Compact Par 7 MKII

Main Menu Options

DMX address
Master-Slave
Auto run
Built-in Programs
Manual Color
Sound

1.DMX Addressing

With this menu you can set the DMX address.
01) Press the MODE button and then the Up / Down buttons, until the display shows
02) Press the SETUP button to open this menu. You can choose 512 different DMX addresses.
03) Use the Up / Down buttons to select the required address from
Once you have set the desired DMX address, you can also choose the desired DMX Mode.
04) Press the SETUP button to set 3 different DMX Modes. Use the Up / Down buttons to choose between
3, 6 or 7 Channels.

2.Slave Mode

With this menu you can set the Master or Slave.
01) Press the MODE button and then the Up / Down buttons, until the display shows
If the device has not been set to slave, it is automatically classified as a master device. All slave
devices will follow the master movement.
If the device has been set to slave, it will react the same as its master device.

3.Auto Run Mode

With this menu you can set Auto Run mode of the Compact Par 7 MKII.
01) Press the MODE button and then the Up / Down buttons, until the display shows
Ordercode: 42595
