Box
Function
Used in User Interface in Settings to set the text entry mode used for alphanumeric text
entry.
Used in applications that give a concentration result. Units are entered via either
alphanumeric entry or from a list of options.
Used in User Access when creating a new user.
Numeric entry to 3 decimal places, this is used in the CyDye DNA application and is the
volume of the probe in µL.
Numeric entry to 1 decimal place and is used in all fixed wavelength applications to
determine the wavelength at which the measurement will be performed.
Numeric entry to 1 decimal place. Used in the CyDye DNA application, this is the
wavelength at which the absorbance of the dye will be measured. Note for dyes included in
the Ultrospec software these values are not editable and this box will be greyed out.
Numeric entry to 3 decimal places. This is the maximum value of the Y axis shown during
a kinetics measurement. Note the graph will automatically re-scale at the end of the
measurement to give the optimum Y max.
Numeric entry to 3 decimal places. This is the minimum value of the Y axis shown during
a kinetics measurement. Note the graph will automatically re-scale at the end of the
measurement to give the optimum Y min.
5061-046 Rev1
76
29004782UM AA 10/2011
