GV-IPCam H.264
User's Manual
Before attempting to connect or operate this product,
ICH264TIV111-A
please read these instructions carefully and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-BX130D-0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoVision GV-BX130D-0

Summary of Contents for GeoVision GV-BX130D-0

  • Page 1 GV-IPCam H.264 User's Manual Before attempting to connect or operate this product, ICH264TIV111-A please read these instructions carefully and save this manual for future use.
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
  • Page 3 Safety Notice FCC Compliance for GV-CBW120/220 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation of the device.
  • Page 4 To upgrade your camera to firmware V1.09 or later, it is required to use GV IP Device Utility V8.5.3.0. Firmware Model Model Number Version Fixed Lens GV-BX110D V1.08 Varifocal Lens GV-BX120D Varifocal Lens GV-BX130D-0 Varifocal Lens GV-BX130D-1 Fixed Lens GV-BX140DW Box Camera GV-BX220D-0 V1.11 GV-BX220D-1 GV-BX220D-2 Varifocal Lens GV-BX220D-3...
  • Page 5 Firmware Model Model Number Version GV-BX120D-E GV-BX220D-E IR Arctic Box Varifocal Lens V1.11 Camera GV-BX320D-E GV-BX520D-E GV-MFD110 V1.08 GV-MFD120 Mini Fixed GV-MFD130 Fixed Lens V1.11 Dome GV-MFD220 GV-MFD320 GV-MFD520 Mini Fixed GV-MDR120 Rugged GV-MDR220 Fixed Lens V1.11 Dome GV-MDR320 GV-MDR520 GV-BL110D Varifocal Lens V1.08...
  • Page 6 Firmware Model Model Number Version GV-VD120D (IK10+, Transparent Cover) GV-VD121D (IK10+, Smoked Cover) GV-VD122D (IK7, Transparent Cover) GV-VD123D (IK7, Smoked Cover) GV-VD220D (IK10+, Transparent Cover) GV-VD221D Vandal Proof Varifocal (IK10+, Smoked Cover) V1.11 IP Dome Lens GV-VD222D (IK7, Transparent Cover) GV-VD223D (IK7, Smoked Cover) GV-VD320D...
  • Page 7 Firmware Model Model Number Version GV-FD120D Varifocal Fixed IP V1.11 GV-FD220D Lens Dome GV-FD320D GV-CB120 V1.11 Cube Camera Fixed Lens GV-CB220 GV-CBW120 Wireless V1.11 Fixed Lens Cube Camera GV-CBW220...

  • Page 8: Table Of Contents

    Contents Naming and Definition...........XVI Options ................XVII Note for Connecting to GV-System......XVIII Note for Adjusting Focus and Zoom......XIX Note for Installing Camera Outdoor......XX Chapter 1 Introduction .............1 1.1 System Requirement ..............7 Chapter 2 Box Camera .............8 2.1 Packing List................10 2.2 Features..................11 2.2.1 GV-BX140DW with WDR Function ........
  • Page 9 Chapter 3 IR Arctic Box Camera ........29 3.1 Packing List................30 3.2 Features..................31 3.3 Overview..................32 3.4 Installation.................33 3.5 Connecting the Camera............37 3.5.1 Wire Definition..............37 3.6 Notice for Using the IR Arctic Box Camera ......39 3.6.1 Enabling IR LED after Loading Default ........ 39 3.6.2 Disabling Status LED under Low Light Conditions ....
  • Page 10 5.4 Installation.................61 5.4.1 Connecting the Camera ............62 5.4.2 Adjusting the Angles ............66 5.4.3 Adjusting Lens and Inserting a Micro SD Card..... 70 5.4.4 Installing the Sun-Shield Cover ........... 72 Chapter 6 PTZ Camera ...........73 6.1 Packing List................74 6.2 Features..................75 6.3 Overview..................76 6.4 Installation.................78 6.4.1 Ceiling Mount ..............
  • Page 11 7.3 Overview..................106 7.4 Installation................108 7.5 Connecting the Camera............108 7.6 Focus Adjustment..............108 7.7 I/O Terminal Block ..............109 7.7.1 Pin Assignment ..............109 7.7.2 Voltage Load Expansion (Optional) ........109 7.8 PT Control ................110 Chapter 8 Vandal Proof IP Dome.........112 8.1 Packing List................113 8.2 Features...................114 8.3 Overview..................115 8.4 Installation................116...
  • Page 12 9.5 Connecting the Camera............143 9.6 I/O Terminal Block ..............144 9.6.1 Pin Assignment ..............144 9.6.2 Voltage Load Expansion (Optional) ........145 CHAPTER 10 Cube & Wireless Camera......146 10.1 Packing List................147 10.2 Features.................148 10.3 Overview................149 10.4 Installation................150 10.5 Connecting the Camera ............152 Chapter 11 Getting Started ..........153 11.1 Accessing the Live View............153 11.1.1 Checking the Dynamic IP Address........
  • Page 13 12.2.6 Picture-in-Picture and Picture-and-Picture View....183 12.2.7 Alarm Notification ............186 12.2.8 Video and Audio Configuration ........188 12.2.9 Remote Configuration ............. 189 12.2.10 Camera Name Display ..........189 12.2.11 Image Enhancement ............. 189 12.2.12 Visual PTZ ..............190 12.2.13 I/O Control..............193 12.2.14 Visual Automation ............
  • Page 14 13.3.8 RTSP ................236 13.4 Monitoring ................237 13.5 Recording Schedule .............239 13.5.1 Recording Schedule Settings .......... 239 13.5.2 I/O Monitoring Settings ............ 240 13.6 Remote ViewLog ..............241 13.7 Network .................242 13.7.1 LAN Configuration............242 13.7.2 Wireless Client Mode ............244 13.7.3 Advanced TCP/IP............
  • Page 15 Chapter 15 Advanced Applications ......271 15.1 Upgrading System Firmware..........271 15.1.1 Using the Web Configuration Interface ......273 15.1.2 Using the IP Device Utility ..........274 15.2 Backing Up and Restoring Settings........276 15.3 Restoring to Factory Default Settings .........278 15.4 Verifying Watermark .............288 15.4.1 Accessing AVI Files............
  • Page 16 18.1.1 Installing GView V2 ............319 18.1.2 Activating the GView Function......... 320 18.1.3 Connecting to the IP Camera .......... 321 18.1.4 Playing Back the Recordings from the IP Camera.... 323 18.1.5 Other Functions............... 324 18.2 Windows Smartphone ............329 18.2.1 Installing MSView V2 / V3 ..........329 18.2.2 Activating the MSView V2 / V3 Function ......
  • Page 17 Specifications: Bullet Camera ........387 Specifications: PTZ Camera .........395 Specifications: PT Camera ...........400 Specifications: Vandal Proof IP Dome......405 Specifications: Fixed IP Dome ........413 Specifications: Cube Camera & Wireless Cube Camera...................420 Appendix ................425 A. Settings for Internet Explorer 8 ..........425 B. Supported Lenses for Box Camera .........426 C.

  • Page 18: Naming And Definition

    Naming and Definition GeoVision Analog and Digital Video Recording Software. The GV-System also refers to GV-Multicam System, GV-System GV-NVR System, GV-DVR System and GV-Hybrid DVR System at the same time.

  • Page 19: Options

    Options Optional devices can expand your camera’s capabilities and versatility. Contact your dealer for more information. Device Description A mountable infrared LED device that improves image performance of Box Cameras under low light conditions. Note that the GV-IR LED is only GV-IR LED compatible with GV-BX110D and GV-IR LED T2 is compatible with GV-BX120D / 130D Series /...

  • Page 20: Note For Connecting To Gv-System

    Note for Connecting to GV-System The GV-IPCAM H.264 is designed to work with GV-System, a hybrid or digital video management system. Note the following when GV-IPCAM H.264 is connected to GV-System: Normally, the images are recorded to the memory card inserted in the GV-IP Camera H.264 (except GV-MFD110 and GV-IR Arctic Box Camera).

  • Page 21: Note For Adjusting Focus And Zoom

    Note for Adjusting Focus and Zoom When adjusting the Focus and Zoom Screws (on Box Camera, IR Arctic Box Camera, Bullet Camera, Vandal Proof IP Dome and Fixed IP Camera), please do not over tighten the Focus and Zoom screws. The screws only need to be as tight as your finger can do it;...

  • Page 22: Note For Installing Camera Outdoor

    Note for Installing Camera Outdoor When installing the IR Arctic Box Camera, Bullet Camera, Vandal Proof IP Dome or Mini Fixed Rugged Dome outdoor, be sure that: The camera is set up above the junction box to prevent water from entering the camera along the cables.
  • Page 23 After opening the camera cover, ensure the screws are tightened and the cover is in place. To prevent the lens from fogging up, ensure to replace the silica gel bag every time you open the camera, and conceal the gel bag in camera within 2 minutes of exposing to open air.

  • Page 25: Chapter 1 Introduction

    Lux, D/N, Auto Iris, f: GV-BX120D Lens 2.8 ~ 12 mm, F/1.4, 1/3’’ CS Lens 1.3 MP, H.264 D/N, Varifocal Auto Iris, f: 2.8 ~ 12 GV-BX130D-0 Camera Lens mm, F/1.4, 1/3’’ CS Lens 1.3 MP, H.264 D/N, Fixed GV-BX130D-1...
  • Page 26 Model Model No. Description 2 MP, H.264 D/N, Auto Iris, f: 2.8 ~ 8.5 GV-BX220D-0 mm, F/1.4, 1/3” CS Lens 2 MP, H.264 D/N, Auto Iris, f: 3.1 ~ 8 GV-BX220D-1 mm, F/1.2, 1/3’’ CS Lens 2 MP, H.264 D/N, Auto Iris, f: 2.8 ~ 6 GV-BX220D-2 mm, F/1.3,...
  • Page 27 Introduction Model Model No. Description 1.3 MP, H.264, Low Lux, D/N, Auto GV-BX120D-E Iris, f: 2.8 ~ 12 mm, F/1.4, 1/3’’ CS Lens 2 MP, H.264 D/N, Auto Iris, f: 2.8 ~ 6 GV-BX220D-E mm, F/1.3, IR Arctic Varifocal 1/3’’ CS Lens Lens Camera 3 MP, H.264 D/N,...
  • Page 28 Model Model No. Description 1.3 MP Low Lux GV-MDR120 H.264, Color, Fixed Iris 2 MP H.264, Color, Mini Fixed GV-MDR220 Fixed Fixed Iris Rugged Lens Dome 3 MP H.264, Color, GV-MDR320 Fixed Iris 5 MP H.264, Color, GV-MDR520 Fixed Iris 1.3 MP, H.264, GV-BL110D Auto Iris...
  • Page 29 Introduction Model Model No. Description GV-VD120D (IK10+, Transparent Cover) GV-VD121D 1.3 MP, H.264, (IK10+, Smoked Cover) Low Lux, GV-VD122D Auto Iris (IK7, Transparent Cover) GV-VD123D (IK7, Smoked Cover) GV-VD220D (IK10+, Transparent Cover) Vandal GV-VD221D Proof IP (IK10+, Smoked Cover) 2 MP, H.264, Varifocal Dome GV-VD222D...
  • Page 30 Model Model No. Description 1.3 MP, H.264, GV-CB120 Cube Fixed Iris Camera 2 MP, H.264, GV-CB220 Fixed Iris Fixed Lens 1.3 MP, H.264, Wireless GV-CBW120 Wireless Fixed Iris Cube 2 MP, H.264, Camera GV-CBW220 Wireless Fixed Iris...

  • Page 31: System Requirement

    Introduction 1.1 System Requirement To perform the GV-IPCAM H.264 operations through Web browser, ensure your PC is in good network connection, and use one of the following web browsers:  Microsoft Internet Explorer 7.x or later  Google Chrome  Mozilla Firefox ...

  • Page 32: Chapter 2 Box Camera

    GV-BX120D Varifocal Lens f:2.8 ~ 12 mm, F/1.4, H.264, Low 1/3” CS Lens Lux, D/N Megapixel, Auto Iris, 1.3 MP, GV-BX130D-0 Varifocal Lens f: 2.8 ~ 12 mm, F/1.4, H.264, D/N 1/3’’ CS Lens Megapixel, Fixed Iris, 1.3 MP, GV-BX130D-1 Fixed Lens f: 4 mm, F/1.4,...
  • Page 33 Box Camera Model No. Specifications Description Megapixel, Fixed Iris, 1 MP, H.264, GV-BX140DW f: 2.8 ~ 12 mm, F/1.4, D/N, WDR 1/3’’ CS Lens Megapixel, Auto Iris, GV-BX220D-0 f:2.8 ~ 8.5 mm, F/1.4, 1/3” CS Lens Megapixel, Auto Iris, f: 3.1 ~ 8 mm, GV-BX220D-1 F/1.2, 1/3’’...

  • Page 34: Packing List

    2.1 Packing List  Box Camera  Terminal Block  Fixed Focal or Varifocal Megapixel Lens  Pin Wrench (for GV-BX110D only)  C-mount Lens Adapter (for GV-BX110D only)  Six Lens Rings (for GV-BX120D / 130D series / 220D series / 520D series) ...

  • Page 35: Features

    Box Camera 2.2 Features  1.3 / 2 / 3 / 5 megapixel progressive scan CMOS  Dual video streams For GV-BX110D: Dual streams from H.264, MPEG4 or MJPEG For Box Camera (except GV-BX110D): Stream 1 from H.264 or MJPEG; Stream 2 from H.264, MPEG4 or MJPEG Frame rate: ...

  • Page 36: Gv-Bx140Dw With Wdr Function

     Support for iPhone, iPad, Android and 3GPP  28 languages on Web interface 2.2.1 GV-BX140DW with WDR Function GV-BX140DW is equipped with a wide dynamic range (WDR) sensor. The special sensor can deal with the scenes having a large difference in foreground and background light intensities, and heighten the details visible in the camera view.

  • Page 37: Overview

    Box Camera 2.3 Overview 2.3.1 GV-BX110D Figure 2-1 Note: The Zoom Screw and Auto Iris Connector are only available in the varifocal model.
  • Page 38 Name Description Audio Out Connects a speaker for audio output. Audio In Connects a microphone for audio input. Resets all configurations of the GV-IPCAM Default H.264 to the default factory settings. See 15.3 Restoring to Factory Default Settings. Inserts a micro SD/SDHC card to store Memory Card Slot recording data.
  • Page 39 Box Camera Status LED The status LED is used to reflect the system status of the camera. Status LED Description Red Light ON The system powers on and succeeds to boot up. Flashing Red and Green The camera is ready for use with network Lights connectivity.

  • Page 40: Gv-Bx120D / 130D Series / 140Dw / 220D Series / 320D Series / 520D-0

    2.3.2 GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series / 520D-0 Figure 2-2 Note: 1. The Light Sensor (No.11) is only available in GV-BX140DW. Keep the Light Sensor unobscured for accurate light detection. 2. The Iris Screw (No.13) is only available for GV-BX520D-0. 3.
  • Page 41 Box Camera Name Description Connects to a portable monitor for setting Video Out the focus and angle of Box Camera during initial installation. Inserts a micro SD/SDHC card to store Memory Card Slot recording data. Audio Out Connects a speaker for audio output. Audio In Connects a microphone for audio input.

  • Page 42: Connecting The Camera

    2.4 Connecting the Camera The Box Camera is designed for indoor use. Please make sure the installing site is shielded from rain and moisture. 2.4.1 GV-BX110D Figure 2-3...
  • Page 43 Box Camera If you are using the auto iris model, plug the iris control cable to the Auto Iris Connector on the camera. Use a standard network cable to connect the camera to your network. Optionally connect a speaker and an external microphone. Optionally connect a monitor using an RCA video-out wire.

  • Page 44: Series / 520D-0

    2.4.2 GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series / 520D-0 Figure 2-4 If you are using the auto iris model, plug the iris control cable to the Auto Iris Connector on the camera. Use a standard network cable to connect the camera to your network. Optionally connect a speaker and an external microphone.
  • Page 45 Box Camera You are ready to access the live view, adjust the image clarity and configure the basics. See Getting Started, Chapter 11.

  • Page 46: Accessory Installation

    2.5 Accessory Installation 2.5.1 C-Mount Lenses If you use a C-mount lens, it requires a certain distance from the camera’s imaging chip to focus the lens. Mount the supplied C-mount lens adapter / lens ring to the camera, and then attach the lens onto the camera body. GV-BX110D ...
  • Page 47 Box Camera GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series /  520D-0 Three types of C-mount lens rings are provided for GV-BX120D / 130D Series / 220D Series / 320D Series / 520D-0:  0.188 mm (transparent color) x 2 ...

  • Page 48: Infrared Illuminators (Optional)

    2.5.2 Infrared Illuminators (Optional) If you use an infrared (IR) illuminator with I/O function, follow the steps below to install it. Connect the infrared illuminator to the terminal block on the camera. See 2.6 The I/O Terminal Block. Access the Web interface of the camera. Select Video and Motion, select Video Settings, select Streaming 1 and set the IR Check Function option to be Trigger by Input or Trigger IR by D/N.

  • Page 49: I/O Terminal Block

    Box Camera 2.6 I/O Terminal Block The terminal block, located on the back panel of the Box Camera, provides the interface to one input and one output devices. The I/O terminal block can be used for applications such as motion detection, event alerts via E- Mail and FTP, and center monitoring through Center V2 and VSM.
  • Page 50 GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series /  520D-0 The GV-BX120D / 130D Series / 140DW / 220D Series / 320D Series / 520D-0 support one digital input and one digital output of dry contact. Function Digital Input Digital Output...

  • Page 51: Connecting To Gv-Relay V2 (Optional)

    Box Camera 2.6.2 Connecting to GV-Relay V2 (Optional) The Box Camera (except GV-BX110D) can only drive a maximum load of 200mA 5V DC. Connect the camera to a GV-Relay V2 module (optional product) to expand the maximum voltage load. See a comparison on maximum voltage loads with and without GV-Relay: Maximum Voltage Load Models...
  • Page 52 To connect the Box Camera to GV-Relay V2, refer to the figure and table below. Figure 2-9 GV-Relay V2 I/O Terminal Block Pin 2 (GND) Pin 3 (Digital Output)

  • Page 53: Chapter 3 Ir Arctic Box Camera

    Chapter 3 IR Arctic Box Camera The IR Arctic Box Camera series is a variant of the Box Camera series. They are outdoor cameras with IP66 rating. They are designed for day and night surveillance in environments with extreme temperatures. IR Arctic Box Camera Model No.

  • Page 54: Packing List

    3.1 Packing List  IR Arctic Box Camera  Screw Anchor x 4  Screw x 4  Washer x 4  Big Torx Wrench  Small Torx Wrench  Silica Gel Bag x 2  Sticker x 2  GV-PA481 ...

  • Page 55: Features

    IR Arctic Box Camera 3.2 Features  1.3 / 2 / 3 / 5 megapixel progressive scan CMOS  Stream 1 from H.264 or MJPEG; Stream 2 from H.264, MPEG4 or MJPEG  Frame rate: Camera Model Frame Rate GV-BX120D-E Up to 30 fps at 1280 x 1024 GV-BX220D-E Up to 30 fps at 1920 x 1080...

  • Page 56: Overview

    3.3 Overview Figure 3-1 Note: The Iris Screw (No. 7) is only available in GV-BX520D-E. Name Description Desiccant that keeps the camera housing Silica gel bag dry. IR power plug Supplies power to the built-in IR LEDs. Focus Screw Adjusts the focus of the camera. Module screw Holds the module in place.

  • Page 57: Installation

    IR Arctic Box Camera 3.4 Installation The IR Arctic Box Camera is designed for outdoor use. Mark the installation site and drill four holes for screw anchors. Insert the supplied screw anchors. Secure the camera to the wall using the supplied washers and screws. Figure 3-2 Connect the camera to the network and supply power via the PoE cable.
  • Page 58 Tilt Adjustment Figure 3-4 Pan Adjustment Figure 3-5 Based on the live view, adjust the focus, zoom and iris (in GV- BX520D-E only) of the camera. Unscrew the cover with the supplied small torx wrench. Figure 3-6...
  • Page 59 IR Arctic Box Camera Hold the connectors and unplug them. Figure 3-7 Important: Unscrew and remove the cover carefully. Pulling the cover off may cause damages to the inner wiring of the camera. Adjust the focus, zoom and iris screws. Figure 3-8...
  • Page 60 Replace the silica gel bag. Paste the sticker to the front side of the silica gel bag. Press the sticker several times to make sure it adheres properly. Paste the silica gel bag to the indicated place. Figure 3-9 Important: Be sure that the new silica gel bag is concealed in the camera housing within 2 minutes of exposing to open air.

  • Page 61: Connecting The Camera

    IR Arctic Box Camera 3.5 Connecting the Camera 3.5.1 Wire Definition Figure 3-10 Wire Color Definition Black (thick) Black BNC TV out Green RCA Audio Out Pink RCA Audio In Optionally connect a speaker (green) and an external microphone (pink). Optionally connect a monitor using a Video Out wire.
  • Page 62 Connect the camera’s cable to the GV-PA481 PoE adapter as illustrated below. The power and network will be supplied simultaneously. Figure 3-11 The status LED of the camera will be on. You are ready to access the live view, adjust the image clarity and configure the basics.

  • Page 63: Notice For Using The Ir Arctic Box Camera

    IR Arctic Box Camera 3.6 Notice for Using the IR Arctic Box Camera Ensure that you:  enable IR LED function on the Web interface after loading the default settings.  disable the status LED to reduce reflection when a green light spot appears on the live view.

  • Page 64: Disabling Status Led Under Low Light Conditions

    3.6.2 Disabling Status LED under Low Light Conditions If you have a green light spot on the live view, this is likely due to insufficient light at the installation site, which causes the status LED to reflect on the camera cover. In this case, it is advisable that you disable the status LED.

  • Page 65: Chapter 4 Mini Fixed Dome & Mini Fixed Rugged Dome

    Chapter 4 Mini Fixed Dome & Mini Fixed Rugged Dome The Mini Fixed Dome is a fixed, mini-sized ceiling-mount network camera. Two series are available, the Mini Fixed Dome series, which are designed for indoor surveillance and the Mini Fixed Rugged Dome series for outdoor environments.

  • Page 66: Packing List

    4.1 Packing List  Mini Fixed Dome or Mini Fixed Rugged Dome  Torx Wrench  Self Tapping Screw x 2  Screw Anchor x 2  Cable stopper x 1  Installation sticker (for GV-MDR series only)  Silica gel bag x 2 (for GV-MDR series only) ...

  • Page 67: Features

    Mini Fixed & Rugged Dome 4.2 Features  1/3’’ progressive scan CMOS  Megapixel lens  Dual video streams Camera Model Frame Rate Dual video streams from two of H.264, GV-MFD110 MPEG4 or MJPEG GV-MFD series (except GV-MFD110) Stream 1 from H.264 or MJPEG; Stream 2 from H.264, MPEG4 or MJPEG GV-MDR series ...
  • Page 68  Day and night function (electronic)  IK7 rating (for GV-MDR series only)  IP66 rating (for GV-MDR series only)  Endurable to low environment temperatures (-20°C ~ 50°C / -4°F ~ 122°F) (for GV-MDR series only)  2-axis mechanism (GV-MFD series); 3-axis mechanism (GV-MDR series) Camera Type Tilt...

  • Page 69: Overview

    Mini Fixed & Rugged Dome 4.3 Overview 4.3.1 GV-MFD110 Figure 4-1 Name Description Resets the camera to factory default. See Default Button 15.3 Restoring to Factory Default Settings. Lens Rotates the les right/left to adjust focus. Focus Screw Loosens the screw to adjust the focus. Tilt Screw Loosens the screw to adjust the tilt angle.

  • Page 70: Gv-Mfd120 / 130 / 220 / 320 / 520

    4.3.2 GV-MFD120 / 130 / 220 / 320 / 520 Figure 4-2 Name Description Resets the camera to factory default. See Default Button 15.3 Restoring to Factory Default Settings. Lens Receives image inputs. Tilt Screw Loosens the screw to adjust tilt angle. Built-In Microphone Provides one-way audio.

  • Page 71: Gv-Mdr120 / 220 / 320 / 520

    Mini Fixed & Rugged Dome LED Name Description 1. Link Turns on when the network is connected. 2. ACT Turns on when data are being transmitted. 3. PWR Turns on when power is on. 4. SW RDY (Status) Turns on when the system is ready. 4.3.3 GV-MDR120 / 220 / 320 / 520 Figure 4-3 Name...
  • Page 72 Name Description Built-In Microphone Provides one-way audio. Resets the camera to factory default. See Default Button 15.3 Restoring to Factory Default Settings. Turns red when the power is on. Flashes Power and status orange light twice when the system is ready.

  • Page 73: Installation

    Mini Fixed & Rugged Dome 4.4 Installation To install a Mini Fixed Dome, make sure the installing site is shielded from rain and moisture. 4.4.1 GV-MFD Series Unscrew the housing cover using the supplied torx wrench. Put the camera on the desired location and make 2 marks on the ceiling for screw anchors.
  • Page 74 Tilt Adjustment Figure 4-5 For GV-MFD110, adjust image clarity using the GV-IP Device Utility program. For details, see 11.2 Adjusting Image Clarity. Except for GV-MFD110, insert a Micro SD/SDHC card into the memory card slot (No. 7, Figure 4-2). 10. Secure the housing cover using the supplied torx wrench. 11.

  • Page 75: Gv-Mdr Series

    Mini Fixed & Rugged Dome 4.4.2 GV-MDR Series Paste the installation sticker on the desired location. The arrow should point toward the direction that the camera faces. Drill one hole on each of the two curves for screw anchors. Drill the circle (30 mm in diameter) if you want to run the cable into the ceiling.
  • Page 76 Access the live view. For details, see 11.1 Accessing the Live View. Adjust the angles based on the live view. Pan Adjustment Figure 4-9 Tilt Adjustment Figure 4-10 Rotational Adjustment Figure 4-11...
  • Page 77 Mini Fixed & Rugged Dome Insert a Micro SD/SDHC card into the memory card slot (No. 9, Figure 4-3). 10. Secure the housing cover using the supplied torx wrench. 11. Optionally conceal the cable opening with the supplied cable stopper. Figure 4-12...

  • Page 78: Connecting The Camera

    4.5 Connecting the Camera Refer to the wire definition and illustrations below to connect the power and network. 4.5.1 Wire Definition GV-MFD120 / 130 / 220 / 320 / 520 The data cable provides connections for power and network access. The wires are illustrated and defined below: Figure 4-13 Wire Color...

  • Page 79: Power And Network Connection

    Mini Fixed & Rugged Dome 4.5.2 Power and Network Connection For GV-MFD120 / 130 / 220 / 320 / 520, there are two ways to supply power to the camera:  Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time.

  • Page 80: Vehicle Installation

    4.5.3 Vehicle Installation To install the Mini Fixed Rugged Dome on a vehicle, clip the ferrite core to the camera cable. In accordance to EN 50155, the ferrite core is used for reduction of the cable-based and radiated interferences, ensuring stable image quality.

  • Page 81: Chapter 5 Bullet Camera

    Chapter 5 Bullet Camera The Bullet Cameras is specifically designed for outdoors and is weather- sealed and IP66 rating. The camera also features IR LEDs for infrared illumination in night vision applications. Four models are available: Model No. Specifications Description GV-BL110D 1.3 MP, H.264 1.3 MP, H.264,...

  • Page 82: Packing List

    5.1 Packing List  Bullet Camera  Lens (Megapixel and Built-In 16 IR LEDs)  Self Tapping Screw x 3  Plastic Screw Anchor x 3  Torx Wrench x 2  Sun-Shield Cover Kit (1 Sun-Shield Cover, 2 Philips Head Screws, 2 Plastic Screw Spacers and 2 Hexagon Screws included) ...

  • Page 83: Features

    Bullet Camera 5.2 Features  1/3’’ progressive scan CMOS for GV-BL110D / 120D 1/2.5’’ progressive scan CMOS for GV-BL130D / 220D / 320D  Dual video streams GV-BL110D: Dual streams from H.264, MPEG4 or MJPEG GV-BL120D / 220D / 320D: Stream 1 from H.264 or MJPEG; Stream 2 from H.264, MPEG4 or MJPEG ...

  • Page 84: Overview

    5.3 Overview Figure 5-1 Name Description Memory Card Slot Receives a Micro SD/SDHC memory card. Zoom Screw Holds the zoom lens in place. Focus Screw Holds the focus lens in place Resets all configurations to factory default. Default Button See 15.3. Restoring to Factory Default Settings.

  • Page 85: Installation

    Bullet Camera 5.4 Installation These instructions describe the basic installation of the Bullet Camera. Slide the cable clamp to the camera base. Figure 5-2 Install the Bullet Camera to the wall. Figure 5-3 Remove the protection sticker from the camera’s cover Connect the power, network and other wires to the Bullet Camera.

  • Page 86: Connecting The Camera

    Access the live view. For details, see 11.1. Accessing the Live View. Adjust angles of the camera body based on the live view. Three shafts can be adjusted. See 5.4.2 Adjusting the Angles. Loosen the camera’s cover, adjust the focus of the camera and optionally insert a micro SD card into the SD card slot.
  • Page 87 Bullet Camera Wire Color Definition Digital In Brown DC 12V+ / AC 24V- Orange Digital Out Black DC 12V- / AC 24V+ Yellow Ground Red RCA Audio in Green RCA Audio out Power Connection There are two ways to supply power to the camera: ...
  • Page 88 Voltage Load Expansion (Optional) The camera can only drive a maximum load of 200mA 5V DC. Connect the camera to a GV-Relay V2 module (optional product) to expand the maximum voltage load. See a comparison on maximum voltage loads with and without GV-Relay below: Maximum Voltage Load Models...
  • Page 89 Bullet Camera To connect the GV-Relay V2 module to the Bullet Camera, refer to the figure and table below. Output Devices Connect to Power Figure 5-7 GV-Relay V2 Bullet Camera Ground (Yellow) Digital Out (Orange)

  • Page 90: Adjusting The Angles

    5.4.2 Adjusting the Angles The Bullet Camera is designed to be adjustable in three shafts for easy and flexible installation. First Shaft You can adjust the camera body by 360 degrees to the right or the left. Unscrew the panning lock screw with the torx wrench. Panning Lock Screw Torx Wrench Figure 5-8...
  • Page 91 Bullet Camera Second Shaft You can adjust the camera body up and down by 90, 112.5, 135, 157.5 or 180 degrees by using the gears inside the camera body and the camera base. Unscrew the tilting lock screw with the torx wrench. Tilting Lock Screw Torx Wrench Figure 5-10...
  • Page 92 Adjust the angle of camera body to 90, 112.5, 135, 157.5 or 180 degrees. Then move the camera base to the left to combine the gears. Figure 5-12 Fasten the tilting lock screw. Third Shaft You can adjust the camera base by 360 degrees. Unscrew the base fixing screw with the torx wrench.
  • Page 93 Bullet Camera Adjust the angle of camera base, and fasten the base fixing screw. Figure 5-14...

  • Page 94: Adjusting Lens And Inserting A Micro Sd Card

    5.4.3 Adjusting Lens and Inserting a Micro SD Card To adjust the camera’s lens to produce a clear image and insert a micro SD card into the SD card slot, follow the steps below. Loosen the camera’s cover. Figure 5-15 Remove the silica gel bag.

  • Page 95: Bullet Camera

    Bullet Camera If you want to insert a micro SD/SDHC card, follow the steps below. Loosen the fixing screw. Figure 5-17 Slightly pull out the camera module. Insert a micro SD/SDHC card into the memory card slot. Figure 5-18 Push the camera module back and fasten the fixing screw. Insert a new silica gel bag to the camera module and fasten the camera’s cover within 2 minutes of opening the silica gel bag package.

  • Page 96: Installing The Sun-Shield Cover

    5.4.4 Installing the Sun-Shield Cover After setting up the Bullet Camera, now you can install the sun-shield cover to the camera. Fasten the hexagon screws either on top or below the camera. Figure 5-19 Put the sun-shield cover on top of hexagon screws. Make sure to aim the rear hexagon screw at the edge of the sun-shield cover’s aperture for optimal sun-shield performance.

  • Page 97: Chapter 6 Ptz Camera

    Chapter 6 PTZ Camera The GV-PTZ010D camera is a ceiling-mount device that provides panning, tilting and zooming functions. The camera is designed to monitor a wide area and also to focus on a specific part on the live view when suspicious events occur.

  • Page 98: Packing List

    6.1 Packing List  GV-PTZ010D  Mounting Base  Mounting Cover  Wall Mount Bracket  Screw Anchor x 3  Long Screw x 3  Short Screw x 3  Round Screw x 3  DC 12V Power Adapter ...

  • Page 99: Features

    PTZ Camera 6.2 Features  1/4" CCD image sensor  Dual streams from H.264, MPEG4 or MJPEG  Up to 30 fps at 704 x 480 / Up to 25 fps at 704 x 576  Day and night function (electronic) ...

  • Page 100: Overview

    6.3 Overview Figure 6-1 Name Description DC 12V / AC 24V Connects to a DV 12V or AC 24V Power Terminal Block Adapter. LAN/PoE Connects to a 10/100 Ethernet or PoE. I/O Terminal Block For details, see 6.7 I/O Terminal Block. Inserts a micro SD/SDHC card to store Memory Card Slot recording data.
  • Page 101 PTZ Camera Name Description Turns green when the power is on and Power LED turns off when the power is off. Microphone Records the sounds. Resets to system default settings. For Default details, see 15.3 Restoring to Factory Default Settings.

  • Page 102: Installation

    6.4 Installation The GV-PTZ010D / GV-PT110D camera is designed for indoor usage. Please make sure that the installing location is shielded from rain and moisture. There are two ways to mount the PTZ / PT Camera: Ceiling Mount and L-Shaped Wall Mount. 6.4.1 Ceiling Mount Use the mounting base to make 3 marks on the wall for screw anchors.
  • Page 103 PTZ Camera Fix the mounting base (now with the PTZ / PT Camera attached) to the wall with 3 long screws. Figure 6-4 Put on the mounting cover. To fit the installation environment, you can cut the parts indicated by arrows to make an opening for wires and cables.

  • Page 104: L-Shaped Wall Mount

    6.4.2 L-Shaped Wall Mount You may wall-mount the GV-PTZ010D / GV-PT110D camera with or without the mounting cover. Take the wall mount bracket and make 2 marks on the wall for screw anchors. Figure 6-6 Drill the marks and insert 2 screw anchors. Insert the long screws and leave enough distance (approximately 2 mm) to hang the wall mount bracket later.
  • Page 105 PTZ Camera Hang the wall mount bracket on the screws and push the wall mount bracket downward. Make sure the long screws are tightened. Figure 6-8 Without Mounting Cover Attach the wall mount bracket with the PTZ / PT Camera using 3 ...
  • Page 106 With Mounting Cover To install the mounting cover, attach the mounting base to the  camera and then put on the mounting cover. See steps 3 and 5 in the Ceiling Mount section. Attach the wall mount bracket with the PTZ / PT Camera using 3 ...

  • Page 107: Connecting The Camera

    PTZ Camera 6.5 Connecting the Camera Figure 6-11 Use a standard network cable to connect the camera to your network. Optionally connect a speaker and an external microphone. Connect power using one of the following methods:  plugging the supplied power adapter to the power port. ...

  • Page 108: Focus Adjustment

    6.6 Focus Adjustment On initial installation, it is advised that you adjust the focus for image clarity. Print out the diagram of radiating lines included on Software CD and hang up the diagram at the surveillance area. Use the Zoom In / Out and Focus In / Out buttons on the PTZ control panel from the Web interface (No.4 and 5, Figure 6-15) and adjust the PTZ Camera until it displays clear radiating lines as shown in picture on the left.

  • Page 109: I/O Terminal Block

    PTZ Camera 6.7 I/O Terminal Block The 3-pin terminal block, located on the back panel of the PTZ Camera, provides the interface to one digital input and one digital output. The I/O terminal block can be used for applications such as motion detection, event alerts via E-Mail and FTP, and center monitoring through Center V2 and VSM.

  • Page 110: Voltage Load Expansion (Optional)

    6.7.2 Voltage Load Expansion (Optional) The camera can only drive a maximum load of 200mA 5V DC. Connect the camera to a GV-Relay V2 module (optional product) to expand the maximum voltage load. See a comparison on maximum voltage loads with and without GV-Relay below: Maximum Voltage Load Model...

  • Page 111: Ptz Control

    PTZ Camera 6.8 PTZ Control After you have installed the PTZ Camera on network and accessed the camera’s Web interface you are ready to configure the PTZ Camera. To see how to install the PTZ Camera on network, see Getting Started, Chapter 11.
  • Page 112 Buttons on the PTZ control panel: Name Description Exit Closes the PTZ control panel. Moves the PTZ Camera to 8 directions: Pan / Tilt Control up, down, left, right, left up, left down, right up and right down. Brings the camera view back to the home Home point where the camera faces front at a 90 degree angle to the base of the device.

  • Page 113: Automatic Focus

    PTZ Camera 6.8.2 Automatic Focus When the camera view is fuzzy, you may use the auto focus feature to obtain a sharper view. On the PTZ control panel, click the Option button (No. 6, Figure 6-15) and select AF for automatic focus. 6.8.3 PTZ Camera Settings Accessing the PTZ Camera Settings To access PTZ camera settings, click the Option button (No.
  • Page 114  PT Speed: Determines the panning (horizontal movement) and tilting (vertical movement) speed when using the Pan / Tilt Control buttons on the PTZ control panel. The drop-down list contains 5 speed settings: 1 is the slowest and 5 the fastest. ...

  • Page 115: Image Settings

    PTZ Camera 6.8.4 Image Settings Image Setting provides features on iris control, white balance, image orientation and other image processing tools to generate clearer images. To access these features, open the VISCA OSD Configuration dialog box and select Image Setting. [Iris] adjusts the amount of exposure.
  • Page 116  AWB: Automatic White Balance (AWB) automatically compensates for colors under different light levels. AWB is ideal for scenes with a fixed light source. Use the slider to select from 0 to 8. A higher value produces a brighter image and a lower value produces a dimmer image.
  • Page 117 PTZ Camera  Freeze: Instantly freezes the live view image when On is selected.  AGC: Automatic Gain Control (AGC) utilizes an electronic circuit  which amplifies video signal when the signal strength falls below a given value due to lack of the light on the camera. Adjust camera sensitivity to provide clear images.

  • Page 118: Preset Settings

    6.8.5 Preset Settings For PTZ Camera to automatically move toward a point in live view, establish a Preset. A Preset is a point in live view that can be configured and saved for future use. The PTZ Camera allows up to 256 Preset points. For details on the maximum number of Preset points, see 6.8.3 PTZ Camera Settings.
  • Page 119 PTZ Camera Renaming a Preset Point To rename a Preset point: Click the Option button (No. 6, Figure 6-15), select Preset Set and select Naming. The dialog box appears. Figure 6-18 Click the Preset point you wish to rename and type the new name in the blank at the top.
  • Page 120 Starting and Stopping a Preset Point To start a Preset movement, click the Option button (No. 6, Figure 6-15), select Preset Go, and select a Preset number which has been set previously. Alternatively, you may use the number pad on the PTZ control panel to enable a Preset movement: Click the Show Preset button (No.

  • Page 121: Sequence Settings

    PTZ Camera 6.8.6 Sequence Settings For PTZ Camera to automatically perform a series of movements, you can configure a Sequence. A Sequence links up more than two Preset points to form a sequence of movements. Up to 8 Sequences can be created. Configuring a Sequence After you have configured the Preset points you wish the camera to follow (for details, see 6.8.5 Preset Settings), you are ready to...
  • Page 122 Use the Preset drop-down list to select the Preset points for the Sequence. Use the Dwell Time drop-down list to select the staying time that the camera stays at the Preset point. The dwell time ranges from 0 to 127 seconds at an interval of 0.5 second.

  • Page 123: Auto Pan Settings

    PTZ Camera 6.8.7 Auto Pan Settings For the PTZ Camera to survey a horizontal view, establish an Auto Pan. Up to 4 sets of Auto Pan can be created. Configuring an Auto Pan To configure a horizontal movement: Adjust the angle of the camera view using the Up and Down Control buttons since any vertical movements of the camera will not be recorded by Auto Pan.
  • Page 124 Configuring the Speed of Auto Pan You can configure the speed for each set of Auto Pan differently: Open the VISCA OSD Configuration dialog box and select Advance. Figure 6-20 Select the Auto Pan number you wish to configure and select the Speed.

  • Page 125: Rebooting The Camera

    PTZ Camera Starting and Stopping Autopan To start an Auto Pan, click the Option button (No. 6, Figure 6-15), select Auto and select a desired Auto Pan number. The PTZ Camera will first return to the starting position of the selected Auto Pan and proceeds with the selected Auto Pan movement.

  • Page 126: System Configuration

    6.8.8 System Configuration To configure lens settings, open the VISCA OSD Configuration dialog box and select System Configure. Figure 6-21  Zoom + AF: Automatically focuses after zooming. It is advised to use this feature with a zooming distance of at least 1 meter. ...

  • Page 127: Chapter 7 Pt Camera

    Chapter 7 PT Camera The GV-PT110D camera is a ceiling-mount device that features panning and tilting functions. The GV-PT110D is designed to monitor a wide area and to focus on a selected point on live view when suspicious events occur. 7.1 Packing List ...
  • Page 128  DC 12V Power Adapter  Washer x 3  GV-PT110D Software CD  GV-PTZ110D / GV-PTZ010D Quick Start Guide  GV-NVR Software DVD  GV-NVR Quick Start Guide...

  • Page 129: Features

    PT Camera 7.2 Features  1.3 megapixel progressive scan CMOS  Dual streams from H.264, MPEG4 or MJPEG  Up to 15 fps at 1280 x 1024  Day and night function (with removable IR-cut filter)  Pan and tilt (Pan: -175° ~ 175°; Tilt: -45° ~ 90°) ...

  • Page 130: Overview

    7.3 Overview Figure 7-1 Name Description DC 12V / AC 24V Connects to a DV 12V or AC 24V Power Terminal Block Adapter. LAN / PoE Connects to a 10/100 Ethernet or PoE. I/O Terminal Block For details, see 7.7 I/O Terminal Block. Inserts a micro SD/SDHC card to store Memory Card Slot recording data.
  • Page 131 PT Camera Name Description Turns green when the system operates Status LED normally and turns off when system error occurs. Turns green when the power is on and Power LED turns off when the power is off. Manually rotates this ring left or right to Focus Ring adjust focus.

  • Page 132: Installation

    7.4 Installation For installation procedures of the GV-PT110D, see 6.4 Installation. 7.5 Connecting the Camera For procedures of connecting the GV-PT110D, see 6.5 Connecting the Camera. 7.6 Focus Adjustment After you have followed 5.5 Connecting the Camera and connected all the necessary cables and wires, follow the steps below to adjust image clarity.

  • Page 133: I/O Terminal Block

    PT Camera 7.7 I/O Terminal Block The 3-pin terminal block, located on the back panel of the PT Camera, provides the interface to one digital input and one digital output. The I/O terminal block can be used for applications such as motion detection, event alerts via E-Mail and FTP, and center monitoring through Center V2 and VSM.

  • Page 134: Pt Control

    7.8 PT Control The GV-PT110D shares similar user interfaces and features with the GV- PTZ010D camera. The supported functions are listed in the table below. Supported Function Description PT Control Panel The following buttons on the PT control panel are available: Exit, Pan / Tilt Control, Home, Option and Show Preset.
  • Page 135 PT Camera Supported Function Description Sequence A Sequence consists of a series of Preset points. Configure a Sequence to direct the camera to perform s series of movements. For details, see 6.8.6 Sequence Settings. Auto Pan The camera can be configured to monitor the surveillance area in a horizontal movement.

  • Page 136: Chapter 8 Vandal Proof Ip Dome

    Chapter 8 Vandal Proof IP Dome The Vandal Proof IP Domes are designed for outdoor usage. They are equipped with automatic infrared cut filters for day and night surveillance. Model options range from 1.3. to 3 megapixels: Model No. Specification Description GV-VD120D Megapixel,...

  • Page 137: Packing List

    Vandal Proof IP Dome 8.1 Packing List  Vandal Proof IP Dome  Silica Gel Bag x 2  Screw Anchor x 4  Torx Wrench x 1  Ceiling Screw x 4  Blue Screw x 3  T-Cap Screw x 3 ...

  • Page 138: Features

    8.2 Features  1/3’’ progressive scan CMOS for GV-VD120D 1/2.5’’ progressive scan CMOS for GV-VD220D / 320D  Dual video streams. Stream 1 from H.264 or MJPEG; stream 2 from H.264, MPEG4 or MJPEG  Up to 30 fps at 1280 x 1024 for GV-VD120D Up to 30 fps at 1920 x 1080 for GV-VD220D Up to 20 fps at 2048 x 1536 for GV-VD320D ...

  • Page 139: Overview

    Vandal Proof IP Dome 8.3 Overview Figure 8-1 Name Description Turns on (green) when the power is on Power LED and turns off when there is no power supply. Turns on (green) when the system Status LED operates normally and turns off when system error occurs.

  • Page 140: Installation

    8.4 Installation The Vandal Proof IP Dome is designed for outdoors. With the standard packing, there are two ways to install the Vandal Proof IP Dome: hard- ceiling mount and in-ceiling mount. 8.4.1 Hard-Ceiling Mount Figure 8-2 Unpack the camera package and take out the camera body. Unscrew the housing cover...
  • Page 141 Vandal Proof IP Dome Unscrew thread lock Unscrew the inner housing Take out the camera body...
  • Page 142 Mark the position of four screw holes on the desired installation location, and drill holes in the marked locations. Drill the ellipse part if you wish to put the wires through it. Figure 8-3 Insert the screw anchors to the 4 holes on the ceiling. Secure the back cover to the ceiling with 4 ceiling screws.
  • Page 143 Vandal Proof IP Dome Connect the network, power and other cables to the camera. See 8.5 Connecting the Camera. Access the live view. See 11.1 Accessing the Live View. Based on the live view, adjust the camera to a desired angle as illustrated below.
  • Page 144 Rotational Adjustment Figure 8-7 10. Adjust image clarity using the GV-IP Device Utility program. For details, see 11.2 Adjusting Image Clarity. 11. Screw on the thread lock as shown in step 1. 12. Replace the silica gel bag on the camera body within 2 minutes of opening the silica gel bag package.

  • Page 145: In-Ceiling Mount

    Vandal Proof IP Dome 8.4.2 In-Ceiling Mount Figure 8-8 Follow step 1 in 8.4.1 Hard-Ceiling Mount section to remove the housing cover, thread lock and back cover, and take out the camera body. Cut out a circle with a diameter of 142 mm on the ceiling. Insert a blue screw to the indicated holes on the camera body.
  • Page 146 Screw in a plastic clip to the blue screw, hold it with one hand and use a screw driver to rotate the blue screw until the plastic clip moves half way down. Figure 8-10 Secure a T-cap on top of the blue screw with a small screw cap and a T-cap screw.
  • Page 147 Vandal Proof IP Dome Insert the camera to the ceiling with the plastic screws moved inward. Figure 8-12 Move the blue screws out and rotate the blue screw with a screw driver until the plastic clip and the bottom of the camera body clamps the ceiling tightly.

  • Page 148: Connecting The Camera

    8.5 Connecting the Camera Connect your Vandal Proof IP Dome to power, network and other cables needed. 8.5.1 Wire Definition The cables of Vandal Proof IP Dome are illustrated and defined below. Figure 8-14 Wire Color Definition Black (thick) Shielding Ground Black (thin) DC 12V+ / AC 24V+ DC 12V- / AC 24V-...

  • Page 149: Power Connection

    Vandal Proof IP Dome 8.5.2 Power Connection There are two ways to supply power to the camera:  Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time. ...

  • Page 150: Voltage Load Expansion (Optional)

    8.5.3 Voltage Load Expansion (Optional) The camera can only drive a maximum load of 200mA 5V DC. Connect the camera to a GV-Relay V2 module (optional product) to expand the maximum voltage load. See a comparison on maximum voltage loads with and without GV-Relay: Maximum Voltage Load Models...

  • Page 151: Chapter 9 Fixed Ip Dome

    Chapter 9 Fixed IP Dome The Fixed IP Dome is an indoor device designed with 3-axis mechanism for easy and flexible installation. The Fixed IP Dome also features IR LED for infrared illumination during low light conditions. Three models are available: Model No.

  • Page 152: Packing List

    9.1 Packing List 9.1.1 Packing List for Hard-Ceiling Mount  Fixed IP Dome  Torx Wrench x 1  Mounting Plate x 1  Short Screw Anchor x 3  Ceiling Screw x 3  Plate Screw x 3  TV-out Wire ...

  • Page 153: Packing List For In-Ceiling Mount

    Fixed IP Dome 9.1.2 Packing List for In-Ceiling Mount  In-Ceiling Housing Cover  Mounting Plate x 1  Mounting Bracket x 3  Copper Pillar x 3  Copper Pillar Screw x 6  Bracket Screw x 3  Thread Lock Screw x 1 ...

  • Page 154: Features

    9.2 Features  1/3’’ progressive scan CMOS for GV-FD120D 1/2.5” progressive scan CMOS for GV-FD220D / 320D  Dual video streams. Stream 1 from H.264 or MJPEG; stream 2 from H.264, MPEG4 or MJPEG  Up to 30 fps at 1280 x 1024 for GV-FD120D Up to 30 fps at 1920 x 1080 for GV-FD220D Up to 20 fps at 2048 x 1536 for GV-FD320D ...

  • Page 155: Overview

    Fixed IP Dome 9.3 Overview Figure 9-1 Name Description Focus Screw Adjusts the focus of the camera. Zoom Screw Adjusts the zoom of the camera. Rotational Screw Loosens to adjust the camera angle. Tilt Screw Loosens the screw to tilt the camera. Pan Disc Loosens to pan the camera.
  • Page 156 Name Description Connects I/O devices. For details, see 9.6 I/O Terminal Block I/O Terminal Block. DC 12V Port Connects to power. Turns on (green) when the system Status LED operates normally and turns off when system error occurs. Turns on (green) when the power is on Power LED and turns off when there is no power supply.

  • Page 157: Installation

    Fixed IP Dome 9.4 Installation The Fixed IP Dome is designed for indoors. With the standard packing, there are three ways to install the Fixed IP Dome: hard-ceiling mount, in- ceiling mount and wall-surface mount. 9.4.1 Hard-Ceiling Mount Figure 9-2 Paste the supplied sticker onto a desired location on the ceiling.
  • Page 158 Take out the camera body Figure 9-4 Secure the camera body to the mounting plate with three ceiling screws. Figure 9-5 Connect the network, power and other cables to the camera. See 9.5 Connecting the Camera. Access the live view. See 11.1 Accessing the Live View.
  • Page 159 Fixed IP Dome Based on the live view, adjust the camera to a desired angle as illustrated below. Tip: The 3-axis mechanism offers flexible and easy ceiling / wall installation. Pan Adjustment Figure 9-6 Tilt Adjustment Figure 9-7...
  • Page 160 Rotational Adjustment Figure 9-8 Adjust image clarity using the GV-IP Device Utility program. For details, see 11.2 Adjusting Image Clarity. Secure the housing cover as shown in step 2. Remove the indicated part when necessary. Figure 9-9 Note: Adjust the black mask inside the housing cover to make sure the camera view is not obscured.

  • Page 161: In-Ceiling Mount

    Fixed IP Dome 9.4.2 In-Ceiling Mount Figure 9-10 Follow step 2 in the 9.4.1 Hard-Ceiling Mount to remove the housing cover and take out the camera body. Paste the supplied sticker onto a desired location on the ceiling and cut a circle on the ceiling along the edge of the sticker. On the mounting plate, locate the 3 holes labeled as 1 and insert the 3 copper pillars from the back side.
  • Page 162 From the side with the numbering, secure the copper pillars with 3 copper pillar screws. Figure 9-12 Place the 3 mounting brackets at the indent next to the copper pillars (labeled as 2 on the mounting plate) and secure them using the 3 bracket screws.
  • Page 163 Fixed IP Dome Place the mounting plate on the camera body with the copper pillars inserted in the locations indicated below. The arrow on the mounting plate should be pointing toward the front of the camera. Figure 9-14 From the bottom of the camera, secure the copper pillars using the 3 copper pillars screws.
  • Page 164 14. Use the housing cover thread and the thread lock screw to attach the housing cover to the camera body. Figure 9-16 15. Place the housing cover on the camera body with the GeoVision logo pointing toward the front of the camera. Figure 9-17...

  • Page 165: Wall-Surface Mount

    Fixed IP Dome 9.4.3 Wall-Surface Mount Figure 9-18 Follow step 2 in 9.4.1 Hard-Ceiling Mount section to remove the housing cover and take out the camera body. Paste the supplied sticker onto a desired location on the wall. Drill the three red dots, and the ellipse mark only if you wish to run the wires into the wall.
  • Page 166 Access the live view. See 11.1 Accessing the Live View. Follow steps 6 and 7 in 9.4.1 Hard-Ceiling Mount section to adjust the angle, focus and zoom of the camera. Follow step 8 in 9.4.1 Hard-Ceiling Mount section to secure the housing cover.

  • Page 167: Connecting The Camera

    Fixed IP Dome 9.5 Connecting the Camera Figure 9-20 Use a standard network cable to connect the camera to your network. Optionally connect a speaker and an external microphone. Optionally connect a monitor using a Video Out wire. Enable this function by selecting your signal format at the TV Out field on the Web interface.

  • Page 168: I/O Terminal Block

    9.6 I/O Terminal Block The terminal block, located on the back panel of the Fixed IP Dome, provides the interface to one input and one output devices. The I/O terminal block can be used for applications such as motion detection, event alerts via E-Mail and FTP, and center monitoring through Center V2 and VSM.

  • Page 169: Voltage Load Expansion (Optional)

    Fixed IP Dome 9.6.2 Voltage Load Expansion (Optional) The camera can only drive a maximum load of 200mA 5V DC. Connect the camera to a GV-Relay V2 module (optional product) to expand the maximum voltage load. See a comparison on maximum voltage loads with and without GV-Relay below: Maximum Voltage Load Models...

  • Page 170: Chapter 10 Cube & Wireless Camera

    Chapter 10 Cube & Wireless Camera The Cube Camera is a light weighted wired / wireless network camera designed for indoor usage. Its simple design allows for fast and easy installation and fixed-spot surveillance once installed. Four models are available: Model No.

  • Page 171: Packing List

    Cube & Wireless Camera 10.1 Packing List • Cube Camera • Supporting Rack • Screw x 3 • Screw Anchor x 3 • DC 5V or DC 12V Power • DC 5V Power Adapter Adapter (for GV-CBW120 / 220 (for GV-CB120 / 220) •...

  • Page 172: Features

    10.2 Features • 1/2.5’’ progressive scan CMOS • Stream 1 from H.264 or MJPEG; stream 2 from H.264, MPEG4 or MJPEG • Up to 30 fps at 1280 x 1024 for GV-CB120 / CBW120 Up to 30 fps at 1920 x 1080 for GV-CB220 / CBW220 •...

  • Page 173: Overview

    Cube & Wireless Camera 10.3 Overview Figure 10-1 Name Description Microphone Receives sounds. Speaker Plays sounds. Connects to a 10/100 Ethernet. Turns red when the system powers on. Status LED Turns orange when the system is ready. Turns green when the camera is connected to the Internet through wires.

  • Page 174: Installation

    10.4 Installation Follow the steps below to install, connect to and adjust your Cube Camera and Wireless Cube Camera. Put the supporting rack on the desired location and make marks for screw anchors. Figure 10-2 Drill the marks and insert the screw anchors. Secure the supporting rack onto the wall using the supplied screws.
  • Page 175 Cube & Wireless Camera Connect the network and power cables to the camera. See 10.5 Connecting the Camera. Access the live view. See 11.1 Accessing the Live View. Adjust the angle of the camera based on live view and fasten the indicated screw.

  • Page 176: Connecting The Camera

    10.5 Connecting the Camera Figure 10-5 Use a standard network cable to connect the camera to your network. Power on using the supplied power adapter. The status LED of the camera will be orange.

  • Page 177: Chapter 11 Getting Started

    Chapter 11 Getting Started This section provides the initial and basic configurations of the GV-IPCAM H.264. 11.1 Accessing the Live View Access or configure your camera according to the camera type and its firmware version: Camera Type & Default Connection Type Firmware Version ...
  • Page 178  GV-BX110D camera is connected to the network.  GV-BL110D  GV-MFD110 To avoid IP conflict with other GeoVision  GV-PT110D IP devices, it is advisable to re-assign a  GV-PTZ010D different IP address. See 11.1.2 Configuring the IP Address for more...

  • Page 179: Checking The Dynamic Ip Address

    Getting Started 11.1.1 Checking the Dynamic IP Address Follow the steps below to look up the IP address and access the Web interface. Install the GV-IP Device Utility program included on the GV-IPCAM H.264 Software CD. Note: The PC installed with GV-IP Device Utility must be under the same LAN with the GV-IPCAM H.264 you wish to configure.
  • Page 180 Find the camera with its Mac Address, click on its IP address and select Web Page. Figure 11-2 The login page appears. Figure 11-3 Type the default ID and password admin and click Apply to log in.

  • Page 181: Configuring The Ip Address

    Getting Started 11.1.2 Configuring the IP Address Follow the steps below to configure the IP address. Open your web browser, and type the default IP address http://192.168.0.10. In both Login and Password fields, type the default value admin. Click Apply. In the left menu, select Network and then LAN to begin the network settings.
  • Page 182 Important: If Dynamic IP Address or PPPoE is enabled, you need to know which IP address the camera will get from DHCP server or ISP to log in. If your camera is installed in the LAN, use the GV-IP Device Utility to look up its current dynamic IP address.

  • Page 183: Configuring The Wireless Connection

    Getting Started 11.1.3 Configuring the Wireless Connection For GV-CBW120/220, you may choose to create wireless connection to the Internet. To set up the wireless LAN for the first time, power on and connect a standard network cable to the camera. An IP address will be automatically assigned to the camera.
  • Page 184 C. Select Ad-Hoc or Infrastructure for the Network type. D. Select the Authentication Type using the drop-down list. You can also obtain this information by clicking the Access Point Survey button. E. Type the WPA-PSK Pre-shared Key or WEP depending on the encryption setting for the Access Point.

  • Page 185: Getting Started

    Getting Started Enable wireless LAN. A. On the Web interface, select Network and LAN. This page appears. Figure 11-6 B. Select Wireless for Optional Network Type C. To use a dynamic IP address assigned by the DHCP server, select Dynamic IP address. To use a fixed IP address, select Static IP address and type the IP address information.

  • Page 186: Adjusting Image Clarity

    11.2 Adjusting Image Clarity Note the procedures described in this section only apply to Box Camera, IR Arctic Box Camera, GV-MFD110, Bullet Camera, PT Camera, Vandal Proof IP Dome and Fixed IP Dome. To adjust focus of a PTZ camera, refer to 6.6 Focus Adjustment;...
  • Page 187 Getting Started On the GV-IP Utility window, click the button to search for the IP devices connected in the same LAN. Click the IP Address of the camera you desire. A drop-down list appears. Figure 11-7 Select Focus Value. The Login dialog box appears. Figure 11-8...
  • Page 188 Type the user name and password of the camera selected. The default is admin for both user name and password. This window appears. Figure 11-9 For GV-VD120D / 121D, VD-220D / 221D and VD-320D / 321D, hold the supplied Focus Adjustment Cap over the camera view. For details, see 11.2.1 Using Focus Adjustment Cap for details.

  • Page 189: Using Focus Adjustment Cap

    Getting Started 11.2.1 Using Focus Adjustment Cap There are two types of Focus Adjustment Caps for GV-VD120D / 121D, VD-220D / 221D and VD-320D / 321D. Hold and close the Focus Adjustment Cap to the lens in order to simulate the IK10+ housing cover before installing it.
  • Page 190 Do not leave a distance between the Focus Adjustment Cap and the camera.

  • Page 191: Locations Of Adjustment Screws

    Getting Started 11.2.2 Locations of Adjustment Screws Models Adjustment Screws GV-BX110D GV-BX120D GV-BX130D Series GV-BX140DW GV-BX220D Series GV-BX320D Series GV-BX520D-0 GV-MFD110 Bullet Camera...
  • Page 192 Models Adjustment Screws PT Camera Vandal Proof IP Dome Fixed IP Dome Note: GV-BX110D (fixed lens) and GV-BX130D-1 do not contain a Zoom Screw.

  • Page 193: Configuring The Basics

    Getting Started 11.3 Configuring the Basics Once the camera is properly installed, the following important features can be configured using the browser-based configuration page and are discussed in the following sections in this manual:  Date and time adjustment: see 13.8.1 Date & Time Settings. ...

  • Page 194: Chapter 12 Accessing The Camera

    Chapter 12 Accessing the Camera Two types of users are allowed to log on to the GV-IPCAM H.264: Administrator and Guest. The Administrator has unrestricted access to all system configurations, while the Guest has the access to live view and network status only.
  • Page 195 Click Apply. A video image, similar to the example on Figure 12-2, is now displayed in your browser. Note: To enable the updating of images in Internet Explorer, you must set your browser to allow ActiveX Controls and perform a once-only installation of GeoVision’s ActiveX component onto your computer.

  • Page 196: Functions Featured On The Main Page

    12.2 Functions Featured on the Main Page This section introduces the features of the Live View window and Network Status on the main page. The two features are accessible by both Administrator and Guest. Main Page of Guest Mode Video and Motion ▼...

  • Page 197: The Live View Window

    Accessing the Camera 12.2.1 The Live View Window Internet Explorer When accessing the live view using Internet Explorer, the following window appears. Figure 12-3 No. Name Function 1 Play Plays live video. 2 Stop Stops playing video. Talks to the surveillance area from the local 3 Microphone computer.
  • Page 198 No. Name Function Takes a snapshot of live video. 5 Snapshot --- See 12.2.3 Snapshot of Live Video. Records live video to the local computer. 6 File Save --- See 12.2.4 Video Recording. Switches to full screen view. Right-click the image to have these options: Snapshot, Full Screen, Resolution, Zoom In, Zoom Out, Wide Angle Dewarping, PIP, PAP, GPS and Google...
  • Page 199 Accessing the Camera No. Name Function Enables the I/O Control Panel or the Visual Automation. --- See 12.2.13 I/O Control. 10 I/O Control Note this function is not available in Mini Fixed Dome, Mini Fixed Rugged Dome, Cube Camera and Wireless Cube Camera. Non-IE Browsers When accessing the live view using Google Chrome, Firefox or Safari, this window appears.

  • Page 200: The Control Panel Of The Live View Window

    12.2.2 The Control Panel of the Live View Window To open the control panel of the Live View window, click the arrow button on top of the window. You can access the following functions by using the right and left arrow buttons on the control panel. Figure 12-5 Tip: Administrator may also access live view and camera adjustment settings using the GV-IP Device Utility:...
  • Page 201 Accessing the Camera [Information] Displays the version of the camera, time of the local computer, time of the camera (host time), the number of users logging in the camera and the OCX registration path. [Video] Displays the current video codec, resolution and data rate. [Audio] Displays the audio data rates when the microphone and speaker devices are enabled.
  • Page 202 Figure 12-6...
  • Page 203 Accessing the Camera Brightness: Adjusts the brightness of the image.  Contrast: Adjusts the relative differences between one pixel and the  next. Saturation: Adjusts the saturation of the image.  Sharpness: Adjusts the sharpness of the image  Gamma: Adjusts the relative proportions of bright and dark areas ...
  • Page 204 Shutter Speed Balanced Quality Image Brightness Poor Good Excellent Image Clarity Poor Good Excellent Image Smoothness Excellent Good Poor D/N: Select Auto for automatic switch between day mode and night  mode depending on the amount of light detected. Select Black and white to switch the camera to night mode.

  • Page 205: Snapshot Of Live Video

    Accessing the Camera 12.2.3 Snapshot of Live Video To take a snapshot of live video, follow these steps: Click the Snapshot button (No. 5, Figure 12-3). The Save As dialog box appears. Specify Save in, type the File name, and select JPEG or BMP as Save as Type.

  • Page 206: Wide Angle Dewarpping

    12.2.5 Wide Angle Dewarpping The live view can be curved especially near the corners. Use this function to correct the warping of live view. To access this feature: Right-click the live view to display the drop-down list and select Wide Angle Setting.

  • Page 207: Picture-In-Picture And Picture-And-Picture View

    Accessing the Camera 12.2.6 Picture-in-Picture and Picture-and-Picture View The full screen mode provides two types of close-up views: Picture-in- Picture (PIP) and Picture-and Picture (PAP). The two views are useful to provide clear and detailed images of the surveillance area. Picture-in-Picture View With the Picture in Picture (PIP) view, you can crop the video to get a close-up view or zoom in on the video.
  • Page 208 Picture-and-Picture View With the Picture and Picture (PAP) view, you can create a split video effect with multiple close-up views on the image. A total of 7 close-up views can be defined. Figure 12-9 Right-click the live view and select PAP. A row of three inset windows appears at the bottom.
  • Page 209 Accessing the Camera To delete a navigation box, right-click the desired box, select Focus Area of PAP Mode and click Delete. To exit the PAP view, right-click the image and click PAP again.

  • Page 210: Alarm Notification

    12.2.7 Alarm Notification After input triggers and motion detection, you can be alerted by a pop-up live video and view up to four captured images. Pop-up live Captured video images video Figure 12-10 To configure this function, click the Show System Menu button (No. 8, Figure 12-3), and select Alarm Notify.
  • Page 211 Accessing the Camera  I/O Alarm Notify: Once the input device is triggered, the captured images are displayed on the control panel of the Live View window. For this function to work, the Administrator needs to install the input device properly. See 13.2.1 Input Setting. ...

  • Page 212: Video And Audio Configuration

    12.2.8 Video and Audio Configuration You can enable the microphone and speaker for two-way audio communication and adjust the audio volume. To change audio configuration, click the Show System Menu button (No. 8, Figure 12-3), and select Video and Audio Configuration. Figure 12-12...

  • Page 213: Remote Configuration

    Accessing the Camera 12.2.9 Remote Configuration You can upgrade firmware over the network. Click the Show System Menu button (No. 8, Figure 12-3), and select Remote Config. The Remote Config dialog box will appear. [Firmware Upgrade] In this tab, you can upgrade the firmware over the Internet.

  • Page 214: Visual Ptz

    12.2.12 Visual PTZ Note this feature is only available in PTZ Camera and PT Camera. The Visual PTZ provides two types of PTZ control panels on live images for easy and direct PTZ operation. Activating Visual PTZ Click the PTZ Control button (No.
  • Page 215 Accessing the Camera Figure 12-15 The Visual PTZ Panel provides the following features: Name Description Shortens the apparent distance between the Zoom In camera and the view. Lengthens the apparent distance between the Zoom Out camera and the view. Focus In Adjusts the sharpness of the camera view.
  • Page 216 Setting Visual PTZ Panel Click the .button on the top left corner and select Visual PTZ, the following options will appear.  PTZ Control Type: Two types of visual PTZ control panels are available.  Type 1: Appears only when a movement of the cursor is detected and disappears when it is static.

  • Page 217: I/O Control

    Accessing the Camera 12.2.13 I/O Control Note this function is only available for Box Camera, Bullet Camera, Vandal Proof IP Dome and Fixed IP Dome. The I/O Control window provides a real-time graphic display of camera status, I/O status, and alarm events. Additionally, you can remotely force output to be triggered.

  • Page 218: Visual Automation

    12.2.14 Visual Automation Note this function is only available for Box Camera, Bullet Camera, Vandal Proof IP Dome and Fixed IP Dome. The Visual Automation allows you to change the current state of the electronic device by simply clicking on its image, e.g. turning the light ON. This feature is only available when the Visual Automation is set ahead by the Administrator.

  • Page 219: Network Status

    Accessing the Camera 12.2.15 Network Status To view the network status, in the left menu, click Network and select Status. Figure 12-18...

  • Page 220: Chapter 13 Administrator Mode

    Chapter 13 Administrator Mode The Administrator can access the system configuration through the network. Eight categories of configurations are involved in the system configuration: Video and Motion, I/O Control or Digital I/O and PTZ, Events and Alerts, Monitoring, Recording Schedule, Remote ViewLog, Network and Management.
  • Page 221 Administrator Mode List of Menu Options Find the topic of interest by referring to the section number prefixed to each option. The available options vary among camera models. 13.1.1 Video Settings 13.1.2 Motion Detection 13.1.3 Privacy Mask 13.1 Video and Motion 13.1.4 Text Overlay 13.1.5 Tampering Alarm 13.1.6 Visual Automation...

  • Page 222: Video And Motion

    13.1 Video and Motion The GV-IPCAM H.264 can simultaneously process one video stream in two different codec and resolutions. The dual-stream design benefits for lower bandwidth environment, allowing Streaming 2 set with lower resolution and codec for live streaming, and Streaming 1 set with highest resolution and codec H.264 for best recording quality.

  • Page 223: Video Settings

    Administrator Mode 13.1.1 Video Settings Figure 13-2A...
  • Page 224 Figure 13-2B [Name] Rename the video stream. To display the name of video stream on the Live View window, see 12.2.10 Camera Name Display. [Connection Template] Select the type of your network connection. Unless you select Customized, this option will automatically bring up the recommended video resolution, frame rate, bandwidth and GOP size.
  • Page 225 Administrator Mode Note that for all the cameras (except GV-PTZ010D), the resolution options available for sub stream vary with the resolution selected for its main stream. For example, if a 4:3 resolution is selected for the main stream in GV-BX320D-0, two options, 640 x 480 and 320 x 240 will be available for its sub stream.
  • Page 226 [Record Settings] The alarm settings allow you to capture images before and/or after the motion or I/O events happen. Note: This function is not available for GV-MFD110. Pre-alarm recording time: Activates video recording before an event occurs. Set the recording time to 1 or 2 seconds. The recording is saved in the buffer of the camera.
  • Page 227 Administrator Mode [Audio In Source] Note this function is only available in GV-BX110D, GV- PT110D and GV-PTZ010D which contain a built-in microphone and also allow you to install an external microphone. Built-in Microphone: Enable the built-in microphone to record sounds. By default the option is enabled. External Microphone: Enable the externally connected microphone to record sounds.
  • Page 228 [Mechanical Iris Adjustment] Note this function is only available in GV-BX110D and GV-BL110D. Auto adjustment: Click Start to automatically adjust the auto iris lens and bring exposure to optimum. [Special View Setting] D/N: Sets the sensitivity of day-night mode switch. For a more sensitive switch from day mode to night mode, set the sensitivity to 5.
  • Page 229 Administrator Mode Note: If an infrared illuminator is installed for outdoor surveillance, it is suggested to use the Trigger by Input or the Trigger IR by D/N function to avoid incorrect judgment of lighting and hence the action of the IR cut filter. See 2.5.2 Infrared Illuminators. If you select Trigger by Input / Trigger IR by D/N option, make sure you have set D/N as Auto and configured its sensitivity level.

  • Page 230: Motion Detection

    13.1.2 Motion Detection Note for models with firmware V1.07 or later (except GV-BX110D, GV- MFD110, GV-BL110D, GV-PTZ010D and GV-PT110D), motion detection is disabled by default. For all firmware versions of GV-BX110D, GV-MFD110, GV-BL110D, GV-PTZ010D and GV-PT110D, motion detection is enabled by default.
  • Page 231 Administrator Mode Select the desired sensitivity by moving the slider. There are ten values. The higher the value, the more sensitive the camera is to motion. Drag an area on the image. Click Add when you are prompted to confirm the setting. To create several areas with different sensitivity values, repeat steps 2 and 3.

  • Page 232: Privacy Mask

    13.1.3 Privacy Mask The Privacy Mask can block out sensitive areas from view, covering the areas with dark boxes in both live view and recorded clips. This feature is ideal for locations with displays, keyboard sequences (e.g. passwords), and for anywhere else you don’t want sensitive information visible. Figure 13-4 Select the Enable option.

  • Page 233: Text Overlay

    Administrator Mode 13.1.4 Text Overlay The Text Overlay allows you to overlay any text in any place on the camera view. Up to 16 text messages can be created on one camera view. The overlaid text will be saved in the recordings. Figure 13-5 Select the font, font style and font size in a pop-up window.
  • Page 234 Click Save to apply the settings, or click Load (Undo) to revert to the last saved setting. Click Preview to see how the text will appear on the image. Click Close to end the preview.

  • Page 235: Tampering Alarm

    Administrator Mode 13.1.5 Tampering Alarm Note this function is not available for PTZ Camera and PT Camera. The Tampering Alarm is used to detect whether a camera is being physically tampered. An alarm can be generated when the camera is moved, covered up, or out of focus.
  • Page 236 To configure the tampering alarm: Select the Enable option. If you want the camera to ignore any movement or scene change in certain areas, click the button to drag areas on the camera view. Select the desired detection sensitivity by moving the slider. The higher the value, the more sensitive the camera is to scene changes.

  • Page 237: Visual Automation

    Administrator Mode 13.1.6 Visual Automation Note this function is only available for Box Camera, Bullet Camera, Vandal Proof IP Dome and Fixed IP Dome. This intuitive feature helps you automate any electronic device by triggering the connected output device. When you click on the image of the electronic device, you can simply change its current state, e.g.
  • Page 238 Assign the connected module and output device. In the Note field, type a note to help you manage the device. Click OK to save the settings. To change the frame color of the set area, click the Set Color button. To emboss the set area, select Float Up;...

  • Page 239: I/O Settings

    Administrator Mode 13.2 I/O Settings Note the I/O settings are only available for Box Camera, Bullet Camera, PTZ Camera, PT Camera, Vandal Proof IP Dome and Fixed IP Dome. After installing the I/O device, you need to enable the I/O settings on the camera.
  • Page 240 Normal State: You can set the input state to trigger actions by selecting Open Circuit (N/O) or Grounded Circuit (N/C). Latch Mode: Enable this option to have a momentary output alarm. Trigger digital output relay: When this option is enabled, the output will be triggered once the input is activated.

  • Page 241: Output Settings

    Administrator Mode 13.2.2 Output Settings Select Enable to start the output device. Choose the output signal that mostly suits the device you are using: N/O (Open Circuit), N/C (Grounded Circuit), N/O Toggle, N/C Toggle, N/O Pulse or N/C Pulse. For Toggle output type, the output continues to be triggered until a new input trigger ends the output.

  • Page 242: Ptz Settings

    13.2.3 PTZ Settings Note this function is only available in PTZ Camera and PT Camera. You can change the image settings, configure sequences, and access settings including autopan speed, motor reset, digital zoom and system default loading. For details, see Accessing the VISCA OSD Configuration in 6.7.3 PTZ Camera Settings.

  • Page 243: Events And Alerts

    Administrator Mode 13.3 Events and Alerts For the events of motion detection or I/O trigger, the Administrator can set up two trigger actions: 1. Send a captured still image by E-mail or FTP. 2. Notify Center Monitoring Station, Center V2 or VSM, by video or text alerts.

  • Page 244: E-Mail

    13.3.1 E-mail After a trigger event, the camera can send the e-mail to a remote user containing a captured still image. Figure 13-13 [Enable] Select to enable the e-mail function. Sever URL/IP Address: Type the URL address or IP address of the SMTP Server.
  • Page 245 Administrator Mode [Need authentication to login] If the SMTP Server needs authentication, enable this option and type a valid username and password to log in the SMTP server. [E-Mail Alarm Settings] You can choose to automatically send an e-mail alert under these conditions: tampering alarm (not available for PTZ and PT Camera), disk write error (Rec Error), full memory card (HD Full), motion detection and input trigger (not available for Mini Fixed Dome, Mini Fixed Rugged Dome, Cube Camera and Wireless Cube Camera).

  • Page 246: Ftp

    13.3.2 FTP You can also send the captured still image to a remote FTP server for alerts. Figure 13-14 [Upload to an FTP Server] Enable: Select to enable the FTP function. Server URL/IP Address: Type the URL address or IP address of the FTP Server.
  • Page 247 Administrator Mode Alerts Interval time in minute: Specify the interval between FTP alerts. The interval can be between 0 and 60 minutes. The option is useful for the frequent event occurrence by which any event triggers during the interval period will be ignored. [Alarm Settings] Motion Detection: When a motion is detected on the camera, a still image will be sent to the FTP Server.
  • Page 248 When you are prompted for Username and Password, enter the default value 123456 in both fields. Then you should find the AVI files recorded after trigger events. To change login information of the internal FTP server, see 13.8.4 User Account. For related settings to send FTP alerts, see 13.1.2 Motion Detection, 13.2.1 Input Settings and 13.4 Monitoring.

  • Page 249: Center V2

    Administrator Mode 13.3.3 Center V2 After a motion or an I/O triggered event, the central monitoring station Center V2 can be notified by live videos and text alerts. For the live monitoring through Center V2, you must already have a subscriber account on Center V2.
  • Page 250 To enable the Center V2 connection: 1. Activate Link: Enable the monitoring through Center V2. 2. Host Name or IP Address: Type the host name or IP address of Center V2. 3. Port Number: Match the port to the Port 2 value on Center V2. Or keep the default value 5551.

  • Page 251: Vsm

    Administrator Mode 13.3.4 VSM After a motion or an I/O triggered event, the central monitoring station VSM can get notified by text alerts. For the monitoring through VSM, you must already have a subscriber account on VSM. A camera can connect up to 2 VSM simultaneously.
  • Page 252 To enable the VSM connection: Activate Link: Enable the monitoring through VSM. Host Name or IP Address: Type the host name or IP address of VSM. Port Number: Match the port to the Port 2 value on VSM. Or keep the default value 5609.

  • Page 253: Backup Center

    Administrator Mode 13.3.5 Backup Center For the supported version of different models, see Appendix D. The connection to the GV-Backup Center allows you to back up another copy of recordings and system log to the GV-Backup Center on an offsite location while the camera is saving these data to the memory card.
  • Page 254 To enable connection to GV-Backup Center: Activate Link: Enable the connection to the GV-Backup Center. Host Name or IP Address: Type the host name or IP address of the GV-Backup Center. Port Number: Match the communication port on the GV-Backup Center.
  • Page 255 Administrator Mode If you have a failover GV-Backup Center server which provides uninterrupted backup services in case the first GV-Backup Center failed, configure the failover GV-Backup Center as below. Automatic Failover Support: Enable the automatic connection to the failover GV-Backup Center once the connection between camera and the first GV-Backup Center is interrupted.

  • Page 256: Video Gateway / Recording Server

    13.3.6 Video Gateway / Recording Server For the supported version of different models, see Appendix D. The GV-Video Gateway / GV-Recording Server is a video streaming server designed for large-scale video surveillance deployments. The GV-Video Gateway / GV-Recording Server (with recording capability) can receive up to 128 channels from various IP video devices, and distribute up to 300 channels to its clients.
  • Page 257 Administrator Mode Figure 13-18 Activate Link: Enable the connection to the GV-Video Gateway / GV- Recording Server. Host Name or IP Address: Type the host name or IP address of the GV-Video Gateway / GV-Recording Server. Port Number: Match the communication port on the GV-Video Gateway / GV-Recording Server.
  • Page 258 Enable Schedule mode: Enable the GV-Video Gateway / GV- Recording Server on the schedule you set in the Select Schedule Time section. Refer to 13.5 Recording Schedule for the same settings. Click Apply. The Connection Status should display “Connected” and the connected time.

  • Page 259: Viewlog Server

    Administrator Mode 13.3.7 ViewLog Server Note this feature is not available for GV-MFD110. The ViewLog Server is designed for remote playback function. This server allows you to remotely access the recorded files saved at the GV-IPCAM H.264 and play back video with the ViewLog player. Select Enable to activate the built-in server.

  • Page 260: Rtsp

    13.3.8 RTSP The RTSP enables video and audio streaming to your 3G-enabled mobile phone. The RTSP streaming is enabled by default. Figure 13-20 Activate Link: Enable the RTSP service. RTSP/TCP Port: Keep the default value 8554, or modify it if necessary.

  • Page 261: Monitoring

    Administrator Mode 13.4 Monitoring You can start monitoring manually, by schedule or by input trigger. Note: See Note for Connecting to GV-System at the beginning of the manual. Figure 13-21 [Manual] Manually activates motion detection and I/O monitoring. Select one of the following options and then click the Start button. Select all: Manually starts both motion detection and I/O monitoring.
  • Page 262 [Camera Status Icon] : On standby : Enabled for motion detection and input trigger : Recording is on.

  • Page 263: Recording Schedule

    Administrator Mode 13.5 Recording Schedule The schedule is provided to activate recording and I/O monitoring on a specific time each day. 13.5.1 Recording Schedule Settings Note this function is not available for GV-MFD110. You can set the schedule for recording. Figure 13-22 Span 1- Span 3: Set a different recording mode for each time frame during the day.

  • Page 264: I/O Monitoring Settings

    13.5.2 I/O Monitoring Settings Note this function is not available for Mini Fixed Dome, Mini Fixed Rugged Dome, Cube Camera and Wireless Cube Camera. You can set the schedule for I/O monitoring to start. Figure 13-23 Span 1- Span 3: Set different time frames during the day to enable I/O monitoring.

  • Page 265: Remote Viewlog

    Administrator Mode 13.6 Remote ViewLog Note this function is not available for GV-MFD110. With the Remote ViewLog player, you can play back the files recorded at the GV-IPCAM H.264 over TCP/IP network. For the first-time user, you need to install the Remote ViewLog program from the Software CD.

  • Page 266: Network

    13.7 Network The Network section includes some basic but important network configurations that enable the camera to be connected to a TCP/IP network. 13.7.1 LAN Configuration According to your network environment, select among Static IP, DHCP and PPPoE. Figure 13-24...
  • Page 267 Administrator Mode [LAN Configuration] Note the wireless option is only available in GV-CBW120 / 220. According to the network environment, select Wired or Wireless. Before enabling the Wireless option, follow the steps in 10.2 Configuring the Wireless Connection to configure the wireless settings first. [LAN Configuration] Dynamic IP address: The network environment has a DHCP server which will automatically assign a dynamic IP address to the camera.

  • Page 268: Wireless Client Mode

    13.7.2 Wireless Client Mode Note this function is only supported in GV-CBW120 / 220. Set up the client mode before enabling the wireless function. Figure 13-25 Network type: Select the network mode Ad Hoc or Infrastructure. Infrastructure: Connect to the Internet via the Access Point. This mode further gives wireless access to the Internet or data sharing under a previously wired environment.
  • Page 269 Administrator Mode Access Point Survey: Click this button to search all the available Access Points (Infrastructure mode) and wireless stations (AD-Hoc mode) within the LAN. Authentication Type: Select one of these network authentication and data encryption: Disable, WEP, WPAPSK-TKIP, WPAPSK-AES, WPA2PSK-TKIP or WPA2PSK-AES.

  • Page 270: Advanced Tcp/Ip

    13.7.3 Advanced TCP/IP This section provides the advanced TCP/IP settings, including DDNS Server, HTTP port, HTTPS, streaming port, UPnP, QoS and network connection check. Figure 13-26...
  • Page 271 DHCP Server or ISP (in xDSL connection) has changed. Before enabling the following DDNS function, the Administrator should have applied for a Host Name from the DDNS service provider’s website. There are 2 providers listed in the camera: GeoVision DDNS Server and DynDNS.org. To enable the DDNS function: Enable: Enable the DDNS function.
  • Page 272 [HTTPS Settings] By enabling the Hypertext Transfer Protocol Secure (HTTPS) settings, you can access the camera through a secure protocol. You can use self-generated Certificate and Private Key or the ones verified by the SSL authority. Click Browse to locate the Certificate and Private Key files and type the password if the .pem files are protected by password.
  • Page 273 Administrator Mode for the network traffic. When the video stream from GV-IPCAM H.264 reaches a router, the DSCP value will tell the router what service level to be applied, e.g. the bandwidth amount. This value ranges from 0 to 63 in decimal format.

  • Page 274: Ip Filter Settings

    13.7.4 IP Filter Settings The Administrator can set IP filtering to restrict access to the camera. Figure 13-27 To enable the IP Filter function: Enable IP Filtering: Enable the IP Filter function. Filtered IP: Type one IP address or a range of IP addresses you want to restrict the access.

  • Page 275: Snmp Settings

    Administrator Mode 13.7.5 SNMP Settings The Simple Network Management Protocol (SNMP) allows you to monitor the status of the camera through SNMP network management software. Figure 13-28...
  • Page 276 Select Enable SNMPv1 SNMPv2c to enable the function. To enable access to Read/Write community, type a community string. This will serve as a password to allow read and write access to the camera from the SNMP software. To enable Read only community, type a community string to allow read-only access to the camera from the SNMP software.

  • Page 277: Management

    Administrator Mode 13.8 Management The Management section includes the settings of data and time and user account. You can also view the firmware version and execute certain system operations. 13.8.1 Date & Time Settings The date and time settings are used for date and time stamps on the image. Figure 13-29...
  • Page 278 [Date & Time on GV-IP Camera] Displays the current date and time on the camera. [Time Zone] Sets the time zone for local settings. Select Enable Daylight Saving Time to automatically adjust the camera for daylight saving time. Type the Start Time and End Time to enable the daylight saving function. To play back, see 14.2.4 Playback of Daylight Saving Time Events.

  • Page 279: Gps Maps Settings

    Administrator Mode 13.8.2 GPS Maps Settings The Maps Settings allows you to see the location of your GV-IPCAM H.264 on Google maps, without a GPS device. To see the location of your camera on maps: It is required to sign up for a Google Maps API key before using the Google Maps.
  • Page 280 Click Open. A warning message appears. Figure 13-32 Right-click the warning message and select Allow Blocked Content. The map will be displayed. The icon indicates the location of your camera. At the upper right corner you have options to view different map formats, such as Satellite and Hybrid.

  • Page 281: Storage Settings

    Administrator Mode 13.8.3 Storage Settings Note this function is not available for GV-MFD110. Based on Linux ext3 file system, the GV-IPCAM H.264 supports memory cards for video and audio recordings. You need to format the memory card by using the following Storage Settings. After being formatted, the memory card will be ready to use by Linux OS of the camera.
  • Page 282 [Disk Information] This section shows the details of the attached storage device. [Partition Information] This section shows the partition details of the attached storage device. To add a memory card: Insert the memory card to the camera. Click the Format button. After the format is complete, the partition information will display.

  • Page 283: User Account

    Administrator Mode 13.8.4 User Account You can change the login name and password of Administrator and Guest. The default Administrator login name and password are admin; the default Guest login name and password are guest. To allow a Guest user log in without entering name and password, select Disable authentication for guest account.

  • Page 284: Log Information

    13.8.5 Log Information The log information contains dump data that is used by service personnel for analyzing problems. Figure 13-36...

  • Page 285: System Log

    Administrator Mode 13.8.6 System Log For the supported versions, see Appendix F. The System Log records the events in the four types of logs: System Event, Monitoring Event, I/O Event and Login/Logout Event. With the System Log, you can search and obtain the detailed information of an event.
  • Page 286 Click Query. The filtering results may look like the figure below. Figure 13-38...

  • Page 287: Tools

    Administrator Mode 13.8.7 Tools You can execute certain system operations and view the firmware version. Figure 13-39...
  • Page 288 [Host Settings] Enter a descriptive name for the camera. [Auto Reboot Setup] Select Enable to activate automatic reboot and specify the time for reboot in the sub fields. Day Interval: Type the day interval between each reboot. Reboot Time: Use the drop-down lists to specify the time for automatic reboot.

  • Page 289: Chapter 14 Recording And Playback

    Chapter 14 Recording and Playback Note this chapter and the function is not available for GV-MFD110 The GV-IPCAM H.264 can record video and audio directly to the memory card. You can play back the recorded files on the GV-System or over the TCP/IP network.

  • Page 290: Playback

    14.2 Playback These methods are available to play back the video files recorded at the GV-IPCAM H.264:  Playback by using the memory card by connecting it directly to the GV-System through a memory card reader  Playback by using the Remote ViewLog function over the TCP/IP network ...
  • Page 291 Recording and Playback Run ViewLog. Click the Advanced button , select Reload Database and click Video Server/Compact DVR. This dialog box appears. Figure 14-2 Click Add to assign the hard drive. Click OK to load the data to the ViewLog for playback. Note: IFS Driver supports Windows NT / 2000 / XP / Windows 7.

  • Page 292: Playback Over Network

    14.2.2 Playback over Network With the Remote ViewLog function, you can play back the files recorded at the GV-IPCAM H.264 over TCP/IP network. The camera needs to allow the remote access with ViewLog Server activated. See 13.3.7 ViewLog Server. For the first-time user, run the Remote ViewLog program from the Software CD.

  • Page 293: Access To The Recorded Files Through Ftp Server

    Media Player. For details to download files, see [Act as FTP Server], 13.3.2 FTP. Note: To play back videos, ensure you have installed Geovision codec on the computer. The codec is available on the software CD. If you have installed the Remote Playback player on the computer, it is not required to install the codec.
  • Page 294 To remotely connect to the camera from GV-System, click the Tools button and select Remote ViewLog Service. The Connect to Remote ViewLog Service dialog box appears. Enter the connection information of the camera, and click Connect. Once the connection is established, the video events will be displayed on the Video Event list.

  • Page 295: Chapter 15 Advanced Applications

    (Power over Ethernet or PoE supported). WARNING: The interruption of power supply during updating causes not only update failures but also damages to the camera. In this case, please contact your sales representative and send your device back to GeoVision for repair.
  • Page 296 Do not turn the power off within 10 minutes after the firmware is updated. If firmware upgrade fails, you will need to restore the camera to its default settings. For details, see 15.3 Restoring to Factory Default Settings.

  • Page 297: Using The Web Configuration Interface

    Advanced Applications 15.1.1 Using the Web Configuration Interface In the Live View window, click the Show System Menu button (No. 8, Figure 12-3) and select Remote Config. This dialog box appears. Figure 15-1 Click the Browse button to locate the firmware file (.img) saved at your local computer.

  • Page 298: Using The Ip Device Utility

    15.1.2 Using the IP Device Utility The IP Device Utility provides a direct way to upgrade the firmware to multiple units of GV-IPCAM H.264. Note the computer used to upgrade firmware must be under the same network of the camera. Insert the Software CD, select IP Device Utility, and follow the onscreen instructions to install the program.
  • Page 299 Advanced Applications Double-click one camera in the list. This dialog box appears. Figure 15-3 Click the Firmware Upgrade tab. This dialog box appears. Figure 15-4 Click the Browse button to locate the firmware file (.img) saved at your local computer. If you like to upgrade all the cameras in the list, select Upgrade all devices.

  • Page 300: Backing Up And Restoring Settings

    15.2 Backing Up and Restoring Settings With the IP Device Utility included in the Software CD, you can back up the configurations in the GV-IPCAM H.264, and restore the backup data to the current camera or import it to another camera. To back up the settings: Run IP Device Utility and locate the desired camera.
  • Page 301 Advanced Applications To restore the settings: In Figure 15-3, click the Import Settings tab. This dialog box appears. Figure 15-6 Click the Browse button to locate the backup file (.dat). Select Upgrade all devices to import the settings into the same type of device in the same LAN.

  • Page 302: Restoring To Factory Default Settings

    15.3 Restoring to Factory Default Settings Please refer to the corresponding section of your camera type and follow the steps to restore factory default settings. Box Camera GV-BX110D Unplug the power cable and the network cable to start. Use a pin to press and hold the Default button on the back panel of the camera.
  • Page 303 Advanced Applications Wait until the status LED turns off. This will take about 10 seconds. Soon after the status LED turns off, it turns red again and a clicking sound appears. Then you can release the default button and the process of loading default values is completed.
  • Page 304 Mini Fixed Dome GV-MFD110 Unplug the network cable to start. Unscrew the camera’s cover. Press and hold the default button. Default button Figure 15-11 Power on the camera using the network cable. Wait until the network LED turns off. This will take about 40 seconds. Soon after the network LED turns off, release the default button.
  • Page 305 Advanced Applications Release the default button when the status LED blinks. When the status LED fades, the process of loading default settings is completed and the camera reboots automatically. Mini Fixed Rugged Dome Press and hold the default button. Default button Status LED Figure 15-13 Release the default button when the status LED blinks.
  • Page 306 Bullet Camera GV-BL110D Loosen the camera’s cover and remove the Silica Gel Bag. Press and hold the default button for 50 seconds while plugging the power cable. Default Button Figure 15-14 Release the default button and the process of loading default settings is completed.
  • Page 307 Advanced Applications GV-BL120D / 130D / 220D / 320D Loosen the camera’s cover and remove the Silica Gel Bag. Press and hold the default button for 4 seconds. Default Button Figure 15-15 Release the default button. When the process of loading default settings is completed, the camera reboots automatically.
  • Page 308 PTZ and PT Camera There are two types of default settings: camera default settings and system default settings. Camera default settings include all settings on Iris, White Balance, Image Reverse and Other in the VISCA OSD Configuration dialog box (Figure 15-16). System default settings refer to all the settings of the PTZ / PT camera except the camera settings.
  • Page 309 Advanced Applications To load system default settings: Unplug the power cable or the network cable (if it is also used as the power supply). Press and hold the default button (No. 10, Figure 6-1). Power on the camera using the power cable or the PoE cable. Hold the default button until the two network LEDs fade.
  • Page 310 When the status LED fades, the process of loading default settings is completed and the camera reboots automatically. Fixed IP Dome Use a pin to press and hold the default button on the panel. Default button Status LED Figure 15-19 Release the default button when the status LED blinks.
  • Page 311 Advanced Applications Cube Camera Use a pin to press and hold the default button on the panel. Default button Status LED Figure 15-20 Release the default button when the status LED blinks. When the status LED fades, the process of loading default settings is completed and the camera reboots automatically.

  • Page 312: Verifying Watermark

    15.4 Verifying Watermark The watermark is an encrypted and digital signature embedded in the video stream during the compression stage, protecting the video from the moment of creation. Watermarking ensures that an image is not edited or damaged after it is recorded. To enable the watermark function, see [Watermark Setting], 13.1.1 Video Settings.

  • Page 313: Accessing Avi Files

    Advanced Applications 15.4.1 Accessing AVI Files To verify watermark, first you have to access the recorded AVI files by one of these methods: Use the File Save function (No.6, Figure 12-3) to start recording on the local computer. Use the Act as FTP Server function to download AVI files from the GV-IPCAM H.264.

  • Page 314: Running Watermark Proof

    15.4.2 Running Watermark Proof Install Watermark Proof from the Software CD. After installation, a WMProof icon is created on your desktop. Double-click the created icon. The Water Mark Proof window appears. Click File from the menu bar, select Open and locate the recording (.avi).

  • Page 315: The Watermark Proof Window

    Advanced Applications 15.4.3 The Watermark Proof Window Figure 15-21 The controls in the window: No. Name Description Open File Opens the recording. First Frame Goes to the first frame of the file. Play Plays the file. Previous Frame Goes to the previous frame of the file. Next Frame Goes to the next frame of the file.

  • Page 316: Downloading Videos From The Sd Card

    15.5 Downloading Videos from the SD Card When connections of GV-IP Cameras to the GV-System are lost, recordings are automatically saved to the memory cards inserted in the GV-IP Cameras. To automatically synchronize and download recordings from the SD cards to a local folder, install and execute the GV-SDCardSync Utility program.

  • Page 317: Installing The Gv-Sdcardsync Utility

    Advanced Applications 15.5.1 Installing the GV-SDCardSync Utility Download the GV-SD Card Sync Utility program from http://ftp.geovision.tw/FTP/neo/Utility/GvSDCardSync_Setup.zip Note: The GV-SD Card Sync Utility must be installed on the computer installed with GV-System V8.5.4 or later. Execute the GV-SDCard Sync Utility program. The main window and the Setting window appear.
  • Page 318 To configure synchronization, network and startup settings, see the steps below. Figure 15-23 [Synchronization] Synchronize automatically at an interval: Automatically synchronize videos from SD cards to a local folder at the specified interval. Synchronize automatically at: Automatically synchronize videos from SD cards to a local folder at the specified time. Download Audio Files: You may choose to download audio files along with the video files.
  • Page 319 Advanced Applications [Network] Max. download speed of each device (Kb/sec): To make sure the bandwidth is not completely taken up while downloading files from the memory card, specify a maximum download speed. If you do not want to set a bandwidth limit, type 0. [General] Start up automatically at Windows login: GV-SDSync Utility launches automatically when Windows starts up.
  • Page 320 [Recycle] Recycle when the storage space is less than (GB): Specify a minimum free space of your local storage for file recycling. Keep the downloaded files for (Days): Specify the number of days to keep the download files at the local hard drive. [Storage Location] To configure the storage path, click the button next to the location field and specify a storage location.

  • Page 321: The Gv-Sdcardsync Utility Window

    Advanced Applications 15.5.2 The GV-SDCardSync Utility Window After you have installed the GV-SDCardSync Utility, point to Start, select Programs, select GV-SDCardSync and select to launch the program. This window appears. Figure 15-25 No. Name Description Plays downloaded recordings of the selected GV-IP Cameras using the ViewLog player.
  • Page 322 Note: 1. The synchronization time is recorded according to the system time of the GV-IP Camera. 2. The logs are deleted once the GV-SDCardSync Utility is re- activated.

  • Page 323: Chapter 16 Dvr Configurations

    Chapter 16 DVR Configurations The GV-System provides hybrid solution, integrating the digital videos from IP cameras with other analog videos. For the digital videos, the GV-System provides the complete video management, such as video viewing, recording, playback, alert settings and almost every feature of the system. Following is the integration specifications: •...
  • Page 324 DVR Configurations Compatible version Camera Models of GV-System GV-MDR120 Mini Fixed GV-MDR220 V8.5 or later Rugged Dome GV-MDR320 GV-MDR520 GV-BL120D V8.4 (with patch GV-BL220D files) or later Bullet Camera GV-BL320D GV-BL130D V8.5 or later PTZ and PT Camera V8.4 or later V8.4 (with patch Vandal Proof IP Dome files) or later...
  • Page 325 TCP/ IP IP Camera GV-System with 32-channel Display IP Camera Figure 16-1 • The maximum number of streams which the GV-IPCAM H.264 allows varies according to its resolution: Max. No. of Resolution Camera Models Streams BX110D, MFD110, BL110D, 1.3 M PTZ010D, PT110D BX120D, BX130D Series, BX140DW, BX120D-E, MFD120, MFD130,...
  • Page 326 DVR Configurations • When a GV-IPCAM H.264 is connected to IE browser or any other applications, it takes up 1 stream; when a GV-IPCAM H.264 is connected to GV-System, it takes up 2 streams. Note: The above maximum numbers of streams are based on the maximum resolution for each camera and the codec H.264.

  • Page 327: Setting Up An Ip Camera

    16.1 Setting up an IP Camera To set up the GV-IPCAM H.264 on the GV-System, follow these steps: On the main screen, click the Configure button, select System Configure, select Camera Install and click IP Camera Install. This dialog box appears. Figure 16-2 •...
  • Page 328 DVR Configurations Click Add Camera. The dialog box appears. Figure 16-3 Type the IP address, username and password of the IP camera. Select the camera brand and device from the drop-down lists. This dialog box appears. Figure 16-4 The GV-System will automatically query for the IP camera, and the status will be indicated as “Standby”.
  • Page 329 The options in the setup dialog box may vary depending on the camera model. Dual Stream: Click this button to set the codec type to H.264 in the main stream and to MPEG4 in the sub stream, and each stream with a different resolution. For details on supported versions and resolutions in different cameras, see Appendix G.

  • Page 330: Customizing Ip Camera Settings

    DVR Configurations 16.1.1 Customizing IP Camera Settings After the IP camera is connected and assigned with a display position, you can configure the camera’s settings such as frame rate, codec type and resolution. Right-click the desired camera to see the following list of options: Figure 16-6 Change Resolution: Changes the display ratio, live view resolution and record resolution...
  • Page 331 Recording Codec Format: Specifies whether to record in standard or GeoVision type of JPEG, MPEG4, H.264 codec. GIS Setting: Records the video with the GPS data. To record the GPS data, remember to also enable the GIS function of the GV- System (Configure button <...

  • Page 332: Remote Monitoring With Multi View

    DVR Configurations 16.2 Remote Monitoring with Multi View You can use the Multi View to monitor and manage the GV-IPCAM H.264. 16.2.1 Connecting to the IP Camera On the Multi View window, click the Edit Host button. The Edit Host window appears.

  • Page 333: Remote Monitoring With E-Map

    16.3 Remote Monitoring with E-Map You can use the Remote E-Map to monitor and manage the GV-IPCAM H.264. 16.3.1 Creating an E-Map for the IP Camera With the E-Map Editor, you can create an E-Map for the GV-IPCAM H.264. The E-Map Editor is available in the two applications: Main System and E- Map Server.

  • Page 334: Connecting To The Ip Camera

    DVR Configurations Click OK to save the settings. Expand the created host folder. Drag and drop the icons of camera and I/O devices onto the imported E-Map. Close the E-Map Editor. Click Yes when you are promoted to save the file. For details on creating an E-Map file on the E-Map Server, see “E-Map Server”, E-Map Application, DVR User’s Manual on the Surveillance System Software DVD.

  • Page 335: Chapter 17 Cms Configurations

    Chapter 17 CMS Configurations This section introduces the related settings to enable connecting to the GV- IPCAM H.264 in the central monitoring stations Center V2, VSM and Dispatch Server. 17.1 Center V2 The Center V2 can monitor and manage the camera and I/O devices connected to the GV-IPCAM H.264.
  • Page 336 CMS configurations • To set the appropriate port for IP camera connection, click the Preference Settings button, select System Configure, click the Network tab, and select Accept connections from GV-Compact DVR, Video Server & IP Cam. Keep default port 5551, or modify it to match the Center V2 port on the IP camera.
  • Page 337 Manual close channel: Closes the triggered camera view manually. Close the camera view when motion stopped: Closes the triggered camera view automatically when motion stops. Post Motion: Specify the duration of the camera view remaining on the monitoring window after a motion stops. Camera send by I/O trigger will monitor: Specify the duration of the camera view remaining on the monitoring window when an I/O device is triggered.

  • Page 338: Vsm

    CMS configurations 17.2 VSM The VSM is designed to monitor and manage the camera and I/O devices connected to the GV-IPCAM H.264 under low bandwidth network. TCP/ IP IP Camera Text Data IP Camera Figure 17-4 • To set the appropriate port connecting to the IP camera, click Configure on the window menu, and select System Configure to display this dialog box.

  • Page 339: Dispatch Server

    17.3 Dispatch Server The Dispatch Server minimizes overloading of Center V2 Servers by re- distributing GV-IPCAM H.264 subscribers to the least busy Center V2 Server. TCP/ IP Center V2 IP Camera Video Data Text Data Dispatch Server IP Camera Center V2 Figure 17-6...
  • Page 340 CMS configurations • To set the appropriate port connecting to the IP camera, click the Server Setting button on the toolbar, and select Allow GV IP devices to login as subscriber from port. Keep the default port as 5551, or modify it to match the Center V2 port on the IP camera. Figure 17-7 For further information on how to mange the video received from the IP camera, see GV-CMS Series User’s manual.

  • Page 341: Chapter 18 Mobile Phone Connection

    Chapter 18 Mobile Phone Connection Using a Pad, PDA, Smartphone or 3G-enabled mobile phone, you can receive live video streaming from the GV-IPCAM H.264. The chart below lists the GV mobile applications for GV-IPCAM H.264. Handheld Video Settings on OS Supported Default Port Device View GV-IPCAM H.264...
  • Page 342 Mobile Phone Connection Android V1.6 or above Data Port: 8866 GV-AView V1.1 for Android HTTP Port: 80 Smartphone VSS Port: 10000 iPhone OS 4.3 or GV-Eye V1.0 above for iPhone and VSS Port: 10000 iPod Touch GV-Eye HD iPad OS 4.3 or above VSS Port: 10000 V1.0 for iPad...

  • Page 343: Pda

    GView V2 should be installed on a PDA device with Microsoft Windows Mobile operating system. To download GV-GView V2, please go to http://www.geovision.com.tw/english/5_4_gview.asp. Click the Download button. Consult your PDA user’s manual for how to install a program to the...

  • Page 344: Activating The Gview Function

    Mobile Phone Connection 18.1.2 Activating the GView Function To allow remote access to the GV-IPCAM H.264: Select 3GPPv7, MSViewV2/V3, SSViewV3 and GViewV2 Supported in the Connection Template field on the Web interface. For details, see “Connection Template” in 13.1.1 Video Settings. Figure 18-1 Enable RTSP server on the Web interface.

  • Page 345: Connecting To The Ip Camera

    18.1.3 Connecting to the IP Camera Once GView V2 is installed on your PDA, you can use it to monitor your GV-IPCAM H.264. Make sure your PDA has wireless LAN adapter properly in place with access to the Internet. Execute GView V2 on your PDA. Figure 18-2...
  • Page 346 Mobile Phone Connection Click the button located at the lower left corner. The login screen appears. Figure 18-3 Enter the IP address of your camera, port value (default value is 10000), a username and a password. Then click OK. Once the connection is established, the live image will appear.

  • Page 347: Playing Back The Recordings From The Ip Camera

    18.1.4 Playing Back the Recordings from the IP Camera To play back the recordings from the GV-IPCAM H.264, follow these steps: Enable the ViewLog Server on the camera. Keep the connection port to be 5552 or modify it if necessary. See 13.3.7 ViewLog Server for details.

  • Page 348: Other Functions

    Mobile Phone Connection 18.1.5 Other Functions In addition to live view and playback, GView V2 offers these functions: viewing / controlling I/O devices, PTZ control, adjusting image quality, and starting / stopping recording. On the live view screen, click the buttons on the toolbar to have the desired functions.
  • Page 349 Button Description Click it to start or stop recording. Click it to display the camera status. The supervisor is given the highest priority to control the PTZ camera and is not restrained by the 60-second time limit. When the supervisor logs in, the Timer shows 999.
  • Page 350 Mobile Phone Connection The numbers on the toolbar indicate the connected module. Click the desired number to access its I/O devices. The I/O control buttons appear on the toolbar. Figure 18-7 Button Description Click it to view the log of input triggers. Click it to display and force the connected output devices.
  • Page 351 Forcing Outputs To force any connected output devices, click the “O” button to, and click the desired number. The numbers on the toolbar indicate the connected output devices. Figure 18-9 Controlling PTZ Cameras To control the PTZ camera, use the drop-down list to select the desired camera, and click the button on the live view screen (Figure 18-5).
  • Page 352 Mobile Phone Connection Button Description Click it to return to the previous page. Use these buttons to move the PTZ camera to the left, up, down and right Click it to return to home. Viewing Camera Status To view the camera status, click the button on the live view screen (Figure 18-5).

  • Page 353: Windows Smartphone

    Chart 1. 18.2.1 Installing MSView V2 / V3 To download GV-MSView V2 / V3, please go to http://www.geovision.com.tw/english/5_4_msview.asp. Click the Download button. Consult your smartphone user’s manual for how to install a program to the smartphone.

  • Page 354: Activating The Msview V2 / V3 Function

    Mobile Phone Connection 18.2.2 Activating the MSView V2 / V3 Function To allow remote access to the GV-IPCAM H.264: Select 3GPPv7, MSViewV2/V3, SSViewV3 and GViewV2 Supported in the Connection Template field on the Web interface. For details, see “Connection Template” in 13.1.1 Video Settings. Figure 18-12 Enable RTSP server on the Web interface.

  • Page 355: Connecting To The Ip Camera

    18.2.3 Connecting to the IP Camera The following operations may vary slightly for different modules. Execute MSViewV2.exe or MSViewV3.exe on your Smartphone. Figure 18-13 Click Type and then Live. Figure 18-14...
  • Page 356 Mobile Phone Connection On the login screen, enter the IP address of your camera, port value (default value is 10000), a username and a password. Then click Control and select Connect. Figure 18-15 Once the connection is established, the live image will appear. You can use the scroll key on your Smartphone to navigate camera channels.

  • Page 357: Playing Back The Recordings From The Ip Camera

    18.2.4 Playing Back the Recordings from the IP Camera To play back the recordings from the GV-IPCAM H.264, follow these steps: Enable ViewLog Server on the camera. Keep the connection port to be 5552 or modify it if necessary. See 13.3.7 ViewLog Server for details.

  • Page 358: Other Functions

    Mobile Phone Connection 18.2.5 Other Functions In addition to live view, MSView V2 or MSView V3 offers these functions: zooming in/out a camera view, rotating images and controlling outputs. Select the Control option to have these features.

  • Page 359: Symbian Smartphone

    18.3.1 Installing SSView V3 To install SSView Version 3 for Nokia S60 2nd and 3rd Edition: To download GV-SSView V3, please go to http://www.geovision.com.tw/english/5_4_ssview.asp. Click the Download button. Consult your smartphone user’s manual for how to install a program to the smartphone.

  • Page 360: Activating The Ssview V3 Function

    Mobile Phone Connection 18.3.2 Activating the SSView V3 Function To allow remote access to the GV-IPCAM H.264: Select 3GPPv7, MSViewV2/V3, SSViewV3 and GViewV2 Supported in the Connection Template field on the Web interface. For details, see “Connection Template” in 13.1.1 Video Settings. Figure 18-18 Enable RTSP server on the Web interface.

  • Page 361: Connecting To The Ip Camera

    18.3.3 Connecting to the IP Camera The following operations may vary slightly for different modules. Execute SSView on your Smartphone. When the message SSView V3 appears, select Options, and select Live Connect. The login screen appears. Figure 18-19 Enter the IP address of your camera, port value (default value is 10000), a username and a password.

  • Page 362: Quick Connection

    Mobile Phone Connection 18.3.4 Quick Connection The IP addresses of connected servers can be stored for quick connection in the future. Press the [<] and [>] buttons on the mobile device to select the desired camera for connection. 18.3.5 Playing Back the Recordings from the IP Camera To play back the recordings from the GV-IPCAM H.264, follow these steps: Enable ViewLog Server on the camera.

  • Page 363: Other Functions

    18.3.6 Other Functions In addition to live view, SSView offers these functions: changing camera channels, zooming in a camera view, rotating images and controlling outputs. Select Options to have these features.

  • Page 364: Mobile Phone

    Mobile Phone Connection 18.4 3G Mobile Phone Without installing any GV applications, you can use a 3G mobile phone to access GV-IPCAM H.264 directly. 18.4.1 Activating the 3G Mobile Phone Function To allow remote access to the GV-IPCAM H.264, follow the steps below: Select 3GPPv7, MSViewV2/V3, SSViewV3 and GViewV2 Supported to be the connection type in the Connection Template field on the Video Setting page.

  • Page 365: Connecting To The Ip Camera

    18.4.2 Connecting to the IP Camera Open the Internet browser in the mobile phone, and enter the IP address of your camera, a user name and a password. Then click Apply to connect. Figure 18-24 After the connection is established, an image similar to this example appears.
  • Page 366 Mobile Phone Connection Select the desired channel. Its live image will appear. Figure 18-26 Note: Currently the 3GPP application does not support remote playback and I/O control.

  • Page 367: Android Smartphone

    18.5 Android Smartphone GV-AView V1.1 is a remote view application for Android smartphone. You can access the GV-IPCAM H.264 using Android version 1.6 or above. For the supported operating system version, see Chart 1. Download GV-AView V1.1 from Android Market, and after installing the application., the GV-AView icon will appear on the desktop.

  • Page 368: Connecting To Gv-Ipcam H.264

    Mobile Phone Connection 18.5.1 Connecting to GV-IPCAM H.264 Double-tap the AView icon on the main page. Figure 18-28 To see the installation guide, tap the Information button Tap the Add button to type the login information of the GV-IP device.. Figure 18-29...
  • Page 369 Type the name, IP address, port number, user name and password of the GV IP device. Tap the Add button to add the login information to the address book. If you want to edit existing login information, tap the Edit button to save the information after making the changes.
  • Page 370 Mobile Phone Connection The following function buttons are available on the bottom of the screen. Snapshot : Saves the current image in the mobile device. PTZ Control : Enables the PTZ function. A message will appear asking if you want to use Gesture Detector to control PTZ. Tap OK if you want to be able to drag across the live view screen to control the PTZ function in addition to using the PTZ control buttons on the bottom of the screen.

  • Page 371: Iphone, Ipod Touch And Ipad

    18.6 iPhone, iPod Touch and iPad With GV-Eye V1.0 / HD V1.0, you can connect to GV-IPCAM H.264 from your iPhone, iPod Touch or iPad to remotely watch live view, force output devices to be triggered and take snapshots. GV-Eye V1.0 is designed for iPhone and iPod Touch, while GV-Eye HD V1.0 is designed for iPad.

  • Page 372: Connecting To Gv-Ipcam H.264

    Mobile Phone Connection 18.6.2 Connecting to GV-IPCAM H.264 To connect your iPhone, iPod Touch or iPad to the GV-IPCAM H.264, follow these steps: Click the GV-Eye icon on the desktop of your phone. The welcome page appears. Tap the Add button. This page appears. Figure 18-32 Enter the Host name, Domain/IP address, port number, username and password to log in to the GV-IPCAM H.264.
  • Page 373 Tap the Save button. The GV-IPCAM H.264 is now added to the IPCam list and will be available the next time you access GV-Eye. You can tap the Edit button and then select an IP camera to edit existing device login information. Figure 18-33 Tap the device name to connect to the live view of the device.
  • Page 374 Mobile Phone Connection The following function buttons are available when the iPhone, iPod Touch or iPad is positioned vertically. Button Name Function Displays up to four channels on the Screen division same page if the GV-IPCAM H.264 supports multiple channels. Enables PTZ control.

  • Page 375: Specifications: Box Camera

    Specifications: Box Camera Camera GV-BX110D GV-BX120D 1/3" progressive scan CMOS GV-BX140DW Image GV-BX130D Series Sensor GV-BX220D Series 1/2.5” progressive scan CMOS GV-BX320D Series GV-BX520D-0 GV-BX140DW 1280 (H) x 720 (V) GV-BX110D GV-BX120D 1280 (H) x 1024 (V) Picture GV-BX130D Sereis Elements GV-BX220D Series 1920 (H) x 1080 (V)
  • Page 376 (1/5 sec) 0.08 Lux (1/30 sec), 0.04 Lux GV-BX120D (1/5 sec) 0 Lux IR ON 0.5 Lux at F/1.4 Color GV-BX130D-0 0.1 Lux at F/1.4 0 Lux IR On 0.5 Lux at F/1.5 Color GV-BX130D-1 0.1 Lux at F/1.5 0 Lux...
  • Page 377 Automatic (Balanced, Speed Priority, Quality Priority), Manual (1/5 ~ 1/4000 GV-BX110D sec) GV-BX140DW Automatic Shutter GV-BX120D Speed GV-BX130D Series GV-BX220D Sereis Automatic, Manual (1/5 ~ 1/8000 sec) GV-BX320D Series GV-BX520D-0 White Balance Automatic, Manual (2800K ~ 8500K) Gain Control Automatic GV-BX120D 50 dB GV-BX130D Series 45 dB...
  • Page 378 Torque (Focus Screw) 3.9 ~ 4.9 N.cm Varifocal Lens Megapixel Day/Night Yes (with removable IR-cut filter) GV-BX110D 4 ~ 9 mm GV-BX120D GV-BX130D-0 2.8 ~ 12 mm GV-BX140DW GV-BX220D-3 Focal GV-BX220D-0 2.8 ~ 8.5 mm Length GV-BX220D-1 3.1 ~ 8 mm...
  • Page 379 GV-BX110D GV-BX120D GV-BX130D-0 F/1.4 GV-BX140DW GV-BX220D-0 Maximum GV-BX220D-3 Aperture GV-BX220D-1 F/1.2 GV-BX320D-0 GV-BX220D-2 F/1.3 GV-BX320D-1 GV-BX520D-0 F/1.6 Mount GV-BX120D GV-BX130D-0 GV-BX140DW GV-BX220D-0 1/3” GV-BX220D-1 Image Format GV-BX220D-2 GV-BX220D-3 GV-BX320D-0 GV-BX320D-1 GV-BX520D-0 1/2’’ GV-BX110D Horizontal 60° ~ 30° GV-BX120D Diagonal 115° ~ 45.3°...
  • Page 380 Angle of GV-BX520D-0 Horizontal 80.5°~ 37.12° View Vertical 60° ~ 28° Focus Manual (w/lock) Zoom Manual (w/lock) GV-BX110D GV-BX120D Operation GV-BX130D-0 DC drive GV-BX220D Series Iris GV-BX320D Series GV-BX140DW Fixed GV-BX520D-0 Manual Torque 0.049 N.m (Focus/Zoom screws) Operation Video Compression H.264, MPEG4, MJPEG...
  • Page 381 20 fps at 2048 x 1536 GV-BX320D Series Frame 30 fps at 1920 x 1080 Rate GV-BX520D-0 10 fps at 2560 x 1920 Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Image Setting Flicker-less, Image Orientation, Shutter Speed, D/N Sensitivity, Backlight Compensation Audio Compression G.711, AAC (16 kHz / 16 bit)

  • Page 382: Video Resolution

    Specifications: Box Camera Video Resolution 1280 x 960, 640 x 480, 320 x 240 Main Stream 1280 x 1024, 640 x 512, 320 x 256 GV-BX110D 640 x 480, 320 x 240 Stream 640 x 512, 320 x 256 1280 x 960, 640 x 480, 320 x 240 Main 16:9 1280 x 720, 640 x 360, 448 x 252...
  • Page 383 2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main 1920 x 1080, 1280 x 720, 16:9 Stream 640 x 360, 448 x 252 GV-BX320D Series 1280 x 1024, 640 x 512, 320 x 256 640 x 480, 320 x 240 16:9 640 x 360, 448 x 252...
  • Page 384 Specifications: Box Camera Mechanical GV-BX110D C / CS-Mount GV-BX120D GV-BX130D Series Lens Mounting GV-BX140DW CS Mount GV-BX220D Series GV-BX320D Series GV-BX520D-0 GV-BX110D GV-BX120D GV-BX130D Series Temperature Detector GV-BX140DW GV-BX220D Series GV-BX320D Series GV-BX520D-0 GV-BX110D DC Jack, PoE GV-BX120D GV-BX130D Series Power GV-BX140DW 2-pin terminal block, PoE...
  • Page 385 GV-BX110D (fixed lens) GV-BX130D-1 Not functional GV-BX140DW GV-BX520D-0 Auto Iris GV-BX110D (Varifocal) GV-BX120D GV-BX130D-0 GV-BX220D Series GV-BX320D Series Micro SD / SDHC memory card slot Local Connectors Storage (for Class 6 card or above) TV-Out BNC connector (640 x 480 resolution)
  • Page 386 Specifications: Box Camera General Operating Temperature 0°C ~ 50°C / 32 °F ~ 122 °F Humidity 10% to 90% (no condensation) Power Source 12V DC / PoE GV-BX110D 9.2 W GV-BX120D GV-BX130D Series Max. Power GV-BX140DW Consumption GV-BX220D Series GV-BX320D Series GV-BX520D-0 115 x 65 x 60 mm / GV-BX110D...

  • Page 387: Power Over Ethernet

    Power over Ethernet PoE Standard IEEE 802.3af Power over Ethernet / PSE PoE Power Supply Type End-Span PoE Power Output Per Port 48V DC, 350mA. Max. 15.4 watts Note: An STP cable can only work with a one-port PoE adapter. Web Interface Installation Management Web-based configuration...
  • Page 388 Specifications: Box Camera Application GV-NVR, GV-System, GV-Backup Center, Network Storage GV-Recording Server GV-AView for Android Smartphone, GV-Eye HD for iPad, GV-Eye for iPhone and iPod Touch, GV-GView for Windows PDA, GV- Mobile Phone support MSView for Windows Smartphone, GV- SSView for Symbian Smartphone, 3G- enabled phone Live Viewing IE , GV-MultiView...

  • Page 389: Specifications: Ir Arctic Box Camera

    Specifications: IR Arctic Box Camera Camera GV-BX120D-E 1/3" progressive scan CMOS Image GV-BX220D-E Sensor GV-BX320D-E 1/2.5” progressive scan CMOS GV-BX520D-E GV-BX120D-E 1280 (H) x 1024 (V) GV-BX220D-E 1920 (H) x 1080 (V) Picture Elements GV-BX320D-E 2048 (H) x 1536 (V) GV-BX520D-E 2560 (H) x 1920 (V) Color...
  • Page 390 Specifications: IR Arctic Box Camera GV-BX120D-E 50 dB GV-BX220D-E S/N Ratio GV-BX320D-E 45 dB GV-BX520D-E Lens Megapixel Day/Night Yes (with removable IR-cut filter) Lens Type Varifocal GV-BX120D-E 2.8 ~ 12 mm GV-BX220D-E Focal 2.8 ~ 6 mm Length GV-BX320D-E GV-BX520D-E 4.5 ~ 10 mm GV-BX120D-E F/1.4...
  • Page 391 Focus Manual (w/lock) Zoom Manual (w/lock) GV-BX120D-E Operation GV-BX220D-E DC drive Iris GV-BX320D-E GV-BX520D-E Manual IR Quantity IR Distance 15 m / 50 ft. (Max.) Torque 0.049 N.m (Focus/Zoom screws) Operation Video Compression H.264, MPEG4, MJPEG Stream 1 from H. 264 or MJPEG Video Stream Stream 2 from H.264, MPEG4 or MJPEG GV-BX120D-E...
  • Page 392 Specifications: IR Arctic Box Camera Video Resolution 1280 x 960, 640 x 480, 320 x 240 Main 16:9 1280 x 720, 640 x 360, 448 x 252 Stream 1280 x 1024, 640 x 512, 320 x 256 GV-BX120D-E 640 x 480, 320 x 240 16:9 640 x 360, 448 x 252 Stream...
  • Page 393 2560 x 1920, 2048 x 1536, 4 : 3 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main Stream 1920 x 1080, 1280 x 720, 640 x 16 :9 360, 448 x 252 GV-BX520D-E 5 : 4 1280 x 1024, 640 x 512, 320 x 256 4 : 3 640 x 480, 320 x 240...
  • Page 394 Specifications: IR Arctic Box Camera LED Indicator 2 LEDs: Power, Status Note: The TV-Out function only works in 640 x 480 resolution. For TV-Out to work properly, you must set the video resolution to 1280 x 1024 or lower. If both streams are enabled, the Sub Stream must be set to 640 x 480. General Operating Temperature -40°C ~ 50°C / -40 °F ~ 122 °F...
  • Page 395 Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser or Maintenance Utility Camera live view, video recording, change video quality, bandwidth control, image snapshot, digital I/O control, audio, Wide Access from Web Browser Angle Lens Dewarping, Picture in Picture, Picture and Picture, Privacy Mask, Visual Automation, Tampering Alarm, Text Overlay Bulgarian / Czech / Danish / Dutch / English...
  • Page 396 Specifications: IR Arctic Box Camera Specifications: GV-PA481 PoE Standard IEEE 802.3at Power over Ethernet / PSE PoE Power Output (10/100 DC 48V, 1A (48W Max.) Out) Max 100 m / 328 ft from GV-PA481 to IP Ethernet Cable Length device, CAT5 Power Input DC 48V, 1A Operation Temperature...

  • Page 397: Specifications: Mini Fixed & Rugged Dome1

    Specifications: Mini Fixed & Rugged Dome Camera GV-MFD110 GV-MFD120 1/3" progressive scan CMOS GV-MFD130 GV-MDR120 Image GV-MFD220 Sensor GV-MFD320 GV-MFD520 1/2.5’’ progressive scan CMOS GV-MDR220 GV-MDR320 GV-MDR520 GV-MFD110 GV-MFD120 1280 (H) x 1024 (V) GV-MFD130 GV-MDR120 GV-MFD220 Picture 1920 (H) x 1080 (V) Elements GV-MDR220 GV-MFD320...
  • Page 398 Specifications: Mini Fixed & Rugged Dome 1.5 Lux (1/60 sec), 0.2 Lux (1/5 sec), (F/1.8, GV-MFD110 Color AGC-On, slow shutter- Off) GV-MFD120 Color 0.08 Lux at F/1.5 GV-MDR120 Minimum GV-MFD130 Illumination GV-MFD220 GV-MFD320 Color GV-MFD520 0.5 Lux at F/2.8 GV-MDR220 GV-MDR320 GV-MDR520 Automatic (Balanced, Speed...
  • Page 399 GV-MFD120 50 dB GV-MDR120 GV-MFD130 GV-MFD220 GV-MFD320 S/N Ratio GV-MFD520 45 dB GV-MDR220 GV-MDR320 GV-MDR520 GV-MFD110 GV-MFD (except GV-MFD110) GV-MDR Lens Megapixel GV-MFD110 GV-MFD Day/Night Yes (electronic) (except GV-MFD110) GV-MDR Iris Fixed GV-MFD110 3.6 mm GV-MFD120 4.05 mm GV-MDR120 Focal Length GV-MFD130 GV-MFD220 2.54 mm...
  • Page 400 Specifications: Mini Fixed & Rugged Dome GV-MDR220 Focal Length GV-MDR320 2.54 mm GV-MDR520 GV-MFD110 F/1.8 GV-MFD120 F/1.5 GV-MDR120 GV-MFD130 Maximum GV-MFD220 Aperture GV-MFD320 GV-MFD520 F/2.8 GV-MDR220 GV-MDR320 GV-MDR520 Mount M12, Pitch 0.5 mm GV-MFD110 GV-MFD120 1/3’’ GV-MDR120 GV-MFD130 GV-MFD220 Image Format GV-MFD320 GV-MFD520 1/2.5’’...
  • Page 401 GV-MFD110 80.4° (D) 65.4° (H) 49.9° (V) GV-MFD120 100.2°(D) 77°(H) 54°(V) GV-MDR120 GV-MFD130 GV-MFD220 Angle of View GV-MFD320 GV-MFD520 162.5°(D) 130.1°(H) 97.3°(V) GV-MDR220 GV-MDR320 GV-MDR520 GV-MFD110 GV-MFD120 GV-MFD130 GV-MFD220 Focus GV-MFD320 Operation GV-MFD520 GV-MDR Zoom Iris Fixed Note: For GV-MFD (except GV-MFD110), the day/night function is only supported by V1.07 or later.
  • Page 402 Specifications: Mini Fixed & Rugged Dome Operation Video Compression H.264, MJPEG, MPEG4 Dual Streams from two of H.264, GV-MFD110 MPEG4 or MJPEG GV-MFD120 GV-MFD130 GV-MFD220 GV-MFD320 Video Stream Stream 1 from H.264 or MJPEG GV-MFD520 Stream 2 from H.264, MPEG4 or MJPEG GV-MDR120 GV-MDR220...
  • Page 403 GV-MFD110 G.711 GV-MFD120 GV-MFD130 GV-MFD220 GV-MFD320 Audio Compression GV-MFD520 G.711, AAC (16 kHz / 16 bit) GV-MDR120 GV-MDR220 GV-MDR320 GV-MDR520 Sensor Input Alarm Output Note: The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes). AAC is not available for GV-MFD110 and is only supported by GV- System V8.5 or later.
  • Page 404 Specifications: Mini Fixed & Rugged Dome 1280 x 960, 640 x 480, 320 x 240 Main 16:9 1280 x 720, 640 x 360, 448 x 252 Stream GV-MFD120 1280 x 1024, 640 x 512, 320 x 256 GV-MFD130 640 x 480, 320 x 240 GV-MDR120 16:9 640 x 360, 448 x 252...
  • Page 405 2560 x 1920, 2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480, 320 x Main Stream 1920 x 1080, 1280 x 720, 640 x 360, 16:9 448 x 252 GV-MFD520 GV-MDR520 1280 x 1024, 640 x 512, 320 x 256 640 x 480, 320 x 240 16:9 640 x 360, 448 x 252...
  • Page 406 Specifications: Mini Fixed & Rugged Dome GV-MFD110 GV-MFD120 GV-MFD130 Temperature GV-MFD220 Detector GV-MFD320 GV-MFD520 GV-MDR GV-MFD110 GV-MDR GV-MFD120 Power GV-MFD130 PoE, GV-MFD220 3-pin terminal block GV-MFD320 GV-MFD520 Ethernet RJ-45 Connectors Audio Built-in microphone GV-MFD110 None GV-MFD120 GV-MFD130 Micro SD / SDHC Local GV-MFD220 memory card slot...
  • Page 407 General GV-MFD 0°C ~ 50°C / 32°F ~ 122°F Operating Temperature -20°C ~ 50°C / -4°F ~ 122°F GV-MDR Humidity 10% - 90% (no condensation) GV-MFD110 GV-MDR Power Source GV-MFD PoE, DC 12V (all except GV-MFD110) GV-MFD110 5.8 W GV-MFD120 4.5 W GV-MFD130 GV-MFD220...
  • Page 408 Specifications: Mini Fixed & Rugged Dome ø 106 x 55.6 mm Camera Body 4.2 x 2.2 in Cable Length 1 m / 3.28 ft Cable GV-MFD ø 8 mm / 0.31 in Diameter Max. ø 28.5 mm Connector ø 1.12 in Diameter Dimensions ø...
  • Page 409 Power over Ethernet PoE Standard IEEE 802.3af Power over Ethernet PoE Power Supply Type End-Span and Mid-Span Per Port 48V DC, 350 mA. Max. 15.4 PoE Power Output watts Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser Maintenance or Utility Camera live view, video recording,...
  • Page 410 Specifications: Mini Fixed & Rugged Dome Applications GV-NVR, GV-System, GV-Backup Network Storage Center, GV-Recording Server GV-AView for Android Smartphone, GV- Eye HD for iPad, GV-Eye for iPhone and iPod Touch, GV-GView for Windows Mobile Phone support PDA, GV-MSView for Windows Smartphone, GV-SSView for Symbian Smartphone, 3G-enabled phone Live Viewing...

  • Page 411: Specifications: Bullet Camera

    Specifications: Bullet Camera Camera GV-BL110D 1/3" progressive scan CMOS GV-BL120D Image Sensor GV-BL130D 1/2.5’’ progressive scan CMOS GV-BL220D GV-BL320D GV-BL110D GV-BL120D 1280 (H) x 1024 (V) GV-BL130D Picture Elements GV-BL220D 1920 (H) x 1080 (V) GV-BL320D 2048 (H) x 1536 (V) 1 Lux (1/60 sec), 0.1 Lux (1/5 GV-BL110D sec), (F/1.3, AGC-On, slow...
  • Page 412 Specifications: Bullet Camera Automatic (Balanced, Speed GV-BL110D Priority, Quality Priority), Manual (1/5 ~ 1/4000 sec), GV-BL120D Shutter Speed GV-BL130D Automatic, Manual (1/5 ~ 1/8000 sec) GV-BL220D GV-BL320D White Balance Automatic, Manual (2800K ~ 8500K) Gain Control Automatic GV-BL120D 50 dB GV-BL220D S/N Ratio 45 dB...
  • Page 413 Diagonal 76° (W) ~ 32° (T) GV-BL130D Horizontal 66° (W) ~ 27.9° (T) GV-BL220D Vertical 37.3° (W) ~ 15.7° (T) Angle of View Diagonal 88.8° (W) ~ 36.3° (T) GV-BL320D Horizontal 71° (W) ~ 29° (T) Vertical 53.3° (W) ~ 21.8° (T) Focus Manual (w/lock) Operation...
  • Page 414 Specifications: Bullet Camera Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Image Setting Flicker-less, Image Orientation, Shutter Speed, D/N Sensitivity, Backlight Compensation Audio Compression G.711, AAC (16 kHz / 16 bit) Two-Way Audio Sensor Input 1 Input (Dry Contact) Alarm Output 1 Output (200mA 5V DC) Note: The frame rate and performance may vary depending on the...
  • Page 415 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main 1920 x 1080, 1280 x 720, 640 x 360, 16:9 Stream 448 x 252 1280 x 1024, 640 x 512, 320 x 256 GV-BL220D 640 x 480, 320 x 240 16:9 640 x 360, 448 x 252 Stream...
  • Page 416 Specifications: Bullet Camera Mechanical Lens Mounting ø 14 mm 0° ~ 360° Camera Angle Tilt 90° ~ 180° Adjustment Rotate 0° ~ 360° Temperature Detector Power 3-pin terminal block, PoE Ethernet RJ-45 1 In (RCA female for microphone) Audio 1 Out (RCA female for speaker) Digital I/O I/O Wire Connectors...
  • Page 417 Protection Classification IP66 Regulatory CE, FCC, C-Tick, RoHS compliant Power over Ethernet PoE Standard IEEE 802.3af Power over Ethernet / PSE PoE Power Supply Type End-Span PoE Power Output Per Port 48V DC, 350mA. Max. 15.4 watts Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser Maintenance...
  • Page 418 Specifications: Bullet Camera Application GV-NVR, GV-System, GV-Backup Center, Network Storage GV-Recording Server GV-AView for Android Smartphone, GV- Eye HD for iPad, GV-Eye for iPhone and iPod Touch, GV-GView for Windows PDA, Mobile Phone support GV-MSView for Windows Smartphone, GV-SSView for Symbian Smartphone, 3G- enabled phone Live Viewing IE , Mobile Phone...

  • Page 419: Specifications: Ptz Camera

    Specifications: PTZ Camera Camera Model Name GV-PTZ010D-N GV-PTZ010D-P Image Sensor 1/4" CCD image sensor Picture Elements 704 (H) x 480 (V) 704 (H) x 576 (V) Color 2.5 Lux at F/1.8 Minimum Illumination 0.07 Lux at F/1.8 Automatic, Automatic, Shutter Speed Manual (1/60 ~ Manual (1/50 ~ 1/120,000 sec)
  • Page 420 Specifications: PTZ Camera Operation Model Name GV-PTZ010D-N GV-PTZ010D-P Video Format NTSC Video Compression H.264, MPEG4, MJPEG Dual Streams from two of H.264, Video Stream MPEG4 or MJPEG 704 x 480 704 x 576 Main Stream 704 x 240 704 x 288 Video 352 x 240 352 x 288...
  • Page 421 Mechanical -175° ~ 175° Camera Angle Adjustment Tilt -45° ~ 90° Temperature Detector Power 2-pin terminal block, PoE Ethernet RJ-45 1 In (Using a built-in or an externally connected microphone) Audio 1 Out (Stereo phone jack, 3.5 mm / Connectors 0.14 in) 3-pin terminal block Digital I/O...
  • Page 422 Specifications: PTZ Camera Power over Ethernet IEEE 802.3af Power over Ethernet / PoE Standard PoE Power Supply Type End-Span Per Port 48V DC, 350mA. Max. 15.4 PoE Power Output watts Web Interface Installation Management Web-based configuration Firmware upgrade through Web Maintenance Browser or Utility Camera live view, video recording,...
  • Page 423 Application GV-NVR, GV-System, GV-Backup Network Storage Center, GV-Recording Server GV-AView for Android Smartphone, GV-Eye HD for iPad, GV-Eye for iPhone and iPod Touch, GV-GView for Mobile Phone support Windows PDA, GV-MSView for Windows Smartphone, GV-SSView for Symbian Smartphone, 3G-enabled phone Live Viewing IE , Mobile Phone GV-Center V2, GV-VSM, GV-Control...

  • Page 424: Specifications: Pt Camera

    Specifications: PT Camera Specifications: PT Camera Camera Image Sensor 1/3" progressive scan CMOS Picture Elements 1280 (H) x 1024 (V) 1.5 Lux (1/60 sec) Color 0.2 Lux (1/5 sec) (F1.5, AGC-On, slow Minimum shutter-Off) Illumination 0 Lux (1/60 sec) (F/1.5, AGC-On, slow shutter-Off) IR ON Automatic (Balanced, Speed Priority,...
  • Page 425 Focus Manual (w/lock) Operation Zoom Iris Fixed IR LED Quantity 14 IR LEDs IR Distance 15 m / 50 ft (Max.) Operation Video Compression H.264, MPEG4, MJPEG Dual Streams from two of H.264, Video Stream MPEG4 or MJPEG 1280 x 960, 640 x 480, 320x 240 Main Stream 1280 x 1024, 640 x 512, 320 x 256...
  • Page 426 Specifications: PT Camera Network Interface 10/100 Ethernet HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, Protocol 3GPP/ISMA, RTSP, PSIA, SNMP, QoS (DSCP) Note: HTTPS, SNMP and QoS are only suppported in V1.08 or later. Mechanical Lens Mounting M12, Pitch 0.5 mm -175°...
  • Page 427 General Operating Temperature -10°C ~ 50°C / 14°F ~ 122°F Humidity 10% to 90% (no condensation) Power Source 12V DC / 24V AC / PoE Max. Power Consumption 12 W 167.75 x 166.78 x 135.2 mm / With mounting base and cover 6.6 x 6.57 x 5.32 in Dimensions Without...
  • Page 428 Specifications: PT Camera Bulgarian / Czech / Danish / Dutch / English / French / German / Greek / Hebrew / Hungarian / Indonesian / Italian /Japanese / Lithuanian / Language Norwegian / Persian / Polish / Portuguese / Romanian / Russian / Serbian / Simplified Chinese / Slovakian / Slovenian / Spanish / Thai / Traditional Chinese / Turkish...

  • Page 429: Specifications: Vandal Proof Ip Dome

    Specifications: Vandal Proof IP Dome Camera GV-VD120D GV-VD121D 1/3" progressive scan CMOS GV-VD122D GV-VD123D GV-VD220D Image GV-VD221D Sensor GV-VD222D GV-VD223D 1/2.5’’ progressive scan CMOS GV-VD320D GV-VD321D GV-VD322D GV-VD323D GV-VD120D GV-VD121D 1280 (H) x 1024 (V) GV-VD122D GV-VD123D Picture Elements GV-VD220D GV-VD221D 1920 (H) x 1080 (V) GV-VD222D...
  • Page 430 Specifications: Vandal Proof IP Dome GV-VD320D GV-VD321D Picture 2048 (H) x 1536 (V) Elements GV-VD322D GV-VD323D GV-VD120D 0.15 Lux (1/30 sec), Color 0.08 Lux (1/5 sec) GV-VD121D GV-VD122D 0 Lux IR ON GV-VD123D GV-VD220D 1 Lux (1/30 sec), GV-VD221D Minimum Color 0.5 Lux (1/5 sec) Illumination...
  • Page 431 Lens Megapixel Day/Night Yes (with removable IR-cut filter) Lens Type Varifocal Focal Length 2.7 ~ 9 mm Maximum Aperture F/1.3 Mount ø 14 mm GV-VD120D Diagonal 126° (W) ~ 38.2° (T) GV-VD121D Horizontal 98.5° (W) ~ 29.8° (T) GV-VD122D GV-VD123D Vertical 78.7°...
  • Page 432 Specifications: Vandal Proof IP Dome Operation H.264, MPEG4, MJPEG Video Compression Stream 1 from H.264 or MJPEG Video Stream Stream 2 from H.264, MPEG4 or MJPEG GV-VD120D GV-VD121D 30 fps at 1280 x 1024 GV-VD122D GV-VD123D GV-VD220D GV-VD221D Frame 30 fps at 1920 x 1080 Rate GV-VD222D GV-VD223D...
  • Page 433 Video Resolution 1280 x 960, 640 x 480, 320 x 240 Main Stream 16:9 1280 x 720, 640 x 360, 448 x 252 GV-VD120D 1280 x 1024, 640 x 512, 320 x 256 GV-VD121D 640 x 480, 320 x 240 GV-VD122D GV-VD123D Sub Stream 16:9...
  • Page 434 Specifications: Vandal Proof IP Dome Mechanical Lens Mounting ø 14 mm 0° ~ 350° Camera Angle Tilt 10° ~ 90° Adjustment Rotate 0° ~ 340° Temperature Detector Power 3-pin terminal block, PoE Ethernet RJ-45 1 In (RCA female for microphone) Audio 1 Out (RCA female for speaker) Connectors...
  • Page 435 Camera Body ø 165 x 125 mm / 6.49 x 4.92 in Cable Length 1 m / 3.28 ft Dimensions Cable Diameter ø 16.7 mm / 0.66 in Max. Connector ø 16.7 mm / 0.66 in Diameter Weight 1.7 kg / 3.75 lb Protection Classification IP66 GV-VD120D...
  • Page 436 Specifications: Vandal Proof IP Dome Camera live view, video recording, change video quality, bandwidth control, image snapshot, digital I/O control, audio, Wide Access from Web Browser Angle Lens Dewarping, Picture in Picture, Picture and Picture, Privacy Mask, Visual Automation, Tampering Alarm, Text Overlay Bulgarian / Czech / Danish / Dutch / English / French / German / Greek / Hebrew / Hungarian / Indonesian / Italian /Japanese /...

  • Page 437: Specifications: Fixed Ip Dome

    Specifications: Fixed IP Dome Camera GV-FD120D 1/3" progressive scan CMOS Image GV-FD220D Sensor 1/2.5’’ progressive scan CMOS GV-FD320D GV-FD120D 1280 (H) x 1024 (V) Picture GV-FD220D 1920 (H) x 1080 (V) Elements GV-FD320D 2048 (H) x 1536 (V) 0.15 Lux (1/30 sec), 0.08 Lux (1/5 Color sec) GV-FD120D...
  • Page 438 Specifications: Fixed IP Dome Lens Megapixel Day/Night Yes (with removable IR-cut filter) Lens Type Varifocal Focal Length 2.7 ~ 9 mm Maximum Aperture F/1.3 ± 5% Mount ø 14 mm Image Format 1/3’’ Diagonal 126° (W) ~ 38.2° (T) GV-FD120D Horizontal 98.5°...
  • Page 439 GV-FD120D 30 fps at 1280 x 1024 Frame GV-FD220D 30 fps at 1920 x 1080 Rate GV-FD320D 20 fps at 2048 x 1536 Image Setting Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker-less, Image Orientation, Shutter Speed, Backlight Compensation, D/N Sensitivity Audio Compression G.711, AAC (16 k / 16 bit)
  • Page 440 Specifications: Fixed IP Dome 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240 Main GV-FD220D 1920 x 1080, 1280 x 720, 640 x 360, Stream 16:9 448 x 252 1280 x 1024, 640 x 512, 320 x 256 640 x 480, 320 x 240 GV-FD220D 16:9...
  • Page 441 Mechanical Lens Mounting ø 14 mm 0° ~ 350° Camera Angle Tilt 10° ~ 90° Adjustment Rotate 0° ~ 340° Temperatire Detector Power 2-pin terminal block, PoE Ethernet Ethernet (10/100 Base-T), RJ-45 1 In (microphone phone jack, 3.5 mm / 0.14 Audio 1 Out (Stereo pohone jack, 3.5 mm / 0.14 in) Connectors...
  • Page 442 Specifications: Fixed IP Dome Power over Ethernet PoE Standard IEEE 802.3af Power over Ethernet / PSE PoE Power Supply Type End-Span PoE Power Output Per Port 48V DC, 350mA. Max. 15.4 watts Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser Maintenance or Utility Camera live view, video recording, change...
  • Page 443 Application GV-NVR, GV-System, GV-Backup Center, Network Storage GV-Recording Server GV-AView for Android Smartphone, GV- Eye HD for iPad, GV-Eye for iPhone and iPod Touch, GV-GView for Windows PDA, Mobile Phone support GV-MSView for Windows Smartphone, GV- SSView for Symbian Smartphone, 3G- enabled phone Live Viewing IE , Mobile Phone...

  • Page 444: Specifications: Cube Camera & Wireless Cube Camera

    Specifications: Cube & Wireless Cube Camera Specifications: Cube Camera & Wireless Cube Camera Camera Image Sensor 1/2.5’’ progressive scan CMOS GV-CB120 1280 (H) x 1024 (V) GV-CBW120 Picture Elements GV-CB220 1920 (H) x 1080 (V) GV-CBW220 Minimum Color 1 Lux (1/30 sec), 0.5 Lux (1/5 sec) Illumination Automatic, Manual (1/5 ~ 1/8000 sec) Shutter Speed...
  • Page 445 Mount M12 mm Image Format 1/3’’ Diagonal 142° Angle of Horizontal 131° View Vertical 112° Operation H.264, MPEG4, MJPEG Video Compression Stream 1 from H.264 or MJPEG Video Stream Stream 2 from H.264, MPEG4 or MJPEG GV-CB120 30 fps at 1280 x 1024 GV-CBW120 Frame Rate GV-CB220...
  • Page 446 Specifications: Cube & Wireless Cube Camera Video Resolution 1280 x 960, 640 x 480, 320 x 240 Main Stream 16:9 1280 x 720, 640 x 360, 448 x 252 1280 x 1024, 640 x 512, 320 x 256 GV-CB120 GV-CBW120 640 x 480, 320 x 240 Sub Stream 16:9...
  • Page 447 Mechanical Lens Mounting M12 mm Temperature Detector Power DC Jack Ethernet Ethernet (10/100 Base-T), RJ-45 Connectors Audio Built-in speaker & microphone Micro SD / SDHC memory card slot Local Storage (for Class 6 card or above) LED Indicator 2 LEDs: Status, LAN General GV-CB120 0°C ~ 50°C / 32°F ~ 122°F...
  • Page 448 Specifications: Cube & Wireless Cube Camera Web Interface Installation Management Web-based configuration Firmware upgrade through Web Browser or Maintenance Utility Camera live view, video recording, change video quality, bandwidth control, image Access from Web snapshot, , audio, Wide Angle Lens Browser Dewarping, Picture in Picture, Picture and Picture, Privacy Mask, Tampering Alarm,...

  • Page 449: Appendix

    Appendix A. Settings for Internet Explorer 8 If you use Internet Explorer 8, it is required to complete the following setting. Set the Security to Medium-high (default). Enable Allow previously unused ActiveX controls to run without prompt. Disable Only allow approved domains to use ActiveX without prompt.

  • Page 450: Supported Lenses For Box Camera

    Appendix B. Supported Lenses for Box Camera Provider Model No. RV0409D.IR Fujian Forecam Optics RV0515D.IR RV0820D.IR EVD03618F-IR EVD04218F-IR EVD06018F-IR EVETAR EVD08018F-IR EVD12018F-IR EVD16018F-IR Pentax TS3VP213ED-M...

  • Page 451: Resolution And Frame Rate

    C. Resolution and Frame Rate Note that the frame rate and the performance may vary depending on the number of connections and data bitrates (different scenes). Max. Frame GV-IP Camera Stream Ratio Resolution Rate 1280 x 960 15 fps 640 x 480 30 fps 320 x 240 Main...
  • Page 452 Appendix Max. Frame GV-IP Camera Stream Ratio Resolution Rate 1280 x 720 Main 16:9 640 x 360 448 x 252 GV-BX140DW 30 fps 640 x 360 16:9 448 x 252 1600 x 1200 1280 x 960 640 x 480 320 x 240 GV-BX220D Series GV-BX220D-E 1920 x 1080...
  • Page 453 Max. Frame GV-IP Camera Stream Ratio Resolution Rate 2048 x 1536 20 fps 1600 x 1200 1280 x 960 640 x 480 320 x 240 GV-BX320D Series 1920 x 1080 GV-BX320D-E Main 1280 x 720 GV-MFD320 16:9 640 x 360 GV-MDR320 448 x 252 GV-BL320D...
  • Page 454 Appendix Max. Frame GV-IP Camera Stream Ratio Resolution Rate 2560 x 1920 10 fps 2048 x 1536 20 fps 1600 x 1200 1280 x 960 640 x 480 320 x 240 Main 1920 x 1080 1280 x 720 16:9 GV-BX520D-0 640 x 360 GV-BX520D-E 448 x 252...
  • Page 455 Max. Frame GV-IP Camera Stream Ratio Resolution Rate 704 x 480 NTSC 704 x 240 30 fps 352 x 240 Main 704 x 576 704 x 288 25 fps 352 x 288 GV-PTZ010D 704 x 480 NTSC 704 x 240 30 fps 352 x 240 704 x 576...

  • Page 456: Support Lists

    Appendix D. Support Lists • Support List for GV-Backup Center, GV-Video Gateway and GV- Recording Server GV-IP Camera Model Supported Version GV-BX110D V1.08 or later GV-BX120D GV-BX220D Series V1.03 or later Box Camera GV-BX320D Series GV-BX130D Series V1.04 or later GV-BX520D-0 V1.05 or later GV-BX120D-E...
  • Page 457 Supported Version GV-IP Camera Model GV-BL110D V1.08 or later GV-BL120D Bullet Camera V1.03 or later GV-BL220D GV-BL320D GV-BL130D V1.04 or later GV-PTZ010D PT and PTZ Camera V1.08 or later GV-PT110D GV-VD120D Series GV-VD220D Series Vandal Proof IP Dome V1.03 or later GV-VD320D Series GV-FD120D GV-FD220D...
  • Page 458 Appendix • Support List for Transmit Audio GV-IP Camera Model Supported Version GV-BX110D V1.08 or later GV-BX120D GV-BX220D Series V1.05 or later Box Camera GV-BX320D Series GV-BX130D Series V1.04 or later GV-BX520D-0 V1.05 or later GV-BX120D-E GV-BX220D-E IR Arctic Box Camera V1.07 or later GV-BX320D-E GV-BX520D-E...
  • Page 459 Supported Version GV-IP Camera Model GV-BL110D V1.08 or later GV-BL120D Bullet Camera GV-BL220D V1.05 or later GV-BL320D GV-BL130D V1.04 or later PTZ Camera GV-PTZ010D V1.08 or later PT Camera GV-PT110D V1.08 or later GV-VD120D Series Vandal Proof IP Dome GV-VD220D Series V1.05 or later GV-VD320D Series GV-FD120D...
  • Page 460 Appendix • Support List for System Log Supported Version GV-IP Camera Model GV-BX110D V1.08 or later GV-BX120D GV-BX220D Series Box Camera GV-BX320D Series V1.11 or later GV-BX130D Series GV-BX520D-0 GV-BX120D-E GV-BX220D-E V1.11 or later IR Arctic Box Camera GV-BX320D-E GV-BX520D-E GV-MFD110 V1.08 or later GV-MFD130...
  • Page 461 Supported Version GV-IP Camera Model GV-PTZ010D PT and PTZ Camera V1.08 or later GV-PT110D GV-VD120D Series Vandal Proof IP Dome GV-VD220D Series V1.11 or later GV-VD320D Series GV-FD120D GV-FD220D Fixed IP Dome V1.11 or later GV-FD320D GV-CB120 Cube Camera V1.11 or later GV-CB220 GV-CBW120 Wireless Cube...

  • Page 462: Rtsp Protocol Command

    Appendix E. RTSP Protocol Command The GV-IPCAM H.264 can support RTSP protocol for both audio and video streaming. If you use the QuickTime player, enter: rtsp://<IP of the GV-IPCAM H.264:8554/<CH No.>.sdp For example, rtsp://192.168.3.111:8554/CH001.sdp If you use the VLC, and if authentication is required, enter: rtsp://username:password@<IP of the GV-IPCAM H.264:8554/<CH No.>.sdp For example, rtsp://admin:admin@192.168.3.111:8554/CH001.sdp...

  • Page 463: The Cgi Command

    F. The CGI Command Please note the supported version of the CGI command in different models: GV-IP Camera Supported Version GV-BX110D V1.04 or later GV-MFD110 GV-BL110D GV-BX120D V1.0 or later GV-BX220D-0 / 220D-1 / 220D-2 / 223D-3 GV-BX320D-0 / 320D-1 GV-BL120D / 220D / 320D GV-VD120D / 121D / 122D / 123D V1.02 or later...
  • Page 464 Appendix You can use the CGI command to obtain a snapshot of the live view or access the User Account Web interface. For a GV-IPCAM H.264 with the following details: IP address: 192.168.2.11 Username: admin Password: admin Desired stream: 1 To obtain a snapshot of the live view, type the following into your web browser: http://192.168.2.11/PictureCatch.cgi?username=admin&password=admin&...

  • Page 465: Dual Stream Support List

    G. Dual Stream Support List The table lists the firmware versions of GV-IP Cameras that support dual stream and the default resolutions after the camera is added to GV-System. Resolution Supported GV-IP Camera Firmware Main Stream Sub Stream Version (H.264) (MPEG4) V1.00 to GV-BX110D...
  • Page 466 Appendix Resolution Supported Firmware GV-IP Camera Main Stream Sub Stream Version (H.264) (MPEG4) GV-BX130D Series V1.04 or later GV-MFD130 1280 x 1024 320 x 256 GV-BL130D GV-BX140DW V1.10 or later 1280 x 720 640 x 360 GV-BX220D Series V1.00 or later GV-MFD220 V1.05 or later GV-BX220D-E...
  • Page 467 Resolution Supported Firmware GV-IP Camera Main Stream Sub Stream Version (H.264) (MPEG4) GV-BX320D Series V1.00 or later GV-MFD320 V1.05 or later GV-BX320D-E V1.07 or later GV-MDR320 2048 x 1536 320 x 240 GV-BL320D GV-VD320D V1.02 or later GV-VD321D GV-VD322D GV-VD323D GV-FD320D V1.03 or later GV-BX520D-0...

  • Page 468: Power Supply Support List

    Appendix H. Power Supply Support List The supported power type is indicated with a tick ( ) and the unsupported power type with a cross ( ). GV-IP Camera DC Power AC Power Box Camera IR Arctic Box Camera GV-MFD110 GV-MFD120 Mini Fixed Dome GV-MFD130...

  • Page 469: Supported Firmware For Flash Memory

    I. Supported Firmware for Flash Memory The 128 MB flash memory is supported in V1.09 or later in all models of GV-IPCam H.264 Series except GV-BX110D, GV-MFD110, GV-BL110D, GV-PTZ010D, GV-PT110D, To look up if the camera contains a 128 MB type flash memory, access the web interface or the GV IP Device Utility: Web Interface Click Management and click Tools.

This manual is also suitable for:

Gv-bx120dGv-bx140dwGv-bx130d-1Gv-bx110dGv-bx220d-0Gv-bx220d-1 ... Show all

Table of Contents
