GV-EBD4700 IR Eyeball IP Dome
User's Manual
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
EBDV10-A-EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-EBD4700 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoVision GV-EBD4700

Summary of Contents for GeoVision GV-EBD4700

  • Page 1 GV-EBD4700 IR Eyeball IP Dome User's Manual Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. EBDV10-A-EN...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
  • Page 3 Preface Welcome to the GV-EBD4700 IR Eyeball IP Dome User’s Manual. This Manual is designed for the following models and firmware versions: Model Model Number Firmware Version IR Eyeball Dome GV-EBD4700 V1.0...

  • Page 4: Table Of Contents

    Contents Naming Definition..............iv Note for Connecting to GV-VMS / DVR / NVR ......v Note for Installing Camera Outdoor ........vi Chapter 1 Introduction ............1 1.1 Key Features ......................2 1.2 Packing List ......................3 1.3 System Requirements.................... 4 1.4 Optional Accessories ..................... 5 1.5 Overview........................
  • Page 5 3.2.6 Port Mapping ....................37 3.2.7 802.1x.......................38 3.3 Video ........................39 3.3.1 Video ......................39 3.3.2 Capture.....................41 3.3.3 ROI ......................42 3.3.4 Media Stream ...................43 3.4 Image ........................45 3.4.1 Image .......................45 3.4.2 OSD......................51 3.4.3 Privacy Mask....................52 Events ........................53 3.5.1 Motion Detection ..................53 Security ........................55 3.6.1 User......................55 3.6.2 Network Security..................56 System .........................58...

  • Page 6: Naming Definition

    Naming Definition GV-System GeoVision Analog and Digital Video Recording Software. The GV- System also refers to Multicam System, GV-NVR System, GV- DVR System and GV-Hybrid DVR System at the same time GV-VMS GeoVision Video Management System for IP cameras.

  • Page 7: Note For Connecting To Gv-Vms / Dvr / Nvr

    Note for Connecting to GV-VMS / DVR / NVR The H.265 Target Eyeball Dome is designed to work with and record on GV-VMS / DVR / NVR, a video management system. Once the camera is connected to the GV-VMS / DVR / NVR, the resolution set on the GV-VMS / DVR / NVR will override the resolution set on the camera’s Web interface.

  • Page 8: Note For Installing Camera Outdoor

    Note for Installing Camera Outdoor When installing the camera outdoor, be sure that: The camera is set up above the junction box to prevent water from entering the camera along the cables. Any power, audio and I/O cables are waterproofed using waterproof silicon rubber or the like.

  • Page 9: Chapter 1 Introduction

    Introduction Chapter 1 Introduction The H.265 Target Eyeball Dome is an outdoor, network camera equipped with an automatic IR-cut filter and an IR LED for day and night surveillance. The camera adheres to IP66 standards. The camera supports H.265 video codec to achieve better compression ratio while maintaining high quality pictures at reduced network bandwidths.

  • Page 10: Key Features

    1.1 Key Features  1/3" progressive scan low lux CMOS sensor  Min. illumination at 0.03 lux (B/W) and 0.05 lux (color)  Triple streams from H.265, H.264 and MJPEG  Up to 20 fps at 2592 x 1520, 25 fps at 2560 x 1440, 30 fps at 2048 x 1520 ...

  • Page 11: Packing List

    Introduction 1.2 Packing List   H.265 Target Eyeball Dome Screw x 3   Screw Anchor x 3 Waterproof Rubber Set  Drill Template Paster  Software Download Guide  Warranty Card...

  • Page 12: System Requirements

    1.3 System Requirements Intel Core i5-4670, 3.40 GHz Memory DDR3 8 GB RAM On Board Graphics Intel HD Graphics 4600 (Versions of driver from year 2014 or later required) Web Browsers  Internet Explorer 11.0 or above Mozilla Firefox  ...

  • Page 13: Optional Accessories

    Introduction 1.4 Optional Accessories Optional accessories can expand the capabilities and versatility of your GV-EBD4700. Contact your dealer for more information. Model Number Name Details GV-Mount211 Wall Mount Bracket Dimensions: 233 x 126 x 126 mm (9.2” x 5” x 5”) Weight: 0.92 kg (2.0 lb)

  • Page 14: Overview

    1.5 Overview Figure 1-1 Description Bottom ring Housing Lens Infrared indicator Power connector (DC 12 V) An optional power adapter is required. Ethernet connector / PoE...

  • Page 15: Installation

    The Target Eyeball Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Alternatively you can purchase optional mounting accessories to mount GV-EBD4700 on a wall. 1.6.1 Standard Installation Below are the instructions for Ceiling Mount. There are two kinds of Ceiling Mount: Concealed Installation and Open Installation.
  • Page 16 3. Remove the bottom ring by turning it anticlockwise. Figure 1-4 4. Connect the cables and then secure the camera. Figure 1-5 5. Adjust the monitoring direction. Figure 1-6...
  • Page 17 Introduction 6. Mount the bottom ring. Figure 1-7 For Open Installation Lead the cables out from the open slot on the bottom ring before screwing the camera to the ceiling as shown in Figure 1-5.   Figure 1-8...

  • Page 18: Optional Installation

    1.6.2 Optional Installation You can optionally purchase GV-Mount211 for Wall Bracket Mount. Follow the instructions below. Figure 1-9...
  • Page 19 Introduction GV-Mount 211 Packing List   GV-Mount211 Wall Mount Bracket Long Screw x 5   Short Screw x 4 Screw Anchor x 5   Plastic PG21 Conduit Connector Drill Template Paster 1. Unscrew the bracket. Figure 1-10...
  • Page 20 2. Loosen the indicated area by turning it anticlockwise. Figure 1-11 3. Stick the drill template paster to the wall with the arrow pointing up. 4. Drill 4 holes according to the sticker and insert the 4 screw anchors to the 4 holes. 5.
  • Page 21 Introduction 6. Remove the bottom ring by turning it anticlockwise. Figure 1-13 7. Thread the network and power wires through the wall mount bracket. 8. Secure the camera to the wall mount bracket with 3 short screws. Figure 1-14...
  • Page 22 9. Thread the Ethernet cable through the PG21 conduit connector and the power box as shown in No. 9, Figure 1-15. 10. Rotate the plastic ring to secure the conduit connector to the power box. Screw in the cap as shown in No. 10, Figure 1-15. 11.

  • Page 23: Waterproofing The Cable

    Introduction 1.7 Waterproofing the Cable Waterproof the Ethernet cable by using the supplied waterproof rubber set. 1. Attach the seal ring to the RJ-45 plug. Seal ring Figure 1-17 2. Insert the waterproof components through the Ethernet cable as shown below. 2 ...
  • Page 24 4. Insert the cable into the RJ-45 plug and screw the waterproof bolt in. Figure 1-20 5. Screw in the waterproof bolt lid. Bolt lid Figure 1-21 6. Finish the waterproof Installation. Figure 1-22...

  • Page 25: Chapter 2 Accessing The Camera

    Accessing the Camera Chapter 2 Accessing the Camera Once installed, the IP Eyeball Dome is accessible on a network. Follow these steps to configure the network settings and access your surveillance images. 2.1 Installing on a Network These instructions describe the basic connections to install the camera on the network. 1.

  • Page 26: Checking The Dynamic Ip Address

    Follow the steps below to look up the IP address and access the Web interface. Download and install the GV-IP Device Utility program from http://www.geovision.com.tw/english/5_8.asp Note: The PC installed with GV-IP Device Utility must be under the same LAN with the camera you wish to configure.
  • Page 27 Accessing the Camera The login page appears. Figure 2-3 For the first time accessing the Web interface, download and install the plug-in. Type the default ID and password admin and click Apply to login.

  • Page 28: Assigning An Ip Address

    2.1.2 Assigning an IP Address To assign a new static IP address, log in the Web interface to access the network setting page. Note: If your router does not support DHCP, the default IP address will be 192.168.0.10. In this case, it is strongly suggested that you modify the IP address to avoid the IP address conflict with other GV-IP devices on the same LAN.

  • Page 29: Accessing Live View

    Accessing the Camera 2.2 Accessing Live View After logging in to the eyeball dome, you will see the Home page as shown below: Figure 2-5...

  • Page 30: The Live View Window

    2.2.1 The Live View Window Figure 2-6 No. Name Function Set the display ratio of the image.  Scale: display images by 16:9. Proportional  Stretch: display images by window size.  Original: display images in its original size. Select a live video stream: main stream, sub stream or third Live Stream stream.
  • Page 31 Accessing the Camera Display packet loss rate and bit rate information in the bottom. Note: The paths for saving snapshots and local recordings are set in System Configuration. The buttons (No. 9 and No. 10) will appear on the floating toolbar after you move the mouse cursor on a live view window.

  • Page 32: Digital Zoom

    2.2.1.1 Digital Zoom To use the digital zoom function, follow these steps: 1. Click (No. 8, Figure 2-6) on the toolbar. 2. Click and hold the mouse button, and then drag from the top down to specify an area. 3. To restore the original image size, click in the enlarged area, or drag from the bottom up. 4.

  • Page 33: Chapter 3 Administrator Mode

    Administrator Mode Chapter 3 Administrator Mode The Administrator can access and configure GV-EBD4700 through the network. Click Setup at the top of the Web interface to access the following seven configuration tabs: Common, Network, Video, Image, Events, Security and System.
  • Page 34 List of Options See the table below for the settings available on the Web interface. Find the topic of interest by referring to the section number prefixed to each option. 3.1.1 Basic Info 3.1 Common 3.1.2 Local Settings 3.2.1 TCP/IP 3.2.2 Port 3.2.3 DDNS 3.2 Network...

  • Page 35: Common

    Administrator Mode 3.1 Common Under the Common tab, the Administrator can find the general settings for the camera, as well as shortcuts to the following setting pages.  TCP/IP: See 3.2.1 TCP/IP for details.  Time: See 3.7.1 Time for details. ...

  • Page 36: Local Settings

    3.1.2 Local Settings You can set local parameters for your PCs. Figure 3-3 [Video Param]  Processing Mode  Real Time Prior: Select this if the network is in good condition.  Fluent Prior: Select this if you want short time lag for live video. ...
  • Page 37 Administrator Mode [Recording and Snapshot]  Recording  Subsection By Time: Set a maximum time length of each recording file. If you select 5 minutes, a 30-minute event will be chopped into six 5-minute event files.  Subsection by Size: Set a maximum size limit of each recording file. When Storage Full ...

  • Page 38: Network

    3.2 Network The network section allows you to configure the network settings, modify ports, configure FTP server, and set up e-mail for notification. 3.2.1 TCP/IP Figure 3-4  IPv4: Select Static IP or DHCP according to your network environment.  Static IP address: Assign a static IP or fixed IP to the camera. Type the camera’s IP address, Subnet Mask, Router/Gateway, Preferred DNS server and Alternate DNS server.
  • Page 39 Administrator Mode  DHCP: The network environment has a DHCP server which will automatically assign a dynamic IP address to the camera. You can look up the current IP address using GV-IP Device Utility.  IPv6: Type the camera’s IPv6 Address and Default Gateway. Optionally change the Prefix Length according to your network settings.

  • Page 40: Port

    3.2.2 Port You can modify the default HTTP port, HTTPS port and RTSP port if necessary. Figure 3-5...

  • Page 41: Ddns

    Administrator does not need to go through the trouble of checking if the IP address assigned by DHCP Server or ISP (in xDSL connection) has changed. Figure 3-6 1. Enable DDNS Service. 2. Copy the website address http://ns.gvdip.com/register.aspx to a browser to access Geovision DDNS service. Figure 3-7...
  • Page 42 3. In the Geovision DDNS Server page, type a desired Hostname and Password. Re-type Password and type the verification letters shown in the image. Click Send. 4. In the Web interface of your GV-EBD4700, type Username. The username is the hostname registered in DDNS Server.

  • Page 43: Ftp

    Administrator Mode 3.2.4 FTP After the configuration of FTP, you will be able to upload snapshots from the camera to the specified FTP server. Figure 3-9 1. Type the Server IP address. 2. Change the Port No. of the FTP server if needed. 3.

  • Page 44: E-Mail

    3.2.5 E-mail After the configuration of E-mail, you will be able to send messages to the specified E-mail address when alarms are triggered. Figure 3-10 [Sender] 1. Type the Name and Address of the sender. 2. Type the SMTP Server. 3.

  • Page 45: Port Mapping

    Administrator Mode 3.2.6 Port Mapping This function can automatically forward and open certain ports on your router, allowing connection to your camera from the Internet. Figure 3-11 1. Enable Port Mapping, and select Mapping Type. 2. If you select Automatic, external ports will be automatically configured by the router. 3.

  • Page 46: 802.1X

    3.2.7 802.1x IEEE 802.1x is an IEEE standard for port-based Network Access Control. It provides an authentication mechanism to devices wishing to attach to a LAN or WLAN. Figure 3-12 1. Enable IEEE 802.1x. 2. Type the Username and Password. Type the password again for confirmation. 3.

  • Page 47: Video

    Administrator Mode 3.3 Video This section allows you to configure the three video streams. 3.3.1 Video You can set video parameters that your camera supports. You may also enable the sub- stream and third stream as needed. Figure 3-13  Capture Collect Mode: Sets the maximum resolution and frame rate.
  • Page 48  Resolution: You may select the different resolutions for each stream.  Frame Rate: Select a frame rate for encoding images. The unit is frame per second.  Bit Rate:  CBR: The camera transmits data at a constant data rate by varying the quality of the stream ...

  • Page 49: Capture

    Administrator Mode 3.3.2 Capture Using the Capture function, when an alarm is triggered, the camera will automatically upload the captured snapshots to the FTP server or send snapshots to the specified e-mail address. Figure 3-14 Enable Capture. Select Resolution. Choose the Image Quality. Choose the Number (of snapshot) to Capture upon alarm trigger.

  • Page 50: Roi

    3.3.3 ROI When Region of Interest (ROI) is enabled, the system ensures image quality for ROI first if the bit rate is insufficient. Figure 3-15 Enable ROI. Click and hold the mouse button, and then drag from the top down to specify an area.

  • Page 51: Media Stream

    Administrator Mode 3.3.4 Media Stream Media Stream By configuring media stream, you can set the camera to transmit code streams by UDP or TCP protocol to a specified IP address and port number. The settings can be saved and take effects after the camera is restarted.
  • Page 52 RTSP Multicast Address After an RTSP multicast address is configured, the third-party player can request the RTSP multicast media stream from the camera through the RTP protocol. Figure 3-17 1. Type the Multicast Address (224.0.0.0 to 239.255.255.255) and Port number (0 to 65535).

  • Page 53: Image

    Administrator Mode 3.4 Image This section introduces the Image Settings, On-screen Display, and Privacy Mask. 3.4.1 Image This page allows you to adjust image settings such as brightness, exposure, IR illumination and white balance. Figure 3-18 [Scene]  Current: Indicates the scene that is being used. ...
  • Page 54 Figure 3-19 [Image Enhancement]  Brightness: Adjust the degree of brightness of the image.  Saturation: Adjust the amount of a hue contained in a color.  Contrast: Set the degree of difference between the blackest pixel and the whitest pixel. ...
  • Page 55 Administrator Mode Figure 3-20 [Exposure] Exposure Mode: Select the correct exposure mode to achieve the desired exposure  effect. The default setting is Outdoor.  Shutter (s): The length of time that allows light to enter into the lens. You can set a shutter speed when Exposure Mode is set to Manual.
  • Page 56  Slowest Shutter: Set the slowest shutter speed that the camera can use during exposure.  Compensation: Adjust the compensation value as required to achieve the desired effects. You can set this parameter only when Exposure Mode is not set to Manual. Metering Control: Set the way the camera measures the intensity of light.
  • Page 57 Administrator Mode Figure 3-21 [Smart Illumination] Smart Illumination: Select Enable to adjust the IR illumination settings.   Control Mode:  Global Mode: Adjust IR illumination and exposure to achieve balanced image effects. Some areas might be overexposed if you select this option. This option is recommended if monitored range and image brightness are your first priority.
  • Page 58 Figure 3-22 [White Balance]  White Balance: Adjust the red or blue offset of the image.  Auto: Adjust the red and blue offset automatically according to the light condition (the color tends to be blue).  Outdoor: It is recommended for the outdoor scenes with a wide range of the color temperature variation.

  • Page 59: Osd

    Administrator Mode 3.4.2 OSD On Screen Display (OSD) is the text displayed on the screen with video images and may include time and other customized contents.   Figure 3-24 1. Enable a No. to select an area #, and then click Overlay OSD Content to select the content to display on screen.

  • Page 60: Privacy Mask

    3.4.3 Privacy Mask On certain occasions, you may need to set a mask area to block out parts of the camera image to protect privacy, for example, the keyboard of an ATM machine. When PTZ changes its position or zooms, the Privacy Mask will be adjusted accordingly to protect the area all along.

  • Page 61: Events

    Administrator Mode Events You can set the camera to generate an alarm upon motion detection. 3.5.1 Motion Detection Motion detection is used to generate an alarm whenever movement occurs in the specified area. Figure 3-26 1. In the Detection Area, click to add a new detection area.
  • Page 62 [Alarm Parameters]  Suppress alarm: After an alarm is triggered, the same alarm will not be reported within the set time.  Clear alarm: After an alarm is triggered,  If the same alarm is not triggered within the set time, the alarm will be cleared and the same alarm can be reported again.

  • Page 63: Security

    Administrator Mode 3.6 Security This section allows you to create user accounts and set the network security settings. 3.6.1 User There are two types of accounts: Administrator and Common User. Administrator: The default name of the administrator is admin, which cannot be ...

  • Page 64: Network Security

    3.6.2 Network Security There are four types of network security settings: HTTPS, RTSP Authentication, ARP Binding and IP Address Filtering. HTTPS You can enable the Hypertext Transfer Protocol Secure (HTTPS) settings to access the camera through a secure protocol. Click Enable and click Save. Figure 3-29 RTSP Authentication RTSP (Real Time Streaming Protocol) is an application layer protocol for transmitting video.
  • Page 65 Administrator Mode ARP Binding This function can protect the camera from ARP attacks. When the camera visits an IP of another network segment via a gateway, it can only communicate with the MAC address binding to the gateway address in the same segment. Figure 3-31 1.

  • Page 66: System

    System This section allows you to set the camera time, and update the firmware. 3.7.1 Time You can use the following methods to adjust the system time of your camera. Figure 3-33 To manually set a time or synchronize with the computer time: Enable Time Sync.
  • Page 67 Administrator Mode To adjust the camera’s time for daylight saving time: Click the DST tab at the top. Figure 3-34 Select Enable DST. Set a Start Time and End Time for the daylight saving time. Select a time period for DST Bias. Click Save.

  • Page 68: Maintenance

    3.7.2 Maintenance This section allows you to upgrade firmware, restart the camera, and backup/import camera configurations. Figure 3-35 [Firmware Upgrade] Under Firmware Upgrade, click Browse and select the firmware file (.zip). Optionally, select the check box to enable Upgrade Boot Program. Click Upgrade and then confirm to start.

  • Page 69: Chapter 4 Advanced Applications

    This chapter introduces more advanced applications. 4.1 Upgrading System Firmware GeoVision periodically releases the updated firmware on the website. The new firmware can be simply loaded into the camera using the Web interface or the IP Device Utility. Important Notes before You Start Before you start updating the firmware, please read these important notes: 1.

  • Page 70: Using The Web Interface

    4.1.1 Using the Web Interface Log into the Web interface and follow the steps below to update the firmware. 1. At the top, click Setup. In the left menu, select System and select Maintenance. This page appears. Figure 4-1 3. Click the Browse button to locate the firmware file (.zip) saved at your local computer. 4.

  • Page 71: Using The Gv-Ip Device Utility

    You can upgrade the camera firmware using the GV-IP Device Utility. Note the computer used to upgrade firmware must be under the same network of the camera. 1. Download IP Device Utility from http://www.geovision.com.tw/english/5_8.asp Then follow the onscreen instructions to install the program.
  • Page 72 7. Click the Browse button to locate the firmware file (.zip) saved at your local computer. 8. Click Upgrade to start upgrading the firmware.

  • Page 73: Restoring To Factory Default Settings

    Advanced Applications 4.2 Restoring to Factory Default Settings You can restore the camera to factory default settings using the Web interface. 1. At the top, click Setup. 2. In the left menu, select System and select Maintenance. 3. Under the Config Management section, click the Default button. Figure 4-4 Note: There is no default button on the camera.

  • Page 74: Chapter 5 Dvr Configurations

    The maximum number of streams supported by GV-EBD4700 is 8.  When a GV-EBD4700 is connected to IE browser or any other applications, it takes up 1 stream; when it is connected to GV-VMS / DVR / NVR, it takes up 2 streams.

  • Page 75: Setting Up Ip Cameras On Gv-System

    Camera Install and click IP Camera Install. This dialog box appears. Figure 5-1 To automatically set up the camera, click Scan Camera to detect any GV IP devices on the LAN. Double-click the GV-EBD4700 and type the user name and password of the camera. Figure 5-2...
  • Page 76 Click OK. This dialog box appears. Figure 5-3 Click OK. The IP camera is added to the connection list. Click the listed camera and select Display position to map the IP camera to a channel on the GV-System. Figure 5-4 The Statue column should display “Connected”.

  • Page 77: Customizing The Basic Settings On Gv-System

    DVR Configurations 5.1.1 Customizing the Basic Settings on GV-System After the camera is connected and assigned with a display position, you can configure the camera’s settings such as frame rate, codec type and resolution. Right-click the desired camera to see the following list of options: Figure 5-5 ...

  • Page 78: Setting Up Ip Cameras On Gv-Vms

    1. To access the IP Device Setup page, click Home , select Toolbar , click Configure and select Camera Install. Figure5 -6 2. Click Automatic Setup 3. Double-click the GV-EBD4700 and type the user name and password of the camera. Figure 5-7...
  • Page 79 DVR Configurations 4. Click OK. This dialog box appears. Figure 5-8 5. Click OK to add the camera to the list. 6. To connect the added camera, click the box besides the ID column. Upon successful connection, the Status icon shows green, with the video resolution and bitrate being displayed in the correspondent columns.

  • Page 80: Appendix

    Appendix A. RTSP Protocol Support The camera can support RTSP protocol for both video and audio streaming. If you are using Quick Time player, use the following RTSP command: rtsp://<IP of the camera>:554/<CH No.>.sdp For example, rtsp://192.168.3.111:554/CH001.sdp If you are using VLC player, use the following RTSP command: rtsp://<ID>:<Password>@<IP of the camera>:554/<CH No.>.sdp For example, rtsp://admin:admin@192.168.3.111:554/CH001.sdp If you use the VLC, and if authentication is not required, enter:...
