Rele�ant menus can also be accessed directly from other menu screens �ia the coloured softkey
options shown at the base of each menu. The options a�ailable will depend on the menu being
�iewed. Select a softkey option by pressing either the corresponding button on the �R Remote
Control (if �iewing the menus locally), or by selecting the rele�ant option �ia the �C mouse (if
�iewing the webpages).
Note: Any changes made via the webpages are automatically saved when the page is closed. To
'manually' save changes, select the Save option.

Using the IR Remote Control

�ress the ��NU button to access configuration menus �ia a connected local monitor. The menu will
ha�e a red indicator highlighting the first option. Select a main menu heading to open a drop down
list of further sub-options. �ress the Down Directional button to highlight the ne�t menu option, press
O� to open the highlighted menu.
�ress the Right Directional button to highlight the first editable parameter on the screen.
Use the �eft�Right�Up�Down Directional buttons to mo�e between fields.
Select O� to start editing a field (the option will be outlined in green).
Use the Up�Down Directional buttons to change the settings within an editable field.
Numeric fields can be edited with the Directional buttons. Use the Up�Down Directional buttons to
increase�decrease by an increment of 1, use the �eft�Right Directional buttons to increase�decrease
by an increment of 10.
Use the O� button to accept a new setting. Use the coloured softkeys to select the accompanying
colour option on screen i.e. red button to select the red option. To undo changes made to any menu,
select the Refresh (�urple) option.
Entering Alpha-Numeric Data via a Local Monitor
Numeric or te�t data is entered using the on-screen �irtual �eyboard (�rrow �ey �ditor).
To display the �irtual �eyboard, na�igate to the rele�ant te�t input bo� using the Directional buttons
and double press the O� button twice on the �R Remote Control. The �irtual �eyboard is displayed.
Use the Directional buttons to mo�e between characters, use the O� button to select a character.
Select 'Submit' to enter details, press 'Cancel' to e�it without entering any te�t.
�lpha-numeric data can also be entered in either upper or lower case format by 'multi-tapping'
a rele�ant button. For e�ample, with the cursor located in the te�t entry window of the �irtual
�eyboard, repeatedly tap button '1' to cycle through the following characters: 1,�,a,�,b,C,c,1 etc.
To select one of these characters, simply stop tapping the button when the chosen character is
displayed. The cursor will then progress, ready for the ne�t character entry.
Note: A USB Keyboard (not supplied) can be connected via one of the USB ports on the unit. The
USB Keyboard can then be used to enter alpha-numeric data via the local menus.
