Table A.19: CN20: External USB
Part Number
Footprint
Description
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
UTC-318 User Manual
1654010969-01
USB_9x2P_UEA1112C-8HS6-4F
USB Conn. 18P 2.0 mm 90D(F) DIP UEA1112C
Pin Name
+5VSB
D-
D+
GND
SSRX-
SSRX+
GND
SSTX-
SSTX+
+5VSB
D-
D+
GND
SSRX-
SSRX+
GND
SSTX-
SSTX+
