Advantech UTC-115 User Manual

15.6”/21.5”/23.8” ubiquitous touch computer

Hide thumbs Also See for UTC-115:

User manual (31 pages)

page of 57

/ 57
Bookmarks

Quick Links

Download this manual

User Manual

UTC-115/120/124

15.6"/21.5"/23.8"

Ubiquitous Touch Computer

Need help?

Do you have a question about the UTC-115 and is the answer not in the manual?

Questions and answers

Summary of Contents for Advantech UTC-115

Page 1 User Manual UTC-115/120/124 15.6”/21.5”/23.8” Ubiquitous Touch Computer...
Page 2 The documentation and the software included with this product are copyrighted 2021 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. also reserves the right to improve the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
Page 3 Product Warranty (3 years) Advantech warrants the original purchaser that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products that have been repaired or altered by persons other than repair personnel authorized by Advantech, or products that have been subject to misuse, abuse, accident, or improper installation.
Page 4 Technical Support and Assistance Visit the Advantech website at http://support.advantech.com to obtain the latest product information. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before calling: ...
Page 5 In accordance with the IEC 704-1:1982 specifications, the sound pressure level at the operator’s position does not exceed 70 dB (A). DISCLAIMER: These instructions are provided according to IEC 704-1 standards. Advantech disclaims all responsibility for the accuracy of any statements contained herein. UTC-100 User Manual...
Page 6 Warning! Because of the risk of electric shock, do not remove the equipment cover during operation or when connected to a power outlet. Caution! To avoid short circuits and otherwise damaging the device, do not allow fluids to come in contact with the device. If fluids are accidentally spilled on the equipment, remove the affected unit from service as soon as pos- sible.
Page 7 UTC-124I1/I3 ................. 4 Chapter System Setup ........Quick Tour ....................6 2.1.1 Front View ..................6 Figure 2.1 UTC-115/120/124 with Glass Panel and PCAP Touch6 2.1.2 Rear View ..................6 I/O Ports ....................7 2.2.1 UTC-115/120 (Right Side) ............. 7 2.2.2...
Page 8 A.2.2 Packing list ................. 17 A.2.3 Ordering information ..............17 A.2.4 Installation .................. 19 UTC-100P-C10E (5M Camera ) ............... 20 A.3.1 Specifications ................20 A.3.2 Packing list ................. 20 A.3.3 Ordering information ..............20 A.3.4 Installation .................. 22 UTC-100P-R10E (RFID) ................23 A.4.1 Specifications ................
Page 9 Chapter General Information...
Page 10 1.1 Introduction Advantech's UTC-100 series comprises 15.6” / 21.5” / 23.8” fanless, low-power, all- in- one touch panel computers that can be deployed as control room computing devices, production line signage displays, showroom interactive signage, self-service kiosks, and public service terminals to support diverse retail, hospitality, healthcare, education, entertainment, and information processing applications.
Page 11 1.2.2 UTC-115H, 120H Product UTC-115 UTC-120 15.6” ubiquitous 21.5” ubiquitous touch Description touch computer computer Model UTC-115H UTC-120H ® ® Core™ i5-8365UE Core™ i5-8365UE Intel Intel ® ® Core™ i3-8145UE Core™ i3-8145UE Intel Intel Cache 2 MB 2 MB System...
Page 12 1.2.4 UTC-115K, 120K, 124K Product UTC-115 UTC-120 UTC-124 15.6” ubiquitous 21.5” ubiquitous touch 23.8” ubiquitous Description touch computer computer touch computer Model UTC-115K UTC-120K UTC-124K Intel ® Core™ N97 K: Intel ® Core™ N97 K: Intel ® Core™ N97 Intel ® Core™ i3-N305 K: Intel ®...
Page 13 Windows 10 IoT Enterprise (64 Windows 10 IoT Enterprise (64 OS Support bit), Linux bit), Linux 1.2.6 UTC-124I1/124I3 Product UTC-124I1 UTC-124I3 15.6” ubiquitous 21.5” ubiquitous Description touch computer touch computer Model UTC-124I1 UTC-124I3 ® ® Core™ i5-8365UE Core™ i5-8365UE Intel Intel ®...
Page 14 1.3.2 UTC-115H/I...
Page 15 1.3.3 UTC-115K 1.3.4 UTC-120G 1.3.5 UTC-120H/I...
Page 16 1.3.6 UTC-120K...
Page 17 1.3.5 UTC-124G1/124G3/124K(N97) 1.3.6 UTC-124I1/124I3/124K(I3)
Page 18 Chapter System Setup...
Page 19 Before setting up the device, take a moment to familiarize yourself with the connector locations and functions, as shown in the images below. 2.1.1 Front View Figure 2.1 UTC-115/120/124 with Glass Panel and PCAP Touch 2.1.2 Rear View UTC-115/120H, UTC-115/120I, UTC-115/120K(I3)
Page 20 UTC-124G1/124K(N97) UTC-124G3...
Page 21 UTC-124I1/124K(I3) UTC-124I3...
Page 22 I/O Ports 2.2.1 UTC-115/120 (Right Side) UTC-115/120 G/H UTC-115/120I UTC-115/120K UTC-115/120 (Left Side) UTC-115/120 G/H...
Page 23 UTC-115/120I UTC-115/120K 2.2.2 UTC-124 (Top Side) UTC-124G1 UTC-124I1 UTC-124K 2.2.3 UTC-124(Bottom Side) UTC-124G1 UTC-124I1 UTC-124G3/I3...
Page 24 After installing the system software, users can setup the Ethernet, XGA, audio, and touchscreen functions. Note! The relevant drivers and utilities are subject to change without notice. Download the latest drivers for the UTC-100 series products from the Advantech website at http://support.advantech.com or contact our appli- cation engineers for further assistance.
Page 25 Chapter Hardware Installation...
Page 26 3.2 Remove the Side Rear Covers After turning the power off and disconnecting all cables, place the UTC-100 series computer face-down on a soft, flat surface. Remove the rear bottom cover first. UTC-115/120 UTC-124 UTC-100 User Manual...
Page 27 With your thumbs under the edge of the one side rear cover, gently lift to dis- engage the tabs holding the cover in place. Then slide the cover outwards to remove it. UTC-124 Pull out the covers gently from both sides UTC-100 User Manual...
Page 28 3.3 Replace the Side Rear Covers Align the tabs of the rear cover with the slots on the enclosure while placing the cover on the computer. Press down on the cover firmly until the tabs snap into place, locking the cover securely in position.
Page 29 3.4 SATA SSD Installation UTC-100 systems feature a 2.5” SATA SSD bay reserved for customizable storage. To install a 2.5” SATA SSD, follow the steps outlined below. C-100 Series 3.4.1 UT Remove the bottom and side rear cover. Loosen the affixing screws and remove the SSD bracket. Insert the SATA SSD into the SSD bracket and fasten it in place with screws.
Page 30 3.5 Memory Module Installation Remove the bottom and side rear covers. Loosen the affixing screws and remove the VESA mount plate. Remove the 4 screws from the DRAM memory module heatsink. Turn the memory module over. Install the DRAM module in the SODIMM socket. Replace the DRAM memory module heatsink and tighten the screws to affix it in place.
Page 31 Appendix UTC Peripherals...
Page 32 Windows 10 & Android Dimensions 50.0 x 39.0 x 27.0 mm Operating -10° C to 40° C Temperature A.1.2 Packing List Description Quantity Barcode Reader Unit Barcode Bracket for UTC-115 long (bottom) side A.1.3 Ordering information Description UTC-100P-B11E 2D Barcode Module for UTC-115/UTC-120...
Page 33 Barcode scanner on UTC-115 Long (bottom) side 1. Remove bottom I/O cover on UTC-115 2.Take out the bracket in the accessory box 3.Thread the cable from the hole 4. Lock barcode scanner with 2pcs M3*8L screws on UTC-115 long in the middle of bracket (bottom)side...
Page 34 Dimensions 96.0 x 17.3 x 26.5 mm Operating Temperature 0 ~ 40° C A.2.2 Packing List Description Quantity Magnetic Stripe Reader Unit Magnetic Stripe Reader bracket for UTC-115 long (bottom) side A.2.3 Ordering information Description UTC-100P-M10E MSR Module for UTC-115/120...
Page 35 A.2.4 Installation  MSR on UTC-115/120/124 Short side 1.Take out the module from the package. Remove two screws on the peripheral cover. (rear bottom I/O cover) 2.Remove rear bottom I/O cover first 3.Remove the side cover, and open the small side door on the side cover.
Page 36  MSR on UTC-115/120/124 Long (Top) side 1.Take out the module from the package, and remove the two screws on the peripheral cover. 2.Remove the top cover on the UTC. 3.Connect module to small 5 pin cable. (the circled connector) 4.Lock bracket with two screws on the UTC.
Page 37 Video Format MJPG OS Support Windows 10 & Android Dimensions 101.4 x 22.2 x 11.5 mm Operating 0 ~ 40° C Temperature A.3.2 Packing List Description Quantity Camera Module Unit A.3.3 Ordering information Description UTC-100P-C10E 5M Camera Module for UTC-115/120...
Page 38 A.3.4 Installation  Camera on UTC-115/120/124 Short side 1.Take out the module from the package. Remove two screws on the peripheral cover. (Rear bottom I/O cover) 2.Remove rear bottom I/O cover first 3.Remove the side cover, and open the small side door on the side cover.
Page 39  Camera on UTC-115/120/124 Long (Top) side 1.Take out the module from the package, and remove the two screws on the peripheral cover. 2.Remove the top cover on the UTC. 3.Connect module to small 5 pin cable. (the circled connector) 4.Lock bracket with two screws on the UTC.
Page 40 Windows 10 & Android Dimensions 101 x 37 x 25 mm Operating 0 ~ 40° C Temperature A.4.2 Packing List Description Quantity RFID Module Unit RFID Module Bracket of UTC-115 long (bottom) side A.4.3 Ordering information Description UTC-100P-R10E RFID Module for UTC-115/120...
Page 41 A.4.4 Installation  RFID on UTC-115/120/124 Short side 1.Take out the module from the package. Remove two screws on the peripheral cover. (Rear bottom I/O cover) 2.Remove rear bottom I/O cover first 3.Remove the side cover, and open the small side door on the side cover.
Page 42  RFID on UTC-115/120/124 Long (Top) side 1.Take out the module from the package, and remove the two screws on the peripheral cover. 2.Remove the top cover on the UTC. 3.Connect module to small 5 pin cable. (the circled connector) 4.Lock bracket with two screws on the UTC.
Page 43 101.0 x 34.9 x 33.8 mm Operating Temperature 0 ~ 40° C A.5.2 Packing List Description Quantity Smart Card reader Unit Smart Card reader Bracket of UTC-115 long (bottom) side A.5.3 Ordering information Description UTC-100P-S10E Smart Card reader for UTC-115/120...
Page 44 A.5.4 Installation  Smart card module on UTC-115/120/124 Short side 1.Take out the module from the package. Remove two screws on the peripheral cover. (Rear bottom I/O cover) 2. Remove rear bottom I/O cover first 3. Remove the side cover, and open the small side door on the side cover.
Page 45  Smart card module on UTC-115/120/124 Long (Top) side 1.Take out the module from the package, and remove the two screws on the peripheral cover. 2.Remove the top cover on the UTC. 3.Connect module to small 5 pin cable. (the circled connector) 4.Lock bracket with two screws on the UTC.
Page 46 USB (Cable Length:50cm) OS Support Windows 10 & Android Dimensions 160.0 x 18.5 x 9.0 mm Operating 0 ~ 40° C Temperature A.6.2 Packing List Description Quantity LED Light Bar Unit A.6.3 Ordering information Description UTC-100P-L10E LED Light Bar for UTC-115/120...
Page 47 1.Take out the contents from the peripheral package. Remove two screws from peripheral cover. 2.Remove rear bottom I/O cover first 3.Remove the side cover of UTC-115 or UTC-120., and open the small side door on the side cover. 4.Connect cable to the connector on the UTC.
Page 48  LED Light bar on UTC-115/120/124 Long (Top) side 1.Take out the contents from the peripheral package and remove the two screws of peripheral cover. 2.Remove the top cover of UTC. 3. Connect module to big 4 pin cable. (the circled connector) 4.Lock bracket with two screws on the UTC.
Page 49 Windows 10 & Android Dimensions 101.0 x 34.9 x 9.4 mm Operating 0 ~ 40° C Temperature A.7.2 Packing List Description Quantity Fingerprint Module Unit Fingerprint Module Bracket of UTC-115 long (bottom) side A.7.3 Ordering information Description UTC-100P-F10E Fingerprint Module for UTC-115/120...
Page 50 A.7.4 Installation  Finger print module on UTC-115/120/124 Short side (Rear bottom I/O cover) 1.Take out the module from the package. Remove two screws on the peripheral cover. 2.Remove rear bottom I/O cover first 3.Remove the side cover, and open the small side door on the side cover.
Page 51  Finger print module on UTC-115/120/124 Long (Top) side 1.Take out the module from the package, and remove the two screws on the peripheral cover. 2.Remove the top cover on the UTC. 3.Connect module to small 5 pin cable. (the circled connector) 4.Lock bracket with two screws on the UTC.
Page 52 150mk OS Support Windows 10 & Android Dimensions 101.0 x 34.9 x 33.8 mm Operating 0 ~ 40° C Temperature A.8.2 Packing List Description Quantity Module Unit Bracket of UTC-115 long (bottom) side A.8.3 Ordering information Description UTC-100P-T10E for UTC-115/120...
Page 53 A.8.4 Installation Thermal camera module on UTC-115/120/124 Short side (only)  (Rear bottom I/O cover) 1.Take out the module from the package. Remove two screws on the peripheral cover. 2.Remove rear bottom I/O cover first 3.Remove the side cover, and open the small side door on the side cover.
Page 54 Appendix UTC Stands Installation...
Page 55 B.1 UTC-UPOS-STAND0E Installation VESA Mount Screw UTC-115: M4*7L UTC-120: M4*7L UTC-124: M4*7L...
Page 56 B.2 UTC-AVALO-STAND0E Installation VESA Mount Screw UTC-115: M4*7L UTC-120: M4*7L UTC-124: M4*7L...
Page 57 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2024...
