Operation/Reference Guide
NXD-1000Vi
®
10" Modero
Wall/Flush Mount
Touch Panel with Intercom
Touch Panels
L a s t R e v i s e d : 7 /2 / 2 0 1 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NXD-1000Vi and is the answer not in the manual?

Questions and answers

Related Manuals for AMX NXD-1000Vi

Summary of Contents for AMX NXD-1000Vi

  • Page 1 Operation/Reference Guide NXD-1000Vi ® 10" Modero Wall/Flush Mount Touch Panel with Intercom Touch Panels L a s t R e v i s e d : 7 /2 / 2 0 1 2...
  • Page 2 AMX is not responsible for products returned without a valid RMA number. AMX is not liable for any damages caused by its products or for the failure of its products to perform. This includes any lost profits, lost savings, incidental damages, or consequential damages.
  • Page 3 LICENSE GRANT. AMX grants to Licensee the non-exclusive right to use the AMX Software in the manner described in this License. The AMX Software is licensed, not sold. This license does not grant Licensee the right to create derivative works of the AMX Software.
  • Page 4 FCC Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received; including interference that may cause undesired operation. Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of...

  • Page 5: Table Of Contents

    Installing the NXD into drywall using Expansion Clips ..........28 Installing the NXD into a Flat Surface using #4 screws ..........31 Installing an NXD-1000Vi into an (optional) Rack Mount Kit (NXA-RK10) ..... 32 Wiring Guidelines for the NXD-1000Vi Panels............33...
  • Page 6 Using G4 Web Control to Interact with a G4 Panel ..........54 Using your NetLinx Master To Control The G4 panel ..........56 Upgrading Modero Firmware ................59 Overview ........................ 59 Upgrading the Modero Firmware via the USB port ..........59 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 7 G4 Web Control Page ....................105 Sensor Setup ....................... 107 Making the most of the Automated Brightness Control feature (DIM Mode) ..... 109 Other Settings ...................... 110 Image Caching Page....................111 Setting the image cache....................113 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 8 Creating Intercom Pages ..................131 Programming ....................133 Overview ......................133 Button Assignments ..................... 133 Page Commands ....................133 @APG............................133 @CPG ............................133 @DPG............................134 @PDR ............................134 @PHE ............................134 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 9 ^BMF............................147 ^BMI............................149 ^BML............................149 ^BMP ............................149 ^BNC............................150 ^BNN ............................150 ^BNP ............................150 ^BNT ............................150 ^BOP............................151 ^BOR............................151 ^BOS ............................151 ^BPP............................152 ^BRD ............................152 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 10 ?BCF ............................164 ?BCT ............................164 ?BMP ............................165 ?BOP............................165 ?BRD ............................166 ?BWW ............................. 166 ?FON ............................167 ?ICO............................167 ?JSB ............................168 ?JSI ............................168 ?JST ............................169 ?TEC............................169 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 11 ^TPS ............................177 ^VK ............................S 177 Embedded Codes ....................178 Panel Setup Commands ..................179 CLOCK............................. 179 ^CFE............................179 ^CPR ............................179 ^CFS............................179 ^CFSM............................. 180 ^CEX ............................180 ^DLD ............................180 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 12 ^PHN-CALL..........................186 ^PHN-INCOMING ........................186 ^PHN-LINESTATE ........................186 ^PHN-MSGWAITING ......................187 ^PHN-PRIVACY........................187 ^PHN-REDIAL ......................... 187 ^PHN-TRANSFERRED ......................187 Touch Panel SIP Commands ..................188 ^PHN-ANSWER ........................188 ^PHN-AUTOANSWER ......................188 viii NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 13 Appendix D - Wireless Technology ..............205 Overview of Wireless Technology................. 205 Terminology......................206 802.1x ......................... 206 AES ..........................206 CERTIFICATES (CA) ..................... 206 MIC..........................206 TKIP..........................206 WEP ..........................206 WPA ..........................206 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 14 Step 1: Setup the Panel and PC for USB Communication..........210 Step 2: Confirm the Installation of the USB Driver on the PC ........210 Uploading a Certificate File .................. 212 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 15: Introduction

    Composite/S-Video support and the ability to create a high quality digital home/ office intercom network or to make/receive digital local, long distance and international telephone calls. Simply add the AMX SIP Communications Gateway (FG2182-0x) for calls that sound incredibly clear (FIG. 1).
  • Page 16 Composite or S-Video), data (via Ethernet), and audio to Modero touch panels located up to 200 feet (60.96 m) from the breakout box. NXD-1000Vi panels are ideally suited for displaying full motion video and audio with overlay graphics for applications with demanding visual requirements.

  • Page 17: Nxd-1000Vi Specifications

    (5 RU - rack units high) 8.72" x 19.0" x 0.50" (22.15 cm x 48.26 cm x 1.27 cm) • NXD-1000Vi (with faceplate): 7.96" x 11.16" x 3.32" (20.22 cm x 28.34 cm x 8.43 cm) • CB-TP10 Conduit/Wallbox (optional): 9.23" x 10.90" x 3.40"...
  • Page 18 • RJ-45 port for 10/100 Mbps communication. The Ethernet port automatically negotiates the connection speed (10 Mbps or 100 Mbps), and whether to use half duplex or full duplex mode. • NXD-1000Vi panels communicate with the NetLinx Master using the ICSP protocol over Ethernet. Ethernet 10/100 LEDs: •...

  • Page 19: Nxd-1000Vi Panels - Connector Layout

    A/V panel over CAT5 cable (up to 200’/60.96m) and accepts either Composite or S-Video. - Although the NXD-1000Vi is only sold as part of a KIT configuration, the breakout box can be purchased as a separate accessory.
  • Page 20 Introduction NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 21: Nxa-Avb/Ethernet Breakout Box

    NXA-AVB/ETHERNET Breakout Box Overview The NXA-AVB/ETHERNET Breakout Box (FG2254-10) is included as part of the NXD-1000Vi Kit configuration (panel and box) but can be purchased as a separate accessory. This box facilitates the installation and distribution of video, data, and audio to Modero touch panels located up to 200 feet (60.96 m) from the AVB box.

  • Page 22: Installing The Nxa-Avb/Ethernet

    The power supply being used on the NXA-AVB/ETHERNET is dependant on the power requirements of the target touch panel. Use a standard CAT5 Ethernet cable to provide both communication and 10/100 network connectivity between the panel, NXA-AVB/ETHERNET, NetLinx Master, and the network. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 23: Wiring The Nxa-Avb/Ethernet Connectors And Cables

    Mic Out port. This signal can be fed as a Line Level In to either an amplifier or an AMX VOL card. Either a balanced (+, -, and GND) or unbalanced (+ and GND) audio signal can be connected to this output.

  • Page 24: Wiring The Nxa-Avb/Ethernet For Unbalanced Audio

    -, and GND), then connect the "+" terminal to the "live" signal, the "-" terminal to the "return" signal, and the "GND" terminal to the ground signal. Ground signal Return signal Balanced OUT OUT- Line signal OUT+ FIG. 8 Wiring the rear MIC OUT connector for use with Balanced Audio NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 25: Nxd-1000Vi Touch Panel Accessories

    The following section outlines and describes the other AMX equipment available for the NXD-1000Vi. NXA-WC80211B/CF 802.11b Wireless Card (FG2255-03) These touch panels can connect to a wireless network using an optional AMX 802.11b Wireless Interface Card shown in FIG. 9. This internal card is field-upgradeable within both models of panels.

  • Page 26: Nxa-Wc80211Gcf 802.11G Wireless Card (Fg2255-07)

    This card works with compatible 802.11b/g Wireless Access Points such as the NXA-WAP200G (which uses a default SSID of AMX). Please follow your particular Wireless Access Point’s instruction manual for the correct procedures to setup either a secured or unsecured connection. The following table lists the specifications for the NXA-WC80211GCF.
  • Page 27 - 14: (Ch 1 - 14) - Japan (802.11b) Note: To alter the card’s default country code (North America), please contact an AMX Technical Support representative for detailed procedures and information. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 28 • 802.11g communication: 12 +-1 dBm (6, 9, 12, 18, 24, 36, 48, and 54 Mbps) Wireless LAN Security: • EAP-FAST • EAP-LEAP • EAP-PEAP • EAP-TLS • EAP-TTLS • WEP 64 & 128 • WPA-PSK NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 29 NXA-CFSP128M - 128 MB compact flash card (FG2116-36) NXA-CFSP256M - 256 MB compact flash card (FG2116-37) NXA-CFSP512M - 512 MB compact flash card (FG2116-38) NXA-CFSP1GB - 1 GB compact flash card (FG2116-39) NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 30 NXD-1000Vi Touch Panel Accessories NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 31: Nxa-Cfsp Compact Flash (Fg2116-7X)

    NXA-CFSP Compact Flash (FG2116-7x) NXA-CFSP Compact Flash (FG2116-7x) Overview Every NXD-1000Vi Modero panel is shipped with a 128 MB Compact Flash card (NXA-CFSP). If possible, upgrade the panel’s internal components (Compact Flash or wireless interface cards) prior to installing or using the panel.
  • Page 32 NXA-CFSP Compact Flash (FG2116-7x) NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 33: Installation / Upgrade Of Internal Nxd Components

    Gently slide the connector overlay away from the back box housing. Unscrew the outer housing (back box) by using a grounded Phillips-head screwdriver to remove the two sets of pan-head Housing Screws, located on both sides of the housing (FIG. 11). NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 34: Step 2: Install The New Compact Flash Memory Card

    To complete the upgrade process, either upgrade the remaining wireless card (Step 3) or close and re- secure the enclosure using the procedures in Step 3: Close and Re-secure the NXD Panel Enclosure section on page 21. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 35: Step 3: Close And Re-Secure The Nxd Panel Enclosure

    Re-install the faceplate back onto the panel. Refer to the Installing the Button Trim Ring section on page 24 for more detailed faceplate installation information. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 36 Installation / Upgrade of Internal NXD Components NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 37: Installation

    Installing the No-Button Trim Ring The NXD-1000Vi panel is shipped from AMX with a default Button Trim Ring already installed. The unit is also shipped with an included Trim Ring containing no button openings (a No-Button Trim Ring) that allows you, if desired, to change the default configuration of the NXD panel Faceplate to that with no-button openings.

  • Page 38: Installing The Button Trim Ring

    Ring and the outer surface of the Faceplate. Place the Faceplate back onto the main NXD-1000Vi unit. Make sure to align the Microphone, Light, and PIR Motion sensor locations on the main unit to their respective openings on the Faceplate assembly.
  • Page 39 Faceplate and that there are no gaps between this Trim Ring and the outer surface of the Faceplate. Place the Faceplate back onto the main NXD-1000Vi unit. Make sure to align the Microphone, Light, and PIR Motion sensor locations on the main unit to their respective openings on the Faceplate assembly.

  • Page 40: Pre-Wall Installation Of The Conduit Box

    This section describes the installation procedures for the most common installation scenario. The most important thing to remember when mounting this conduit box is that the NXD-1000Vi Mounting Tabs must lie flush against the outside of the sheetrock (FIG. 19).

  • Page 41: Installation Of An Nxd Touch Panel

    Install the drywall/sheetrock before inserting the main NXD unit into the CB-TP10. Installation of an NXD Touch Panel The NXD-1000Vi can be installed either directly into the (optional) CB-TP10 or other solid surface environment using the two different mounting options: drywall clips or solid surface screws. The following sections describe mounting the touch panel directly into a pre-wall conduit box, a solid surface or drywall, and optional NXA-RK10 Rack Mount Kit for installation.

  • Page 42: Installing The Nxd Into Drywall Using Expansion Clips

    Don’t disconnect the connectors from the touch panel. The unit must be installed with the attached connectors before being inserted into the conduit box. Carefully slide the main NXD-1000Vi unit (B in FIG. 20) into the conduit box, so that all Mounting Tabs lie flush against the conduit box (C in FIG. 20).
  • Page 43 Verify that the terminal end of the power cable is not connected to a power source before plugging in the 2-pin power connector.  The USB connectors can be from a either a USB extension cable, or a wireless USB RF transmitter. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 44 Carefully insert the main unit (with expansion clips) into the cutout until the Mounting Tabs on the NXD unit lie flush against the wall. The drywall clip set must be re-ordered from AMX if the drywall clip is bent accidentally during an installation or removed during a re-installation.

  • Page 45: Installing The Nxd Into A Flat Surface Using #4 Screws

    Mounting screws (#4-40, included) are secured through two sets of circular holes located at the left and right sides of the NXD-1000Vi. The most important thing to remember when mounting the NXD Wall Mount is that the outer frame (Mounting Tabs) must be installed flush against the mounting surface.

  • Page 46: Installing An Nxd-1000Vi Into An (Optional) Rack Mount Kit (Nxa-Rk10)

    Don’t disconnect the connectors from the touch panel. The unit must be installed with the necessary connectors before being inserted into the solid surface. Carefully slide the main unit into the cutout until the Mounting Tabs of the NXD-1000Vi unit lie flush against the wall.

  • Page 47: Wiring Guidelines For The Nxd-1000Vi Panels

    Reconnect the terminal power connector on the 12 VDC-compliant power supply and apply power. Wiring Guidelines for the NXD-1000Vi Panels NXD-1000Vi panels use a 12 VDC-compliant power supply to provide power to the panel via the 2-pin 3.5 mm mini-Phoenix PWR connector. Use the power requirements information (page 3) to determine the power draw.

  • Page 48: Wiring A Power Connection

    L - Link LED (green) lights when lights when receiving or the Ethernet cables are connected transmitting Ethernet and terminated correctly. data packets ETHERNET 10/100 FIG. 26 Ethernet connector (showing communication and connection LEDs) NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 49: Usb Port: Connecting And Using Input Devices

    RJ-45 wiring diagram USB Port: Connecting and Using Input Devices The NXD-1000Vi panel can have up to two USB-capable input devices connected for use on its different firmware and TPD4 panel pages. These input devices can consist of a keyboard or mouse.
  • Page 50 Installation NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 51: Panel Calibration

    When the panel is ready, the AMX Splash Screen is replaced by the Initial Panel Page (FIG. 28). AMX Splash Screen...

  • Page 52: Testing Your Calibration

    If the crosshairs do not appear directly below your LCD touch points, press the Back button and re- calibrate the panel using the above steps. Exit this Calibration Test page by pressing the Back button to return to the Protected Setup page. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 53: Configuring Communication

    Modero Setup and System Settings AMX Modero panels feature on-board Setup pages. Use the options in the Setup pages to access panel information and make various configuration changes. Accessing the Setup and Protected Setup Pages Press the grey Front Setup Access button for 3 seconds to open the Setup page (FIG.

  • Page 54: Wireless Settings Page - Wireless Access Overview

    The Wireless Access Point communication parameters must match those of the pre-installed wireless CF card inside the panel. The panels allow users to connect to a wireless network through their use of the pre-installed AMX 802.11g wireless interface card to communicate with a Wireless Access Point (WAP) such as the NXA-WAP200G).

  • Page 55: Wireless Communication Using A Dhcp Address

    This address must be obtained before Static assignment of the panel continues. Toggle the DHCP/Static field (from the IP Settings section) until the choice cycles to Static. The IP Address, Subnet Mask, and Gateway fields then become user-editable (red). NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 56: Using The Site Survey Tool

    If the WAP’s SSID is hidden (not broadcast) it will not show up on the site survey screen but it  can still be configured via the SSID field on the specified security mode screen. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 57: Step 2: Configure The Card's Wireless Security Settings

    Configuring the Modero’s wireless card for unsecured access to a WAP200G In the Protected Setup page: Press the Wireless Settings button (located on the lower-left) to open the Wireless Settings page. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 58 Text) Settings dialog (FIG. 38). An Open security method does not utilize any encryption methodology but does require that an SSID (alpha-numeric) be entered. Using this method causes network packets to be sent out as unencrypted text. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 59: Configuring The Modero's Wireless Card For Secured Access To A Wap200G

    The card should be given the SSID used by the target WAP. If this field is left blank, the unit will attempt to connect to the first available WAP. By default, all WAP200Gs use AMX as their assigned SSID value.

  • Page 60: Automatically Set Ssid

    Press the SSID field and from the Network Name (SSID) keyboard, enter the SSID name you are using on your target Wireless Access Point (case sensitive), and press Done when finished. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 61 The card should be given the SSID used by the target WAP. If this field is left blank, the unit will attempt to connect to the first available WAP. By default, all WAP200Gs use AMX as their assigned SSID value.
  • Page 62 Remember that you will need to navigate to the System Settings page and configure the connection to a target Master. After the panel restarts, return to the Wireless Settings page to verify the Link Quality and Signal Strength: NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 63: Configuring Multiple Wireless Moderos To Communicate To A Target Wap200G

    NetLinx Studio can be setup to run a Virtual Master where the PC acts as the Master by supplying its own IP Address for communication to the panel. For a PC to establish a USB connection with a Modero panel, it must have the AMX USBLAN driver installed. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 64: Prepare Your Pc For Usb Communication With The Panel

    (FIG. 46) is displayed. This window notifies you that the panel has been detected as a USB device, and the appropriate USB driver is being installed to establish communication with ® the panel. It also indicates that the AMX USBLAN driver does not contain a Microsoft digital signature.

  • Page 65: Configure A Virtual Netlinx Master Using Netlinx Studio

    In NetLinx Studio, select Settings > Master Communication Settings, from the Main menu to open the Master Communication Settings dialog (FIG. 47). IP Address of computer (not needed as this is a direct USB connection) FIG. 47 Assigning Communication Settings for a Virtual Master NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 66: Ethernet

    Ethernet, the Master IP/URL field must be configured to match the IP Address of the PC and make sure to use the Virtual System value assigned to the Virtual Master within NetLinx Studio. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 67 Verify the panel has been configured to communicate with the Wireless Access Point and verify the signal strength quality bargraph is On. Launch NetLinx Studio 2.x (default location is Start > Programs > AMX Control Disc > NetLinx Studio 2 > NetLinx Studio 2).

  • Page 68: Using G4 Web Control To Interact With A G4 Panel

    By selecting URL, the System Number field becomes read-only (grey) because the panel pulls this value directly from the communicating target Master (virtual or not). A Virtual Master system value can be set within the active AMX software applications such as: NetLinx Studio, TPD4, or IREdit.
  • Page 69 The default value is 5900. Press Done when you are finished entering the value. The remaining fields within the G4 Web Control Settings section of this page are read-only and cannot be altered. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 70: Using Your Netlinx Master To Control The G4 Panel

     If the Master has been previously configured for secured communication, click OK to accept the AMX SSL certificate (if SSL is enabled) and then enter a valid username and password into the fields within the Login dialog. Click OK to enter the information and proceed to the Master’s Manage WebControl Connections window.
  • Page 71 Wired Ethernet - System Settings > IP Settings section within the IP Address field.  Wireless - Wireless Settings > IP Settings section within the IP Address field.  If you do not get this field continue to step 9. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 72 A small circle appears within the on-screen G4 panel page and corresponds to the location of the mouse cursor. A left-mouse click on the computer-displayed panel page equates to an actual touch on the target G4 panel page. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 73: Upgrading Modero Firmware

    Calibration section on page 37. The latest NXD-1000Vi firmware kit file is now panel-specific. Only NXD-1000Vi firmware should be loaded onto this specific panel type. This new firmware also provides both backwards compatibility with the previous 802.11b cards and new security protocols for the new 802.11g wireless CF card.

  • Page 74: Step 2: Prepare Netlinx Studio For Communication Via The Usb Port

    Navigate back to the System Settings page. Step 2: Prepare NetLinx Studio for communication via the USB port Launch NetLinx Studio 2.x (default location is Start > Programs > AMX Control Disc > NetLinx Studio 2 > NetLinx Studio 2).

  • Page 75: Step 3: Confirm And Upgrade The Firmware Via The Usb Port

    NetLinx Workspace window (showing the panel connection via a Virtual NetLinx Master) The latest NXD-1000Vi firmware kit file is now panel-specific. Only NXD-1000Vi firmware should be loaded onto this specific panel type. This new firmware also provides both backwards compatibility with the previous 802.11b cards and new security protocols for the new 802.11g wireless CF card.
  • Page 76 If the panel firmware being used is not current, download the latest Kit file by first logging in to www.amx.com and then navigate to Tech Center > Firmware Files and from within the Modero section of the web page locate your Modero panel.

  • Page 77: Upgrading The Modero Firmware Via Ethernet (Ip Address)

     Note the IP Address and Gateway information. Launch NetLinx Studio 2.x (default location is Start > Programs > AMX Control Disc > NetLinx Studio 2 > NetLinx Studio 2). Select Settings > Master Communication Settings from the Main menu to open the Master Communication Settings dialog (FIG.

  • Page 78: Step 2: Prepare The Panel For Communication Via An Ip

    Master (virtual or not). A Virtual Master system value can be set within the active AMX software applications such as: NetLinx Studio, TPD4, or IREdit. Press the red Master IP/URL field to open a Keyboard and enter the NetLinx Master’s IP Address (obtained from the Diagnostics - Networking Address dialog of the NetLinx Studio application).
  • Page 79 If the panel firmware being used is not current, download the latest Kit file by first logging in to www.amx.com and then navigate to Tech Center > Firmware Files and from within the Modero section of the web page locate your Modero panel.
  • Page 80 Master, and populates the System list with devices on your particular system. Confirm the panel has been properly updated to the correct firmware version. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 81: Firmware Pages And Descriptions

    NetLinx Master. Refer to both the Protected Setup Navigation Buttons section on page 78 and the Protected Setup Page section on page 67 for more detailed information. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 82: Setup Page

    • Use this button to set the timeout value to zero and disable the sleep mode. • Note: Display timeout values affect battery performance. Small timeout values increase the life of the battery charge. Greater timeout values may require more frequent battery charging. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 83: Information

    The Information button provides a menu to select either the Project Information Page section on page 70 or the Panel Information Page section on page 71. Select either option to access that page. FIG. 62 Information menu NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 84: Project Information Page

    Displays the purchase order information. AMX IR 38k Assigned Port: Displays the AMX 38 kHz IR channel port used by the IR receiver on the panel. • This information is pulled by the panel from AMX IR Receivers section of the TPD4 Project Properties >...

  • Page 85: Panel Information Page

    Firmware Pages and Descriptions Project Information Page Elements (Cont.) AMX IR 455k Displays the AMX 455 kHz IR channel port used by the IR receiver on the Assigned Port: panel. This information is pulled by the panel from AMX IR Receivers section of the TPD4 Project Properties >...
  • Page 86 Displays the sleep string used during a panel’s sleep mode. File System: Displays the amount of Compact Flash memory available on the Modero panel. RAM: Displays the available RAM (or Extended Memory module) on the Modero panel. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 87: Time & Date Setup Page

    Time Display fields: • These fields display the time in three formats: STANDARD, STANDARD AM/PM, and 24 HOUR. Date Display fields: • These fields display the calendar date information in several different formats. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 88: Volume Page

    • A Lock only appears on the icon if the panel has established a connection with a currently secured target Master (requiring a username and password). NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 89 Environmental acoustics, personal voice level and ambient noise are all deciding factors when setting your mic, intercom and panel sound levels. Consider your environment when adjusting intercom and sound levels and use caution so as not to damage the speaker. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 90: Supported Sampling Rates For Wav

    Video properties of the incoming video signal from an NXA-AVB/ETHERNET Breakout Box. Incoming Video signal Once done making your screen adjustments, SAVE SETTINGS. FIG. 67 Video Setup page (showing default values) NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 91 • Range = 0 - 255, default = 128. Hue: Use the UP/DN buttons to alter the hue level of the incoming signal. • Range = 0 - 255, default = 128. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 92: Protected Setup Navigation Buttons

    Press to access the Other Settings menu and select Cache, Passwords, or SIP. Press to access the Tools menu and select Panel Logs, Panel Statistics, or Connection Utility. FIG. 68 Protected Setup Navigation Buttons NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 93: Protected Setup Page

    • A Lock only appears on the icon if the panel has established a connection with a currently secured target Master (requiring a username and password). Device Number: Opens a keypad that is used to set and display the current device number. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 94 • The Remove User Pages button allows you remove all current TPD4 touch panel pages currently on the panel (including the pre-installed AMX Demo pages). - Pressing this button launches a Confirmation dialog (FIG. 70) which asks you to confirm your selection.

  • Page 95: System Settings Page

    • A Lock only appears on the icon if the panel has established a connection with a currently secured target Master (requiring a username and password). NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 96 • Choices are: Auto, 10 Half Duplex, 10 Full Duplex, 100 Half Duplex, or 100 Full Duplex. MAC Address Displays a read-only field that is factory set by AMX for the built-in Ethernet interface. Master Connection: Sets the NetLinx Master communication values:...

  • Page 97: Wireless Settings Page

    EAP technology (some of which require the upload of unique certificate files to a target panel). Refer to the Appendix B - Wireless Technology section on page 1 for more further information. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 98 Enter the secondary DNS address for this panel. Domain Enter a unique name to the panel for DNS look-up. MAC Address This unique address identifies the wireless Ethernet card in the panel (read- only). NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 99 • Refer to the Wireless Security Page section on page 83 for details. • For information on uploading a certificate file, refer to the AMX Certificate Upload Utility section on page 6.
  • Page 100 (panel) before allowing it access to the network. • Refer to the Wireless Security Page section on page 83 for details. • For information on uploading a certificate file, refer to the AMX Certificate Upload Utility section on page 6.

  • Page 101: Open (Clear Text) Settings

    Wireless Security pages (each Wi Fi card supports different security features) Open (Clear Text) Settings Press the Open (Clear Text) button to open the Open (Clear Text) Settings page (FIG. 74). NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 102 • Cancel - discard changes and return to the previous page.  Refer to the Configuring a Wireless Network Access section on page 40 for further details on these security options. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 103: Static Wep Settings

    • Make sure this setting is the same for all points in your wireless network. • NXA-WAP200Gs use AMX as their default SSID. • If this field is left blank, the panel will attempt to connect to the first available WAP. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 104 • The Passphrase generator is case sensitive. Note: This Key generator is unique to Modero panels and does not generate the same keys as non-AMX wireless devices. For example, a Current Key string generated anywhere else will not match those created on Modero pan- els.

  • Page 105: Wpa-Psk Settings

    WAP, not in the firmware. WAPs do not display “WPA” or “WPA2” on their configuration screens:  WPA is normally displayed as TKIP.  WPA2 is normally displayed as AES CCMP. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 106: Eap-Leap Settings

    Server, also known as a Radius server. The configuration fields described below take variable length strings as inputs. An on-screen keyboard is opened when these fields are selected. LEAP (Lightweight Extensible Authentication Protocol) was developed to transmit authentication information securely in a wireless network environment. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 107 This works in tandem with the Password string which is similar to the password entered to gain access to a secured workstation. Typ- ically, this is in the form of a username such as: jdoe@amx.com. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 108: Eap-Fast Settings

    Refer to FIG. 78 for an example of what a typical EAP-LEAP system configuration page would like. EAP-FAST Settings Press the EAP-FAST button to open the EAP-FAST Settings dialog (FIG. 79). NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 109 Automatic certificate downloading is convenient but slightly less secure, since its the certificate is transferred wirelessly and could theoretically be “sniffed-out”. EAP-FAST Settings NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 110 This works in tandem with the Password string which is similar to the password entered to gain access to a secured workstation. Typ- ically, this is in the form of a username such as: jdoe@amx.com. Anonymous Identity: Opens an on-screen keyboard.

  • Page 111: Eap-Peap Settings

     MSCHAPv2 with PEAPv0  GTC with PEAPv1 EAP-PEAP security is designed for wireless environments where it is necessary to transmit data securely over a wireless network. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 112: Eap-Ttls Settings

    This works in tandem with the Password string which is similar to the password entered to gain access to a secured workstation. Typ- ically, this is in the form of a username such as: jdoe@amx.com. Password: Opens an on-screen keyboard. Enter the network password string specified...
  • Page 113 EAP. However, a successful connection is not guaranteed because the detected WAP may be connected to a RADIUS server, which may not support this EAP type and/or have the proper user identities configured. EAP-TTLS Settings (Cont.) NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 114: Eap-Tls Settings

    This works in tandem with the Password string which is similar to the password entered to gain access to a secured workstation. Typically, this is in the form of a username such as: jdoe@amx.com. Anonymous Identity: Opens an on-screen keyboard. Enter an IT provided alpha-numeric string which (similar to the username) used as the identity, but that does not repre- sent a real user.
  • Page 115 This works in tandem with the Password string which is similar to the password entered to gain access to a secured workstation. Typ- ically, this is in the form of a username such as: jdoe@amx.com. EAP-TLS Settings (Cont.)

  • Page 116: Client Certificate Configuration

    Format is: PKCS12 First file contains the client certificate, second file not supported not supported contains the private key. Format is: PKCS12 AMX supports the following security certificates  PEM (Privacy Enhanced Mail) NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 117: Calibration Page

    Client Certificate field PEM and DER Private Key field .PEM, DER, and PKCS12 Calibration Page This page (FIG. 83) allows you to calibrate the touch panel using a pre-selected touch driver. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 118 Calibrate button through your VNC window. This action causes the panel to go to the Calibration page seen above, where you can physically re-calibrate the actual touch panel again using the above procedures. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 119: G4 Web Control Page

    Displays the maximum number of users that can be simultaneously connected Connections to this panel via VNC. Default = 1. Current Connection Count Displays the number of users currently connected to this panel via VNC. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 120 Refer to the Using G4 Web Control to Interact with a G4 Panel section on page 54 for more detailed instructions on how to use the G4 Web Control page with the new web-based NetLinx Security application. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 121: Sensor Setup Page Elements

    • A Lock only appears on the icon if the panel has established a connection with a currently secured target Master (requiring a username and password). NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 122 NetLinx Master (set in TPD4) (read-only). • The Motion Sensor Channel field indicates the channel used to report the motion sensor channel back to the NetLinx Master (set in TPD4) (read-only). NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 123: Making The Most Of The Automated Brightness Control Feature (Dim Mode)

    8. Move around the panel and block the direct or indirect light from the room fixtures with your body. Take note of the drop in the lighting level being detected by the panel in response to your movements. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 124: Other Settings

    The Other Settings button provides a menu to select the Image Caching page, Password Setup page, or SIP Settings page. Select any option to access its page. FIG. 87 Other Settings menu NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 125: Image Caching Page

    The icon in the upper-right corner of each Setup page provides a constant visual indication of current connection status. Note: a Lock appears on the icon if the panel is connected to a secured NetLinx Master. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 126 # of flash cache misses - # of times a dynamic image could not be found in either RAM or flash cache. RAM cache hits are not relevant in this calculation. Items in Cache (Flash) The number of images that are currently stored in the Flash cache. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 127: Setting The Image Cache

    All status information is located in the Image Cache Status section of the page. Password Setup Page The Password Setup page (FIG. 89) centers around the properties used to assign passwords for the Modero panel pages. FIG. 89 Password Setup page NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 128: Sip Settings Page

    A sample UI module is provided in the module package. It is not intended to cover every possible application, but can be expanded as needed by a dealer to meet the requirements of a particular installation. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 129 This field is optional. Password: This option enables you to enter the password for the user at the proxy server. This field is optional. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 130: Tools

    Tools menu Panel Logs Page The options on the Panel Logs page allow you to view and track the connection history of the panel (FIG. 92). FIG. 92 Panel Logs page NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 131: Checking The Panel Connection Logs

    The options on the Panel Statistics page allow you to track the connection status for the panel. The Panel Statistics page tracks ICSP messages, Blink messages, Ethernet connection statistics, and Wireless connection statistics (FIG. 89). NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 132 • Received - The total Blink messages received by the panel in the last 15 minutes. • Missed - The total Blink messages missed by the panel in the last 15 minutes. Ethernet Statistics The Ethernet connection statistics for the panel. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 133: Checking The Panel Statistics

    The options on the Connection Utility page allow you to utilize your panel as a site survey tool. While in this page, move around your wireless network coverage area and see if there are any weak points within the spaces between your WAPs (FIG. 89). FIG. 94 Connection Utility page NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 134 The number of messages sent from the panel to the master. Responses Received The number of responses the panel has received from the master. Responses Missed The number of expected responses from the master to the panel missed. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 135: Using The Connection Utility

    MAC Address for the WAP currently in use. The Connection Statistics show the current quality of the panel connection. 4. Push Close when you are done using the site survey tool. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 136 Firmware Pages and Descriptions NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 137: Eap Security & Server Certificates

    If no server certificate will be used then, this field should be left blank. If the field contains a file name, then a valid certificate file with the same file name must be previously installed on the panel. Otherwise the authentication process will fail. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 138 EAP Security & Server Certificates NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 139: Full Duplex Intercom

    Incorporating an Intercom Capable Panel Into Your Netlinx System Download the module for the intercom panel from www.amx.com, and include it in your NetLinx project file. For searching purposes, the module manufacturer is AMX and the model is Intercom. The intercom module will only work with AMX intercom capable panels.

  • Page 140: Setting The Intercom Session Timeout

    It is important to name the intercom panel; the name is displayed in other panels’ intercom call directory pages. FIG. 98 Intercom Advanced Setup Page NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 141: Allowing A Panel To Be Monitored

    Type the name of the panel and press Done. This is the name that is displayed in other panels’ intercom call directory pages. Press Back to return to the intercom setup pages. Press Exit when you are finished. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 142: Sample Intercom Page

    Ends an intercom call to a panel. Privacy Off Toggles the privacy option of the intercom. When enabled, other panels cannot contact the panel. Monitor Room Enables the panel to monitor 1:19 another room’s intercom panel. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 143 Monitor Panel Display only; indicates the 1:23 panel is being monitored by another panel. Monitor Panel Display only; indicates the 1:26 panel is being monitored by another panel. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 144: Answering An Incoming Call

    Answer - Pressing this button opens the intercom session with the other panel.  Ignore - Pressing this button denies the intercom session with the other panel. FIG. 102 Answer Call To answer a call: In the popup window, press the Answer button. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 145: Creating Intercom Pages

    Creating Intercom Pages The easiest method of creating your own intercom pages is to start with the pages provided by AMX in the module download .ZIP file. You can change the aesthetics of the pages as long as the channel, address, level and links remain untouched.
  • Page 146 Full Duplex Intercom NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 147: Programming

    Syntax: "'@CPG-<popup group name>'" Variable: popup group name = 1 - 50 ASCII characters. Name of the popup group. Example: SEND_COMMAND Panel,"'@CPG-Group1'" Clears all popup pages from the popup group ’Group1’. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 148: Dpg

    = 1 - 50 ASCII characters. Name of the page the popup is displayed hide effect time = Given in 1/10ths of a second. Example: SEND_COMMAND Panel,"'@PHT-Popup1;50'" Sets the Popup1 hide effect time to 5 seconds. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 149: Ppa

    • This command works in the same way as the 'Clear Group' command in TPDesign 4. Syntax: "'@PPK-<popup page name>'" Variable: popup page name = 1 - 50 ASCII characters. Name of the popup page. Example: SEND_COMMAND Panel,"'@PPK-Popup1'" Kills the popup page ’Popup1’ on all pages. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 150: Ppm

    Close all popups on all pages. • This command works in the same way as the 'Clear All' command in TPDesign 4. Syntax: "'@PPX'" Example: SEND_COMMAND Panel,"'@PPX'" Close all popups on all pages. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 151: Pse

    • If the page is currently active, it will not redraw the page. Syntax: "'PAGE-<page name>'" Variable: page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On. Example: SEND_COMMAND Panel,"'PAGE-Page1'" Flips to page1. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 152: Ppof

    = 1 - 50 ASCII characters. Name of the page the popup is displayed On. Example: SEND_COMMAND Panel,"'PPON-Popup1; Main'" Activates the popup page ’Popup1’ on the Main page. Example 2: SEND_COMMAND Panel,"'PPON-Popup1'" Activates the popup page ’Popup1’ on the current page. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 153: Programming Numbers For Colors, Fonts, And Borders

    Very Light Cyan Black Light Cyan TRANSPARENT Cyan Medium Cyan Dark Cyan Very Dark Cyan Very Light Aqua Light Aqua Aqua Medium Aqua Dark Aqua Very Dark Aqua Very Light Blue Light Blue NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 154: Font Styles And Id Numbers

    No border 10-11 Picture frame Single line Double line Double line Bevel-S Quad line Bevel-M Circle 15 22-23 Circle 15 Single line 24-27 Neon inactive-S Double line 40-41 Diamond 55 Quad line NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 155: Tpd4 Border Styles By Name

    Oval V 75x150 Menu Top Rounded 195 Oval V 100x200 Menu Right Rounded 15 Picture Frame Menu Right Rounded 25 Quad Line Menu Right Rounded 35 Single Line Menu Right Rounded 45 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 156: Button Commands

    = End of button state. time = In 1/10 second intervals. Example: SEND_COMMAND Panel,"'^ANI-500,1,25,100'" Runs a button animation at text range 500 from state 1 to state 25 for 10 second. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 157: Apf

    1 = Off state and 2 = On state). unicode text = 1 - 50 ASCII characters. Unicode characters must be entered in Hex format. Example: SEND_COMMAND Panel,"'^BAU-520,1,00770062'" Appends Unicode text '00770062' to the button’s OFF state. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 158: Bcb

    = Refer to theRGB Values for all 88 Basic Colors table on page 139 for more information. Example: SEND_COMMAND Panel,"'^BCT-500.504&510,1,12'" Sets the Off state border color to 12 (Yellow). NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 159: Bdo

    = Refer to theText Area Input Masking section on page 196 for character types. Example: SEND_COMMAND Panel,"'^BIM-500,AAAAAAAAAA'" Sets the input mask to ten ’A’ characters, that are required, to either a letter or digit (entry is required). NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 160: Bln

    315 onto the OFF state border, font, Text, bitmap, icon, fill color and text color of the button with a variable text address of 150. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 161: Bmf

    ’%GH<bargraph hi>’ = Set the bargraph upper limit. ’%GL<bargraph low>’ = Set the bargraph lower limit. ’%GN<bargraph slider name>’ = Set the bargraph slider name/Joystick cursor name. ’%GC<bargraph slider color>’ = Set the bargraph slider color/Joystick cursor color. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 162 ’%VN<network name>’ = Set network connection name. ’%VP<password>’ = Set the network connection password. Example: SEND_COMMAND Panel,"'^BMF-500,1,%B10%CFRed%CB Blue %CTBlack%Ptest.png'" Sets the button OFF state as well as the Border, Fill Color, Border Color, Text Color, and Bitmap. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 163: Bmi

    1 = Off state and 2 = On state). name of bitmap/picture = 1 - 50 ASCII characters. Example: SEND_COMMAND Panel,"'^BMP-500.504&510.515,1,bitmap.png'" Sets the OFF state picture for the buttons with variable text ranges of 500-504 & 510-515. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 164: Bnc

    Syntax: "'^BNT-<vt addr range>,<network port>'" Variables: variable text address range = 1 - 4000. network port = 1 - 65535. Example: SEND_COMMAND Panel,"'^BNT-973,5000'" Sets the TakeNote button network port to 5000. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 165: Bop

    Sets the border by number (#10) to those buttons with the variable text range of 500-504 & 510-515. SEND_COMMAND Panel,"'^BOR-500.504&510,AMX Elite -M'" Sets the border by name (AMX Elite) to those buttons with the variable text range of 500-504 & 510-515. ^BOS Set the button to display either a Video or Non-Video window.

  • Page 166: Bpp

    = top of page. right = right side of page. bottom = bottom of page. Example: SEND_COMMAND Panel,"'^BSP-530,left,top'" Sets the button with variable text 530 in the left side top of page. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 167: Bsm

    Variables: variable text address range = 1 - 4000. network password = 1 - 50 ASCII characters. Example: SEND_COMMAND Panel,"'^BVP-500,PCLOCK'" Sets the password to PCLOCK for the specific PC control button. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 168: Bvt

    ClearA[ll] - Clear all popup pages from all pages page name = 1 - 50 ASCII characters. Example: SEND COMMAND Panel,"'^DPF-409,Prev'" Deletes the assignment of a button from flipping to a previous page. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 169: Ena

    2 = Invert vertical axis 3 = Invert both axis locations For a bargraph 1 = Invert , 0 = Non Invert Example: SEND_COMMAND Panel,"'^GIV-500,3'" Inverts the joystick axis origin to the bottom right corner. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 170: Glh

    = 1 - 4000. color value = Refer to the RGB Values for all 88 Basic Colors table on page 139. Example: SEND_COMMAND Panel,"'^GSC-500,12'" Changes the bargraph or joystick slider color to Yellow. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 171: Gsn

    = 0 - 9900 (a value of 0 is clear). Example: SEND_COMMAND Panel,"'^ICO-500.504&510.515,1&2,1'" Sets the icon for On and Off states for buttons with variable text ranges of 500-504 & 510-515. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 172: Jsb

    Zero can be used for an absolute position Example: SEND_COMMAND Panel,"'^JSI-500.504&510.515,1&2,1'" Sets the Off/On state icon alignment to upper left corner for those buttons with variable text range of 500-504 & 510-515. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 173: Jst

    "'^SHO-<vt addr range>,<command value>'" Variables: variable text address range = 1 - 4000. command value = (0= hide, 1= show). Example: SEND_COMMAND Panel,"'^SHO-500.504&510.515,0'" Hides buttons with variable text address range 500-504 & 510-515. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 174: Skt

    Note: Move should be used with caution. This setting can generate a significant amount of traffic to the master depending on user interaction. Example command: "'^TOP-1'" Example Response: "String Event: Text: Press,320,480" Example Response: "String Event: Text: Release,320,480" NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 175: Txt

    SEND_COMMAND TP,"'^UNI-1,0,0041'" Note: Unicode is always represented in a HEX value. TPD4 generates (through the Text Enter Box dialog) unicode HEX values. Refer to the TPDesign4 Instruction Manual for more information. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 176: Text Effects Names

    // Text Effect Color CUSTOM_EVENT[TP,529,1010] // Word Wrap CUSTOM_EVENT[TP,529,1011] // ON state Border Color CUSTOM_EVENT[TP,529,1012] // ON state Fill Color CUSTOM_EVENT[TP,529,1013] // ON state Text Color CUSTOM_EVENT[TP,529,1014] // Border Name CUSTOM_EVENT[TP,529,1015] // Opacity NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 177: Bcb

    The result sent to the Master would be: ButtonGet Id = 529 Type = 1011 Flag VALUE1 = 1 VALUE2 = 9 VALUE3 = 0 TEXT = #222222FF TEXT LENGTH = 9 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 178: Bcf

    The result sent to Master would be: ButtonGet Id = 529 Type = 1013 Flag VALUE1 = 1 VALUE2 = 9 VALUE3 = 0 TEXT = #FFFFFEFF TEXT LENGTH = 9 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 179: Bmp

    Gets the button 'OFF state' opacity information. The result sent to the Master would be: ButtonGet Id = 529 Type = 1015 Flag VALUE1 = 1 VALUE2 = 200 VALUE3 = 0 TEXT TEXT LENGTH = 0 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 180: Brd

    Gets the button 'OFF state' word wrap flag status information. The result sent to the Master would be: ButtonGet Id = 529 Type = 1010 Flag VALUE1 = 1 VALUE2 = 1 VALUE3 = 0 TEXT TEXT LENGTH = 0 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 181: Fon

    Gets the button 'OFF state' icon index information. The result sent to the Master would be: ButtonGet Id = 529 Type = 1003 Flag VALUE1 = 2 VALUE2 = 12 VALUE3 = 0 TEXT TEXT LENGTH = 0 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 182: Jsb

    Gets the button 'OFF state' icon justification information. The result sent to the Master would be: ButtonGet Id = 529 Type = 1006 Flag VALUE1 = 1 VALUE2 = 6 VALUE3 = 0 TEXT TEXT LENGTH = 0 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 183: Jst

    The result sent to the Master would be: ButtonGet Id = 529 Type = 1009 Flag VALUE1 = 1 VALUE2 = 9 VALUE3 = 0 TEXT = #5088F2AE TEXT LENGTH = 9 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 184: Tef

    The result sent to the Master would be: ButtonGet Id = 529 Type = 1001 Flag VALUE1 = 1 VALUE2 = 14 VALUE3 = 1 TEXT = This is a test TEXT LENGTH = 14 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 185: Panel Runtime Operations

    Pops up the Keypad and initializes the text string '12345'. AKEYR Remove keyboard or keypad that was displayed using 'AKEYB', 'AKEYP', 'PKEYP', @AKB, @AKP, @PKP, @EKP, or @TKP commands. Syntax: "'AKEYR'" Example: SEND COMMAND Panel,"'AKEYR'" Removes the Keyboard/Keypad. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 186: Akp

    = 0 - 100. Example: SEND COMMAND Panel,"'@BRT-70'" Sets the brightness level to 70. DBEEP Output a double beep. Syntax: "'DBEEP'" Example: SEND COMMAND Panel,"'DBEEP'" Outputs a double beep. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 187: Ekp

    SHUTDOWN Shut down the batteries providing power to the panel. This function saves the battery from discharging. Syntax: "'SHUTDOWN'" Example: SEND COMMAND Panel,"'SHUTDOWN'" Shuts-down the batteries feeding power to the panel. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 188: Sleep

    = 1 - 50 ASCII characters. prompt text = 1 - 50 ASCII characters. Example: SEND COMMAND Panel,"'@TKP-999.222.1211;Enter Phone Number'" Pops-up the Keypad and initializes the text string '999.222.1211' with prompt text 'Enter Phone Number'. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 189: Tnc

    SEND COMMAND Panel,"'@VKB'" Pops-up the virtual keyboard. WAKE Force the panel out of screen saver mode. Syntax: "'WAKE'" Example: SEND COMMAND Panel,"'WAKE'" Forces the panel out of the screen saver mode. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 190: Input Commands

    Sets the mouse button mode for the virtual PC to LEFT. ^MDC Set the mouse double click ON for the virtual PC. Syntax: "'^MDC'" Example: SEND COMMAND Panel,"'^MDC'" Enables the double click for the virtual PC. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 191: Mps

    ASCII character set. Syntax: "'^VKS-<string>'" Variable: string = Only 1 string per command/only one stroke per command. Example: SEND COMMAND Panel,"'^VKS-'8" Sends out the keystroke 'backspace' to the G4 application. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 192: Embedded Codes

    ($9B) SYSRQ ($9C) ($9D) Windows ($9E) Menu ($9F) Up Arrow ($A0) Down Arrow ($A1) Left Arrow ($A2) Right Arrow ($C0) CTRL key up ($C1) ALT key up ($C2) Shift key up NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 193: Panel Setup Commands

    75% of free Flash space), the size reverts to the maximum size allowed. Syntax: “’^CFS-<size in MB>’” Variable: size in MB - MB of allocated Flash memory Example: SEND_COMMAND Panel, “’^CFS-12’” Modifies the Flash cache size to 12MB. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 194: Cfsm

    Variables: password level = 1 - 4. page flip password = 1 - 50 ASCII characters. Example: SEND COMMAND Panel,"'^PWD-1,Main'" Sets the page flip password on Password Level 1 to 'Main'. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 195: Dynamic Image Commands

    Note that the %%5F in the file path is actually encoded as %5F. ^RFR Force a refresh for a given resource. Syntax: "'^RFR-<resource name>'" Variable: resource name = 1 - 50 ASCII characters. Example: SEND_COMMAND Panel,"'^RFR-Sports_Image'" Forces a refresh on ’Sports_Image’. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 196: Raf, ^Rmf - Embedded Codes

    Set protocol. HTTP (0) or FTP (1). ’%P <0-1>’ user Set Username for authentication. ’%U <user>’ password Set Password for authentication. ’%S <password>’ host Set Host Name (fully qualified DNS or IP Address). ’%H <host>’ NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 197: Escape Sequences

    Neuron ID (Only supported on panels that use ICSNet; ignored on all other panels) X resolution of current panel mode/file Y resolution of current panel mode/file Current state Address code Address port Channel code Channel port Level code NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 198: Intercom Commands

    Set the state of the microphone on a panel to muted (1) or unmuted (0). At the start of each call the microphone starts out unmuted. Syntax: "'^ICM-MUTEMIC,<state>'" Variables: 0 - unmuted 1 - muted Example: SEND_COMMAND Panel, "'^ICM-MUTEMIC,1'" Sets the microphone to muted. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 199: Ics

    SEND_COMMAND TP1, "^ICS-192.168.0.3,9000,9002,0" SEND_COMMAND TP2, "^ICS-192.168.0.4,9002,9000,1" ^MODEL? Gets the panel model name. Syntax: "'^MODEL?'" Example: SEND_COMMAND Panel,"'^MODEL?'" The panel (an MVP-8400i) responds with, ^MODEL-MVP-8400i NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 200: Sip Commands

    ID = The identifying number of the connection. state = IDLE, HOLD, or CONNECTED extn = The local extension of this panel (see Example) Example: SEND_COMMAND Panel,"'^PHN-LINESTATE, 1, IDLE, 2, CONNECTED, SIP, <extn>'" NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 201: Phn-Msgwaiting

    Indicates the panel is redialing the number. Syntax: "'^PHN-REDIAL, <number>'" Variable: number = The phone number to dial. Example: SEND_COMMAND Panel,"'^PHN-REDIAL, 2125551000’" ^PHN- Indicates a call has been transferred. TRANSFERRED Syntax: "'^PHN-TRANSFERRED'" Example: SEND_COMMAND Panel,"'^PHN-TRANSFERRED’" NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 202: Touch Panel Sip Commands

    SEND_COMMAND Panel,"'^PHN-DECLINE,0"" ^PHN-DTMF Sends DTMF codes. Syntax: "’^PHN-DTMF, <DTMF code>’" Variable: DTMF code = 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, POUND, or ASTERISK. Example: SEND_COMMAND Panel,"'^PHN-DTMF, 1234567879ASTERISK'" NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 203: Phn-Hangup

    "’^PHN-TRANSFER, <connection id>, <number>’" Variable: connection id = The identifying number of the connection number = The number to which you want to transfer the call. Example: SEND_COMMAND Panel,"'^PHN-TRANSFER, 1, 2125551000'" NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 204: Sip Setup Commands

    IP = The IP address for the proxy server Example: SEND_COMMAND Panel,"’^PHN-SETUP-PROXYADDR, 192.168.223.111’" ^PHN-SETUP-STUNADDR Sets the IP address for the STUN server. Syntax: "’^PHN-SETUP-STUNADDR, <IP>’" Variable: IP = The IP address for the STUN server Example: SEND_COMMAND Panel,"’^PHN-SETUP-STUNADDR, 192.168.223.111’" NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 205: Phn-Setup-Username

    SIP Setup Commands (Cont.) ^PHN-SETUP-USERNAME Sets the user name for authentication with the proxy server. Syntax: "’^PHN-SETUP-USERNAME, <username>’" Variable: username = The user name (usually the phone extension) Example: SEND_COMMAND Panel,"’^PHN-SETUP-USERNAME, 6003’" NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 206 Programming NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 207: Troubleshooting

    System Tray. • Double click on the icon to bring up the list of USB devices (you should see the "AMX USB LAN LINK" device in the list). • If the "Install Driver" dialog doesn't appear automatically, select the "Properties"...
  • Page 208 PC (either within the NetLinx Studio or TPDesign4 connecting. applications). • Remove the USB connector from the panel and close any AMX applications. • Reboot the panel. • Launch the AMX application and attempt reconnect to the panel.
  • Page 209 • This is due to the graphics controller settings in the firmware. • Update to the latest v2.XX.XX firmware. • Visit the www.amx.com > Tech Center > Downloadable Files > Firmware Files > Modero panels. Then Download the KIT file to your computer.
  • Page 210 "graphics hierarchy" errors, etc.… indicating problems with the Compact Flash. • Panel will not boot, or gets stuck on "AMX" splash screen. • Other problems also started after downloading to a new panel or a panel with a TPD4 file that takes up a considerable amount of the available Compact Flash.

  • Page 211: Appendix A - Text Formatting Codes

    Example Format Display $A out of $R 32 out of 100 $A of 0 - $R 32 of 0 - 100 $V of $L - $H 532 of 500 - 600 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 212 Appendix A - Text Formatting Codes NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 213: Appendix B - Text Area Input Masking

    ^BIM - Sets the input mask for the specified addresses. (see the ^BIM section on page 145).  ^BMF subcommand %MK - sets the input mask of a text area (see the ^BMF section on page 147). NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 214: Input Mask Ranges

    If a user enters a value that is larger than the max, the maximum number of right-most characters is used to create a new, acceptable value. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 215: Input Mask Output Examples

    Any value from 1 to 12 Minute/Second [0|59]{:} Any value from 0 to 59 Frames [0|29]{:} Any value from 0 to 29 Phone Numbers (999) 000-0000 (555) 555-5555 Zip Code 00000-9999 75082-4567 NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 216 Appendix B - Text Area Input Masking NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 217: Appendix C - Url Resources

    Mac Address Address Port Neuron ID Channel Code X Resolution of current panel mode/file Channel Port Y Resolution of current panel mode/file Level Code X Resolution of current button Level Port NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 218 Appendix C - URL Resources NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 219: Appendix D - Wireless Technology

    Although the calculations required to encrypt data with WEP can impact the performance of your wireless network, it's generally seen only when running benchmarks, and not large enough to be noticeable in the course of normal network usage. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 220: Terminology

    The certificate authority (CA) is a trusted external third party which "signs" or validates the certificate. When a certificate has been signed, it gains some cryptographic properties. AMX supports the following security certificates within three different formats: ...

  • Page 221: Wpa2

    With the RC4 released to the general public the IEEE implemented the Advanced Encryption Standard (AES) as the cipher engine for 802.11i, which the Wi-Fi Alliance has branded as WPA2. FIG. 104 WPA2 Overview NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 222: Eap Authentication

    • Easy deployment • Susceptible to MS-CHAP and MS-CHAPv2 dictionary attacks • Fixed Passwords authentication protocols • One-time passwords (tokens) EAP-FAST • Certificates • N/A • N/A • N/A • Fixed Passwords • One-time passwords (tokens) NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 223: Eap Communication Overview

    RADIUS server). As an example, the WAP might switch the panel to a particular VLAN or install a set of firewall rules. NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...

  • Page 224: Amx Certificate Upload Utility

    Step 2: Confirm the Installation of the USB Driver on the PC The first time each AMX touch panel is connected to the PC it is detected as a new hardware device and the USBLAN driver becomes associated with it (panel specific).
  • Page 225 If this is your first time installing the USB driver, a USB driver installation popup window appears on the PC. Complete the USB driver installation process by clicking Yes and then installing the new AMX USB LAN LINK when told that a new USB device was found.

  • Page 226: Uploading A Certificate File

    Appendix D - Wireless Technology Uploading a Certificate File Install the latest AMX USB LAN LINK driver onto your computer by installing the latest versions of either TPDesign4 or NetLinx Studio2.  This USB driver prepares your computer to properly communicate with a directly connected G4 touch panel (MVP/CV7/CV10/700Vi/1000Vi).
  • Page 227 Appendix D - Wireless Technology NXD-1000Vi 10" Modero® Wall/Flush Mount Touch Panel with Intercom...
  • Page 228 It’s Your World - Take Control™ 3000 RESEARCH DRIVE, RICHARDSON, TX 75082 USA • 800.222.0193 • 469.624.8000 • 469-624-7153 fax • 800.932.6993 technical support • www.amx.com...

Table of Contents
