ISPORT 10-15cc
6) Using a modeling knife, carefully re-
move the covering that overlaps the sta-
bilizer mounting platform sides in the
fuselage. Remove the covering from both
the top and the bottom of the platform
sides.
7) When you are sure that everything
is aligned correctly, mix up a generous
amount of 30 Minute Epoxy. Apply a thin
layer to the top and bottom of the stabi-
lizer mounting area and to the stabilizer
mounting platform sidesin the fuselage.
Slide the stabilizer in place and rea-
lign. Double check all of your measure-
ments once more before the epoxy cures.
Hold the stabilizer in place with T-pins
or masking tape and remove any excess
epoxy using a paper towel and rubbing
alcohol.
8) After the epoxy has fully cured, remove
the masking tape or T-pins used to hold
the stabilizer in place. Carefully inspect
the glue joints. Use more epoxy to fill
in any gaps that may exist that were not
filled previously and clean up the excess
using a paper towel and rubbing alcohol.
22
Instruction Manual.

INSTALLING VERTICAL STABILIZER

1) While holding the vertical stabilizer
firmly in place, use a pen and draw a
line on each side of the vertical stabilizer
where it meets the top of the fuselage.
2) Using a modeling knife, remove the
covering from over the precut hinge slot
cut into the lower rear portion of the fu-
selage.
Remove the covering.
.
