DV-IP HD
Installation and
Operation Guide

Advertisement

Table of Contents
loading

Related Manuals for Dedicated Micros DV-IP HD

Summary of Contents for Dedicated Micros DV-IP HD

  • Page 1 DV-IP HD Installation and Operation Guide...

  • Page 2: Table Of Contents

    Appendix B ....................106 Appendix C ....................108 Whilst every attempt is made to ensure these manuals are accurate and current, Dedicated Micros reserve the right to alter or modify the specification of the machine described herein without prejudice. Dedicated Micros ©2008...
  • Page 3 CCTV with High Definition recording capabilities at an affordable price. The DV-IP HD is the ideal companion to the DM CamVu 2000, allowing multiple megapixel video streams to be viewed and recorded simultaneously in high definition.
  • Page 4 Features The DV-IP HD from Dedicated Micros is equipped with an array of valuable features designed to enhance the operator experience. • 8, camera inputs • Up to 200pps at QCIF to 4CIF resolution • Telemetry support (Coax & Serial) •...

  • Page 5: Design Of The Manual

    With no need for a telemetry keyboard, users are able to use Pan & Tilt control of a Dedicated Micros Oracle Dome simply by clicking an area of the monitor. The camera will instantly respond, positioning the selected area in the middle of the screen, ideal for tracking movement through a scene.

  • Page 6: Important Safeguards

    This reminder is provided to call the CCTV system installer’s attention to Art. 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical. Dedicated Micros ©2008...
  • Page 7 CE Mark If this product is marked with the CE symbol it indicates compliance with all applicable directives. Directive 89/336/EEC. A ‘Declaration of Conformity’ is held at Dedicated Micros Ltd., 1200 Daresbury Park, Daresbury, Cheshire, WA4 4HS, UK. Laser The unit supports an integrated CD/DVD writer, the following are additional warnings associated with installing and operating the CD/DVD writer, please pay particular attention to this information.

  • Page 8: Installing The Unit

    Choosing a location for installation • The DV-IP HD is designed to be desk, shelf or rack mounted. Rack mounting brackets are available as an optional accessory. • Ensure the DV-IP HD unit is properly ventilated to protect from overheating.
  • Page 9 • Active video signals i.e. at least one working camera feed • PC with CD ROM drive and connection to the same network as the DV-IP HD unit (Recommended). Quick Overview of DV-IP HD Record Settings CONFIRM BELOW INFO IS CORRECT DV-IP HD units provide out of the box: High performance recording on ALL cameras with minimal configuration.

  • Page 10: Installation

    S Video Connection HDMI 2x High-Definition Multimedia Interface connectiors Audio Audio IN (Dual) RCA (phono) socket, 8KHz/16KHz/22KHz sampling 75Ω input impedance, 1V pk-pk Audio OUT (Dual) RCA (phono) socket, line level <100Ω output impedance,1V pk- pk amplification required Dedicated Micros ©2008...

  • Page 11: Alarms And Relays

    SERIAL 4 (PTZ) RS-485 (2 wire & 4 wire) 2x USB2.0 connectors RJ45 Ethernet network connector, 10/100 Mb/s Ethernet Network RJ12 connector for use with Dedicated Micros telemetry keyboards (KBC1, KBC2)) RJ12 expansion port for future use SATA 2x E-Sata port available for storage expansion...

  • Page 12: Installing The Dv-Ip Hd Unit

    This procedure shows the sixteen camera input version. Step 1 Connecting Video The DV-IP HD supports up to 8 connected Video Inputs via the 75Ω BNC connectors. Connect cameras to the video inputs, starting from input 1. 8 and 16 channel variants have two rows of connectors providing video input and loop-through support.
  • Page 13 Step  Monitor The DV-IP HD supports a main monitor via BNC ‘A’ and a spot monitor via BNC ‘B’. Step  Connecting Audio The DV-IP HD supports two channels of bi-directional audio, accessible through NetVu ObserVer. Connect the audio equipment to the phono sockets AUDIO IN and AUDIO OUT. The audio channel defaults to record camera 1.
  • Page 14 Step  Connecting to the Network The DV-IP HD supports a 10/100Mbps auto-detecting network port. Use a CAT5 cable to connect the unit to the network. By default the unit is configured for DHCP (where the unit is automatically allocated an IP address from the network DHCP server).
  • Page 15 The alarms support tamper proof detection using 1k in line and 5K end of line resistance. The DV-IP HD detects short circuit, open circuit and contact closure. This functionality is part of the advanced alarms supported on NetVu Connected products and includes features required for Central Monitoring.
  • Page 16 Closed, the resistive value is 1K ohms, as the circuit does not see the 5.6K ohm resistor. Open Circuit Tamper, the resistive value is infinity as the circuit has been cut and therefore is ‘open’. Short Circuit Tamper, the resistive value is 0 ohms. Dedicated Micros ©2008...
  • Page 17 RS Step  Connecting a Keyboard The DV-IP HD supports Dedicated Micro keyboards DM/KBC1 and DM/KBC2. Connect any of these keyboards via the KBD connector situated on the rear of the unit. Note: Refer to ‘Unit Operation’ for further guidance regarding supported keyboards.
  • Page 18 If the dome is being connected using an RS485 connection, the dome address should be set to match the camera input number on the DV-IP HD i.e. if the dome is connected to video input 3, the camera address should be ‘03’.

  • Page 19: Connecting Storage Devices

    Step 10 Connecting Power The DV-IP HD has an internal power supply unit. Connect the mains lead to the unit and then to the wall socket, or to a fused spur connection. Check local regulations before installation. Some countries require an Alarm/Security device be connected to a fused spur and not a wall outlet socket.

  • Page 20: Configuring The Unit

    The unit can be configured using the on-board web pages. To access these: Launch Internet Explorer (or other web browser package). Type the URL for the unit (IP address or domain and unit name). The System Settings menu page will be displayed. Dedicated Micros ©2008...

  • Page 21: Remote Control

    Use this button to cycle through available cameras. This button should be pressed to carry out auxiliary actions on a PTZ camera. Press the Menu button to enter the Configuration menus. Press the Exit button to exit the Configuration menus. Dedicated Micros ©2008...
  • Page 22 The Number pad should be used to select specific cameras and preset positions when available. Use the Playback buttons to interrogate recorded images. Use the LIVE button to switch from Playback or menus to a LIVE display. Dedicated Micros ©2008...

  • Page 23: Navigating The Menus

    When accessing the configuration menus, the menu tree will be displayed. The configuration pages are navigated using the menu tree (displayed on the left of each page). Selecting one of the menu options will display the relevant page. Any associated submenus will also then be available. Dedicated Micros ©2008...

  • Page 24: Virtual Keyboard

    Note: A selected item in the drop down list will appear highlighted. Navigating away from a page (clicking on a different option on the menu tree) will automatically save any changed settings. To undo changes made to any menu, select the Refresh (Purple) option. Dedicated Micros ©2008...

  • Page 25: System Settings

    Email reporting, webcam support and control of the display resolution. The Maintain page allows the current configuration to be saved, and for previously saved settings to be loaded. It also enables easy upgrade of the system software. Dedicated Micros ©2008...
  • Page 26 DHCP server. Software Revision This identifies the version of software the unit is running. Codec Revision This identifies the codec version the unit is running. Webpage Revision This identifies the version of web pages the unit is running. Dedicated Micros ©2008...

  • Page 27: Unit Status

    Those camera channels with cameras connected will be highlighted light green. Those not in use will appear dark green. Failed Cameras Those camera channels where the connection is deemed to have failed will be highlighted light green. Those working correctly will appear dark green. Dedicated Micros ©2008...

  • Page 28: Alarm Status

    This menu details information regarding the status of the units alarm contacts, alarm zones and relay outputs. Alarm Contacts/Zones/Relay Outputs Alarm Contacts, Alarm Zones and Relay Outputs which are in an ‘active’ state are shown light green. ‘In-active’ ones are shown as dark green (not illuimnated). Dedicated Micros ©2008...

  • Page 29: Time And Date

    Use this button to synchronise the time of the unit to that of the Sync Time (Blue) PC being used to view the web pages. Note: The PC Time and Sync Time options will only be available if viewing the menu via the web pages. Dedicated Micros ©2008...

  • Page 30: Serial Ports

    Serial Ports This menu allows configuration of the units Serial ports. Refer to ‘Installing the DV-IP HD’ for installation information. Serial Port These are the four serial ports available. Port Config The serial ports can be configured to specific uses.

  • Page 31: Audio

    Note: Recording in uncompressed format will significantly increase the disk space used. Playback Sample Rate Audio can be played back at 8Hz, 11Hz, 16Hz or 22Hz. Playback Volume Select a volume setting between 1 to 64 for audio playback. Dedicated Micros ©2008...

  • Page 32: Features

    Select this option to enable automatic FTP downloads to upgrade the unit and/or the web pages, refer to ‘Network Settings-FTP Download’ for more information. Note: When de-selected here, the ‘Automatic FTP Download’ menu will no longer be displayed in the menu tree. Dedicated Micros ©2008...
  • Page 33 Unicode is a specification which allows text in any language to be displayed in a consistent and correct manner. Telemetry Port If ‘User Defined’ as been selected in the Telem UDP Port Selection option, enter the telemetry port data here. Dedicated Micros ©2008...

  • Page 34: Maintain

    Select the relevant media device to save to or restore from i.e. USB or CD/DVD. Server Reset (Red) Select to cycle the power to the unit. Software Software Upgrade (Yellow) Select to perform a software upgrade. The unit will search any connected media device for relevant data. Dedicated Micros ©2008...

  • Page 35: Console Settings

    DVRs/Servers over the network. Selected camera feeds can be viewed and controlled via the Viewer menus. Refer to the individual menus for more information. The System Config page dictates which cameras and systems the DV-IP HD will connect to, and controls how the video feeds will be displayed.
  • Page 36 Select from 20 available systems using the drop down menu. System Name If required, enter a recognisable name for the system e.g. ‘North Car Park cameras’ (this name is held on the DV-IP HD and represents the system). Server URL Enter the IP addresses of the servers providing the video signals.
  • Page 37 Identifies the name assigned to the server the camera is located on. Configure Server Select the Config Pages option to access the configuration pages for the selected Server. Note: Passwords maybe required to successfully access server configuration pages. Dedicated Micros ©2008...

  • Page 38: Viewer Defaults

    PinP (Picture in Picture) Video Output mode This option will eliminate the cut-off present on some monitors, enabling the whole of the captured image to be displayed. Select from: PAl Default, PAl Reduced, NTSC Default and NTSC Reduced. Dedicated Micros ©2008...
  • Page 39 ‘2 minutes’ would result in a connection timing out following two minutes of inactivity. This would help reduce unnecessary costs in applications where ISDN on 3G/GPRS links are being used. To de-activate this feature select ‘None’. Dedicated Micros ©2008...

  • Page 40: Display

    The sequence dwell time can be set from 1 to 99 seconds. The dwell time is the period a camera is displayed before switching to the next camera in the sequence. Multi-Screen Interlace Activate to improve multiscreen display by removing ‘screen flicker’. Dedicated Micros ©2008...

  • Page 41: Map Config

    Enter the radius (in pixels) of the hotspot. Increment by This controls the step size (in pixels) used by the Increment and Decrement buttons. Decrement (Red) Click to reduce the size of the selected hotspot by the ‘Increment by’ setting. Dedicated Micros ©2008...
  • Page 42 20 degrees to the right of its ‘origin’ position, 180 would send it opposite to the origin position. Refer to the ‘Viewer Menus-PTZ Profile menu‘ for information on establishing an Origin position for a PTZ camera. Dedicated Micros ©2008...

  • Page 43: Map Data

    To import data, copy relevant text from an external location and paste into the Map Data text window. When the menu is exited, this data will be used as the Map Config settings. Note: If importing data, remember to first save any current map data as required. Dedicated Micros ©2008...

  • Page 44: User Accounts

    Modify or Delete. Note: If viewing the User Accounts page via a local monitor and navigating with the I.R Remote Control. Press the left directional button from the menu tree to access the Account List. Dedicated Micros ©2008...

  • Page 45: Camera Settings

    The I.P Camera page allows configuration of incoming digital video streams originating from an IP address. The Camera Setup page allows the colour and contrast settings for each individual camera to be adjusted, with a dynamic preview available. The Camera Telemetry page enables telemetry capable cameras to be configured. Dedicated Micros ©2008...
  • Page 46 Note: The arrow button displayed next to each textbox allows settings to be replicated for those cameras listed below. This will only affect the adjacent option i.e. Mode arrow will replicate the Mode setting to cameras below the clicked arrow. Dedicated Micros ©2008...
  • Page 47 Select the type of IP camera i.e. if the stream is originating from Mode a NetVu Connected server select ‘NetVu Server’, if from a NetVu camera such as a Dedicated Micros CamVu 2000, select ‘NetVu Camera’. Edit the URL address of the I.P camera source.

  • Page 48: Camera Setup

    Select a camera channel for review and adjustment. Copy to all Select this option to apply current settings to all connected cameras. Camera Colour Enter a colour value from Min to Max. Camera Contrast Enter a contrast value from Min to Max. Dedicated Micros ©2008...

  • Page 49: Camera Telemetry

    Note: The arrow button displayed next to each textbox allows settings to be replicated for those cameras listed below. This will only affect the adjacent option i.e. Telemetry arrow will replicate the Telemetry setting for cameras below the clicked arrow. Dedicated Micros ©2008...

  • Page 50: Record Settings

    The Holiday and Weekend page enables Set mode to be activated for individual dates i.e. public holidays or weekends. The Protect Video page allows previously recorded data to be protected and retained. If needed, all recording can be halted and saved video deleted. Dedicated Micros ©2008...
  • Page 51 Record Duration/Enhance Quality The recording duration can be limited to a set number of days; allowing the recording quality to be enhanced for a shorter storage period. Note: The default record duration will either be 30 or 60 days, dependant on model. Dedicated Micros ©2008...

  • Page 52: Profile Record

    4CIF global pps at a maximum 100pps. Lowering the resoluion settings will significantly lessen the storage capacity requirements. Channel Enables selection of a specific camera for editing. Copy To All Select to copy the current profile record settings to all camera channels. Dedicated Micros ©2008...
  • Page 53 Select from Maximum, High, Medium, or Low. Select User Defined to use setting established in the Advance Profile Record menu. Note: The higher the Quality setting, the greater the storage space used. Dedicated Micros ©2008...

  • Page 54: Advanced Record

    Alarm or Event. Note that Set and Override schedules will be used only when Timed Schedules are applied. Refer to ‘Schedule’ for further information. Comp Select image compression format (MPEG or JPEG). Select image size (QCIF, CIF, 2CIF or 4CIF). Dedicated Micros ©2008...
  • Page 55 If JPEG is selected, the figure entered here will be the size of the JPEG transmitted (in Kbytes). JPEG file sizes can be configured within the range of 5-45Kbytes This shows the number of pictures recorded per second. Dedicated Micros ©2008...
  • Page 56 This column shows the recording profile used by the camera when operating under Normal (non Event) conditions. Comp Select image compression format (MPEG or JPEG). For both MPEG and JPEG recording, select either Hi, Medium or Low quality resolution settings. Dedicated Micros ©2008...
  • Page 57 A Keyswitch can be used to switch the recording profile (Unset/ Set), If required, select ‘Enable’ then choose a contact to be used as the Keyswitch. Keyswitch-N/O Forces Select whether the unit will be in ‘Day’ (Unset) or ‘Night’ (Set) mode when Keyswitch relay opens. Dedicated Micros ©2008...
  • Page 58 Tick to activate the Weekend function. Set mode will now be active for the dates outlined below. Start Select a Start day and time for Weekend mode. Select an End day and time for Weekend mode. Note: Weekend mode will activate each week until deselected. Dedicated Micros ©2008...

  • Page 59: Protect Video

    Select this option to unprotect recorded video for the set time period. Prot PAR This option will also protect recorded video for the set time period. Unprotect PAR This option will also unprotect recorded video for the set time period. Dedicated Micros ©2008...

  • Page 60: Alarm Settings

    This can trigger a number of operations such as FTP alarm notification or an increase in the recording rate. The Activity Response page enables configuration of responses following an Activity Detection trigger. The Global Relays page allows the five onboard relay connections and global relay settings to be configured. Dedicated Micros ©2008...

  • Page 61: Alarm Input

    Alarm Input This menu allows configuration of the alarm settings, refer to ‘Installing the DV-IP HD Unit’ for hardware installation guidance. Number This identifies which input is being configured. The unit supports 20 on-board alarms. Enabled Each input must be enabled to function. If the input is not enabled and an alarm is received, the unit will not acknowledge the alarm.
  • Page 62 Note: The arrow button displayed next to each textbox allows settings to be replicated for those cameras listed below. This will only affect the adjacent option i.e. Enabled arrow will replicate the Enabled setting to cameras below the clicked arrow. Dedicated Micros ©2008...
  • Page 63 This determines which input(s) will trigger the zone alarm: Input This sets an input or system function as the primary alarm trigger. Select from Alarms 1-32, Activity 1-16, Preset 1-16, Disk Low, Disk Full, Panic, Archiving Slow, Archiving Fault, Virtual 1-16, and Keyword 1-32. Dedicated Micros ©2008...
  • Page 64 Set operation mode. Enable in Override Each alarm can be configured to be active when the unit is in a specific operation mode. Enable this for the zone alarm to be active in Override operation mode. Dedicated Micros ©2008...

  • Page 65: Zone Actions

    Add Still Image This will record a still image of the trigger along with the standard recording. This can then be sent on to an external destination. Alarm images can automatically be protected from being overwritten. Protect alarm Images Dedicated Micros ©2008...
  • Page 66 Enter the time period (in seconds) that the camera should remain at the preset. Relay Select an onboard or external relays to automatically close on receipt of an alarm, if required. Duration Enter (in seconds) how long the relay is to remain closed. Dedicated Micros ©2008...

  • Page 67: Activity Setup

    This option will update the still image displayed in the Grid Editor. Set All (Green) This option will insert a default square of 16 x 16 cells across the displayed video image. Clear All (Yellow) This option will clear all entered cells. Dedicated Micros ©2008...
  • Page 68 Folliowing Activity activation, select ‘Simple Response’ to trigger specific chosen responses. Refer to ‘Activity Response Setup’ for more information. Select ‘Zone’ to apply the Zone Input rules as configured in the Zone Input menu. Refer to ‘Zone Input’ for more information. Dedicated Micros ©2008...

  • Page 69: Activity Response Setup

    Enable in Night (Set) This will enable Activity Detection when the unit is in Night (Set) operation mode. Enable in Weekend (Override) This will enable Activity Detection when the unit is in Weekend (Override) operation mode. Dedicated Micros ©2008...
  • Page 70 System Set (Relay 4) When selected, the unit will automatically switch to Set mode following relay activation. Dial on Alarm (Relay 5) When selected, the unit will automatically connect to the designated Remote Video Monitoring Centre following relay trigger. Dedicated Micros ©2008...

  • Page 71: Network Settings

    Webserver. The images can then be incorporated into a web page and accessed via a standard web browser. The FTP Download page allows data to be archived to a central FTP server. This could be on receipt of an alarm, Activity activation or at a scheduled time to back-up recorded video. Dedicated Micros ©2008...
  • Page 72 PPP Idle Line Timeout s This is the time (in seconds) the unit will wait before disconnecting the PPP (Point to Point Protocol) link if data has not been transmitted or received. Dedicated Micros ©2008...
  • Page 73 PPP Link Down Timer mins If for any reason the PPP connection is lost, this is the time (in minutes) before the unit will be forced to drop the PPP connection. Dedicated Micros ©2008...

  • Page 74: Live Transmissions

    The NetVu Connected remote viewing software will use the settings configured on this page as the defaults for JPEG & MPEG; High, Medium and Low settings. The DV-IP HD transmits live images using JPEG or MPEG image formats utilising soft codec architecture (VISP). The DV-IP HD features TransCoding enabling recorded JPEG images to be Transcoded to low bit rate and MPEG4 for transmission over limited bandwith links.
  • Page 75 (as more images are transmitted for the defined bit rate). MPEG Comp Type Select whether transmitted MPEG4 images are sent as RAW data or in GOV (Group of Video) format. Dedicated Micros ©2008...
  • Page 76 If the fields are left blank the unit will use the system name & DNS name to create a sender name. Display Name (Sender) This is the sender name that will be shown in the email name field. Send on Startup Select to send email notification on startup. Dedicated Micros ©2008...
  • Page 77 A log can be created for every e-mail transaction that the unit issues. Email Image Res Select resolution settings for images sent as ‘thumbnail’ attachments. Choose from TN (Thumbnail), LO (low res), MED (medium res) and HI (high res). Dedicated Micros ©2008...

  • Page 78: Remote Reporting

    It should therefore have some significance to the Operator. Report Startup This will send an alarm report when the unit starts up. Any system resets will be identified. Report Alarms This must be enabled for the unit to automatically connect on alarm. Dedicated Micros ©2008...
  • Page 79 Alarm Responder Port This specifies the network port number used for reporting to the alarm server. In normal circumstances this should be left at the default value. Dedicated Micros ©2008...
  • Page 80 Webcam Enable The webcam function can be: ‘Always Enabled’, ‘Enabled when system SET’, ‘Enabled when system UNSET’ or ‘Disabled’. Webcam Resolution Select the webcam resolution settings to best match the monitor settings of the operator receiving the images. Dedicated Micros ©2008...
  • Page 81 FTP server, enter the relevant password here. Download options Select one of the following options from the drop down menu: On Connection This will automatically start the Archive download when the unit detects the archive destination is present. Dedicated Micros ©2008...
  • Page 82 FTP download overrides Powermanager When selected, if the unit is in the process of an FTP download and the unit is sent into reset, the reset will be not begin under the FTP process has completed. Dedicated Micros ©2008...

  • Page 83: Analytics & Text

    The Analytics and Text menus allow configuration of the units text in image and keywords functionality. Refer to the individual menus for further details. The Text In Image page allows the DV-IP HD to integrate text data with recorded images i.e. a cash register with a camera positioned at that point of sale.

  • Page 84: Text In Image

    2 for Serial port 3 3 for Serial port 4. Text Filter Select the text filter option from the drop down list. The options are: Plain text (default), RAW, EPSON, Laserjet, DM POS Receipt, DM POS Journal, TVC-1066 Dedicated Micros ©2008...
  • Page 85 The colour of the displayed text can be changed. Select from the drop down list. Background Colour A black background box appears by default around the text. It is possible to change the colour of this box. Select from the drop down list. Dedicated Micros ©2008...
  • Page 86 20 characters in length. Note: Increasing the number of keywords can significantly increase the number of stored events. Note: Refer to ‘Text In Image’ and ‘Serial Ports’ for further guidance on integrating text data. Dedicated Micros ©2008...

  • Page 87: Archive

    Space required for archive download. Archive Space Available Space currently available on CD/DVD or USB device. Archive button Select this button to begin the Archive process. Status During Archiving, status messages will be displayed detailing the archive process. Dedicated Micros ©2008...

  • Page 88: Oracle Configuration

    Oracle Dome Configuration If a camera channel has a Dedicated Micros Oracle dome camera connected, the Oracle Configuration menus can be used to view settings and establish Presets, Patrols and Privacy Masks. Refer to individual menus for further details. The Status page details fundamental information regarding the status of the Oracle Dome i.e. the model type and the version of software/firmware installed.
  • Page 89 Details the minimum temperature the camera unit has reached. Fan 1 Status Details the operational status of installed Fan 1. Fan 2 Status Details the operational status of installed Fan 2. Relay State Details the operational status of the camera units relay. Dedicated Micros ©2008...
  • Page 90 This identifies the version of software the camera unit is running. Firmware Version This identifies the version of firmware the camera unit is running. Bootloader Version This identifies the bootloader version of the camera unit is running. Dedicated Micros ©2008...
  • Page 91 Select this button to store the current preset position to the Oracle Dome camera’s memory. Goto Preset (Green) Select this button to immediately send the camera to the currently stored preset position. Delete Preset (Yellow) Select this button to delete the currently displayed preset configuration. Dedicated Micros ©2008...
  • Page 92 Camera Selected camera channel. Camera Title This is the title assigned to the selected camera channel. Sector Select from sector 1-32. Sector Name Enter a name for the selected sector (up to a maximum of 25 characters).. Dedicated Micros ©2008...
  • Page 93 Select the Dwell time (in seconds) the Patrol will remain at this Preset position. Save (Grey) Select to store the preset sequence to the unit and the Oracle Dome camera memory. Play (Red) Select to activate (play) the current patrol sequence. Dedicated Micros ©2008...

  • Page 94: Privacy Masks

    Finish New (Green) Select this option to finish creation of privacy mask. Show (Yellow) Select this option to show camera view with existing privacy mask displayed. Delete (Blue) Select this option to delete the currently displayed privacy mask. Dedicated Micros ©2008...

  • Page 95: Osd Settings

    ‘stacked’ in one segment of the screen. Engineer Display Toggle to switch the Engineer Display text On/Off. This function is intended for future development. Save (Grey) Select to store OSD Settings to the unit and the Oracle Dome camera memory. Dedicated Micros ©2008...
  • Page 96 If the connected Oracle Dome camera is part of the non-wide dynamic range, select to activate the unique wide dynamic function. Digital Zoom Select to activate the Digital Zoom function e.g. the camera will zoom within the actual image. Dedicated Micros ©2008...
  • Page 97 ‘Alarm Settings-Alarm Input’ for more information. UTP Boost If the Oracle Dome camera is connected to the unit via twisted pair cabling. The UTP Boost function can be activated to improve signal strength. Dedicated Micros ©2008...

  • Page 98: Event Settings

    Select the time ( in seconds) for which the camera is inactive i.e. no operator input, before returnng to its home positon. Save (Grey) Select to store Event Settings to the unit and the Oracle Dome camera memory. Dedicated Micros ©2008...

  • Page 99: Unit Operation

    Unit Operation The DV-IP HD unit can be operated via the Viewer menus and the enclosed IR Remote Control, the optional keyboard or with a USB mouse. They can also be viewed and accessed remotely via the web pages and the ‘Go To Viewer’ menu option.
  • Page 100 Note: Camera selection via this feature is only temporary. If Quad or Multiscreen view is selected, the camera selected via the Quick Start drop down menu will not be shown in the top left corner of the display. Dedicated Micros ©2008...

  • Page 101: Video Control

    Video Control Freezes current video display. Green << Rewinds current video. Yellow > Plays from current position. Blue >> Fast forwards video up to current recording position. Purple Next Opens the next page of the Viewer menu. Dedicated Micros ©2008...
  • Page 102 Opens the Preset programming menu. Refer to ‘PTZ Profile’ menu. Purple Next Opens the next page of the Viewer menu. Note: The above menu options will only be available when viewing a PTZ camera in Live mode. Dedicated Micros ©2008...
  • Page 103 When displayed, use these buttons to zoom in / out of the displayed image or by controlling the camera (depending on mode selected). Note: The above camera symbols will only be displayed if viewing via a local monitor and not via the web pages. Dedicated Micros ©2008...

  • Page 104: Ptz Program Option

    -Hotspot Origin’ for more information). Note: This option is only available for Oracle dome cameras. Purple Next Opens the next page of the Viewer menu. Note: These menu options will only be available when viewing a PTZ camera in Live mode. Dedicated Micros ©2008...

  • Page 105: Map Options

    Cameras are then selected via the hotspots. Refer to ‘Console-Map Config’ for further details on creating Camera Maps. Note: For information on creating System Selection and Camera Selection maps. Refer to the ‘Console-Map Config’ section for further information. Dedicated Micros ©2008...

  • Page 106: Selection Page

    Opens the Video Timeline menu. Green Goto Yellow Event Displays the Events page. Blue Setup Opens the units embedded menu pages to allow the configuration settings to be altered. Purple Back Returns to the previous page of the Viewer menu. Dedicated Micros ©2008...
  • Page 107 Selecting the Exit (Purple) button will always exit the Timeline Navigation menu. Note: Depending on the scale used to review the video i.e. Seconds, Minutes, Hours, or Days; the above softkey options will differ, however the same intuitive principles remain. Dedicated Micros ©2008...

  • Page 108: Video Timeline

    Increase Scale button (Blue) Increases the scale of the timeline by one step i.e. if the scale is currently one hour, selecting this button will increase it to four hours, selecting it again will increase it to one day etc. Dedicated Micros ©2008...
  • Page 109 Right Navigation Arrow will play video from one hour in advance. This can also be selected via the Yellow softkey button. Dedicated Micros ©2008...
  • Page 110 Plays the event and displays the Video Controls toolbar. Green live Returns to live video from the currently selected camera. Yellow Event- Opens the previous event. Blue Event+ Opens the next event. Purple Next Opens the Play menu for the currently displayed event. Dedicated Micros ©2008...

  • Page 111: Archive Selection Page

    Copy Event List. Yellow Archive Opens the Archive menu. Blue Seq On/Off Select ‘Seq On’ to display images from all connected cameras in a sequential order. Purple Next Opens the Play menu for the currently displayed camera. Dedicated Micros ©2008...

  • Page 112: Copy Menu

    Displays the space (as a percentage) that will remain following the download. Status Displays messages relevant to the archive process i.e. ‘Archive In Progress’. Progress Displays the progress of the current archive (as a percentage of completion). Dedicated Micros ©2008...
  • Page 113 Select CD/DVD from the Archive Media checkbox. Select the Copy option (Red) to start archive. Selected items are then saved to the CD/DVD. The CD/DVD export status is displayed as a %. On completion the status will read ‘Archive Complete’. Dedicated Micros ©2008...

  • Page 114: Using The Ir Remote Control

    The unit can also be controlled using an optional Dedicated Micros keyboard. This is connected via the KBD connector on the rear of the DV-IP HD and provides the same control functions as the I.R Remote Control. The following keyboards are supported: DM/KBC1 Keyboard Dedicated Micros ©2008...
  • Page 115 Displays the archiving options live mode - No functionality Play mode - Starts fast forwarding from play time. Rewind mode - Starts fast forwarding from play time. Pause mode - Steps forward one frame Dedicated Micros ©2008...
  • Page 116 Toggles control from Main to Spot monitor. Allows the numeric selection of a camera (numeric selection defaults to camera selection). Allows entry of camera and Preset and numbers. For future use. For future use. Triggers the wash function on a telemetry camera. Dedicated Micros ©2008...
  • Page 117 Used as menu and on-screen navigation keys Pan and tilt control for telemetry cameras In Play mode: Used to Mark Start/End positions. ln Live mode: Displays the Copy List and archive controls. Exits menus. Dedicated Micros ©2008...
  • Page 118 The IR Remote Control and supported Keyboards have a common user interface to control the DV-IP HD. In addition to the direct action keys (rewind, fast forward etc.) there are coloured Softkeys that are context sensitive and enable rapid access to required functions.

  • Page 119: Appendix A

    Receive Data Transmit Data Data Terminal Ready Ground Data Set Ready Ready to Send Clear to Send Ring Indicate RS Connectivity (Serial , ) Description Desc Receive Data Transmit Data Ground Ready to Send Clear to Send Dedicated Micros ©2008...

  • Page 120: Appendix B

    Below are detailed the procedures to follow and a listing of the codes associated with common television brands. How to Program The DV-IP HD IR Remote Control Turn the TV you wish to control ON.
  • Page 121 8573/604/623/624 /627/629/ 635 /636/637/643/644 Pioneer 2029/2037/2081 /2093/2379/2382/2387/2390/2392/2444/2449/2498/2584/2627/26 /2637 Sanyo 2003/2004/2006/2014/2016/2021/2023/2024/2025/2030/2032/2076/2088/2161/22 20/2223/2290/2292/2401/2442/2443/2492/2494/2497/2501/2504/2513/2532/2605/ 2627/2629/2633 Sharp 2001/2005/2023/2040/2101/2102/2127/2139/2160/2162/2186/2193/2207/2219/23 35/2352/2354/2360/2365/2366/2368/2372/2373/2376/2403/2407/2417/2422/2423 /2424/2430/2431/2432/2433/2434/2455/2456/2457/2458/2459/2460/2461/2462/24 63/2483/497/502/506/513/533 Sony 2004/2009/2021/2023/2024/2047/2067/2076/2078/2091/2097/2098/2110/21 11/2118/2121/2125/2135 /2142/2166/2177/2185/2204/2234/2236/2326/2344 /2345/2346/2349/2363/ 2400/2402/2404/2405/2410 /2413/2418/2420/2439//2493/ 2494/2497/2508 /2569/2571/587/602/603/607/639 Technics 2043 Toshiba 2015/2021/2051 /2069/2090/2103/2137/2158/2159/2165/2179/2188/2194 /2208/2211/2213/2217 /2218/2222/2243/2244/2250/2271/2284/2288/2294 /2303 /2304/2313/2318/2319/2320/2321/2322/2328/2347/2350/2370/2375/2394/2409/24 21/2435/2437/2440/2465/466/467/485/487/489/490/496/497/503/508 /526/574/54/ 591/595/606/607/632/642 Dedicated Micros ©2008...

  • Page 122: Appendix C

    (MPEG-4/JPEG) across scheduled, normal and alarm modes dynamically on individual cameras. RECORDING FROM Playback and record to hard disk simultaneously. Alarmed or manually selected images can be protected from being overwritten. Timed expiry option allows images to be held for a selected number of days. Dedicated Micros ©2008...
  • Page 123 Built-in RS485/Twisted pair protocols provide direct control of the numerous domes including but not limited to the following: Coax • BBV • BBV RX100 • Pelco Spectra Serial • Dedicated Micros Oracle Dome • AD Matrix/AD 168-Matrix • BBV RE485 StarCard • Bosch/Philips G3 • Dennard/Dennard C • Ernitec • JVC TK-C675BE, TK-C676 & TK-C553E •...
  • Page 124 Ethernet: 1x Ethernet RJ-45 10/100 Ethernet connection. USB: 3 x USB 2.0 Connector (1 positioned on the front panel). TEMPERATURE RANGE 5 - 40°C RELATIVE HUMIDITY 10% - 85% Non-condensing. UNIT DIMENSIONS 447mm deep, 440mm wide, 89mm high. Dedicated Micros ©2008...
  • Page 125 Dedicated Micros ©2008...
  • Page 126 Dedicated Micros ©2008...
  • Page 127 I was performing a walktest and the unit stopped sending alarms................. 65 laser ................6 Lightning Strike .............. 5 Local Admin Passwords ..........48 locating the Unit IP address ........21 Maintain ............... 49 Manual Image Protection ..........31 MultiMode Recording ............. 8 Dedicated Micros ©2008...
  • Page 128 Dedicated Micros Ltd. 1200 Daresbury Park, Daresbury, Cheshire, WA4 4HS, UK Dedicated Micros, Australia PTY. Dedicated Micros France 5/3 Packard Avenue, Castle Hill, 9-13 rue du Moulinet 75013 Paris, France NSW 2154, Australia Dedicated Micros, Asia PTY Dedicated Micros Slovenia...
