Compact Par 7 Q4

DMX Channels

4 channels

Channel 1 – Red Dimmer intensity
0-255 Red from 0-100%
Channel 2 – Green Dimmer intensity
0-255 Green from 0-100%
Channel 3 – Blue Dimmer intensity
0-255 Blue from 0-100%
Channel 4 – White Dimmer intensity
0-255 White from 0-100%
6 channels
Channel 1 – Master Dimmer intensity
0-255 From dark to brightest 0-100%
Channel 2 – Linear strobe (CH1, CH3, CH4, CH5 or CH6 must be set between 001-255
0-10 Closed
11-255 Strobe flash frequency, from slow to fast (0-20 Hz)
Channel 3 – Red Dimmer intensity (CH1 must be set between 001-255
0-255 Red from 0-100%
Channel 4 – Green Dimmer intensity ( CH1 must be set between 001-255
0-255 Green from 0-100%
Channel 5 – Blue Dimmer intensity (CH1 must be set between 001-255
0-255 Blue from 0-100%
Channel 6 – White Dimmer intensity (CH1 must be set between 001-255
0-255 White from 0-100%
11 channels
Channel 1 – Master Dimmer intensity
0-255 From dark to brightest 0-100%
Channel 2 – Linear strobe (CH1, CH4, CH5, CH8, CH9, CH10 or CH11 must be set between 001-255
0-10 Closed
11-255 Strobe flash frequency, from slow to fast (0-20 Hz)
Channel 3 – Random strobe (CH1, CH4, CH5, CH8, CH9, CH10 or CH11 must be set between 001-255
0-10 Closed
11-255 Random strobe flash
Ordercode: 42582
