IN STR U CT IO N MAN U AL
®
M O DE RO
VG S E R I ES WA L L / F LU S H M O U N T TO U CH PA N E L S
NX D/ T- 1200 VG 12" MODER O TOUCH PAN EL
NX D/ T- 1500 VG 15" MODER O TOUCH PAN EL
NX D/ T- 17 00VG 1 7" MODER O TOUCH PAN EL

Advertisement

Table of Contents
loading

Related Manuals for AMX NXD-1700VG

Summary of Contents for AMX NXD-1700VG

  • Page 1 IN STR U CT IO N MAN U AL ® M O DE RO VG S E R I ES WA L L / F LU S H M O U N T TO U CH PA N E L S NX D/ T- 1200 VG 12"...

  • Page 2: Copyright Notice

    COPYRIGHT NOTICE AMX© 2015, all rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of AMX. Copyright protection claimed...

  • Page 3: Table Of Contents

    Table of Contents Table of Contents Modero VG Series Touch Panels ..............12 Overview ......................... 12 Multimedia Streaming Video Touch Panels (VG-Series)..........12 Product Specifications - NXD/T-1200VG ..................... 13 Product Specifications - NXD/T-1500VG ..................... 15 Product Specifications - NXD/T-1700VG ..................... 17 NXA-RGB Supported Resolutions and Formats ..................
  • Page 4 Table of Contents Installation and Upgrade of the Internal NXD Components .......... 37 Step 1: Remove the existing NXD Outer Housing ................. 37 Step 2: Install the new 802.11g mini-PCI Wireless card (NXD)............37 Step 3: Install the new RGB Card Component (NXD) ................38 Step 4: Install the new Compact Flash Memory card (NXD) ..............
  • Page 5 Installing the NXD-1700VG within a CB-TP17 Conduit Box..............63 Installing the NXD-1700VG Into Drywall Using Expansion Clips ............64 Installing the NXD-1700VG into a Flat Surface using #6 Screws ............67 Installing an NXD Into an (Optional) Rack Mount Kit (NXA-RK17) ............69 Wiring Guidelines for the 1700VG Panels..............
  • Page 6 Table of Contents Configuring the Modero’s wireless card for secured access to a WAP200G ........82 Configuring multiple wireless Moderos to communicate to a target WAP200G........84 Configuring a Wired Ethernet Connection ..............84 Step 1: Configuring the Panel’s Wired IP Settings ............84 IP Settings section - Configuring a DHCP Address over Ethernet............
  • Page 7 Table of Contents Video - RGB Settings Page ........................108 Adjusting the Incoming Signal on the RGB Settings Page ..............110 Video - Streaming Settings Page ......................112 Battery Base Page..........................114 Protected Setup Navigation Buttons................116 Protected Setup Page....................117 Security Settings ..........................
  • Page 8 Table of Contents Button Assignments ....................140 Page Commands......................140 @APG....................................140 @CPG....................................140 @DPG ....................................140 @PDR ....................................141 @PHE ....................................141 @PHP ....................................141 @PHT ....................................141 @PPA ....................................141 @PPF....................................141 @PPG ....................................142 @PPK ....................................142 @PPM....................................
  • Page 9 Table of Contents ^DTO ....................................156 ^ENA ....................................156 ^FON ....................................157 ^GDI..................................... 157 ^GIV..................................... 157 ^GLH ....................................157 ^GLL..................................... 157 ^GRD ....................................158 ^GRU....................................158 ^GSC ....................................158 ^GSN ....................................158 ^ICO..................................... 159 ^JSB ..................................... 159 ^JSI...................................... 159 ^JST ..................................... 159 ^MBT....................................
  • Page 10 Table of Contents BRIT ..................................... 172 @BRT ....................................172 DBEEP ....................................172 @EKP ....................................172 PKEYP....................................172 @PKP ....................................172 SETUP ....................................173 SHUTDOWN..................................173 SLEEP ....................................173 @SOU....................................173 @TKP ....................................173 TPAGEON ..................................... 173 TPAGEOFF .................................... 173 @VKB ....................................173 WAKE ....................................
  • Page 11 Table of Contents Input mask character types ....................... 184 Input mask ranges..........................184 Input mask next field characters ....................... 184 Input mask operations ........................184 Input mask literals..........................185 Input mask output examples......................185 URL Resources......................185 Special escape sequences........................185 Modero VG Series Touch Panels - Instruction Manual...

  • Page 12: Modero Vg Series Touch Panels

    15" Modero Multimedia WallMount Touch Panel with Video Kit. NXT-1500VG (FG2252-61V) 15" Modero Multimedia Table Top Touch Panel with Video Kit. NXD-1700VG (FG2256-61V) 17" Modero Widescreen WallMount Touch Panel with Video Kit. NXT-1700VG (FG2257-61V) 17" Modero Widescreen Table Top Touch Panel with Video Kit.

  • Page 13: Product Specifications - Nxd/T-1200Vg

    Memory: 256 MB on-board memory Compactflash: 2GB or greater (upgradeable to 4GB - see Other AMX Equipment). Note: AMX may increase Compactflash size at any time in response to market availability. Weight: 10.80 lbs (4.90 kg) LCD Parameters: • Aspect Ratio: 4:3 •...
  • Page 14 • Included within the Video Kit: - Modero VG Touch Panel (NXD/NXT-1200/1500/1700VG) - Modero 10’ foot Table Top Cable (CA2250-50) - NXA-AVB/ETHERNET Breakout Box (FG2254-10) Other AMX • CB-TP12 Conduit/Wallbox (FG031-10) Equipment: • CC-USB (Type A) to Mini-B 5-Wire programming cable (FG10-5965) •...

  • Page 15: Product Specifications - Nxd/T-1500Vg

    256 MB on-board memory Compactflash: 2GB or greater (upgradeable to 4GB - see Other AMX Equipment). Note: AMX may increase Compactflash size at any time in response to market availability. Weight: • NXD-1500VG: 13.45 lbs (6.10 kg) • NXT-1500VG: 17.15 lbs (7.78 kg) LCD Parameters: •...
  • Page 16 • Included within the Video Kit: - Modero VG Touch Panel (NXD/NXT-1200/1500/1700VG) - Modero 10’ foot Table Top Cable (CA2250-50) - NXA-AVB/ETHERNET Breakout Box (FG2254-10) Other AMX • CB-TP15 Conduit/Wallbox (FG032-10) Equipment: • CC-USB (Type A) to Mini-B 5-Wire programming cable (FG10-5965) •...

  • Page 17: Product Specifications - Nxd/T-1700Vg

    256 MB on-board memory Compactflash: 2GB or greater (upgradeable to 4GB - see Other AMX Equipment). Note: AMX may increase Compactflash size at any time in response to market availability. Weight: • NXD-1700VG: 18.20 lbs (8.26 kg) • NXT-1700VG: 22.00 lbs (9.98 kg) LCD Parameters: •...
  • Page 18 • Included within the Video Kit: - Modero VG Touch Panel (NXD/NXT-1200/1500/1700VG) - Modero 10’ foot Table Top Cable (CA2250-50) - NXA-AVB/ETHERNET Breakout Box (FG2254-10) Other AMX • CB-TP17 Conduit/Wallbox (FG034-10) Equipment: • CC-USB (Type A) to Mini-B 5-Wire programming cable (FG10-5965) •...

  • Page 19: Nxa-Rgb Supported Resolutions And Formats

    Modero VG Series Touch Panels NXA-RGB Supported Resolutions and Formats The following table lists all NXA-RGB Supported Resolutions and Formats: NXA-RGB Supported Resolutions and Formats Supported Format Resolution Refresh Rate VGA Compatible signals 560 x 192 60 Hz Apple II 560 x 384 60 Hz MAC 12"...

  • Page 20: Connecting And Using Usb Input Devices

    Modero VG Series Touch Panels Connecting and Using USB Input Devices These panels can have up to two USB-capable input devices connected for use both on its different firmware and TPD4 panel pages. These input devices can consist of a keyboard or mouse. NOTE: USB-connected input devices are detected and recognized by the panel upon connection.

  • Page 21: Touch Panel Accessories

    Touch Panel Accessories Overview The following section outlines and describes both the included accessories and other AMX equipment available for both the Video and Video/RGB models of touch panels. NOTE: When working with f irmware, it is important to note that version 1.xx of f irmware should only be loaded onto box’s using 1.xx series f irmware.

  • Page 22: Rgb Rj-45 Connection And Wiring Information

    Breakout Box to the VG-Series Modero panel. Standard CAT5 cable can be used for this connection with short cable runs under 50 feet (15.24 m). For cable runs over 50 feet (15.24 m), AMX recommends using the Belden Brilliance VideoTwist 7987. This Belden cable is not CAT5 compliant, but is designed to control skew between the red, green, and blue video signals.

  • Page 23: Using The Hd-15 High-Density Connector

    Touch Panel Accessories Using the HD-15 High-Density Connector Connect the RGB/Comp source equipment HD-15 (male) connector to the RGB/COMPONENT HD-15 high-density connector (female) on the rear of the NXA-AVB/RGB Breakout Box. The following table below lists the HD-15 connector pinouts. HD-15 Connector Pinouts Signal Function...

  • Page 24: Wiring The Nxa-Avb/Rgb Connectors And Cables

    An example of this cable is to strip the terminal ends of a 3.5mm mini-jack and insert them into their respective locations on the Mic Out port. This signal can be fed as a Line Level In to either an amplifier or an AMX VOL card.

  • Page 25: Wiring The Nxa-Avb/Rgb For Unbalanced Audio

    Touch Panel Accessories Wiring the NXA-AVB/RGB for Unbalanced Audio Most domestic audio equipment has unbalanced audio inputs and outputs. This means that the audio output (left, right, or mono) appears on a single wire, and is referenced to "0 V" or "Ground". Typical connectors used are RCA "phono" connectors, DIN plugs/ sockets, and 0.25"...

  • Page 26: Wiring For Pass-Thru Computer Control

    Touch Panel Accessories Properly connect the NXA-AVB/RGB to both a target PC and touch panel using the appropriate cabling. Refer to the following Wiring for Pass-Thru Computer Control section on page 26 for more detailed information. Enable pass-thru via the use of either the ^MPS or ^KPS commands (page 174). Set up a touch panel page (via TPDesign4) with the necessary Video Fill >...

  • Page 27: Nxa-Mtc/Rgb Combo Table Top Cable (Ca2250-70)

    • One NXA-MTC/RGB Combo Table Top Cable (CA2250-70) • One black tie wrap (used to join the Ethernet and Power cables) Other AMX Equipment: Note: All 1200V, VG-Series, and CV10 Table Top panels routing an Audio/Video signal from a breakout box must use the appropriate number of CAT5 Suppression Ferrites which are included as part of installation kits accompanying your particular Modero panel.

  • Page 28: Wiring And Connection Information

    NXD-1500VG RGB KIT, 15" MODERO WALLMOUNT RGB KIT FG2252-61RGB NXT-1500VG RGB KIT, 15" MODERO TABLETOP RGB KIT FG2256-61RGB NXD-1700VG RGB KIT, 17" MODERO WALLMOUNT RGB KIT FG2257-61RGB NXT-1700VG RGB KIT, 17" MODERO TABLETOP RGB KIT FG2255-11 NXA-RGBKIT, RGB UPGRADE KIT FOR EXISTING VG PANELS Wiring and Connection Information FIG.

  • Page 29: Nxa-Rgb Rgb/Vga Interface Card (Fg2260)

    NXA-RGB RGB/VGA Interface Card (FG2260) The NXA-RGB (FIG. 12) is an RGB/VGA plug-in interface card that allows any of AMX’s VG-Series Modero Touch Panels to accept either RGB or HDTV Component signals directly from an external source when routed through an optional NXA-AVB/RGB Breakout Box.

  • Page 30: Product Specifications

    - NXT Table Top replacement I/O plate with RGB connector opening (62-2250-59) - NXD WallMount replacement adhesive overlay for existing I/O plate (53-2250-03) Other AMX Equipment: • Included within the RGB Kit (FGxxxx-xxRGB) is the following: - Modero VG Touch Panel (NXD/NXT-1200/1500/1700VG)

  • Page 31: Rgb Rj-45 Connection And Wiring Information

    Breakout Box to the VG-Series Modero panel. Standard CAT5 cable can be used for this connection with short cable runs under 50 feet (15.24 m). For cable runs over 50 feet (15.24 m), AMX recommends using the Belden Brilliance VideoTwist 7987. This Belden cable is not CAT5 compliant, but is designed to control skew between the red, green, and blue video signals.

  • Page 32: Product Specifications

    • Operates from 2.300-2.500 GHz • Operate at ISM frequency bands (2.4GHz) with 54Mbps data rate • Pre-configured to communicate with current AMX Wireless Access Points • Support for IEEE 802.11b and 802.11g • Wired Equivalent Privacy (WEP) 64-bit and 128-bit data encryption Frequency Range: •...

  • Page 33: Installation And Upgrade Of The Internal Nxt Components

    - NXD-1200V - NXD-1200VG - NXD-1500VG - NXD-1700VG Installation and Upgrade of the Internal NXT Components Upgrading the components within each of the Table Top panels involves removing the outer housing (with speaker plate), removing and/or installing an existing component, and then placing the outer housing back onto the NXT panel, as described in the following sections.

  • Page 34: Step 2: Install The 802.11G Mini-Pci Wireless Card

    Touch Panel Accessories Gently tilt the LCD backward to a 45° angle. In a single motion, carefully pull the outer housing up and then out (away from the LCD panel) to expose the internal circuit board (FIG. 19). The NXA-RGB card is available within both the optional RGB Kit and NXA-RGBKIT upgrade. Unscrew the Stereo Output nut from the Stereo Output jack.

  • Page 35: Step 3: Install The Nxa-Rgb Card Component (Nxt)

    Touch Panel Accessories Antennas connectors Connection point between the braces and the mini-PCI card Installation of the mini-PCI card connector on main board FIG. 18 Locate the terminal ends of the antennas and apply downward pressure to "snap" them onto their gold-tipped counterparts on the mini-PCI card (FIG.

  • Page 36: Step 4: Install The Compact Flash Memory Card Upgrade

    Touch Panel Accessories Step 4: Install the Compact Flash Memory Card upgrade Discharge any static electricity from your body by touching a grounded metal object and then locate the existing Compact Flash card (factory-shipped with 128 MB) on the main board (FIG. 20 for Table Top panels and FIG. 23 for Wall Mount panels). Outer Housing NXA-PCI80211G wireless card...

  • Page 37: Step 5: Close And Re-Secure The Nxt Panel Enclosure

    Touch Panel Accessories Step 5: Close and Re-secure the NXT Panel Enclosure Obtain the new RGB I/O connector plate (similar to the original but containing the added RGB connector opening to the newly installed NXA-RGB) and slide it back into position. Re-secure the Stereo Output nut back onto the new Stereo Output jack onto the new RGB I/O plate.

  • Page 38: Step 3: Install The New Rgb Card Component (Nxd)

    Touch Panel Accessories Step 3: Install the new RGB Card Component (NXD) Discharge any static electricity from your body by touching a grounded metal object. Locate the RGB card’s slot connector on the main board and align it with its counterpart on the bottom of the NXA-RGB card. Carefully, but firmly, insert the NXA-RGB card into the RGB connector slot on the main board until both the card rests atop the four raised securing holes and the RGB RJ-45 connector is evenly aligned with the other RJ-45 connectors on the back of the panel.

  • Page 39: Nxt-Bp Power Pack (Fg2255-10)

    Touch Panel Accessories NXT-BP Power Pack (FG2255-10) The NXT-BP Power Pack (FIG. 25) is a rechargeable Lithium-Ion "smart" battery used to provide power to the NXT Modero panel through the NXA-BASE/B Battery Base. This battery incorporates an on-board battery life indicator. The NXT-BP battery can be charged through either the base (when connected to the Modero panel) or through an optional NXT-CHG Modero Power Station.

  • Page 40: Checking The Nxt-Bp Battery Charge

    • Operating Humidity: 20% - 85% RH • Storage Temperature: -20° C (-4° F) to 60° C (140° F) • Storage Humidity: 5% - 85% RH Other AMX Equipment: • NXT-CHG Kit (FG2250-50K): 1 charger (FG2250-50) and 2 NXT-BP batteries (FG2255-10) •...

  • Page 41: Installing An Nxt-Bp Into The Nxa-Base/B

    Touch Panel Accessories Bottom view Top view Interface connector (male) Panel Interface Alignment connector pegs (female) Captive fasteners NXA-BASE/B shown aligning with NXT panel FIG. 29 Firmly grip both the panel (from the side) and battery base (from below) together. Gently place the touch panel LCD facedown onto a soft cloth (this prevents scratching of the LCD while the battery base is being secured).

  • Page 42: Charging The Nxt-Bp Batteries With The Nxa-Base/B

    Repeat steps 2 through 4 for the other battery. Apply a small amount of pressure to close the battery compartment until the compartment latches. After a few seconds, the panel will turn On and the AMX logo will appear (indicating the panel is receiving power. ...

  • Page 43: Reading Nxt-Chg Led Indicator

    Touch Panel Accessories Reading NXT-CHG LED Indicator FIG. 32 shows the components on the NXT-CHG Smart Battery Charger. Slot 1 (recalibration) Slot 2 Slot 1 Slot 2 Recalibrate Pushbutton Component locations on the NXT-CHG FIG. 32 There is one LED indicator on the front of each battery slot that indicates the status of that slot. The blink patterns for these LEDs are described in the following table: •...

  • Page 44: Installation Procedures: 12" And 15" Panels

    Inspect and confirm the contents of the shipment box to verify that you have all specified parts. Refer to the Specif ications sections on page 13 and page 15 for more information about included accessories and other AMX equipment. Carefully remove the panel from the shipping box.

  • Page 45: Installing The Mp-Tp12/15 Back Box

    Installation Procedures: 12" and 15" Panels DO NOT REMOVE DO NOT REMOVE these these panel panel securing screws securing screws Unscrew these four Housing Screws to remove the back box. These make direct contact with the black outer housing. Location of the attachment screws on the NXD back box FIG.

  • Page 46: Cable Installation For The Mp-Tp12/15 Back Box

    Installation Procedures: 12" and 15" Panels Cable Installation for the MP-TP12/15 Back Box Connect the cable connectors (RJ-45, Ethernet, and any other audio/video wiring) to their respective locations along the side of the touch panel. Use the tie-wrap (45-0009A) to wrap the cables together inside the VESA Mount enclosure. This cable tie is used to insure the cable will not pull through or work itself through the new larger strain relief grommet (45-0032-01) over time.

  • Page 47: Pre-Wall Installation Of The Conduit Boxes

    NOTE: When installing a VESA mount to the rear plastic cover, use only the AMX provided #8-32 screws. 11. Secure the four #8-32 screws to the rear plastic cover with a grounded Phillips-head screwdriver to secure the VESA mount to the rear of the panel.

  • Page 48: Installation Of The Nxd Touch Panel

    Installation Procedures: 12" and 15" Panels Remove any necessary wiring knockouts from the (optional) CB-TP12/15 conduit box (C in FIG. 39) where the necessary cables are threaded through for connection to the touch panel. Thread the incoming RJ-45, Ethernet, and any other audio/video wiring through the knockouts. Refer to the Wiring Guidelines for the 1200VG and 1500VG Panels section on page 56 for pinout descriptions.

  • Page 49: Installing The Nxd Into Drywall Using Expansion Clips

    Installation Procedures: 12" and 15" Panels Insert and secure the four securing #4-40 Mounting Screws into their corresponding holes located along the sides of the NXD (FIG. 38 and FIG. 39). Place the magnetic faceplate (A in FIG. 39) back onto the main NXD unit (B in FIG. 39). Make sure to align the Microphone, Light, and PIR Motion sensor locations to their respective openings on the front bezel/faceplate.
  • Page 50 Installation Procedures: 12" and 15" Panels Remove the magnetic faceplate/bezel (A in FIG. 42) from the main NXD unit (B in FIG. 42) by gripping the faceplate and pulling with gentle outward force. * Notches are NOT SYMMETRICAL CUTOUT FRONT BEZEL NXD-1500VG 15-inch Wall Mount panel dimensions using expansion clips FIG.
  • Page 51 Wall Mount panel (NXD) installation configuration for drywall surfaces FIG. 42 NOTE: The drywall clip set must be re-ordered from AMX if the drywall clip is bent accidentally during an installation or removed during a re-installation. 11. Place the magnetic faceplate (A in FIG. 42) back onto the main NXD unit (B in FIG. 42). Make sure to align the Microphone, Light, and PIR Motion sensor locations to their respective openings on the front bezel/faceplate.

  • Page 52: Installing The Nxd Into A Flat Surface Using #4 Screws

    Installation Procedures: 12" and 15" Panels Installing the NXD Into a Flat Surface Using #4 screws Mounting screws (#4, not included) are secured through circular holes located at the left and right sides of the NXD panel. The most important thing to remember when mounting the NXD is that the outer frame (Mounting Tabs) must be installed flush against the mounting surface.
  • Page 53 Installation Procedures: 12" and 15" Panels Remove the magnetic faceplate/bezel (A in FIG. 45) from the main NXD unit (B in FIG. 45) by gripping the faceplate and pulling with gentle outward force. CUTOUT FRONT BEZEL NXD 15-inch Wall Mount panel dimensions using #4 mounting screws FIG.

  • Page 54: Installing An Nxd Into An (Optional) Rack Mount Kit (Nxa-Rk12 Or Nxa-Rk15)

    Installation Procedures: 12" and 15" Panels Attachment is done Flat surface along the edges of (can include a the cutout wall, podium, or other flat Install the four (#4) surface) mounting screws into the holes (screws not included) B - Main NXD unit consists of A - Faceplate the touch panel and housing (bezel)
  • Page 55 Installation Procedures: 12" and 15" Panels Faceplate Rack mount frame (NXA-RK12) NXD 12 inch Wall Mount panel installed into an NXA-RK12 Rack Mount Kit FIG. 46 Faceplate Rack mount frame (NXA-RK125) NXD 15 inch Wall Mount panel installed into an NXA-RK15 Rack Mount Kit FIG.

  • Page 56: Wiring Guidelines For The 1200Vg And 1500Vg Panels

    Installation Procedures: 12" and 15" Panels Wiring Guidelines for the 1200VG and 1500VG Panels These Modero panels use a 12 VDC-compliant power supply to provide power to the panel via the 2-pin 3.5 mm mini-Phoenix PWR connector. Use the previously referenced power requirements to determine the power draw. The incoming PWR and GND wires from the power supply must be connected to the corresponding locations within the PWR connector.

  • Page 57: Ethernet/Rj-45 Port: Connections And Wiring

    Installation Procedures: 12" and 15" Panels Ethernet/RJ-45 Port: Connections and Wiring FIG. 49 describes the blink activity for the Ethernet 10/100 Base-T RJ-45 connector and cable. The Ethernet cable is connected to the rear of Table Top and side of the Wall Mount panels. A - Activity LED (yellow) L - Link LED (green) lights when lights when receiving or...

  • Page 58: Installation Procedures: 17" Panels

    Removing the Original Modero Back Box Detach all connectors from the side of the touch panel. Remove the magnetic faceplate from the NXD-1700VG unit by gripping the faceplate and pulling outwards while applying a small amount of pressure to remove it from the main unit.

  • Page 59: Installing The Mp-Tp17 Back Box

    Installation Procedures: 17" Panels NOTE: DO NOT REMOVE THE FOUR PANEL SECURING SCREWS. These screws secure the LCD to the metallic casing underneath. Lift the back box housing to separate it from the internal panel casing. Installing the MP-TP17 Back Box Unscrew the four pan-head Housing Screws (#8-32) from the MB-TP17 rear plastic cover.
  • Page 60 NOTE: When installing a VESA mount to the rear plastic cover, use only the AMX provided #8-32 screws. 11. Secure these four #8-32 screws to the rear plastic cover by using a grounded Phillips-head screwdriver. This step secures the VESA mount to the rear of the panel.

  • Page 61: Pre-Wall Installation Of The Cb-Tp17 Conduit Box

    Installation Procedures: 17" Panels Pre-wall Installation of the CB-TP17 Conduit Box Wall Mount panels (NXDs) are contained within a metallic outer housing (back box). This back box is not removed when installing the NXD into a Conduit Box (CB-TP17). The back box is only removed to gain access for the replacement of the Compact Flash component or upgrade to the VESA housing.
  • Page 62 Installation Procedures: 17" Panels Inserted block bridges the gap between the Conduit Box and Stud the notched beam Knockouts should be located on the left-side of the conduit box, alongside the connectors Stud fastening holes Conduit Box can be fastened to both studs) Drywall/sheetrock Use four #8 flat-head...

  • Page 63: Installation Of An Nxd-1700Vg

    TP17 Conduit Box section on page 61 for detailed pre-wall installation instructions. Verify that all necessary cables have been threaded through the knockouts on the conduit box and the connections have been tested prior to installation of the NXD-1700VG. Remove the magnetic faceplate/bezel (A in FIG. 56) from the main NXD unit (B in FIG. 56) by gripping the faceplate and pulling with gentle outward force.

  • Page 64: Installing The Nxd-1700Vg Into Drywall Using Expansion Clips

    Installing the NXD-1700VG Into Drywall Using Expansion Clips Expansion clips are mounted through the four oval holes located along the rim of the NXD-1700VG. As the screw is tightened, the clip bends toward the insertion hole and into the wall. This bending creates a "grip" on the wall by either pressing onto the wall or by securing the drywall between the housing and the drywall clip.
  • Page 65 Remove any screws/nails from the drywall, along the notched beam, before beginning the cutout process. Cut out the surface for the NXD-1700VG Wall Mount using the dimensions shown in FIG. 58. Be sure to cut out the four notches along the top and bottom areas to accommodate the four drywall expansion clips (provided).
  • Page 66 (on the left). NOTE: Replacement drywall clip sets must be ordered from AMX. 17. Tighten the drywall clip sets (screws and clips) until the Mounting Tabs are securely fastened and flush against the wall.

  • Page 67: Installing The Nxd-1700Vg Into A Flat Surface Using #6 Screws

    Installation Procedures: 17" Panels Installing the NXD-1700VG into a Flat Surface using #6 Screws Mounting screws (#6, not included) are secured through two sets of circular holes located at the left and right sides of the NXD- 1700VG. The most important thing to remember when mounting the NXD Wall Mount is that the outer frame (Mounting Tabs) must be installed flush against the mounting surface.
  • Page 68 15. Carefully slide the main unit into the cutout until the Mounting Tabs of the NXD-1700VG unit lie flush against the wall. 16. Insert and secure the four #6 screws into their corresponding holes located along the sides of the NXD-1700VG (using a grounded Phillips-head screwdriver) until the unit is secure and flush against the wall.

  • Page 69: Installing An Nxd Into An (Optional) Rack Mount Kit (Nxa-Rk17)

    482.60 19.00 3.31 NXD-1700VG Wall Mount panel installed into an NXA-RK17 Rack Mount Kit FIG. 62 Secure the panel to the NXA-RK17 mount frame by first inserting and then tightening the four #4-40 screws. Insert the NXA-RK17 (with connected NXD unit) into the equipment rack, making sure to align the screw holes along the sides of the NXA-RK17 with the holes in the equipment rack.

  • Page 70: Wiring Guidelines For The 1700Vg Panels

    Installation Procedures: 17" Panels Wiring Guidelines for the 1700VG Panels 1700VG panels use a 12 VDC-compliant power supply to provide power to the panel via the 2-pin 3.5 mm mini-Phoenix PWR connector. Use the previously referenced power requirements to determine the power draw. The incoming PWR and GND wires from the power supply must be connected to the corresponding locations within the PWR connector.

  • Page 71: Ethernet/Rj-45 Port: Connections And Wiring

    Installation Procedures: 17" Panels Ethernet/RJ-45 Port: Connections and Wiring The Ethernet cable is connected to the rear of Table Top and side of the Wall Mount panels. See the Ethernet/RJ-45 Port: Connections and Wiring section on page 57 for details. A - Activity LED (yellow) L - Link LED (green) lights when lights when receiving or...

  • Page 72: Panel Calibration

    Modero panels are factory setup with specific demo touch panel pages. The first splash screen that appears indicates the panel is receiving power, beginning to load firmware, and preparing to display the default touch panel pages. When the panel is ready, the AMX Splash Screen is replaced by the Initial Panel Page (FIG. 65). AMX Splash Screen...

  • Page 73: Testing Calibration

    Panel Calibration After the "Calibration Successful." message appears, press anywhere on the screen to continue and return to the Setup page. NOTE: If the calibration was improperly set and you cannot return to the Calibrate page (through the panel’s f irmware); you can access this f irmware page via G4 WebControl where you can navigate to the Protected Setup page and press the Calibrate button through your VNC window.

  • Page 74: Configuring Communication

    USB connection of this type until after the unit cycles power. NOTE: Before commencing, verify you are using the latest NetLinx Master and Modero panel f irmware. Verify you are using the latest versions of AMX’s NetLinx Studio and TPDesign4 programs. Modero Setup and System Connection Press the grey Front Setup Access button for 3 seconds to open the Setup page (FIG.

  • Page 75: Configuring And Using Usb With A Virtual Master

    Launch the file by double-clicking on it and follow the on-screen prompts to complete your installation. Note that even if you have loaded the latest AMX Studio or TPD4 software, you will still need to download and install this f ile if you are working with either the 1200V-Series or VG-Series of panels.

  • Page 76: Step 2: Confirming The Installation Of The Usb Driver On The Pc

    Step 2: Conf irming the Installation of the USB Driver on the PC The first time each AMX touch panel is connected to the PC it is detected as a new hardware device and the USBLAN driver becomes associated with it (panel specif ic). Each time thereafter the panel is "recognized" as a unique USBLAN device and the association to the driver is done in the background.

  • Page 77: Step 3: Confirm And View The Current Amx Usb Device Connections

    To remove the USB driver association from a previously connected touch panel, you must navigate back to the Device Manager, right-click on the panel’s USB driver (example AMX USB LAN LINK #2) and select Uninstall from the context menu and then OK.

  • Page 78: Step 5: Confirm And View The Current Amx Usb Device Connections

    Virtual Master setup procedures (outlined in this section). Refreshing the System sends out a request to the panel to respond and completes the communication (turning the System Connection icon green). Step 5: Conf irm and View the current AMX USB device connections Use the CC-USB Type-A to Mini-B 5-wire programming cable (FG10-5965) to provide communication between the mini-USB Program port on the touch panel and the PC.

  • Page 79: Wireless Settings Page - Wireless Access Overview

    Ethernet Communication from the panel can be direct (using an Ethernet cable) or indirect (through the optional NXA-PCI80211G AMX Wireless Card (FG2255-04) communicating to a Wireless Access Point such as the NXA-WAP200G). In determining the Ethernet method of communication, the panel will always default first to the direct Ethernet communication. If no direct connection is detected, the panel will first check to see if there is an installed wireless interface card and then communicate to the WAP using the Wireless Settings assigned within the Wireless Settings page.

  • Page 80: Configuring A Wireless Connection

    Configuring Communication Conf iguring a Wireless Connection When working with a wireless card, the first step is to configure wireless communication parameters within the Wireless Settings page. This page only configures the card to communicate to a target WAP (such as the NXA-WAP200G), it is still necessary to tell the panel which Master it should be communicating with.

  • Page 81: Step 2: Configuring The Card's Wireless Security Settings

    The card should be given the SSID used by the target WAP. If this field is left blank, the unit will attempt to connect to the  first available WAP. By default, all WAP200Gs use AMX as their assigned SSID value. One of the most common problems associated with connection to a WAP arise because the SSID was not entered properly.

  • Page 82: Configuring The Modero's Wireless Card For Secured Access To A Wap200G

     You must maintain the same case when entering the SSID information. ABC is not the same as Abc. The alpha-numeric string is by default AMX but can later be changed to any 32-character entry. This string must be ...
  • Page 83 Configuring Communication 10. Toggle the Default Key field until the you’ve chosen a WEP Key value (from 1- 4) that matches what you’ll be using on your target WAP200G. These WEP Key identifier values must match for both devices. 11. With the proper WEP Key value displayed, press the Generate button to launch the WEP Passphrase keyboard. If you are wanting to have your target WAP (other than a 200G) generate the Current Key - Do not press the Generate button and continue with Step 14.

  • Page 84: Configuring Multiple Wireless Moderos To Communicate To A Target Wap200G

    Configuring Communication NOTE: The signal strength f ield provides some descriptive text regarding the strength of the connection to a Wireless Access Point. If there is no signal or no IP Address displayed; conf iguration of your network could be required. Refer to the NXA-WAP200G Instruction Manual for more detailed setup and configuration procedures.

  • Page 85: Step 2: Choosing A Master Connection Mode Setting

    Configuring Communication Press the optional Host Name field to open the Keyboard and enter the Host Name information. Press Done after you are finished assigning the alpha-numeric string of the host name. Press the Primary DNS field to open a Keyboard, enter the Primary DNS Address (provided by your System Administrator) and press Done when compete.

  • Page 86: Master Connection - Virtual Master Communication Over Ethernet

    Ethernet Hub) or wireless to the Wireless Access Point. Launch NetLinx Studio 2.x (default location is Start > Programs > AMX Control Disc > NetLinx Studio 2 > NetLinx Studio 2). Select Settings > Master Communication Settings, from the Main menu to open the Master Communication Settings dialog (FIG.

  • Page 87: Master Connection Section - Netlinx Master Ethernet Ip Address - Url Mode

    By selecting URL, the System Number field becomes read-only (grey) because the panel pulls this value directly from the  communicating target Master (virtual or not). A Virtual Master system value can be set within the active AMX software applications such as: NetLinx Studio, TPD4, or IREdit.

  • Page 88: Master Connection Section - Netlinx Master Ethernet Ip Address - Auto Mode

    Refer to the G4 Web Control Settings section on page 122 for more detailed field information. NOTE: Verify your NetLinx Master (ME260/64 or NI-Series) has been installed with the latest f irmware KIT f ile from www.amx.com. Refer to your NetLinx Master Instruction Manual for more detailed information on the use of the new web-based NetLinx Security.
  • Page 89 Configuring Communication G4 Web Control page FIG. 85 Press the Enable/Enabled button until it toggles to Enabled (light blue color). The Network Interface Select field is read-only and displays the method of communication to the web. Verify you have selected the proper interface connection as this f ield does not auto-detect the connection type being used (see below). Wired is used when a direct Ethernet connection is being used for communication to the web.

  • Page 90: Using Your Netlinx Master To Control The G4 Panels

    Both HTTP and HTTPS Ports are enabled by default (via the Manage System > Server page).  If the Master has been previously configured for secured communication, click OK to accept the AMX SSL certificate (if SSL  is enabled) and then enter a valid username and password into the fields within the Login dialog.
  • Page 91 Configuring Communication Click Yes from the Security Alert popup window to agree to the installation of the G4 WebControl application on your computer. This application contains the necessary Active X and VNC client applications necessary to properly view and control the panel pages from your computer.

  • Page 92: Upgrading Modero Firmware

    Upgrading Modero Firmware Upgrading Modero Firmware Overview Before beginning the Upgrade process: Setup and configure your NetLinx Master. Refer to your particular NetLinx Master instruction manual for detailed setup  procedures. Calibrate and prepare the communication pages on the Modero panel for use. Refer to the Panel Calibration section on ...

  • Page 93: Step 3: Confirm And Upgrade The Firmware Via The Usb Port

    Upgrading Modero Firmware IP Address of computer (not needed as this is a direct USB connection) Assigning Communication Settings for a Virtual Master FIG. 90 From within this dialog enter the System number (default is 1). Click OK three times to close the open dialogs, save your settings, and return to the main NetLinx Studio application. Click the OnLine Tree tab in the Workspace window to view the devices on the Virtual System.
  • Page 94 Upgrading Modero Firmware NOTE: The panel f irmware is shown on the right of the listed panel. Download the latest f irmware f ile from www.amx.com and then save the KIT f ile to your computer. If the panel firmware being used is not current, download the latest Kit file by first logging in to www.amx.com and then navigate to Tech Center >...

  • Page 95: Upgrading The Modero Firmware Via An Ip Address

     Launch NetLinx Studio 2.x (default location is Start > Programs > AMX Control Disc > NetLinx Studio 2 > NetLinx Studio 2). Select Settings > Master Communication Settings from the Main menu to open the Master Communication Settings dialog (FIG.

  • Page 96: Step 2: Prepare The Panel For Communication Via An Ip

    NOTE: The panel f irmware is shown on the right of the listed panel. If the panel firmware being used is not current, download the latest Kit file by first logging in to www.amx.com and then navigate to Tech Center > Firmware Files and from within the Modero section of the web page locate your Modero panel.

  • Page 97: Upgrading Accessory Devices Via An Ip Address

    Upgrading Modero Firmware Selected Firmware file Description field for selected KIT file Firmware download status Device value and System number must match the values listed in the Workspace window Send to NetLinx Device dialog (showing Modero firmware update via IP) FIG.

  • Page 98: Step 1: Prepare The Nxa-Base/B For Firmware Transfer

    BASE/B will not appear on the system listing. Locate the latest Kit file by first logging in to www.amx.com and then navigate to Tech Center > Firmware Files and from within the Modero section of the web page locate the Modero Battery Base section of the website.
  • Page 99 Upgrading Modero Firmware Selected Battery Base Firmware file Description field for selected KIT file Firmware download status Device value and System number must match the values listed in the Workspace window Send to NetLinx Device dialog (showing NXA-BASE/B firmware update via IP) FIG.

  • Page 100: Upgrading Nxa-Rgb And Nxa-Avb/Rgb Firmware

    Upgrading Modero Firmware Upgrading NXA-RGB and NXA-AVB/RGB Firmware Identify the Device number of the target panel being used for firmware routing to the accessories. Complete the instructions for configuring the NetLinx Master for IP communication found in the Step 1: Prepare the Master for communication via an IP section on page 95.

  • Page 101: Firmware Pages And Descriptions

    Firmware Pages and Descriptions Firmware Pages and Descriptions Overview This section describes each firmware page and their specific functional elements. Setup Navigation Buttons The Setup Navigation Buttons (FIG. 100) appear on-screen when the Setup page is active. Modero Setup Navigation Buttons Setup Navigation Buttons FIG.

  • Page 102: Setup Page

    Firmware Pages and Descriptions Setup Page This page (FIG. 101) centers around basic Modero panel properties such as: Connection Status of the panel, Display Timeout, Inactivity Page Flip Time, Inactivity page file, and the Panel Brightness. Connection Status Red Connection Status icon - indicates no connection to a Master Green Connection Status icon - indicates communication to a Master...

  • Page 103: Panel Information Page

    Displays the model of the Modero panel being used. Firmware Version: Displays the G4 firmware version being used by the panel. • Verify you have the latest version from www.amx.com. Setup Port: Displays the setup port information/value being used by the panel.

  • Page 104: Project Information Page

    Firmware Pages and Descriptions Project Information Page The Project Information page displays the TPDesign4 (TPD4) project file properties currently loaded on the selected Modero panel (FIG. 103). Refer to the TPDesign4 Touch Panel Program instruction manual for more specific information on uploading TPDesign4 files to a panel.

  • Page 105: Time & Date Settings Page

    Firmware Pages and Descriptions Time & Date Settings Page The Time & Date Settings page (FIG. 104) allows you to alter/set the time and date information on the NetLinx Master. If either the Time/Date is modified on this page (then updated to the Master by pressing the Set Time button), all devices communicating to that target Master will then be updated to reflect the new information.

  • Page 106: Audio Settings Page

    Firmware Pages and Descriptions Audio Settings Page The Audio Settings page (FIG. 105) allows you to adjust the master volume parameters and default panel sounds on the panel. Audio Settings page FIG. 105 The elements of the Audio Settings page are described in the table below: Audio Settings Page Elements Back: Saves the changes and returns you to the previously active touch panel page.

  • Page 107: Information Icon

    Firmware Pages and Descriptions Information icon Clicking on the Information icon in the Default Panel Sounds section opens the following window (FIG. 106): Information icon window FIG. 106 Protected Setup Page This button opens the Protected Setup page which centers around the properties used by the panel to properly communicate with the NetLinx Master.

  • Page 108: Video - Rgb Settings Page

    Firmware Pages and Descriptions The elements of the Video Settings page are described in the table below: Video Settings Page Elements Back: Saves the changes and returns you to the previously active touch panel page. Connection Status icon: This visual display of the connection status allows the user to have a current visual update of the panel’s connection status regardless of what page is currently active.
  • Page 109 Firmware Pages and Descriptions RGB Settings Page Elements (Cont.) Status: Displays the input signal properties of the signal routed through the internal NXA-RGB card (H-pixel x V-pixel @ Hz). An example is: 1024x768@85Hz. Cable Variance: Allows you cycle through a choice of available cable compensation parameters (Short, Medium, and Long). •...

  • Page 110: Adjusting The Incoming Signal On The Rgb Settings Page

    This time can be a difference of a up to 30 nano-seconds @ 200ft, and that can be more than enough to cause the image to appear "off" or blurry. For this reason, AMX recommends using the Belden Brilliance VideoTwist 7987 cable.
  • Page 111 Firmware Pages and Descriptions Incoming RGB signal On-screen image controls (activated by pressing the RGB Adjustments bar) Once done making your screen adjustments, SAVE SETTINGS. Full Screen Edit Mode - showing controls FIG. 110 Although these same options are available within the main RGB Settings page, these RGB image controls provide you with ...

  • Page 112: Video - Streaming Settings Page

    Firmware Pages and Descriptions Green and Blue signal Good in sync but Red signal is RGB signal not properly synched-up overlap Full Screen Edit Mode - showing skew adjustment scenario FIG. 111 10. Once done making these adjustments, press the Done button to temporarily save these modifications and place the grey RGB Adjustments bar back onto the bottom of the screen.
  • Page 113 Firmware Pages and Descriptions Streaming Settings Page Elements (Cont.) Video: This read-only field displays the video stream information (Video Streaming format and resolution). • The properties of this incoming (detected) stream is given as: Video Codec and Resolution. • An example would be: MPEG2 720x480. This means that the incoming video is an MPEG2 video stream with resolution 720x480.

  • Page 114: Battery Base Page

    Firmware Pages and Descriptions Streaming Settings Page Elements (Cont.) Saturation: Use the UP/DN buttons to alter the color saturation level of the incoming signal. • Range = 0 - 255, default = 128. Hue: Use the UP/DN buttons to alter the hue level of the incoming signal. •...
  • Page 115 Firmware Pages and Descriptions Battery Base Page Elements (Cont.) Battery Status fields: This section provides the ability to monitor the current battery charge levels and charge qualities: • The Combined Charge Status bargraph indicates the combined power charge available from both internal battery connection slots (bargraph range = 0 - 100).

  • Page 116: Protected Setup Navigation Buttons

    Firmware Pages and Descriptions Protected Setup Navigation Buttons The Protected Setup Navigation Buttons (FIG. 114) appear on the left of the panel screen when the Protected Setup page is currently active. Modero Protected Setup Navigation Buttons Protected Setup Navigation Buttons FIG.

  • Page 117: Protected Setup Page

    Firmware Pages and Descriptions Protected Setup Page The Protected Setup page (FIG. 115) centers around the properties used by the panel to properly communicate with the NetLinx Master. Enter the factory default password (1988) into the password keypad to access this page. Provides access to the panel firmware pages by enabling the grey front setup access button:...

  • Page 118: Security Settings

    • The Remove User Pages button allows you remove all current TPD4 touch panel pages currently on the panel (including the pre-installed AMX Demo pages). - Pressing this button launches a Confirmation dialog which asks you to confirm your selection.

  • Page 119: System Settings Page

    The correct case must be followed with the username: "AMX" or "Amx" will not work. For more information on configuring AMX devices for a secure environment, please refer to the guide Security Prof iles: Conf iguring AMX Devices For Installation Into a Secure Environment, available at www.amx.com.

  • Page 120: Sensor Settings Page

    Firmware Pages and Descriptions System Settings Page Elements (Cont.) Master Connection (Cont.): Type Sets the NetLinx Master to communicate with the panel via either USB or Ethernet. This is based on the cable connection from the rear. ICSNet is not a supported option on this panel. •...

  • Page 121: Using The Automated Brightness Control Feature (Dim Mode)

    Firmware Pages and Descriptions Sensor Settings Page Elements (Cont.) Light Sensor: Allows you to monitor and alter the sensitivity of the Modero panel light sensor: • The Light Sensor Level field indicates the level used to report the light sensor level back to the NetLinx Master (set in TPD4) (read-only).

  • Page 122: Calibration Page

    Firmware Pages and Descriptions Set the Maximum brightness of the Dimmer (Dim Mode Max Level) below the detected drop. This will make sure that the panel does not react to variations in the lighting conditions of a normal working environment. NOTE: The maximum (upper level) of the dimmer should be at least 15% lower than the maximum detected level.

  • Page 123: Other Settings Slide-Out Menu

    Firmware Pages and Descriptions G4 Web Control Page Elements Back: Saves the changes and returns you to the previously active touch panel page. Connection Status icon: This visual display of the connection status allows the user to have a current visual update of the panel’s connection status regardless of what page is currently active.

  • Page 124: Cache Settings Page

    Firmware Pages and Descriptions Cache Settings Page The Cache Settings page (FIG. 123) configures the allocation of memory for image caching. The G4 graphics engine caches images to decrease load time of previously viewed images. RAM caching is always enabled, and images (both static and dynamic) are stored in the RAM cache as they are viewed.

  • Page 125: Setting The Image Cache

    Firmware Pages and Descriptions Cache Settings Page Elements (Cont.) RAM Hit Rate The percentage of image requests (static and dynamic) satisfied by accessing the cache. 100 * (# of cache hits) / (# of cache hits + # of cache misses) # of cache hits - the number of times an image was requested that the image was found in the cache.

  • Page 126: Password Settings Page

    Firmware Pages and Descriptions Password Settings Page The Password Settings page (FIG. 124) centers around the properties used to assign passwords for the Modero panel pages. Password Settings page FIG. 124 The elements of the Password Settings page are described in the table below: Password Settings Page Elements Back: Saves the changes and returns you to the previously active touch panel page.

  • Page 127: Checking The Panel Connection Logs

    Firmware Pages and Descriptions Features on this page include: Panel Connection Logs Page Elements Back: Saves all changes and returns to the previous page. Connection Status icon: The icon in the upper-right corner of each Setup page shows online/offline state of the panel to the master. •...

  • Page 128: Checking The Panel Statistics

    Firmware Pages and Descriptions Connection Status icon: The icon in the upper-right corner of each Setup page shows online/offline state of the panel to the master. • Bright red - disconnected • Bright green - connected. Blinks when a blink message is received to dark green every 5 seconds for half a second then go back to bright green.

  • Page 129: Using The Connection Utility

    Firmware Pages and Descriptions Connection Utility Popup Window Elements Close: Closes the Connection Utility popup. Connection Status icon: The icon in the upper-right corner of the utility provides a constant visual indication of current connection status. A message is sent to the master once per second and expects a response. •...
  • Page 130 Firmware Pages and Descriptions Wireless Settings Page Elements Back: Saves the changes and returns you to the previously active touch panel page. Connection Status icon: This visual display of the connection status allows the user to have a current visual update of the panel’s connection status regardless of what page is currently active.
  • Page 131 Entering the same apple in the Passphrase generator of any Modero panel generates a different key: a1:b2:c3:d4:etc. Only AMX Modero panels generate the same Current Key by using a unique Passphrase key generation technology. A Current Key string, when generated anywhere else, will not match those created on the Modero panels.
  • Page 132 Firmware Pages and Descriptions Wireless Settings Page Elements (Cont.) Data Rate: The data rate (in Mbps) at which the panel is currently communicating with a target WAP at (dynamic). • As you move closer to the target WAP (and both the signal strength/quality), the data rate increases and as the quality degrades this rate decreases.

  • Page 133: Displaying Stream Content

    Requirements for Receiving Streamed Content To receive and display content via a Modero panel: Verify you have installed the latest version of TPDesign4 on your PC. Updates are available from the www.amx.com > Tech  Center > Application Files > Touch Panel Design Tools section of the website. This application is needed to create the necessary page (popup page) used to display the incoming MPEG audio/video stream, identify the IP of the source MAX- CSE, and define the target audio/video ports on the panel.

  • Page 134: Setting Up A Modero Panel To Receive And Display A Stream

    Displaying Stream Content by default, cause the target Modero panel to look for the incoming audio portion of the stream on the same port as the video (port 5000). Obtain the IP Address being used by the target Modero panel by locating the IP Address field on the firmware’s System ...
  • Page 135 Displaying Stream Content Click OK to enter the information and proceed to the Administration page which provides both a descriptive overview of the program stream and lists the currently used firmware. Determine the data throughput available on the network being used by the source encoder. This information determines which Encoder Profile and Transport Protocol will be used to encode the outgoing media stream.

  • Page 136: Step 3: Configuring The Max-Cse Audio/Video Inputs

    Displaying Stream Content These port values must use even numbers Stream Profiles page (showing a sample configuration) FIG. 133 14. Click the Apply button to save the encoding profiles to the MAX-CSE. NOTE: If using RTP, both the Target Port and Target Audio Port must be different and should use even numbers. Step 3: Conf iguring the MAX-CSE audio/video inputs Complete the MAX-CSE connection and wiring procedures outlined within the Wiring the MAX-CSE connectors and cables section of the MAX-CSE Instruction Manual.

  • Page 137: Step 4: Setup A Streaming Page Within Tpdesign4

    From within the Step 1 dialog, enter a generic Job name and use the Panel Type drop-down arrow to choose a VG-Series panel (1200VG, 1500VG, or 1700GVG). For the purpose of these procedures, we’ve chosen to use a Job Name of Test and have selected an NXD-1700VG touch panel (FIG. 135).

  • Page 138: Step 5: Establishing The Final Connection Between The Two Units

    Displaying Stream Content 11. Double-click the All States + symbol to expand this folder (FIG. 137) and locate the Video Fill field. Video Fill - Button Properties setting FIG. 137 12. Use the Video Fill drop-down arrow to select the Streaming Video option (A in FIG. 137). 13.
  • Page 139 Displaying Stream Content Once done making your screen adjustments, SAVE SETTINGS. Incoming Video signal Video Settings page (showing default values) FIG. 139 If there is no signal displayed, return to the MAX-CSE UI pages and from the Encoder Profiles page, confirm that the correct panel IP Address and target port where entered into the Streaming Source field within the TPDesign4 project.

  • Page 140: Programming

    Programming Programming Overview You can program the touch panel, using the commands in this section, to perform a wide variety of operations using Send_Commands and variable text commands. A device must f irst be def ined in the NetLinx programming language with values for the Device: Port: System (in all programming examples - Panel is used in place of these values and represents all Modero panels).

  • Page 141: Pdr

    Programming Page Commands (Cont.) @PDR Set the popup location reset flag. If the flag is set, the popup will return to its default location on show instead of its last drag location. Syntax: "'@PDR-<popup page name>;<reset flag>'" Variable: popup page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On. reset flag = 1 = Enable reset flag, 0 = Disable reset flag Example: SEND_COMMAND Panel,"'@PDR-Popup1;1'"...

  • Page 142: Ppg

    Programming Page Commands (Cont.) @PPG Toggle a specific popup page on either a specified page or the current page. If the page name is empty, the current page is used (see example 2). Toggling refers to the activating/deactivating (On/Off) of a popup page. This command works in the same way as the ’Toggle Popup’...

  • Page 143: Ppx

    Programming Page Commands (Cont.) @PPX Close all popups on all pages. This command works in the same way as the 'Clear All' command in TPDesign 4. Syntax: "'@PPX'" Example: SEND_COMMAND Panel,"'@PPX'" Close all popups on all pages. @PSE Set the show effect for the specified popup page to the named show effect. Syntax: "'@PSE-<popup page name>;<show effect name>'"...

  • Page 144: Ppog

    Programming Page Commands (Cont.) PPOG Toggle a specific popup page on either a specified page or the current page. If the page name is empty, the current page is used (see example 2). Toggling refers to the activating/deactivating (On/Off) of a popup page. This command works in the same way as the ’Toggle Popup’...

  • Page 145: Programming Numbers

    Programming Programming Numbers The following information provides the programming numbers for colors, fonts, and borders. Colors can be used to set the colors on buttons, sliders, and pages. The lowest color number represents the lightest color-specific display; the highest number represents the darkest display.

  • Page 146: Font Styles And Id Numbers

    Arial Courier New Arial Courier New Arial Courier New Arial AMX Bold Arial AMX Bold Arial Bold AMX Bold Arial Bold 32 - Variable Fonts start at 32. NOTE: Fonts must be imported into a TPDesign4 project f ile. The font ID numbers are assigned by TPDesign4. These values are also listed in the Generate Programmer’s Report.

  • Page 147: Button Commands

    Programming "^" Button Commands These Button Commands are used in NetLinx Studio and are case insensitive. All commands that begin with "^" have the capability of assigning a variable text address range and button state range. A device must f irst be def ined in the NetLinx programming language with values for the Device: Port : System (in all programming examples - Panel is used in place of these values).

  • Page 148: Bcb

    Programming "^" Button Commands (Cont.) ^BCB Set the border color to the specified color. Only if the specified border color is not the same as the current color. Note: Color can be assigned by color name (without spaces), number or R,G,B value (RRGGBB or RRGGBBAA). Syntax: "'^BCB-<vt addr range>,<button states range>,<color value>'"...

  • Page 149: Bfb

    Programming "^" Button Commands (Cont.) ^BFB Set the feedback type of the button. ONLY works on General-type buttons. Syntax: "'^BFB-<vt addr range>,<feedback type>'" Variable: variable text address range = 1 - 4000. feedback type = (None, Channel, Invert, On (Always on), Momentary, and Blink). Example: SEND_COMMAND Panel,"'^BFB-500,Momentary'"...

  • Page 150: Bmc

    Programming "^" Button Commands (Cont.) ^BMC Button copy command. Copy attributes of the source button to all the destination buttons. Note that the source is a single button state. Each state must be copied as a separate command. The <codes> section represents what attributes will be copied.

  • Page 151: Bmf

    Programming "^" Button Commands (Cont.) ^BMF Set any/all button parameters by sending embedded codes and data. Syntax: "'^BMF-<vt addr range>,<button states range>,<data>'" Variables: variable text address char array = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state). level range = 1 - 600 (level value is 1 - 65535).

  • Page 152: Bmi

    Programming "^" Button Commands (Cont.) ^BMF (Cont.) ’’%GU<bargraph ramp up>’ = Set the bargraph ramp up time in intervals of 1/10 second. ’%GD<bargraph ramp down>’ = Set the bargraph ramp down time in 1/10 second. ’%GG<bargraph drag increment> = Set the bargraph drag increment. Refer to the ^GDI command on page 157 for more information.

  • Page 153: Bmp

    Programming "^" Button Commands (Cont.) ^BMP Assign a picture to those buttons with a defined address range. Syntax: "'^BMP-<vt addr range>,<button states range>,<name of bitmap/picture>'" Variable: variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state). name of bitmap/picture = 1 - 50 ASCII characters.

  • Page 154: Bor

    SEND_COMMAND Panel,"'^BOR-500.504&510,AMX Elite -M'" Sets the border by name (AMX Elite) to those buttons with the variable text range of 500-504 & 510-515. The border style is available through the TPDesign4 border-style drop-down list. Refer to the Border Styles And Programming Numbers section on page 146 for more information.

  • Page 155: Bsf

    Programming "^" Button Commands (Cont.) ^BSF Set the focus to the text area. Note: Select one button at a time (single variable text address). Do not assign a variable text address range to set focus to multiple buttons. Only one variable text address can be in focus at a time. Syntax: "'^BSF-<vt addr range>,<selection value>'"...

  • Page 156: Bvt

    Programming "^" Button Commands (Cont.) ^BVT Set the computer control network port for the specified address. Syntax: "'^BVT-<vt addr range>,<network port>'" Variable: variable text address range = 1 - 4000. network port = 1 - 65535. Example: SEND_COMMAND Panel,"'^BVT-500,5000'" Sets the network port to 5000. ^BWW Set the button word wrap feature to those buttons with a defined address range.

  • Page 157: Fon

    Programming "^" Button Commands (Cont.) ^FON Set a font to a specific Font ID value for those buttons with a defined address range. Font ID numbers are generated by the TPDesign4 programmers report. Syntax: "'^FON-<vt addr range>,<button states range>,<font value>'" Variable: variable text address range = 1 - 4000.

  • Page 158: Grd

    Programming "^" Button Commands (Cont.) ^GRD Change the bargraph ramp-down time in 1/10th of a second. Syntax: "'^GRD-<vt addr range>,<bargraph ramp down time>'" Variable: variable text address range = 1 - 4000. bargraph ramp down time = In 1/10th of a second intervals. Example: SEND_COMMAND Panel,"'^GRD-500,200'"...

  • Page 159: Ico

    Programming "^" Button Commands (Cont.) ^ICO Set the icon to a button. Syntax: "'^ICO-<vt addr range>,<button states range>,<icon index>'" Variable: variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state). icon index range = 0 - 9900 (a value of 0 is clear).

  • Page 160: Mbt

    Programming "^" Button Commands (Cont.) ^MBT Set the Mouse Button mode On for the virtual PC. Syntax: "'^MBT-<pass data>'" Variable: pass data: 0 = None 1 = Left 2 = Right 3 = Middle Example: SEND COMMAND Panel,"'^MBT-1'" Sets the mouse button mode to ’Left Mouse Click’. ^MDC Turn On the ’Mouse double-click’...

  • Page 161: Top

    Programming "^" Button Commands (Cont.) ^TOP Enables/disables touch output to Master. If enabled, Press/Move/Release events are sent to the Master as string events. Syntax: "'^TOP-<state>'" <state> is 0(disable) 1(presses/releases), 2(moves), 3(press/move/release). Note: Move should be used with caution. This setting can generate a signif icant amount of traff ic to the master depending on user interaction.

  • Page 162: Text Effect Names

    Programming Text Effect Names The following is a listing of text effects names. This list is associated with the ^TEF command on page 160. Text Effects • Glow -S • Hard Drop Shadow 6 • Glow -M • Hard Drop Shadow 7 •...

  • Page 163: Bbv

    Programming All custom events have the following 6 fields: Custom Event Fields Field Description Uint Flag 0 means text is a standard string, 1 means Unicode encoded string slong value1 button state number slong value2 actual length of string (this is not encoded size) slong value3 index of first character (usually 1 or same as optional index string text...

  • Page 164: Bct

    Programming Button Query Commands (Cont.) ?BCT Get the current text color. Syntax: "'?BCT-<vt addr range>,<button states range>'" Variable: variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state). custom event type 1013: Flag - Zero Value1 - Button state number...

  • Page 165: Bop

    Programming Button Query Commands (Cont.) ?BOP Get the overall button opacity. Syntax: "'?BOP-<vt addr range>,<button states range>'" Variable: variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state). custom event type 1015: Flag - Zero Value1 - Button state number...

  • Page 166: Bww

    Programming Button Query Commands (Cont.) ?BWW Get the current word wrap flag status. Syntax: "'?BWW-<vt addr range>,<button states range>'" Variable: variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state). custom event type 1010: Flag - Zero Value1 - Button state number...

  • Page 167: Ico

    Programming Button Query Commands (Cont.) ?ICO Get the current icon index. Syntax: "'?ICO-<vt addr range>,<button states range>'" Variable: variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state). custom event type 1003: Flag - Zero Value1 - Button state number...

  • Page 168: Jsi

    Programming Button Query Commands (Cont.) ?JSI Get the current icon justification. Syntax: "'?JSI-<vt addr range>,<button states range>'" Variable: variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state). custom event type 1006: Flag - Zero Value1 - Button state number...

  • Page 169: Sta

    Programming Button Query Commands (Cont.) ?STA Get the current XML panel stats. Returned in MULTIPLE Custom events (size of strings are limited per message). Values in Custom event will say for example, 1 of 5 messages and how many total bytes of XML data. Value 1 = 1 (which one of multiple events is this (1 based)) Value 2 = 5 (total number of events required to send this string) Value 3 = total size in bytes of string...

  • Page 170: Tef

    Programming Button Query Commands (Cont.) ?TEF Get the current text effect name. Syntax: "'?TEF-<vt addr range>,<button states range>'" Variable: variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state). custom event type 1008: Flag - Zero Value1 - Button state number...

  • Page 171: Panel Runtime Operations

    Programming Panel Runtime Operations Serial Commands are used in the AXCESSX Terminal Emulator mode. These commands are case insensitive. Panel Runtime Operation Commands ABEEP Output a single beep even if beep is Off. Syntax: "'ABEEP'" Example: SEND COMMAND Panel,"'ABEEP'" Outputs a beep of duration 1 beep even if beep is Off. ADBEEP Output a double beep even if beep is Off.

  • Page 172: Akr

    Programming Panel Runtime Operation Commands (Cont.) @AKR Remove keyboard or keypad that was displayed using 'AKEYB', 'AKEYP', 'PKEYP', @AKB, @AKP, @PKP, @EKP, or @TKP commands. Syntax: "'@AKR'" Example: SEND COMMAND Panel,"'@AKR'" Removes the Keyboard/Keypad. BEEP Output a beep. Syntax: "'BEEP'" Example: SEND COMMAND Panel,"'BEEP'"...

  • Page 173: Setup

    Programming Panel Runtime Operation Commands (Cont.) SETUP Send panel to SETUP page. Syntax: "'SETUP'" Example: SEND COMMAND Panel,"'SETUP'" Sends the panel to the Setup Page. SHUTDOWN Shut down the batteries providing power to the panel. Syntax: "'SHUTDOWN'" Example: SEND COMMAND Panel,"'SHUTDOWN'" Shuts-down the batteries feeding power to the panel.

  • Page 174: Input Commands

    Programming Input Commands Input Commands ^CAL Put panel in calibration mode. Syntax: "'^CAL'" Example: SEND COMMAND Panel,"'^CAL'" Puts the panel in calibration mode. ^KPS Set keyboard pass-thru via the RGB card. Syntax: "'^KPS-<passs data>'" Variables: pass data: <blank/empty> = Disables the keyboard. 0 = Pass-thru disabled.

  • Page 175: Slt

    Programming Input Commands (Cont.) ^SLT Send a command to a given slot. These commands are directed at the video card subsystems. Slot commands contain a series of name/value pairs separated by commas. These commands are case insensitive. Syntax: "’^SLT-<slot number>,<slot command>’" Variables: slot number = 1 - 3 (each of these options corresponds to an on-board slot position where the related components reside.) Slot 1= Composite Video (common to both 1200-V and VG-Series)

  • Page 176: Embedded Codes

    Programming Embedded Codes The following is a list of G4 compatible embedded codes: Embedded Codes Decimal numbers Hexidecimal values Virtual keystroke ($08) Backspace ($0D) Enter ($1B) ($80) CTRL key down ($81) ALT key down ($82) Shift key down ($83) ($84) ($85) ($86) ($87)

  • Page 177: Panel Setup Commands

    Programming Panel Setup Commands These commands are case insensitive. Panel Setup Commands ^MUT Set the panel mute state. Syntax: "'^MUT-<mute state>'" Variable: mute state= 0 = Mute Off and 1 = Mute On. Example: SEND_COMMAND Panel,"'^MUT-1''" Sets the panel’s master volume to mute. @PWD Set the page flip password.

  • Page 178: Dynamic Image Commands

    Adds a new resource. • The resource name is ’New Image’ • %P (protocol) is an HTTP • %H (host name) is AMX.COM • %A (file path) is Lab/Test_f ile • %F (file name) is test.jpg. Note that the %%5F in the file path is actually encoded as %5F.

  • Page 179: Raf, ^Rmf - Embedded Codes

    Current state Address code Address port Channel code Channel port Level code Level port X Resolution of Current button Y Resolution of Current button Name of Button For instance, http://www.amx.com/img.asp?device=$DV would become http://www.amx.com/img.asp?device=10001. Modero VG Series Touch Panels - Instruction Manual...

  • Page 180: Troubleshooting

    • This is due to the graphics controller settings in the firmware. • Update firmware to the latest v2.XX. firmware. • Visit the www.amx.com > Tech Center > Downloadable Files > Firmware Files > Modero panels. Then Download the KIT file to your computer.
  • Page 181 • The NXA-BASE/B Battery base should be updated with the latest firmware (part of the Modero firmware KIT file) from www.amx.com. • The base can only charge batteries while the NXT panel is in Sleep Mode. If the panel parameters are set to their highest values, the priority for the power draw becomes the active panel functions and no power is routed to the base for charging.
  • Page 182 • Inability to make further downloads to the panel. May get "directory" errors, "graphics hierarchy" errors, etc.… indicating problems with the Compact Flash. • Panel will not boot, or gets stuck on "AMX" splash screen. • Other problems also started after downloading to a new panel or a panel with a TPD4 file that takes up a considerable amount of the available Compact Flash.

  • Page 183: Appendix

    Appendix Appendix Text Formatting Codes for Bargraphs/Joysticks Text formatting codes for bargraphs provide a mechanism to allow a portion of a bargraphs text to be dynamically provided information about the current status of the level (multistate and traditional). These codes would be entered into the text field along with any other text.

  • Page 184: Input Mask Character Types

    Appendix With this feature, it is NOT necessary to: • Limit you to a choice of selections • Handle complex input tasks such as names, days of the weeks or months by name • Perform complex validation such as Subnet Mask validation Input mask character types These character types define what information is allowed to be entered in any specific instance.

  • Page 185: Input Mask Literals

    (HyperText Transport Protocol) and that the information resides on a host machine named www.amx.com. The image on that host machine is given an assignment (by the program) name of company-info-home.asp (Active Server Page). The exact meaning of this name on the host machine is both protocol dependent and host dependent. The information normally resides in a file, but it could be generated dynamically.
  • Page 186 Appendix Escape Sequences Sequence Panel Information Device Number System Number IP Address Host Name Mac Address Neuron ID X Resolution of current panel mode/file Y Resolution of current panel mode/file X Resolution of current button Y Resolution of current button Name of button Current state Address Code...
  • Page 187 © 2016 Harman. All rights reserved. Metreau, NetLinx, AMX, AV FOR AN IT WORLD, HARMAN, and their respective logos are registered trademarks of Last Revised: HARMAN. Oracle, Java and any other company or brand name referenced may be trademarks/registered trademarks of their respective companies.
