Table A.10: CN11: CSAFE
Part Number
Footprint
Description
Pin
1
2
3
4
5
6
7
8
9
UTC-318 User Manual
1655000197
WF_5x2P_79_BOX_D_P1R
1655_WF_5x2P_79_BOX_D_P1R_0. normal
Pin Name
LINE_IN1_L
LINIE_IN1_R
COM3_ RX+
COM3_TX
V_CSAFE
COM3_CTS#
GND
GND
38
