4. INSTALLING THE
INTERNAL PRINTER
Ensure that the instrument is unplugged before installing the internal printer.
1. Before the internal printer can be installed the printer blanking panel must be
removed. This is accessed from the back of the unit.
2. Remove the screw securing the printer blanking panel.
3. Lift off the printer blanking panel to reveal the connector for the internal
printer.
4. Connect the printer to the ribbon cable.
5061-046 Rev1
15
