Compact Par 7 Q4

Slave Mode

With this menu you can set the device as a Master or Slave.
01) Press the Mode button and then the Up/Down buttons, until the display shows
If the device has not been set to slave, it is automatically classified as a master device. All slave
devices will follow the master movement. If the device has been set to slave, it will react the same as
its master device.

Static Color control

With this menu you can manually set a desired color.
01) Press the Mode button and then the Up/Down buttons, until the display shows
02) Press the Setup button to open this menu.
03) You can use the Setup button to scroll through the 4 color options.
04) Use the Up/Down buttons to change the values.
You can combine Red, Green, Blue and White to create an infinite range of colors (0-255).

Sound control mode

With this menu you can set the sensitivity of the sound mode.
01) Press the Mode button and then the Up/Down buttons, until the display shows
02) Press the Setup button to open this menu.
03) Use the Up/Down buttons to change the values.
04) Set the sensitivity of the sound control mode between

Settings

With this menu you can set various options.
01) Press the Mode button and then the Up/Down buttons, until the display shows
02) Press the Setup button to open this menu.
03) Use the Up/Down buttons to choose between the 3 options,
04) Press the Setup button to open one of the 3 options.
05) With the Up/Down buttons you can set the desired option.
06) With option
out if there is no DMX signal. If you choose "HOLD", the fixture will remember the last settings and will
not go out if there is no DMX signal.
07) The option is a tool which helps to keep multiple fixtures synchronized when using them in
master slave mode.
08) With option
will reset and start up in the Auto Run mode.

Info

With this menu you can see various info of the fixture.
01) Press the Mode button and then the Up/Down buttons, until the display shows
02) Press the Setup button to open this menu.
03) Use the Up/Down buttons to choose between the 2 options,
04) Press the Setup button to see one of the 2 options.
05) With the option
temperature, the display will show "t-on". If the fixture is too hot, the display will show "t-nn". You'll
have to switch off the fixture.
06) The option
Ordercode: 42582
Gradual adjustment red (0-255)
Gradual adjustment green (0-255)
Gradual adjustment blue (0-255)
Gradual adjustment white (0-255)
you can set the fixture to "HOLD" or "OFF". If you choose "OFF", the fixture will go
you can reset the device to the factory settings. If you choose "Yes" the fixture
you can see if the fixture is too hot or not. If the fixture has a normal
is for showing the software version of the fixture.
,
and
15
.
.
.
.
.
and .
.
.
