1.2.5 Device Installation

1.2.5.1 Installation Guidelines
To produce quality image and to avoid software recognition errors, make sure you adhere to the
guidelines when installing your GV-IP LPR Camera 5R. See GV-LPR Camera Installation Guide.
1.2.5.2 Installing the Camera
After you have read through the installation guides and chosen an installation site, follow the
steps below to install the GV-IP LPR Camera 5R.
1. Mark the installation site and drill three holes for screw anchors.
2. Insert the supplied screw anchors.
3. Secure the camera to the wall using the supplied screws.
Figure 1-13
4. Remove the protection sticker from the camera's cover.
5. Connect the camera to the network and supply power via the PoE cable. See 1.2.6
Connecting the Camera.
6. Access the live view. See Chapter 2 Getting Started.
7. Based on the live view, adjust the angle, zoom and focus of the camera of the camera. For
adjusting three shafts, see 1.2.7 Adjusting the Angles. For changing zoom and focus, see
Figure 1-12.
8. Install the sun-shield cover to the camera. For details, see 1.2.9 Installing the Sun-Shield Cover.
