Loading Predefined Configurations - Printronix P9212 Setup Manual

Loading Predefined Configurations

Load Parameters
Load Saved
Parameters 1
Load IGP
Parameters
Use this procedure to load the factory, IGP, IBM 3287, or IBM 5225
configurations. These configurations are stored on ROM and cannot be
altered. See Appendix D.
Although you can use this procedure to load one of the customized
configurations, it is recommended you use the CONFIG key (page 3–22). It
selects and loads a configuration––this configuration is the one that will be
overwritten whenever you save a new setting.
When you load a configuration, it loads all of the stored parameters into the
current configuration. For example, Configuration 1 is selected and loaded
and "1" appears on the LCD. If you load configuration 4 using the menu and
not the CONFIG key, all of its values are temporarily active, but
configuration 4 is not selected. If you change a value and then save it,
Configuration 1 is changed because it is the one that is selected.
To change the current configuration from 1 to 4 and modify 4, you must use
the CONFIG key.
NOTE: The last saved configuration values will load when the printer is
Configuring the Printer
Load IBM 3287
Parameters
turned off and then on again.
Load Factory
Load IBM 5225
Parameters Parameters
3–19
