front of textbox to enable the on-screen display. 3. Input the characters in the textbox. 4. (Optional) Use the mouse to click and drag the red text frame in the live view window to adjust the text overlay position.

  • Page 61: Configuring Picture Overlay

    Thermometric Network Bullet Camera User Manual Figure 5-33 Privacy Mask Settings 2. Check the checkbox of Enable Privacy Mask to enable this function. 3. Click Draw Area. 4. Click and drag the mouse in the live video window to draw the mask area. Note: You are allowed to draw up to 4 areas on the same image.

  • Page 62: Configuring Dpc (Defective Pixel Correction)

    Thermometric Network Bullet Camera User Manual Figure 5-34 Picture Overlay 2. Click Browse to select a picture. 3. Click Upload to upload it. 4. Check Enable Picture Overlay checkbox to enable the function. X Coordinate and Y Coordinate values are for the location of the picture on the image.

  • Page 63: Configuring And Handling Alarm Events

    Thermometric Network Bullet Camera User Manual Figure 5-35 Defective Pixel Correction 4. (Optional) Click to cancel the correction. 5.6 Configuring and Handling Alarm Events This section explains how to configure the network camera to respond to alarm events, including motion detection, video tampering, alarm input, alarm output, exception, face detection, audio exception detection, intrusion detection, defocus detection, and scene change detection, etc.

  • Page 64: Configuring Motion Detection

    Thermometric Network Bullet Camera User Manual 5.6.1 Configuring Motion Detection Purpose: Motion detection detects the moving objects in the configured surveillance area, and a series of actions can be taken when the alarm is triggered. In order to detect the moving objects accurately and reduce the false alarm rate, normal configuration and expert configuration are selectable for different motion detection environment.
  • Page 65 Thermometric Network Bullet Camera User Manual Figure 5-36 Enable Motion Detection (4)Click Draw Area. Click and drag the mouse on the live video to draw a motion detection area. (5)Click Stop Drawing to finish drawing one area. (6)(Optional) Click Clear All to clear all of the areas. (7)(Optional) Move the slider to set the sensitivity of the detection.
  • Page 66 Thermometric Network Bullet Camera User Manual (1)Click Edit to edit the arming schedule. The Figure 6-34 shows the editing interface of the arming schedule. (2)Choose the day you want to set the arming schedule. (3)Click to set the time period for the arming schedule. (4)(Optional) After you set the arming schedule, you can copy the schedule to other days.
  • Page 67 Thermometric Network Bullet Camera User Manual Figure 5-39 Linkage Method ● Audible Warning Trigger the audible warning locally. And it only supported by the device have the audio output. ● Notify Surveillance Center Send an exception or alarm signal to remote management software when an event occurs.

  • Page 68: Configuring Video Tampering Alarm

    Thermometric Network Bullet Camera User Manual ● Expert Configuration Expert mode is mainly used to configure the sensitivity and proportion of object on each area for different day/night switch. Note: Day/night switch can’t be realized for thermal camera channel. But Area, Sensitivity and Proportion of Object on Area are still configurable.

  • Page 69: Configuring Alarm Input

    Thermometric Network Bullet Camera User Manual Figure 5-41 Video Tampering Alarm 2. Check Enable Video Tampering checkbox to enable the video tampering detection. 3. Set the video tampering area. Refer to Task 1 Set the Motion Detection Area in Section 5.6.1. 4.
  • Page 70 Thermometric Network Bullet Camera User Manual 1. Enter the Alarm Input Settings interface: Configuration > Advanced Configuration> Basic Event > Alarm Input 2. Choose the alarm input No. and the Alarm Type. The alarm type can be NO (Normally Open) and NC (Normally Closed). Edit the name to set a name for the alarm input (optional).

  • Page 71: Configuring Alarm Output

    Thermometric Network Bullet Camera User Manual 5.6.4 Configuring Alarm Output Purpose: It detects the alarm output, and take response actions when the alarm is triggered. Steps: 1. Enter the Alarm Output Settings interface: Configuration>Advanced Configuration> Basic Event > Alarm Output 2.

  • Page 72: Handling Exception

    Thermometric Network Bullet Camera User Manual 5.6.5 Handling Exception The exception type can be HDD full, HDD error, network disconnected, IP address conflicted and illegal login to the cameras. Steps: 1. Enter the Exception Settings interface: Configuration > Advanced Configuration> Basic Event > Exception 2.
  • Page 73 Thermometric Network Bullet Camera User Manual function. 3. Check the checkbox of Sudden Increase of Sound Intensity Detection to detect the sound steep rise in the surveillance scene. You can set the detection sensitivity and threshold for sound steep rise. 4.

  • Page 74: Scene Change Detection

    Thermometric Network Bullet Camera User Manual 5.6.7 Scene Change Detection Purpose: Scene change detection function detects the change of surveillance environment affected by the external factors; such as the intentional rotation of the camera, and some certain actions can be taken when the alarm is triggered. Steps: 1.

  • Page 75: Temperature Measurement

    Thermometric Network Bullet Camera User Manual Figure 5-46 Configuring Dynamic Fire Source Detection 3. Check the checkbox of Display Fire Source Frame on Stream to display a red frame around the fire source on stream when fire occurs. (Optional) 4. You can slide the cursor to adjust the sensitivity degree of dynamic fire source detection from 1to 10.

  • Page 76: Temperature Measurement Configuration

    Thermometric Network Bullet Camera User Manual 5.7.1 Temperature Measurement Configuration Steps: 1. Enter Configuration > Advanced Configuration > Temperature Measurement Configuration. Figure 5-47 Dynamic Fire Source Detection 2. Check the checkboxes of the interface to set the temperature measurement configurations. ...
  • Page 77 Thermometric Network Bullet Camera User Manual 2. Set the alarm rule: Select a temperature measurement rule from the rule list and configure the parameters.  Name: You can customize the rule name.  Type: Select point, line, or frame as rule type. ...

  • Page 78: Vca Configuration

    Thermometric Network Bullet Camera User Manual Temperature is Lower than, Average Temperature is Higher than, Average Temperature is Lower than, Temperature Difference is Higher than, and Temperature Difference is Lower than. For targets set by line, the rules include Max. Temperature, Min. Temperature, and Average Temperature. For targets set by point, the rules are distinguished by Average Temperature.

  • Page 79: Vca Information

    Thermometric Network Bullet Camera User Manual resources, the other VCA rule cannot be enabled. 5.8.4 VCA Information  Behavior Analysis Version: It lists the version of the algorithms library.  Display information It includes the display on picture and display on stream. Check the checkboxes to enable corresponding displays.

  • Page 80: Behavior Analysis

    Thermometric Network Bullet Camera User Manual You can set the quality and resolution for the captured picture. ● Upload JPEG Image to Center: Check the checkbox to upload the captured image to the surveillance center when a VCA alarm occurs. ●...
  • Page 81 Thermometric Network Bullet Camera User Manual 4) (Optional) Check the checkbox of Enable Verification of Camera Calibration, click the Horizontal Verify/Vertical Verify button to draw a horizontal/vertical line on the live video, and then click the Calibrate button to calculate the line length. Compare the calculated line length to the actual length to verify the calibration information you set.
  • Page 82 Thermometric Network Bullet Camera User Manual 1:35m 2:45m 3:6m 4:4m Figure 5-51 Draw on Live View Window 3. Draw the Shield Region The shield region allows you to set the specific region in which the behavior analysis will not function. Up to 4 shield regions are supported. Steps: 1) Enter the Shield Region setting interface: Configuration >...
  • Page 83 Thermometric Network Bullet Camera User Manual The behavior analysis supports a series of behaviors, including line crossing, intrusion, region entrance, and region exiting, etc. Note: The rule type for setting varies according to different camera models. Steps: 1) Click Rule Tab to enter the rule configuration interface. 2) Click to add a new rule.
  • Page 84 Thermometric Network Bullet Camera User Manual Figure 5-52 Rule Type-Line Crossing Figure 5-53 Rule Type-Intrusion...
  • Page 85 Thermometric Network Bullet Camera User Manual • Region Entrance detects people, vehicle or other objects which enter a pre-defined virtual region from the outside place, and some certain actions can be taken when the alarm is triggered. • Region Exiting detects people, vehicle or other objects which exit from a pre-defined virtual region, and some certain actions can be taken when the alarm is triggered.
  • Page 86 Thermometric Network Bullet Camera User Manual Note: If the live view is stopped, the detection area / line cannot be draw and the rules cannot be set. 5) Check the checkbox of the combined rule to enable the rule for behavior analysis.
  • Page 87 Thermometric Network Bullet Camera User Manual Detection Sensitivity [0~4]: Refers to the sensitivity of the camera detects a target. The higher the value, the easier a target be recognized, and the higher the misinformation is. The default value of 3 is recommended. Background Update Rate [0~4]: It refers to the speed of the new scene replaces the previous scene.
  • Page 88 Thermometric Network Bullet Camera User Manual live view. And click Maximum Size to draw the rectangle of the max. size on the live view. The target is smaller than the min. size or larger than the max. size will be filtered. Notes: ●...

  • Page 89: Chapter 6 Storage Settings

    Thermometric Network Bullet Camera User Manual Chapter 6 Storage Settings Before you start: To configure record settings, please make sure that you have the network storage device within the network or the SD card inserted in your camera. 6.1 Storage Management Storage management allows you to view the HDD status, including the capacity, free space, status, type, and progress, etc.
  • Page 90 Thermometric Network Bullet Camera User Manual (1) Enter the NAS (Network-Attached Storage) Settings interface: Configuration > Advanced Configuration > Storage > NAS Figure 6-2 Add Network Disk (2) Enter the IP address of the network disk, and enter the file path. (3) Select the mounting type.
  • Page 91 Thermometric Network Bullet Camera User Manual Advanced Configuration > Storage > Storage Management Figure 6-3 Storage Management Interface (2) If the status of the disk is Uninitialized, check the corresponding checkbox to select the disk and click Format to start initializing the disk. When the initialization completed, the status of disk will become Normal.

  • Page 92: Configuring Recording Schedule

    Thermometric Network Bullet Camera User Manual ● To initialize and use the SD card after insert it to the camera, please refer to the steps of NAS disk initialization. 6.3 Configuring Recording Schedule Purpose: There are two kinds of recording for the cameras: manual recording and scheduled recording.
  • Page 93 Thermometric Network Bullet Camera User Manual Figure 6-7 Record Parameters  Pre-record: The time you set to start recording before the scheduled time or the event. For example, if an alarm triggers recording at 10:00, and the pre-record time is set as 5 seconds, the camera starts to record at 9:59:55. The Pre-record time can be configured as No Pre-record, 5 s, 10 s, 15 s, 20 s, 25 s, 30 s or not limited.
  • Page 94 Thermometric Network Bullet Camera User Manual Figure 6-8 Edit Record Schedule 5. Choose the day to set the record schedule. (1) Set all-day record or segment record:  If you want to configure the all-day recording, please check the All Day checkbox.
  • Page 95 Thermometric Network Bullet Camera User Manual  Record Triggered by Motion Detection If you select Motion Detection, the video will be recorded when the motion is detected. Besides configuring the recording schedule, you have to set the motion detection area and check the checkbox of Trigger Channel in the Linkage Method of Motion Detection Settings interface.
  • Page 96 Thermometric Network Bullet Camera User Manual increase/decrease of the sound intensity are detected. Besides configuring the recording schedule, you have to configure the settings on the Audio Exception Detection interface. Refer to Section 5.6.6 for detailed information.  Record Triggered by VCA Recording If you select VCA Recording, the video will be recorded when the VCA detects series of suspicious behaviors, such as line crossing, intrusion, region entrance and region exiting.

  • Page 97: Configuring Snapshot Settings

    Thermometric Network Bullet Camera User Manual 6.4 Configuring Snapshot Settings Purpose: You can configure the scheduled snapshot and event-triggered snapshot. The captured picture can be stored in the SD card (if supported) or the NAS (For detailed information, please refer to Section 6.2 Configuring NAS Settings). You can also upload the captured pictures to a FTP server.
  • Page 98 Thermometric Network Bullet Camera User Manual 2. Select a channel number. For camera models which have more than one camera channels, you should first select the channel number to configure. 3. Check the Enable Timing Snapshot checkbox to enable continuous snapshot. Edit schedule time for snapshots.

  • Page 99: Chapter 7 Playback

    Thermometric Network Bullet Camera User Manual Chapter 7 Playback Purpose: This section explains how to view the remotely recorded video files stored in the network disks or SD cards. Steps: 1. Click Playback on the menu bar to enter playback interface. Figure 7-1 Playback Interface 2.
  • Page 100 Thermometric Network Bullet Camera User Manual Figure 7-3 Playback Toolbar Table 7-1 Description of the buttons Icon Description Icon Description Play Capture a picture Pause Start/Stop clipping video files Stop Audio on and adjust volume/Mute Speed down Download video files Speed up Download captured pictures Playback by frame...

  • Page 101: Chapter 8 Log Searching

    Thermometric Network Bullet Camera User Manual Chapter 8 Log Searching Purpose: The operation, alarm, exception and information of the camera can be stored in log files. You can also export the log files on your demand. Before you start: Please make sure the network storage for the camera is configured, or the local storage (SD card) is working.

  • Page 102: Chapter 9 Others

    Thermometric Network Bullet Camera User Manual Chapter 9 Others 9.1 Managing User Accounts Purpose: The admin user can add, delete or modify user accounts, and grant them different permissions. We highly recommend user manage the device accounts and user permissions properly. Enter the User Management interface to complete settings: Configuration >Basic Configuration>...
  • Page 103 Thermometric Network Bullet Camera User Manual strongly recommend the use of strong passwords for all functions and network devices. The password should be something of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product.

  • Page 104: Authentication

    Thermometric Network Bullet Camera User Manual 3. In the Basic Permission field and Camera Configuration field, you can check or uncheck the permissions. 4. Click OK to finish the user modification. Figure 9-3 Modify a User  Deleting a User Steps: 1.

  • Page 105: Anonymous Visit

    Thermometric Network Bullet Camera User Manual Figure 9-4 RTSP Authentication 2. Select the RTSP Authentication type basic or disable in the drop-down list to enable or disable the RTSP authentication. Note: If you disable the RTSP authentication, anyone can access the video stream by the RTSP protocol via the IP address.

  • Page 106: Ip Address Filter

    Thermometric Network Bullet Camera User Manual Figure 9-6 Login Interface with an Anonymous Checkbox 4. Check the checkbox of Anonymous and click Login. By permitting the Anonymous “Live View” function, you may enable others to access your camera and view live images without providing login credentials. It therefore is critical when permitting the Anonymous "Live View"...
  • Page 107 Thermometric Network Bullet Camera User Manual 3. Select the type of IP Address Filter in the drop-down list, Forbidden and Allowed are selectable. 4. Set the IP Address Filter list.  Add an IP Address Steps: (1) Click the Add to add an IP. (2) Input the IP Adreess.

  • Page 108: Security Service

    Thermometric Network Bullet Camera User Manual 9.5 Security Service To enable the remote login, and improve the data communication security, the camera provides the security service for better user experience. Steps: 1. Enter the security service configuration interface: Configuration > Advanced configuration > Security >Security Service Figure 9-10 Security Service 2.

  • Page 109: Maintenance

    Thermometric Network Bullet Camera User Manual Figure 9-11 Device Information 9.7 Maintenance 9.7.1 Rebooting the Camera Steps: 1. Enter the Maintenance interface: Configuration > Basic Configuration> System > Maintenance Or Configuration > Advanced Configuration> System > Maintenance 2. Click Reboot to reboot the network camera. Figure 9-12 Reboot the Device 9.7.2 Restoring Default Settings Steps:...

  • Page 110: Exporting/Importing Configuration File

    Thermometric Network Bullet Camera User Manual Configuration > Basic Configuration> System > Maintenance Or Configuration > Advanced Configuration> System > Maintenance 2. Click Restore or Default to restore the default settings. Figure 9-13 Restore Default Settings Note: After restoring to the default settings, the IP address is also restored to the default IP address, please be careful for this action.

  • Page 111: Upgrading The System

    Thermometric Network Bullet Camera User Manual Figure 9-14 Import/Export Configuration File 9.7.4 Upgrading the System Steps: 1. Enter the Maintenance interface: Configuration > Basic Configuration> System > Maintenance or Configuration > Advanced Configuration> System > Maintenance 2. Select firmware or firmware directory to locate the upgrade file. Firmware: Locate the exact path of the upgrade file.

  • Page 112: Service Settings

    Thermometric Network Bullet Camera User Manual Figure 9-16 RS-485 Settings 2. Set the RS-485 parameters and click Save to save the settings. By default, the Baud Rate is set as 9600 bps, the Data Bit is 8, the stop bit is 1 and the Parity and Flow Control are None.

  • Page 113: Appendix

    Thermometric Network Bullet Camera User Manual Appendix Appendix 1 SADP Software Introduction  Description of SADP SADP (Search Active Devices Protocol) is a kind of user-friendly and installation-free online device search tool. It searches the active online devices within your subnet and displays the information of the devices.
  • Page 114 Thermometric Network Bullet Camera User Manual Note: Device can be searched and displayed in the list in 15 seconds after it went online; it will be removed from the list in 45 seconds after it went offline.  Search online devices manually You can also click to refresh the online device list manually.
  • Page 115 Thermometric Network Bullet Camera User Manual Figure A.1.2 Modify Network Parameters...

  • Page 116: Appendix 2 Port Mapping

    Thermometric Network Bullet Camera User Manual Appendix 2 Port Mapping The following settings are for TP-LINK router (TL-WR641G). The settings vary depending on different models of routers. Steps: 1. Select the WAN Connection Type, as shown below: Figure A.2.1 Select the WAN Connection Type 2.
  • Page 117 Thermometric Network Bullet Camera User Manual another camera as 81, 8001, 555, 8201 with IP 192.168.1.24. Refer to the steps as below: Steps: 1. As the settings mentioned above, map the port 80, 8000, 554 and 8200 for the network camera at 192.168.1.23 2.
  • Page 118 Thermometric Network Bullet Camera User Manual...
