Mounting The Engine - Seagull Models YAK 54 Assembly Manual

2.
hread locker glue
3.

MOUNTING THE ENGINE

Position the engine with the drive
washer (145mm) forward of the iewall as
shown.
1.
145mm
Use a pin drill and 4mm drill bit to drill
a small indentation in the mount for the
engine mounting screw.
2.
Use a drill to drill the four holes in the
engine mount rails.
3.
he ire wall has the location for the
throttle pushrod tube (pre-drill).
Slide the pushrod tube in the irewall
and guide it through the fuel tank mount.
Use medium C/A to glue the tube to the
irewall and the fuel tank mount.
Connect the Z-bend in the 450mm
throttle pushrod to the outer hole of the
carburetor arm.
Slide the throttle pushrod wire into the
tube. Position the engine between the
mounts. Use four M4x30mm machine
screws to secure the engine to the mount
as shown.
4mm
4mm
25
