Advantech UTC-318 User Manual

Advantech UTC-318 User Manual

Intel core i-based ubiquitous touch computer with 18.5” tft lcd
Hide thumbs Also See for UTC-318:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
User Manual
UTC-318
Intel® Core™i-Based Ubiquitous
Touch Computer with 18.5" TFT
LCD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UTC-318 and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech UTC-318

Summary of Contents for Advantech UTC-318

  • Page 1 User Manual UTC-318 Intel® Core™i-Based Ubiquitous Touch Computer with 18.5” TFT...
  • Page 2 The documentation and the software included with this product are copyrighted 2016 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to improve the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
  • Page 3 UTC-318 User Manual...

  • Page 4: Declaration Of Conformity

    Consult the dealer or an experienced radio/TV technician for assistance. Warning! Any changes or modifications made to the equipment that are not expressly approved by the relevant standards authority may void your authority to operate the equipment. UTC-318 User Manual...

  • Page 5: Packing List

    Packing List Before installing UTC-318, please ensure that the following materials have been shipped:  UTC-318  Accessories for UTC-318 – Warranty card – 1 x adapter – 1 x SATA cable – 1 x packet of screws If any of these items are missing or damaged, contact your distributor or sales repre- sentative immediately.

  • Page 6: Safety Instructions

    The sound pressure level at the operator's position, in accordance with the IEC 704-1:1982, does not exceed 70 dB (A). DISCLAIMER: These instructions are provided in accordance with the IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. UTC-318 User Manual...

  • Page 7: Table Of Contents

    Figure 1.1 UTC-318 dimensions..........5 Chapter System Setup ........7 Quick System Tour..................8 Figure 2.1 UTC-318 front view............. 8 Figure 2.2 UTC-318 rear view ............. 8 Installation Procedures................9 2.2.1 Connecting the Power Cord............9 2.2.2 Connecting a Keyboard or Mouse ..........9 2.2.3...
  • Page 8 Table A.16:CN17: LAN1/LAN2 ........... 41 Table A.17:CN24: HDMI ............. 42 Table A.18:CN19: External USB..........43 Table A.19:CN20: External USB..........44 Table A.20:CN18: External USB..........45 Table A.21:CN23: RJ11.............. 45 Table A.22:SW2 Button: Power Button........46 Table A.23:CN31: DC-In............. 46 UTC-318 User Manual viii...

  • Page 9: Chapter 1 General Information

    Chapter General Information This chapter gives background information on the UTC-318.  Introduction  System Specifications  LCD Specifications  Optional Modules  Dimensions...

  • Page 10: Introduction

    1.1 Introduction UTC-318 is a multi-purpose all-in-one computer equipped with a wide format, touch- based LCD panel. The system can be easily integrated with additional peripherals and display systems to support diverse self-service operations and interactive sig- nage applications at various installation locations. Additionally, with the removable frame design for panel mount applications, the system can also be used for control system operations.

  • Page 11: Touchscreen (Optional)

    VESA Support: 100 x 100 mm (screw type - M4 x 8) Caution! Use suitable mounting apparatus to avoid risk of injury.  Supports landscape and portrait screen modes. Note! Please follow the suggestions when installing UTC-318 models. UTC-318 User Manual...

  • Page 12: Lcd Specifications

    Luminance: 250 cd/m  Note! The color LCD panel integrated with the UTC-318 is of high quality and reliable. However, the display may contain a few defective pixels that do not always illuminate. Even with the most up-to-date technology, it is impossible to completely eliminate defective pixels.

  • Page 13: Dimensions

    1.5 Dimensions Figure 1.1 UTC-318 dimensions UTC-318 User Manual...
  • Page 14 UTC-318 User Manual...

  • Page 15: Chapter 2 System Setup

    Chapter System Setup This chapter details the system setup process for UTC-318.  Quick System Tour  Installation Procedures  BIOS Setup Utility  System Software Installation  Driver Installation...

  • Page 16: Quick System Tour

    When the UTC-318 is upright, the front panel should appear as shown in Figure 2.1. Figure 2.1 UTC-318 front view Located at the rear of the UTC-318 is the I/O section, as shown in Figure 2.2. (The I/O section comprises serial, Ethernet, USB, HDMI, Line-Out/Mic-In, RJ11, and DC-In ports, as well as a power button.)

  • Page 17: Installation Procedures

    Before powering on the device, connect a keyboard or mouse to the relevant port in the I/O section. 2.2.3 Switching on the Power The power button is located at the rear of the UTC-318, as shown in Figure 2.3. Figure 2.3 Connecting the power cord to the DC inlet UTC-318 User Manual...

  • Page 18: Bios Setup Utility

    This equipment is likely to have been set up and configured by the dealer prior to delivery. Nonetheless, users may still need to use the UTC-318's BIOS setup utility to adjust the system configuration data, such as the current date and time or hard drive type.
  • Page 19 Change Serial Port 2 Mode [RS232/RS422/RS485] UTC-318 User Manual...

  • Page 20: System Software Installation

    The UTC-318 BIOS supports system bootup directly from the CD-ROM drive. Users can also insert the system installation CD into the CD-ROM drive. Power on or reset the system by pressing “Ctrl+Alt+Del”. The UTC-318 will automati- cally load the operating system from the disk or CD-ROM.

  • Page 21: Chapter 3 Hardware Installation And Upgrades

    Chapter Hardware Installation and Upgrades This chapter details the UTC-318 hardware installation process.  2.5" Hard Disk Drive Installation  mSATA Card Installation  WLAN Installation...

  • Page 22: Introduction

    3.1 Introduction UTC-318 is a touch-based computer housed in an plastic enclosure. To install HDD, DRAM, and mini SATA cards, or to conduct hardware maintenance or upgrades, the system’s rear cover must be removed. Warning! Do not remove the rear cover until you have verified that no power is flowing within the UTC-318.

  • Page 23: Msata Card Installation

    3.3 mSATA Card Installation Remove the 10 screws on the back cover. Remove the 6 screws on the reinforced board. Figure 3.2 mSATA card installation UTC-318 User Manual...

  • Page 24: Wlan Installation

    Reserve two locations for the external antenna, one at the I/O port, the other on the rear cover. Users can choose the location according to their requirements. Remove the 10 screws from the back cover. Remove the 6 screws on the reinforced board. Coaxial cable (Advantech P/N: 1750006682-01) UTC-318 User Manual...
  • Page 25 Connect the coaxial cable to “ANT1” on the WLAN card. Install the WLAN card on the underside of the motherboard. The ideal wireless antenna cable routing is shown below. UTC-318 User Manual...
  • Page 26 UTC-318 User Manual...

  • Page 27: Chapter 4 Jumper And Connector Settings

    Chapter Jumper and Connector Settings This chapter details instructions for setting jumpers and connect- ing peripherals, switches, and indicators.  Jumpers and Connectors  CMOS Clear for External RTC (JP3)  COM Port Interface  Watchdog Timer Configuration...

  • Page 28: Jumpers And Connectors

    4.1 Jumpers and Connectors 4.1.1 Setting Jumpers Users can configure the UTC-318 to match the application needs by setting jumpers. A jumper is the simplest type of electrical switch and consists of two metal pins and a small metal clip (typically protected by a plastic cover) that slides over the pins to connect them.

  • Page 29: Jumpers And Connectors

    4.1.2 Jumpers and Connectors The UTC-318 motherboard features a number of jumpers and connectors that enable the system to be configured according to the application requirements. The table below lists the function of each board jumper. Table 4.1: Jumper and Connector Functions...

  • Page 30: Jumper And Connector Locations

    4.1.3 Jumper and Connector Locations Figure 4.1 Jumper and connector motherboard locations UTC-318 User Manual...

  • Page 31: Jumpers

    Pin Header 3 x 1P 2.0 mm 180D(M) DIP 2000-13 WS Setting Function (1-2) (2-3)* 3.3 V Table 4.4: JP2: LCD ENABLE POWER Part Number 1653003101 Footprint HD_3x1P_79_D Description Pin Header 3 x 1P 2.0 mm 180D(M) DIP 2000-13 WS Setting Function (1-2) (2-3)* 3.3 V UTC-318 User Manual...

  • Page 32: Table 4.5: Jp3: Lcd Power

    Pin Header 3 x 1P 2.0 mm 180D(M) DIP 2000-13 WS Setting Function (1-2)* +3.3 V (2-3) +3.3VSB Table 4.7: JP5: AT/ATX POWER SEL Part Number 1653005101 Footprint HD_5x1P_79_D Description Pin Header 3 x 1P 2.0 mm 180D(M) DIP 2000-13 WS Setting Function (1-2) (2-3)* UTC-318 User Manual...

  • Page 33: Table 4.8: Jp6: Clear Cmos

    Table 4.10: CN10: CSAFE Power Part Number 1653003201 Footprint HD_3x2P_79_D Description Pin Header 3 x 2P 2.0 mm 180D(M) DIP 21N22050 Setting Function (1-3) * CSAFE output +5 V (3-4) CSAFE output +9 V (3-5) CSAFE output +12 V UTC-318 User Manual...
  • Page 34 UTC-318 User Manual...
  • Page 35 UTC-318 User Manual...
  • Page 36 UTC-318 User Manual...
  • Page 37 Appendix I/O Pin Assignments...

  • Page 38: Table A.1: Cn1: Backlight

    Wafer Box 8P 1.25 mm 180D(M) DIP A1251WV0-8P Pin Name +12 V_INVERTER +12 V_INVERTER BKLT_EN BRIGHT1 +12 V_INVERTER Table A.2: CN2: Internal USB Part Number 1655000453 Footprint WHL5V-2M-24W1140 Description Wafer Box 2.0 mm 5P 180D(M) DIP WO/Pb JIH VEI Pin Name +5 V UTC-318 User Manual...

  • Page 39: Table A.3: Cn3: Sata Power

    B/B Conn. 40P 1.25 mm 90D SMD DF13-40DP-1.25V(91) Pin Name +3.3 V or +5 V +3.3 V or +5 V - +3.3 V or +5 V +3.3 V or +5 V LVDS0_D0- LVDS1_D0- LVDS0_D0+ LVDS1_D0+ GND- LVDS0_D1- LVDS1_D1- LVDS0_D1+ LVDS1_D1+ LVDS0_D2- LVDS1_D2- LVDS0_D2+ LVDS1_D2+- UTC-318 User Manual...
  • Page 40 Table A.4: CN4: LVDS LVDS0_CLK- LVDS1_CLK- LVDS0_CLK+ LVDS1_CLK+ LVDS0_DDC_SC LVDS0_DDC_SD LVDS0_D3- LVDS1_D3- LVDS0_D3+ LVDS1_D3+ +3.3 V or +5 V +3.3 V or +5 V UTC-318 User Manual...

  • Page 41: Table A.5: Cn5: Sata

    Table A.5: CN5: SATA Part Number 1654004659 Footprint WF_5P_98_BOX_D Description Wafer Box 5P 2.5 mm 180D(M) DIP 2503-WS-5 Pin Name Table A.6: CN9:Touch Part Number 1655005110 Footprint WF_5P_100_RA_D Description Wafer 5P 2.54 mm 90D(M) DIP 2542-WR-5 Pin Name SENSE UTC-318 User Manual...

  • Page 42: Table A.7: Cn13: Ddr3L Sodimm

    Table A.7: CN13: DDR3L SODIMM Part Number 1651002087-11 Footprint DDR3_204P_AS0A626-N2S6-7H Description DDR3 SODIMM H= 5.2 mm STD 204P SMD AS0A626-H2S6-7H Pin Name VREF_DQ DQS0 DQS1 UTC-318 User Manual...

  • Page 43: Table A.8: Minipcie1: Minipcie

    Table A.8: MINIPCIE1: MINIPCIE Part Number 1654002538 Footprint FOX_AS0B226-S68K7F Description Mini PCI-E 52P 6.8 mm 90D SMD AS0B226-S68Q-7H Pin Name MPCIE1_WAKE# +3.3VSB MPCIE_CLKREQ# CLK_MINI_PCIE- CLK_MINI_PCI+ MPCIE1_DISABLE# PLTRST# PCIE_RX- +3.3VSB PCIE_RX+ +1.5 V SMB_CLK_MPCIE1 PCIE_TX- SMB_DAT_MPCIE1 PCIE_TX+ USB_D- USB_D+ +3.3VSB +3.3VSB UTC-318 User Manual...

  • Page 44: Table A.9: Msata1: Msata

    Table A.8: MINIPCIE1: MINIPCIE +3.3VSB Table A.9: MSATA1: MSATA Part Number 1654002538 Footprint FOX_AS0B226-S68K7F Description Mini PCI-E 52P 6.8 mm 90D SMD AS0B226-S68Q-7H Pin Name +3.3 V SATA1_RX+ +3.3 V SATA1_RX- UTC-318 User Manual...
  • Page 45 Table A.9: MSATA1: MSATA SATA1_TX- SATA1_TX+ +3.3 V +3.3 V +3.3 V +3.3 V UTC-318 User Manual...

  • Page 46: Table A.10:Cn11: Csafe

    Table A.10: CN11: CSAFE Part Number 1655000197 Footprint WF_5x2P_79_BOX_D_P1R Description 1655_WF_5x2P_79_BOX_D_P1R_0. normal Pin Name LINE_IN1_L LINIE_IN1_R COM3_ RX+ COM3_TX V_CSAFE COM3_CTS# UTC-318 User Manual...

  • Page 47: Table A.11:Cn13: Com2

    (1) 8 data bits + 1 parity bit + 1 stop bit (2) 8 data bits + 1 parity bit + 2 stop bits (3) 8 data bits + 2 stop bits UTC-318 User Manual...

  • Page 48: Table A.12:Cn14: Com1

    Part Number 1655000197 Footprint WF_5x2P_79_BOX_D_P1R Description 1655_WF_5x2P_79_BOX_D_P1R_0. normal Pin Name DTR# DSR# RTS# CTS# Table A.13: CN15: SPEAKER Part Number 1655304020 Footprint WF_4P_79_BOX_R1_D Description Wafer Box 2.0 mm 4P 180D(M) W/LOCK A2001WV2-4P Pin Name AUD_OUTA- AUD_OUTA+ AUD_OUTB+ AUD_OUTB- UTC-318 User Manual...

  • Page 49: Table A.14:Cn21: Line-Out

    Part Number 1652001584 Footprint KUONYI_PJ-2508PA-5-L Description Phone Jack 5P 3.5φ 90D(F) AZALIA PINK DIP WO/Pb Pin Name MIC_L MIC_R Table A.16: CN17: LAN1/LAN2 Part Number 1652003274 Footprint RJ45_28P_RTB-19GB9J1A Description Phone Jack RJ45 28P DIP RTB-19GB9J1A Pin Name UTC-318 User Manual...

  • Page 50: Table A.17:Cn24: Hdmi

    Table A.17: CN24: HDMI Part Number 1654011175-01 Footprint HDMI_19P_QJ51191-LFB4-7F Description HDMI Conn. 19P 0.5 mm 90D(F) SMD QJ51191-LFB4-7F Pin Name HDMI_TX0+ HDMI_TX0- HDMI_TX1+ HDMI_TX1- HDMI_TX2+ HDMI_TX2- HDMI_TX3+ HDMI_TX3- HDMI_CLK HDMI_DAT +5 V HDMI_DET UTC-318 User Manual...

  • Page 51: Table A.18:Cn19: External Usb

    Table A.18: CN19: External USB Part Number 1654010969-01 Footprint USB_9x2P_UEA1112C-8HS6-4F Description USB Conn. 18P 2.0 mm 90D(F) DIP UEA1112C Pin Name +5VSB SSRX- SSRX+ SSTX- SSTX+ +5VSB SSRX- SSRX+ SSTX- SSTX+ UTC-318 User Manual...

  • Page 52: Table A.19:Cn20: External Usb

    Table A.19: CN20: External USB Part Number 1654010969-01 Footprint USB_9x2P_UEA1112C-8HS6-4F Description USB Conn. 18P 2.0 mm 90D(F) DIP UEA1112C Pin Name +5VSB SSRX- SSRX+ SSTX- SSTX+ +5VSB SSRX- SSRX+ SSTX- SSTX+ UTC-318 User Manual...

  • Page 53: Table A.20:Cn18: External Usb

    Description USB Conn. 8P 2.0 mm 90D DIP UB1112C-8FDE-4F Pin Name +5VSB +5VSB Table A.21: CN23: RJ11 Part Number 1652005977-02 Footprint RJ11_6P_RJ1201-66N024R0 Description Phone Jack RJ11 6P6C 90D(F) DIP 6u RJ1201-66N024 Pin Name GPIOA Status Power GPIOB UTC-318 User Manual...

  • Page 54: Table A.22:Sw2 Button: Power Button

    Footprint SW_6P_TC003-N11AABRGXX-RK_D Description Push SW DIP 6P W/LED WO/Pb TC003-N11AABRGXX-RK Pin Name ATX_PWRBTN# ATX_PWRBTN# +5 V Table A.23: CN31: DC-In Part Number 1652005624 Footprint PJ_2P_2DC-G213B200 Description DC Power Jack 2.5 mm 90D(M) DIP 2DC-G213B200 Pin Name DC_IN UTC-318 User Manual...
  • Page 55 UTC-318 User Manual...
  • Page 56 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2015...
