ISPORT 10-15cc

INSTALLING THE SPINNER.

Install the spinner backplate, propeller
and spinner cone.
The propeller should not touch any
part of the spinner cone. If it does, use a
sharp modeling knife and carefully trim
away the spinner cone where the propel-
ler comes in contact with it.
18
Speed control.
Battery.
Instruction Manual.
INSTALLING THE AILERON -FLAP
SERVOS.
Servos
.
Because the size of servos differ, you
may need to adjust the size of the precut
opening in the mount. The notch in the
sides of the mount allow the servo lead to
pass through.
1) Using a small weight (Weighted fuel
pick-up works well) and string, feed the
string through the wing as indicated.
2) Place the servo between the mount-
ing blocks and space it from the hatch.
Use a pencil to mark the mounting hole
locations on the blocks.
3) Use drill bit in a pin vise to drill the
mouting holes in the blocks.
Small weight
.
Thread
.
