3. ACTIVE ACCESSORIES
Accessories that interact with the instrument's software are named active
accessories.
The installation of active accessories that use the internal accessory connector is
outlined below.
Note: The Ultrospec 7000/8000/9000 will be supplied with a single cell holder as
standard; this is removed as described above.
1. To insert the accessory, lift the front end, slide into the brackets at the back of
the cell chamber (indicated by the two arrows) and tighten the thumb screw
by turning clockwise.
2. With the accessory inserted and secured using the thumb screw, plug the
15-pin plug into the internal accessory connector.
3. With the accessory inserted and plugged into the internal accessory
connector, replace front panel and switch on the instrument. The accessory
will be calibrated during instrument start-up.
3.1. 8-Position Cell Changer
The 8-position cell changer is designed to speed up analysis by allowing users to
automatically measure samples. With a cell changer connected the software will
allow the user to perform parallel kinetics measurements.
