2.1. Single Cell Holder
(supplied with unit)
The single cell holder is designed to take measurements of 10 mm pathlength
cuvettes. All Ultrospec 7000/8000/9000 are supplied with a single cell holder as
standard.
2.2. Variable Pathlength Cell Holder
80-7100-05
The variable pathlength cell holder is designed to use 1, 2, 5, 10, 20, 50 & 100 mm
pathlength cells. To accommodate different pathlengths the clips should be moved to
secure the cell and spacers used as required.
2.3. Water Thermostatted Cell Holder
80-7100-03
The water Thermostatted cell holder is designed to work with water circulators to
achieve constant temperatures in the range 5 to 80°C. The accessory has to be
connected to an external fluid circulator so that the water flows into the bottom of
the cell holder (the right hand inlet) and flows out through the top of the cell holder
(the left hand outlet).
2.4. Film Holder
80-7100-12
The film holder is designed to measure the absorbance of solid materials including
thin flexible sheet materials such as plastic, acrylic, gelatine. Applications also include
the quality control of tinted optical lenses.
2.5. Test Tube Holder
80-7100-11
The test tube holder allows samples to be measured in a test tube of between 10 and
24 mm diameter and up to 160 mm tall.
