biochrom ultrospec 7000 User Manual page 71

Icon Title
Auto print - USB
Deuterium lamp off
Deuterium lamp fail
Deuterium lamp on
Deuterium lamp warming
Tungsten lamp fail.
Tungsten lamp off
Tungsten lamp on
Tungsten lamp warming
Xenon lamp failed
Instrument busy
Printing to Bluetooth
device
Printing to internal printer
Printing to USB
Toggle view standard
curve
Replicates
Take sample
measurement
Take reference
measurement
5061-046 Rev1
29004782UM AA 10/2011
Function
Displayed on the status bar. This indicates that the instrument will automatically
print all sample data to the USB printer.
Displayed on the status bar. This indicates that the Deuterium lamp is off.
Displayed on the status bar. This indicates that the Deuterium lamp has failed.
Displayed on the status bar. This indicates that the Deuterium lamp is on.
Displayed on the status bar. This indicates that the Deuterium lamp is warming up.
Displayed on the status bar. This indicates that the Tungsten lamp has failed.
Displayed on the status bar. This indicates that the Tungsten lamp is off.
Displayed on the status bar. This indicates that the Tungsten lamp is on.
Displayed on the status bar. This indicates that the Tungsten lamp is warming up.
Displayed on the status bar. This indicates that the Xenon lamp has failed.
Displayed on the status bar. This indicates that the instrument is performing a
measurement.
Displayed on the status bar. This indicates that the instrument is printing to a
Bluetooth device.
Displayed on the status bar. This indicates that the instrument is printing to the
internal printer.
Displayed on the status bar. This indicates that the instrument is printing to a USB
printer.
When used in standard curve applications i.e. Lowry protein assay, this toggles the
sample measurement screen to display or hide the standard curve.
Used in standard curve applications to collect data from a group of replicates.
Commences a sample measurement.
Commences a reference measurement.
