Throttle.
INSTALLING THE SWITCH RECEIVER.
Install the switch into the precut hole in
the side, in the fuselage.
WWW.SEAGULLMODELS.COM
Rudder.
Elevator.
3/32" Hole.
Trim and cut.
Switch.

MOUNTING THE ENGINE.

1) Position the engine with the drive
washer (110mm) forward of the firewall
as shown.
110 mm
2) Use a pin drill and 2mm drill bit to
drill a small indentation in the mount for
the engine mounting screw.
Trim and cut.
Switch.
