Summary of Contents for Advantech UTC-315
- Page 1 User Manual UTC-315 Intel® Celeron® J1900 Processor- based Ubiquitous Touch Computer with 15.6” TFT...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
-
Page 3: Declaration Of Conformity
Consult the dealer or an experienced radio/TV technician for help. Warning! Any changes or modifications made to the equipment which are not expressly approved by the relevant standards authority could void your authority to operate the equipment. UTC-315 User Manual... -
Page 4: Packing List
Packing List Before you begin installing UTC-315, please make sure that the following materials have been shipped: UTC-315 series Accessories for UTC-315 – Warranty card – 1 x adapter – 1 x SATA cable – Packet of screws If any of these items are missing or damaged, contact your distributor or sales repre- sentative immediately. -
Page 5: Safety Instructions
The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. - Page 6 UTC-315 User Manual...
-
Page 7: Table Of Contents
Jumpers and connectors............. 21 Table 4.1: Jumpers and Connector Functions......21 4.1.3 Locating jumpers and connectors ..........22 Figure 4.1 Jumpers and Connectors on the UTC-315 motherboard Jumpers ....................23 4.2.1 Jumper List ................. 23 Table 4.2: Jumper List ............... 23 4.2.2... - Page 8 Table A.16:CN24:External USB..........36 Table A.17:CN25: External USB..........37 Table A.18:CN26: External USB..........37 Table A.19:CN27:Line-out ............38 Table A.20:CN28:MIC-IN............38 Table A.21:CN30:HDMI .............. 39 Table A.22:CN31: DC-IN ............40 Table A.23:SW2 BUTTON: Power button........40 UTC-315 User Manual viii...
-
Page 9: Chapter 1 General Information
Chapter General Information This chapter gives background information on the UTC-315. Sections include: Introduction General Specifications LCD Specifications Dimensions... -
Page 10: Introduction
Optional - Audio output function 1.2.4 LAN Function Chipset: LAN1 Intel WGI211AT, LAN2 Intel WGI211AT Speed: 1000 Mbps /Interface: 2 x RJ45 Wake-on-LAN: Supports Wake-on-LAN function with ATX power control Supports LAN teaming (in Fault Tolerance) UTC-315 User Manual... -
Page 11: Touch Screen (Optional)
VESA Support: 75 x 75 mm (Suggest screws type- M4 x 5) Caution! Use suitable mounting apparatus to avoid risk of injury. Supports landscape and portrait screen mode Note! Please follow suggestion to install UTC-315 Models. UTC-315 User Manual... -
Page 12: Lcd Specifications
Luminance: 200 cd/m Note! The color LCD display installed in the UTC-315 is high-quality and reli- able. However, it may contain a few defective pixels which do not always illuminate. With current technology, it is impossible to completely eliminate defective pixels. Advantech is actively working to improve this technology. -
Page 13: Dimensions
1.5 Dimensions Figure 1.1 Dimensions of UTC-315 UTC-315 User Manual... - Page 14 UTC-315 User Manual...
-
Page 15: Chapter 2 System Setup
Chapter System Setup This chapter details system setup on the UTC-315. Sections include: A Quick Tour of the UTC-315 Installation procedures Running the BIOS Setup Program Installing System Software... -
Page 16: A Quick Tour Of The Utc-315
Figure 2.1. Figure 2.1 Front view of UTC-315 When you turn the UTC-315 around and look at its rear cover, you will find the I/O section as shown in Fig. 2.2. (The I/O section includes various I/O ports, including serial ports, Ethernet ports, USB ports, HDMI, and LINE-OUT / MIC-IN, DC-IN, Power button.) -
Page 17: Installation Procedures
Before you start the computer, please connect keyboard port on the I/O section of the UTC-315. 2.2.3 Switching on the power When you look at the rear side of the UTC-315, you will see the power switch as shown in Figure 2.3. Figure 2.3 Connect the power cord to the DC inlet... -
Page 18: Running The Bios Setup Program
2.3 Running the BIOS Setup Program Your UTC-315 is likely to have been properly set up and configured by your dealer prior to delivery. You may still find it necessary to use the UTC-315's BIOS (Basic Input-Output System) setup program to change system configuration information, such as the current date and time or your type of hard drive. - Page 19 Select OS Selection [Windows 8.x/ Android / Windows7] COM2 RS232/RS422/RS485 Selection: Enter Into BIOS setup → Advanced → NCT6106D Super IO Configuration. UTC-315 User Manual...
- Page 20 Select Serial Port 2 Configuration. Change Serial Port 2 Mode [RS232/RS422/RS485]. UTC-315 User Manual...
-
Page 21: Installing System Software
Some distributors and system integrators may have already pre- installed system software prior to shipment of your UTC-315. Installing software requires an installed HDD. Software can be loaded in the UTC-315 using any of four methods: 2.4.1 Method 1: Ethernet You can use the Ethernet port to download software to the HDD. - Page 22 UTC-315 User Manual...
-
Page 23: Chapter 3 Hardware Install And Upgrades
Chapter Hardware Install and Upgrades This chapter details installing the UTC-315 hardware. Sections include: Overview of Hardware Installa- tion and Upgrading Installing the 2.5" Hard Disk Drive (HDD) Installing the mSATA Installing the WLAN... -
Page 24: Introduction
3.1 Introduction The UTC-315 consists of a PC-based computer that is housed in an plastic enclo- sure. You can install a HDD, DRAM, and MiniSATA card by removing the rear cover. Any maintenance or hardware upgrades can be easily completed after removing the rear cover. -
Page 25: Installing The Msata Card
3.4 Installing the WLAN Reserve two locations for the external Antenna. One is at the IO port, the other is at the rear cover. Customers can choose based on their requirement. Remove 10 x screws from the back cover. UTC-315 User Manual... - Page 26 Remove 6 screws on the reinforced board. Coaxial cable (Advantech P/N: 1750006682-01) Connect the coaxial cable to "ANT1" on the WLAN card. Install the WLAN card on M/B bottom side. Cable routing of the wireless antenna is shown below. UTC-315 User Manual...
-
Page 27: Chapter 4 Jumper Settings And Connectors
Chapter Jumper Settings and Connectors This chapter tells how to set up the UTC-315 hardware, including instructions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all the safety precautions before you begin the installation procedures. -
Page 28: Jumpers And Connectors
4.1 Jumpers and Connectors 4.1.1 Setting jumpers You can configure your UTC-315 to match the needs of your application by setting jumpers. A jumper is the simplest kind of electrical switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. -
Page 29: Jumpers And Connectors
4.1.2 Jumpers and connectors The motherboard of the UTC-315 has a number of jumpers and connectors that allow you to configure your system to suit your applications. The table below lists the func- tion of each of the board’s jumpers. -
Page 30: Locating Jumpers And Connectors
4.1.3 Locating jumpers and connectors Figure 4.1 Jumpers and Connectors on the UTC-315 motherboard UTC-315 User Manual... -
Page 31: Jumpers
Description PIN HEADER 3x1P 2.54mm 180D(M) DIP 205-1x3GS Setting Function (1-2) (2-3)* 3.3V Table 4.4: JP3:Clear CMOS Part Number 1653004101 Footprint HD_4x1P_79_D Description PIN HEADER 4x1P 2.0mm 180D(M) DIP 21N12050 Setting Function (2-3)* Normal (3-4) Clear CMOS UTC-315 User Manual... -
Page 32: Table 4.5: Jp4:At/Atx Power Sel
PIN HEADER 3*1P 180D(M) 2.0mm DIP SQUARE W/O Pb Setting Function (1-2) (2-3)* Table 4.6: CN17:COM1 Ring Part Number 1653005101 Footprint HD_5x1P_79_D Description PIN HEADER 5x1P 2.0mm 180D(M) DIP 1140-000-05SN Setting Function (1-2) RING (3-4)* COM1 RI output +5V (4-5)* COM1 RI output +12V UTC-315 User Manual... - Page 33 Appendix I/O Pin Assignments...
-
Page 34: Table A.1: Cn1: Backlight
Description WAFER BOX 8P 1.25mm 180D(M) DIP A1251WV0-8P Pin name +12V_INVERTER +12V_INVERTER BKLT_EN BRIGHT1 +12V_INVERTER Table A.2: CN3: Internal USB Part Number 1655000453 Footprint WHL5V-2M-24W1140 Description WAFER BOX 2.0mm 5P 180D(M) DIP WO/Pb JIH VEI Pin name UTC-315 User Manual... -
Page 35: Table A.3: Cn4: Lvds
+3.3V or +5V - +3.3V or +5V +3.3V or +5V LVDS0_D0- LVDS1_D0- LVDS0_D0+ LVDS1_D0+ GND- LVDS0_D1- LVDS1_D1- LVDS0_D1+ LVDS1_D1+ LVDS0_D2- LVDS1_D2- LVDS0_D2+ LVDS1_D2+- LVDS0_CLK- LVDS1_CLK- LVDS0_CLK+ LVDS1_CLK+ LVDS0_DDC_SC LVDS0_DDC_SD LVDS0_D3- LVDS1_D3- LVDS0_D3+ LVDS1_D3+ +3.3V or +5V +3.3V or +5V UTC-315 User Manual... -
Page 36: Table A.4: Cn6: Sata
Table A.4: CN6: SATA Part Number 1654004659 Footprint WF_5P_98_BOX_D Description WAFER BOX 5P 2.5mm 180D(M) DIP 2503-WS-5 Pin name Table A.5: CN7:SATA POWER Part Number 1659254005 Footprint SATA_7P_WATM-07DBN4A3B8UW_D Description Serial ATA 7P 1.27mm 180D(M) DIP WATM-07DBN4A3B8 Pin name +3.3V +12V UTC-315 User Manual... -
Page 37: Table A.6: Cn8: Internal Usb
Table A.6: CN8: Internal USB Part Number 1655000453 Footprint WHL5V-2M-24W1140 Description WAFER BOX 2.0mm 5P 180D(M) DIP WO/Pb JIH VEI Pin name Table A.7: CN9:Touch Part Number 1655005110 Footprint WF_5P_100_RA_D Description WAFER 5P 2.54mm 90D(M) DIP 2542-WR-5 Pin name SENSE UTC-315 User Manual... -
Page 38: Table A.8: Cn13:Ddr3L Sodimm
Table A.8: CN13:DDR3L SODIMM Part Number 1651002087-11 Footprint DDR3_204P_AS0A626-N2S6-7H Description DDR3 SODIMM H=5.2mm STD 204P SMD AS0A626-H2S6-7H Pin name VREF_DQ UTC-315 User Manual... -
Page 39: Table A.9: Minipcie1:Minipcie
Table A.9: MINIPCIE1:MINIPCIE Part Number 1654002538 Footprint FOX_AS0B226-S68K7F Description MINI PCI E 52P 6.8mm 90D SMD AS0B226-S68Q-7H Pin name MPCIE1_WAKE# +3.3VSB MPCIE_CLKREQ# CLK_MINI_PCIE- CLK_MINI_PCI+ MPCIE1_DISABLE# PLTRST# PCIE_RX- +3.3VSB PCIE_RX+ +1.5V SMB_CLK_MPCIE1 PCIE_TX- SMB_DAT_MPCIE1 PCIE_TX+ USB_D- USB_D+ +3.3VSB +3.3VSB UTC-315 User Manual... -
Page 40: Table A.10:Msata1: Msata
Table A.9: MINIPCIE1:MINIPCIE +3.3VSB Table A.10: MSATA1: MSATA Part Number 1654002538 Footprint FOX_AS0B226-S68K7F Description MINI PCI E 52P 6.8mm 90D SMD AS0B226-S68Q-7H Pin name +3.3V UTC-315 User Manual... - Page 41 Table A.10: MSATA1: MSATA SATA1_RX+ +3.3V SATA1_RX- SATA1_TX- SATA1_TX+ +3.3V +3.3V +3.3V +3.3V UTC-315 User Manual...
-
Page 42: Table A.11:Cn16: Com2
Table A.11: CN16: COM2 Part Number 1655000197 Footprint WF_5x2P_79_BOX_D_P1R Description 1655_WF_5x2P_79_BOX_D_P1R_0.Normal Pin name 422/485 TX- 422/485 TX+ 422 RX+ 422 RX- DSR# RTS# CTS# UTC-315 User Manual... -
Page 43: Table A.12:Cn18: Com1
Table A.12: CN18: COM1 Part Number 1655000197 Footprint WF_5x2P_79_BOX_D_P1R Description 1655_WF_5x2P_79_BOX_D_P1R_0.Normal Pin name DTR# DSR# RTS# CTS# Table A.13: CN21: Power switch Part Number 1655302020 Footprint WF_2P_79_BOX_R1_D Description WAFER BOX 2P 2.0mm 180D(M) DIP A2001WV2-2P Pin name PSIN UTC-315 User Manual... -
Page 44: Table A.14:Cn22:Speaker
Table A.15: CN23: LAN1/LAN2 Part Number 1652003274 Footprint RJ45_28P_RTB-19GB9J1A Description PHONE JACK RJ45 28P DIP RTB-19GB9J1A Pin name Table A.16: CN24:External USB Part Number 1654009513 Footprint USB_8P_UB1112C-8FDE-4F Description USB CONN. 8P 2.0mm 90D DIP UB1112C-8FDE-4F Pin name +5VSB +5VSB UTC-315 User Manual... -
Page 45: Table A.17:Cn25: External Usb
USB CONN. 8P 2.0mm 90D DIP UB1112C-8FDE-4F Pin name +5VSB +5VSB Table A.18: CN26: External USB Part Number 1654010199 Footprint USB_13P_UEA1112C-UHS6-4F Description USB Conn. 2.0+3.0 13P 90D(F) DIP UEA1112C-UHS6-4 Pin name +5VSB RX_D- RX_D+ TX_D- TX_D+ +5VSB UTC-315 User Manual... -
Page 46: Table A.19:Cn27:Line-Out
KUONYI_PJ-2508PC-5-L Description PHONE JACK 5P 3.5φ 90D(F) AZALIA GREEN DIP WO/P Pin name OUT_L OUT_R Table A.20: CN28:MIC-IN Part Number 1652001584 Footprint KUONYI_PJ-2508PA-5-L Description PHONE JACK 5P 3.5φ 90D(F) AZALIA PINK DIP WO/Pb Pin name MIC_L MIC_R UTC-315 User Manual... -
Page 47: Table A.21:Cn30:Hdmi
Table A.21: CN30:HDMI Part Number 1654011175-01 Footprint HDMI_19P_QJ51191-LFB4-7F Description HDMI Conn. 19P 0.5mm 90D(F) SMD QJ51191-LFB4-7F Pin name HDMI_TX0+ HDMI_TX0- HDMI_TX1+ HDMI_TX1- HDMI_TX2+ HDMI_TX2- HDMI_TX3+ HDMI_TX3- HDMI_CLK HDMI_DAT HDMI_DET UTC-315 User Manual... -
Page 48: Table A.22:Cn31: Dc-In
1652005624 Footprint PJ_2P_2DC-G213B200 Description DC POWER JACK 2.5mm 90D(M) DIP 2DC-G213B200 Pin name DC_IN Table A.23: SW2 BUTTON: Power button Part Number 1600000055 Footprint SW_6P_TC003-N11AABRGXX-RK_D Description PUSH SW DIP 6P W/LED WO/Pb TC003-N11AABRGXX-RK Pin name ATX_PWRBTN# ATX_PWRBTN# UTC-315 User Manual... - Page 49 UTC-315 User Manual...
- Page 50 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2014...
