• For Deuterium/Tungsten units T 1.6 A H 250 V AC (Anti-Surge, High breaking
capacity).
• For Xenon units T 1.6 A H 250 V AC (Anti-Surge, High breaking capacity).
• Power rating is:
• 100 VA for Xenon units.
• 150 VA for Deuterium/Tungsten units.
• The instrument should be positioned so that the power cable may be readily
removed in the event of a hazard or malfunction occurring.
• Site the instrument in an atmosphere free from dust and corrosive fumes.
• Use the on/off switch on the left hand side of the instrument. The instrument
will automatically perform some start up self diagnostic checks on switch on.
Please wait for these to finish before attempting to use the equipment.
1.2.1. Instrument Connections
On / Off switch
Fuse holder
Mains inlet
(Ultrospec 7000, 8000 and 9000 stand alone units only)
5061-046 Rev1
USB A plug for USB memory sticks
Internal accessory connector
USB B receptacle
for connection to PC
Connector for external
powered accessories
6
