ISPORT 10-15cc
Instruction Manual.
Use a felt tip pen to mark the wire where
it crosses the hole. Use a pair of pliers to
put a shrp 90-degree bend in the wire at
the mark.
Mark.
2x10mm
Bend at the mark
M2 lock nut.
2x10mm
8mm
Metal clevis.
Snap keeper.
Servo arm.
Snap keeper.
AILERON PUSHROD HORN
INSTALLATION.
Please see below pictures.
Nylon Snap keeper.
Hex Nut.
Fuel tubing.
20
