A. COM port
C. Mic-In
E. HDMI
G. RJ11
I. DC-In

2.2 Installation Procedures

2.2.1 Connecting the Power Cord

The UTC-318 can be powered by a DC electrical outlet. When handling power cords,
ensure to only hold the plug ends. Please reference Figure 2.3 when connecting the
male plug of the power cord to the UTC-318's DC inlet.

2.2.2 Connecting a Keyboard or Mouse

Before powering on the device, connect a keyboard or mouse to the relevant port in
the I/O section.

2.2.3 Switching on the Power

The power button is located at the rear of the UTC-318, as shown in Figure 2.3.
Figure 2.3 Connecting the power cord to the DC inlet
B. Line-Out
D. Gigabit LAN x 2
F. USB3.0 x 4/USB2.0 x 2
H. Power button
9 UTC-318 User Manual
