Installing The Aileron Servo; Installing The Aileron Linkage - Seagull Models Arising Star Assembly Manual

Arising Star.
4) Remove the mount, and using a mod-
eling knife, carefully remove the covering from
inside the outline you drew.
5) Using 6 Minute Epoxy, glue the servo
mount into place. Remove any excess epoxy
using a paper towel and rubbing alcohol. Use
pieces of masking tape to hold the tray in place
until the epoxy fully cures.
Pen.
Remove covering.
mount, with the output shaft towards the lead-
ing edge of the wing, using the wood screws
provided with your radio system. Drill 1/16"
pilot holes through the mount before installing
the screws. This will prevent the wood from
splitting.
C/A glue.
horn onto each aileron torque rod. Thread the
horns on until they are flush with the ends of
the torque rods.
onto each of the two threaded wires.
the servo arm onto the servo. The arm should
be installed so it is parallel with the trailing edge
of the wing.
Instruction Manual.
Servo mount.

INSTALLING THE AILERON SERVO.

Install the aileron servo into the servo

INSTALLING THE AILERON LINKAGE.

1) Thread one nylon adjustable control
2) Thread one nylon clevis at least 5/16"
3) With the aileron servo centered, install
1,5mm screw hold.
5
