Installing The Aileron Linkage - Seagull Models ULTIMATE Instruction Manual

ULTIMATE.
Thread.
Attach the string to the servo lead and
carefully thread it though the wing. Once you
have thread the lead throught the wing, remove
the string so it can use for the other servo
lead. Tape the servo lead to the wing to prevent
it from falling back into the wing.
Electric wire.
Secure the servos with the screws pro-
vided with your radio system.
6
Lower wing
bottom.
Small weight.
Thread.
Lower wing bottom.
Instruction Manual.
Lower wing panel
bottom.
Plastic tape.
Aileron electric.
Repeat the procedure for orther wing
haft.

INSTALLING THE AILERON LINKAGE

(LOWER WING).
1
Electric wire.
Pull.
Thread.
1
