Torque Specifications - Polaris 2014 RZR XP 1000 Service Manual

BODY / STEERING / SUSPENSION

TORQUE SPECIFICATIONS

ITEM
Front A-Arm Bolt
Door Hinge Mount Nuts
Door Latch Screws
Tie Rod End to Bearing
Carrier Housing Bolt (Not
reusable)
Ball Joint Fastener
Front Shock Mount Bolts
Rear Shock Mount Bolts
Front Bumper / Fender
Screws
Floor Screws
Wheel Hub Castle Nuts
Wheel Nuts (Cast
Aluminum Rims)
Tie Rod End Jamb Nut
Radius Rod Fasteners
Trailing Arm to Frame Bolt
Bearing Carrier to Trailing
Arm Bolts
Rear Stabilizer Bar Linkage
Rear Shock Reservoir
Mounting Clamps
Rear Stabilizer Bar
Mounting Bracket Bolts
Rear Stabilizer Bar
Locating Clamp Bolts
Seat Belt Mounting
Hardware
Seat Slider Plate
Shock Guard Screws
Skid Plate Screws
Front to Rear Frame Bolts
Tilt Steering Shock
Fasteners
Steering Pivot Tube
Mounting Fasteners
5.4
TORQUE VALUE
42 ft-lb (57 Nm)
8 ft-lb (11 Nm)
8 ft-lb (11 Nm)
15 ft-lbs (20 Nm) + 90°
42 ft-lbs (57 Nm)
44 ft-lb (60 Nm)
70 ft-lbs (95 Nm)
8 ft-ln (11 Nm)
8 ft-lb (11 Nm)
110 ft-lbs (149 Nm)
120 ft-lbs (163 Nm)
14 ft-lbs (19 Nm)
40 ft-lb (54 Nm)
70 ft-lb (95 Nm)
42 ft-lb (54 Nm)
40 ft-lbs (54 Nm)
35 in-lb (4 Nm)
17 ft-lb (23 Nm)
10 ft-lb (14 Nm)
40 ft-lbs (54 Nm)
4 ft-lb (5 Nm)
14 in-lbs (2 Nm)
8 ft-lbs (11 Nm)
40 ft-lb (54 Nm)
7 ft-lb (10 Nm)
8 ft-lb (11 Nm)
9924874 R02 - 2014 RZR XP / XP 4 1000 Service Manual
© Copyright 2013 Polaris Industries Inc.
ITEM
Steering Wheel Nut
Steering Shaft to Power
Steering Unit (upper/lower)
(EPS models)
EPS Cover Screws
Power Steering Unit to
Mount Bracket Bolts
Lower Steering Shaft to
Steering Rack
Power Steering Bracket to
Frame Nuts
Steering Rack Mounting
Bolts
Cab Frame Bolts
Hip Bolster Bolts
Visor Mounting Screws
Seat Base to Frame (Front
Bolts)
Seat Base to Frame (Rear
Bolts)
TORQUE VALUE
65 ft-lbs (88 Nm)
15 ft-lbs (20 Nm)
8 ft-lb (11 Nm)
30 ft-lb (41 Nm)
42 ft-lb (57 Nm)
16 ft-lb (22 Nm)
16 ft-lbs (22 Nm)
40 ft-lb (54 Nm)
14 ft-lb (19 Nm)
8 ft-lb (11 Nm)
14 ft-lb (19 Nm)
30 ft-lb (41 Nm)
