Network Dome Camera
Quick Start Guide
UD05590B
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UD05590B and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION UD05590B

Summary of Contents for HIKVISION UD05590B

  • Page 1 Network Dome Camera Quick Start Guide UD05590B...
  • Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
  • Page 3 LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.

  • Page 4: Regulatory Information

    Network Dome Camera·Quick Start Guide IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 5 Network Dome Camera·Quick Start Guide This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.

  • Page 6: Safety Instruction

    Network Dome Camera·Quick Start Guide Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements. Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 7 Network Dome Camera·Quick Start Guide ● Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with 24 VAC or 12 VDC according to the IEC60950-1 standard. Please refer to technical specifications for detailed information. ●...
  • Page 8 Network Dome Camera·Quick Start Guide ● The sensor may be burned out by a laser beam, so when any laser equipment is in using, make sure that the surface of sensor will not be exposed to the laser beam. ● Do not place the camera in extremely hot, cold (the operating temperature shall be-30°C to +60°C, or -40°C to +60°C if the camera model has an “H”...

  • Page 9: Table Of Contents

    Network Dome Camera·Quick Start Guide Table of Contents 1 Appearance Description ..............9 2 Installation ................11 Memory Card Installation ..........12 Mounting Preparation ............12 2.3 Camera Mounting .............. 14 2.3.1 Ceiling Mounting ............ 14 2.3.2 Wall Mounting ............20 2.3.3 Pendant Mounting ..........

  • Page 10: Appearance Description

    Network Dome Camera·Quick Start Guide 1 Appearance Description The overview of the network dome camera is shown below. Overview of Dome Camera Figure 1-1...
  • Page 11 Network Dome Camera·Quick Start Guide Overview of Dome Camera Table 1-1 Description Description Bubble Junction box Alarm input/output Sealing plugs Audio input/output Lens RJ45 Ethernet port (PoE) Reset button Power interface (12 VDC) Memory card slot Video Out (BNC) Grounding screw Notes: ●...

  • Page 12: Installation

    Network Dome Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12 VDC or PoE (802.3af). Make sure your power supply matches with your camera.

  • Page 13: Memory Card Installation

    Network Dome Camera·Quick Start Guide Memory Card Installation Steps: 1. Unscrew the memory card slot cover. Memory Card Cover Figure 2-1 Install Memory Card 2. Insert the memory card into the memory card slot, and push to get it mounted. 3.
  • Page 14 Network Dome Camera·Quick Start Guide Steps: 1. Lift the camera body to separate the junction box and the adapter plate. 2. Separate the junction box and the adapter plate. 3. Unscrew the bubble. Bubble Junction Adapter Plate Figure 2-2 Disassemble the Camera...

  • Page 15: Camera Mounting

    Network Dome Camera·Quick Start Guide Camera Mounting 2.3.1 Ceiling Mounting Before you start: Plan the cable routing before installation. This camera series supports cable-routing through the ceiling and through side outlet. ● Through the ceiling: you should cut a hole in ceiling and route the cables in advance.
  • Page 16 Network Dome Camera·Quick Start Guide 2. (Skip if not needed) Route cables through a conduit. Screw the supplied conduit joint to the conduit. Conduit Conduit Joint (Supplied) Figure 2-4 Connect the Conduit Joint to Conduit Fit the adapter plate into the conduit joint. Figure 2-5 Install the Conduit 3.
  • Page 17 Network Dome Camera·Quick Start Guide Thread cables through the sealing plugs. Note: For RJ45 network interface, use supplied cable routing tool. Sealing Plug Cable Routing Tool Figure 2-6 Route RJ45 Network Interface through Sealing Plug Junction Box Figure 2-7 Route Cables through Junction Box...
  • Page 18 Network Dome Camera·Quick Start Guide 5. Align the “FRONT” marks on junction box and adapter plate. Secure the junction box to adapter plate with three screws. Safety Rope Figure 2-8 Install Junction Box 6. Hang the camera body on the safety rope. 7.
  • Page 19 Network Dome Camera·Quick Start Guide 8. Fix the camera body to the junction box with three screws. Figure 2-10 Fix the Camera Body 9. Adjust surveillance angle. Use supplied BNC video out cable to connect the camera to a monitor. Power on the camera to obtain live image of the camera.
  • Page 20 Network Dome Camera·Quick Start Guide To Monitor Video Out (BNC) Figure 2-11 Connect Video Out Hold the lens to adjust the panning, tilting, and rotating position. Pan: 0° to 355° Rotate: 0° to 355° Tilt: 0° to 75° Figure 2-12 Adjust Surveillance Angle...

  • Page 21: Wall Mounting

    Network Dome Camera·Quick Start Guide 10. Peel off the protective films and screw the bubble back to the camera body. 2.3.2 Wall Mounting Before you start: Wall mounting bracket is not included in package. If you choose this mounting type, you have to prepare a bracket first. The wall mounting bracket shown below is only for demonstration.

  • Page 22: Pendant Mounting

    Network Dome Camera·Quick Start Guide 4. Route the cables through the cable hole on adapter plate and secure the adapter plate to the cap. Fixing Screw Figure 2-14 Install Adapter Plate to Bracket 5. Repeat step 4 to step 10 of Section 2.3.1 Ceiling Mounting to complete camera installation.
  • Page 23 Network Dome Camera·Quick Start Guide Fixing Screw Figure 2-15 Install the Pendant Mounting Bracket 3. Align the screw holes of the adapter plate with the correspondent screw holes of the cap. 4. Route the cables through the cable hole on adapter plate and secure the adapter plate to the cap.

  • Page 24: Setting The Network Camera Over The Lan

    Network Dome Camera·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 25: Activating The Camera

    Network Dome Camera·Quick Start Guide Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported. We will take activation via SADP software and Activation via Web Browser as examples to introduce the camera activation.

  • Page 26: Activation Via Sadp Software

    Network Dome Camera·Quick Start Guide Figure 3-3 Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 27 Network Dome Camera·Quick Start Guide Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts. Follow the steps to activate the camera. Steps: 1. Run the SADP software to search the online devices. 2.

  • Page 28: Modifying The Ip Address

    Network Dome Camera·Quick Start Guide STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 29 Network Dome Camera·Quick Start Guide Steps: 1. Run the SADP software. 2. Select an active device. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Figure 3-5 Modify the IP Address...
  • Page 30 Network Dome Camera·Quick Start Guide Note: You can enable the Hik-Connect service for the device during activation. Refer to Chapter 5.1 for detailed information. 4. Input the admin password and click Modify to activate your IP address modification. The batch IP address modification is supported by the SADP. Refer to the user manual of SADP for details.

  • Page 31: Accessing Via Web Browser

    Network Dome Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 8.0 and above version, Mozilla Firefox 30.0 to 51, and Google Chrome 31.0 to 44.
  • Page 32 Network Dome Camera·Quick Start Guide 4. Click Login. Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.

  • Page 33: Operating Via Hik-Connect App

    Network Dome Camera·Quick Start Guide 5 Operating via Hik-Connect App Purpose: Hik-Connect is an application for mobile devices. With the App, you can view live image of the camera, receive alarm notification and so Note: Hik-Connect service is not supported by certain camera models. Enable Hik-Connect Service on Camera Purpose: Hik-Connect service should be enabled on your camera before you...

  • Page 34: Enable Hik-Connect Service Via Web Browser

    Network Dome Camera·Quick Start Guide Figure 5-1 Verification Code Setting (SADP) Note: The verification code is required when you add the camera to Hik-Connect app. 3. Click and read "Terms of Service" and "Privacy Policy". 4. Confirm the settings. 5.1.2 Enable Hik-Connect Service via Web Browser Before you start: You need to activate the camera before enabling the service.
  • Page 35 Network Dome Camera·Quick Start Guide Steps: 1. Access the camera via web browser. Refer to Chapter 4. 2. Enter platform access configuration interface: Configuration > Network > Advanced Settings > Platform Access Figure 5-2 Platform Access Configuration (Web) 3. Select Platform Access Mode as Hik-Connect. 4.

  • Page 36: Hik-Connect Setup

    Network Dome Camera·Quick Start Guide Hik-Connect Setup Steps: 1. Download and install the Hik-Connect app by searching “Hik-Connect” in App Store or Google Play 2. Launch the app and register for a Hik-Connect user account. 3. Log in Hik-Connect app after registration. Adding Camera to Hik-Connect Before you start: You need to enable the Hik-Connect service on camera before...
  • Page 37 Network Dome Camera·Quick Start Guide You can find the QR code on the camera or on the cover of the Quick Start Guide of the camera in the package. Figure 5-4 Scan QR Code Note: If the QR code is missing or too blur to be recognized, you can also add the camera by tapping the icon and inputting the camera's serial number.

  • Page 38: Initializing The Memory Card

    Network Dome Camera·Quick Start Guide Initializing the Memory Card Steps: Check the memory card status by tapping on the Storage Status in the Device Settings interface. If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. You can then start recording any event triggered video in the camera such as motion detection.
  • Page 39 Network Dome Camera·Quick Start Guide...
