Network Bullet Camera Quick Start Guide UD04363B...
Page 2
Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
Page 3
LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
Network Bullet Camera·Quick Start Guide IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Page 5
Network Bullet Camera·Quick Start Guide This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.
Network Bullet Camera·Quick Start Guide Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements. Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
Page 7
Network Bullet Camera·Quick Start Guide ● Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with 24 VAC or 12 VDC according to the IEC60950-1 standard. Please refer to technical specifications for detailed information. ●...
Page 8
Network Bullet Camera·Quick Start Guide ● The sensor may be burned out by a laser beam, so when any laser equipment is in using, make sure that the surface of sensor will not be exposed to the laser beam. ● Do not place the camera in extremely hot, cold (the operating temperature shall be-30°C ~+60°C, or -40°C ~ +60°C if the camera model has an “H”...
Network Bullet Camera·Quick Start Guide Table of Contents Appearance Description ..............9 Overview of Type I Bullet Camera ........9 Overview of Type II Bullet Camera ........ 11 1.2.1 Resetting the Camera ......... 12 1.2.2 Setting the WPS Protocol........13 Overview of Type III Bullet Camera .......
Network Bullet Camera·Quick Start Guide Appearance Description Overview of Type I Bullet Camera...
Page 11
Network Bullet Camera·Quick Start Guide Figure 1-1 Type I Bullet Camera Table 1-1 Description Description Description Mounting Base Lens Back Case Sun Shield Front Case Power Cable Reset Button GND Screw 10/100M Self-adaptive Ethernet Interface Type I camera does not support the function of Wi-Fi or memory ...
Network Bullet Camera·Quick Start Guide Table 1-2 Description Description Description Mounting Base Memory Card Slot Back Case Power Supply Interface 10/100M Self-adaptive Sun Shield Ethernet Interface Lens PoE Cable Adjusting Nut GND Screw WPS/RESET Button This type of bullet camera supports PoE power supply. You can ...
Network Bullet Camera·Quick Start Guide WPS/RESET Figure 1-3 WPS/RESET Button 1.2.2 Setting the WPS Protocol A wireless router with the WPS function is required to enable the WPS function of the camera. Steps: Enable the WPS function of your router. Refer to the operation guide of your router for detailed procedures.
Page 15
Network Bullet Camera·Quick Start Guide WPS/RESET Figure 1-4 WPS/RESET Button You can also press the WPS button on the camera first and then enable the WPS function on the router to establish the connection. But the WPS function of the router must be turned on within 120s right after pressing the WPS/RESET button on the camera.
Network Bullet Camera·Quick Start Guide Overview of Type III Bullet Camera Figure 1-5 Type III Bullet Camera...
Page 17
Network Bullet Camera·Quick Start Guide Table 1-3 Description Description Description Mounting Base Grounding Screw 10/100M Self-adaptive Back Case Ethernet Interface (PoE) Front Case Power Supply (DC 12V) Lens Memory Card Slot Sun Shield Reset Button This type of bullet camera supports PoE power supply. You can ...
Network Bullet Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12V DC or 24V AC, please make sure your power supply matches with your camera.
Network Bullet Camera·Quick Start Guide Installation of Memory Card Type II and Type III camera support memory card function. Follow the steps to mount and unmount a memory card. Steps: 1. Unscrew the cover on back case to expose memory card slot. Cover Figure 2-1 Unscrew the Cover...
Network Bullet Camera·Quick Start Guide 3. (Optional)To unmount the memory card, push to get it ejected. 4. Screw the cover back to the camera. Installation of Bullet Camera Both wall mounting and ceiling mounting are suitable for the bullet camera. Wall mounting will be taken as an example in this section. You can take steps of wall mounting for reference if ceiling mounting is adopted.
Page 21
Network Bullet Camera·Quick Start Guide 2. Route the corresponding cables. 3. Secure the camera to the wall with the supplied Screws. Figure 2-4 Secure the Camera to the Ceiling 4. Connect the cables and power on the camera to view live view image.
Network Bullet Camera·Quick Start Guide 1). Loosen the adjusting nut. 2). Adjust the pan direction [0° to 360°]. 3). Adjust the tilt direction [0° to 90°]. 4). Rotate the camera [0° to 360°] to adjust the lens to the desired surveillance angle. 5).
Page 23
Network Bullet Camera·Quick Start Guide Components Network Plug Waterproof Endcap Waterproof Rubber Gasket Lock Nut Network Cable from Router/Switch Align the snap and notch. i. Insert into ⑤ ④ ii. Secure with ⑥ ④ Camera Switch/Router Figure 2-7 Water-proof Accessory Installation...
Page 24
Network Bullet Camera·Quick Start Guide Steps: Feed the plugless network cable ⑦ through the lock nut ⑥, waterproof rubber gasket ⑤ (rubber gasket inset ridge must face waterproof endcap), and the water-proof endcap ④ in order. Crimp an RJ-45 network plug ③onto the end of the cable, taking care to insert the twisted pairs of wires in correct order.
Network Bullet Camera·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.
Network Bullet Camera·Quick Start Guide Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported. We will take activation via SADP software and Activation via Web Browser as examples to introduce the camera activation.
Network Bullet Camera·Quick Start Guide Figure 3-3 Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
Page 28
Network Bullet Camera·Quick Start Guide Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts. Follow the steps to activate the camera. Steps: 1. Run the SADP software to search the online devices. 2.
Network Bullet Camera·Quick Start Guide STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
Page 30
Network Bullet Camera·Quick Start Guide Steps: 1. Run the SADP software. 2. Select an active device. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Figure 3-5 Modify the IP Address...
Page 31
Network Bullet Camera·Quick Start Guide Note: You can enable the Hik-Connect service for the device during activation. Refer to Chapter 5.1 for detailed information. 4. Input the admin password and click Modify to activate your IP address modification. The batch IP address modification is supported by the SADP. Refer to the user manual of SADP for details.
Network Bullet Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
Page 33
Network Bullet Camera·Quick Start Guide 4. Click Login. Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.
Network Bullet Camera·Quick Start Guide 5 Operating via Hik-Connect App Purpose: Hik-Connect is an application for mobile devices. With the App, you can view live image of the camera, receive alarm notification and so Note: Hik-Connect service is not supported by certain camera models. Enable Hik-Connect Service on Camera Purpose: Hik-Connect service should be enabled on your camera before using...
Network Bullet Camera·Quick Start Guide Figure 5-1 Verification Code Setting (SADP) Note: The verification code is required when you add the camera to Hik-Connect app. 3. Click and read "Terms of Service" and "Privacy Policy". 4. Confirm the settings. 5.1.2 Enable Hik-Connect Service via Web Browser Before you start: You need to activate the camera before enabling the service.
Page 36
Network Bullet Camera·Quick Start Guide Steps: 1. Access the camera via web browser. Refer to Chapter 4. 2. Enter platform access configuration interface: Configuration > Network > Advanced Settings > Platform Access Figure 5-2 Platform Access Configuration (Web) 3. Select Platform Access Mode as Hik-Connect. 4.
Network Bullet Camera·Quick Start Guide Hik-Connect Setup Steps: 1. Download and install the Hik-Connect app by searching “Hik-Connect” in App Store or Google Play 2. Launch the app and register for a Hik-Connect user account. 3. Log in Hik-Connect app after registration. Adding Camera to Hik-Connect Before you start: You need to enable the Hik-Connect service on camera before...
Page 38
Network Bullet Camera·Quick Start Guide You can find the QR code on the camera or on the cover of the Quick Start Guide of the camera in the package. Figure 5-4 Scan QR Code Note: If the QR code is missing or too blur to be recognized, you can also add the camera by tapping the icon and inputting the camera's serial number.
Network Bullet Camera·Quick Start Guide Initializing the Memory Card Steps: Check the memory card status by tapping on the Storage Status in the Device Settings interface. If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. You can then start recording any event triggered video in the camera such as motion detection.
