4. FREQUENTLY USED
ICONS
Button Name
Forward
arrow
Back arrow
Tick
Cross/exit
Buttons On The Sample Measurement Screen
Take
reference
Take
measurement
Options arrow
Buttons On The Options Menu
Method
parameters
Save data
Save method
Print
Auto print
Sample
Manager
Trace
Manager
5061-046 Rev1
29004782UM AA 10/2011
Function
Advances to the next screen in a sequence
Returns to the previous screen in a sequence
Confirms selection/entry. Saves and exits
Exit without saving
Performs a reference measurement
Performs a sample measurement
Opens the options menu on the sample measurement
screen
Takes the user from the sample measurement screen to
the first method parameter screen
Allows the user to manually save sample data to a
specified location.
Allows the user to save the current method parameters to
the internal memory or a USB stick
Prints the sample data from the specified printer
Toggles auto print on and off
Accesses Sample Manager
Accesses Trace Manager (wavescan and kinetics only).
