  • Page 1 GV-IP Camera User's Manual GV-EBD Series GV-ABL / TBL Series GV-ADR / TDR Series GV-AVD / TVD Series Before attempting to connect or operate this product, UBN-UM-S please read these instructions carefully and save this manual for future use.
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
  • Page 3 Preface Welcome to the GV-EBD Series IR Eyeball IP Dome, GV-ABL Series Bullet IP Camera, GV-ADR / TDR Series Mini Fixed Rugged IP Dome and GV-AVD Series Vandal Proof IP Camera User’s Manual. The features described in the manual vary among camera models and versions. Some features may not be available in your camera.

  • Page 4: Table Of Contents

    Note for Powering the Camera ..........vii Note for Face Detection ............viii Note for People Counting ............ix Chapter 1 Introduction ............1 1.1 GV-EBD Series...................... 1 1.1.1 Packing List....................2 1.1.2 Optional Accessories ................. 2 1.1.3 Overview....................4 1.1.3.1 GV-EBD2702 / 4700 / 4701 / 8700 / 8800 ..........4 1.1.3.2 GV-EBD4711 / 4712 / 8711 / 8813............
  • Page 5 1.2.5.3 GV-Mount420 + GV-Mount503 ............39 1.2.5.4 GV-Mount504 ................41 1.3 GV-ADR / TDR Series ..................43 1.3.1 Packing List....................45 1.3.2 Optional Accessories ................45 1.3.3 Overview....................47 1.3.4 Installation....................48 1.3.5 Optional Installation ...................51 1.3.5.1 GV-Mount211P ..................51 1.4 GV-AVD / TVD Series...................55 1.4.1 Packing List....................56 1.4.1.1 GV-TVD4711................56 1.4.1.2 GV-AVD / TVD Series..............57 1.4.2 Optional Accessories ................58...
  • Page 6 Chapter 3 Administrator Mode ...........86 3.1 Common .......................85 3.1.1 Basic Info ....................85 3.1.2 Local Parameters..................86 3.2 Network ........................88 3.2.1 Network.....................88 3.2.2 DNS ......................89 3.2.3 Port ......................90 3.2.4 DDNS......................91 3.2.5 E-mail......................93 3.2.6 SNMP .......................94 3.2.7 802.1x .......................95 3.2.8 QoS ......................96 3.3 Video & Audio .......................97 3.3.1 Video......................97 3.3.2 Snapshot....................99 3.3.3 Audio.......................100...
  • Page 7 3.6.1 Motion Detection ..................128 3.6.2 Tampering Alarm ..................130 3.6.3 Audio Detection..................131 3.6.4 Alarm Input....................132 3.6.5 Alarm Output...................133 3.7 Formatting Storage .....................134 3.7.1 Storage ....................134 3.7.2 FTP......................136 3.7.3 Backing Up Storage ................137 3.8 Security.......................138 3.8.1 User ......................138 3.8.2 Network Security..................139 3.9 System........................142 3.9.1 Time......................142 3.9.2 Maintenance ...................144 Chapter 4 Advanced Applications ........145...

  • Page 8: Naming Definition

    Naming Definition GV-DVR / NVR GeoVision Analog and Digital Video Recording Software. The GV- DVR also refers to GV-Multicam System or GV-Hybrid DVR. GV-VMS GeoVision Video Management System for IP cameras.

  • Page 9: Note For Connecting To Gv-Vms / Dvr / Nvr

    Note for Connecting to GV-VMS / DVR / NVR The GV-IPCAM in this Manual is designed to work with and record on GV-VMS / DVR / NVR, a video management system.  Once the camera is connected to the GV-VMS / DVR / NVR, the resolution set on the GV-VMS / DVR / NVR will override the resolution set on the camera’s Web interface.

  • Page 10: Note For Face Detection

    Note for Face Detection To use the camera’s built-in face detection feature (see 3.5.1.7 Face Detection), not supported by GV-ABL2701 series / 2703 series / 4701 series / 4703 / 4711, GV-ADR2701 / 2702 / 4701 / 4702, GV-EBD4701 / 4712 / 8800 / 8813, GV-TBL series, GV-TDR2702 series / 4702 series / 4703 series, and GV-TVD series, it is recommended to install the camera according to the criteria listed below: Surveillance Condition...

  • Page 11: Note For People Counting

    Note for People Counting To use the camera’s built-in people counting feature (see 3.5.1.8 People Counting), not supported by GV-ABL2701 series / 2703 series / 4701 series / 4703 / 4711, GV-ADR2701 / 2702 / 4701 / 4702, GV-EBD4701 / 4712 / 8800 / 8813, GV-TBL series, GV-TDR2702 series / 4702 series / 4703 series, and GV-TVD series, it is recommended to install the camera according to the criteria listed below: Surveillance Condition...

  • Page 12: Chapter 1 Introduction

    Introduction Chapter 1 Introduction 1.1 GV-EBD Series The H.265 Target Eyeball Dome is an outdoor, network camera equipped with an automatic IR-cut filter and IR LEDs for day and night surveillance. The camera adheres to IP67 standards for dust / water protection and supports H.265 video codec to achieve better compression ratio while maintaining high quality image at reduced network bandwidths.

  • Page 13: Packing List

    1.1.1 Packing List  H.265 Target Eyeball Dome   Screw Kit Drill Template Paster   Waterproof Rubber Set Download Guide  Warranty Card 1.1.2 Optional Accessories Optional accessories can expand the capabilities and versatility of your camera. Contact your dealer for more information.
  • Page 14 Introduction Dimensions: 137 x 233 x 160 mm GV-Mount300-2 Convex Corner Mount (5.4” x 9.17” x 6.3”) Weight: 1.65 kg (3.64 lb) GV-Mount310-2 Concave Corner Mount Dimensions: 111.2 x 369.9 x 210 mm (2.6” x 11.4” x 6.6”) Weight: 1.65 kg (3.64 lb) GV-Mount420 Pole Mount Bracket Dimensions: Ø...

  • Page 15: Overview

    1.1.3 Overview 1.1.3.1 GV-EBD2702 / 4700 / 4701 / 8700 / 8800 Figure 1-1 Description Bottom ring Housing Lens Infrared indicator Power connector (DC 12 V) Ethernet connector / PoE Micro SD card slot (GV-EBD4701 / 8800 only) Microphone (GV-EBD4701 / 8800 only)

  • Page 16: Gv-Ebd4711 / 4712 / 8711 / 8813

    Introduction 1.1.3.2 GV-EBD4711 / 4712 / 8711 / 8813 Figure 1-2 Description Bottom ring Housing Microphone Lens Power connector (DC 12 V) Ethernet connector / PoE Micro SD card slot and default button compartment Default button Micro SD card slot Note: If the default button doesn’t respond after pressing for 15 seconds, reboot the camera and try again within 10 minutes of rebooting.

  • Page 17: Installation

    1.1.4 Installation The Target Eyeball Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Alternatively, you can purchase optional mounting accessories to mount the dome on a wall. Below are the instructions for Ceiling Mount. There are two kinds of Ceiling Mount: Concealed Installation and Open Installation.
  • Page 18 Introduction 3. Remove the bottom ring by turning it anticlockwise. Figure 1-5 4. Connect the cables and secure the camera. Figure 1-6 5. Adjust the monitoring direction. Figure 1-7...
  • Page 19 6. Mount the bottom ring. Figure 1-8 For Open Installation Lead the cables out from the open slot on the bottom ring before screwing the camera to the ceiling as shown in Figure 1-6.   Figure 1-9...

  • Page 20: Gv-Ebd4711 / 4712 / 8711 / 8813 Standard Installation

    Introduction 1.1.4.2 GV-EBD4711 / 4712 / 8711 / 8813 Standard Installation For Concealed Installation 1. Stick the drill template paster to the ceiling and drill three holes according to the drill template. Figure 1-10 2. Insert the screw anchors.   Figure 1-11 3.
  • Page 21 4. Secure the bottom ring to the ceiling with 3 supplied screws and connect the cable. Figure 1-13 5. Mount the housing by adjusting to the position as shown and press and turn to anywhere but . Figure 1-14 6. Adjust the monitoring direction. Then tighten the screw. Figure 1-15...
  • Page 22 Introduction WARNING: Make sure the housing is not dismounted from the bottom ring when adjusting the monitoring direction. Unintentional removal of the housing may result in circumstantial damages. For Open Installation Lead the cables out from the open slot on the bottom ring before mounting the housing as shown in Figure 1-14.

  • Page 23: Optional Installation

    1.1.5 Optional Installation You can optionally purchase the following accessories to fit your mounting environment: GV-Mount211P / GV-Mount212P for Wall Box Mount: see section 1.1.5.1 and 1.1.5.2.  GV-Mount420 + GV-Mount211P for Pole Box Mount: see section 1.1.5.3.  GV-Mount212P + GV-Mount107 for Pendant Tube Mount: see section 1.1.5.4. ...
  • Page 24 Introduction Unscrew the bracket. Figure 1-18 Loosen the indicated area by turning it anticlockwise. Figure 1-19 Stick the drill template paster to the wall with the arrow pointing up. Drill 4 holes according to the sticker and insert the 4 screw anchors to the 4 holes. Secure the power box to the wall with 4 long screws Figure 1-20...
  • Page 25 Remove the bottom ring by turning it anticlockwise. Figure 1-21 Secure the camera to the wall mount bracket with the provided short screws according to the screw position for each model: GV-EBD4700 / 4701 / 4711 / 4712 / 8700 / 8711 / 8800 / 8813 Figure 1-22...
  • Page 26 Introduction GV-EBD2702 Figure 1-23 GV-ADR2701 / 4701 Figure 1-24 GV-ADR2702 / ADR4702 / TDR2700 / TDR2702 / TDR4700 / TDR4702 / TDR4703 Figure 1-25...
  • Page 27 Thread the Ethernet cable through the PG21 conduit connector and the power box as shown in No. 8, Figure 1-26. Then connect the cable to the camera. To waterproof the cable, see 1.6 Waterproofing the Cable. Rotate the plastic ring to secure the conduit connector to the power box. Screw in the cap as shown in No.

  • Page 28: Gv-Mount212P

    Introduction 1.1.5.2 GV-Mount212P GV-Mount212P Figure 1-28 GV-Mount212P Packing List   GV-Mount212P Long Screw x 3   Short Screw x 3 Screw Anchor x 3...
  • Page 29 Standard Installation Attach the wall box to the wall and use a marker to mark the location for the center socket and the screws. Make sure the knob points down. Long Screw This knob points down Figure 1-29 Drill 3 holes according to the screw location. Then, drill a bigger hole at the center socket location for the Ethernet cable.
  • Page 30 Introduction Thread the Ethernet cable through the center socket and waterproof the Ethernet cable. For details, see 1.6 Waterproofing the Cable. Figure 1-31 Fit the cable into the wall box. Secure the camera by locking the provided short screws to the screw position for each model: GV-EBD2702 Figure 1-32...
  • Page 31 Note: In addition to the Standard Installation, you can also choose to run the Ethernet cable through a corrugated tube. To do this, you will have to purchase your own conduit connector and corrugated tube. 3/4” NPS is the recommended type of connector. After you secure the wall box to the desired location, remove the knob at the bottom and connect the conduit connector with a self-prepared corrugated tube to the wall box.

  • Page 32: Gv-Mount420 + Gv-Mount211P

    Introduction 1.1.5.3 GV-Mount420 + GV-Mount211P Figure 1-35 GV-Mount420 Packing List   GV-Mount420 M4 Screw x 4  Additional Screw Kit M6 Screw x 4 M6 Nut x 4 M6 Plain Washer x 4 M6 Split Washer x 4 Note: For GV-ADR / TDR / EBD Series, GV-Mount420 can only be used in conjunction with GV-Mount211P.
  • Page 33 1. Unscrew the bracket. Figure 1-36 2. Loosen the indicated area by turning it anticlockwise. Figure 1-37 3. Align and attach the power box to the back plate using the 4 supplied M4 screws as indicated. Figure 1-38 Note: Make sure the direction of the “up ↑” indicator on the back plate match that of the power box.
  • Page 34 Introduction 4. Thread the 3 steel straps onto the back plate. Figure 1-39 5. Follow Step 6 ~ 12 in 1.1.5.1 GV-Mount211P. 6. Secure the camera onto the desired pole by tightening the steel straps.

  • Page 35: Gv-Mount212P + Gv-Mount107

    Torx Wrench Note: Before installing GV-Mount107, note the following.  Install your GV-EBD Series camera on a GV-Mount212P by cutting a hole in the center of the mount and thread the camera wires through.  Prepare 3 long screws for securing the Pendant Bracket to the ceiling.
  • Page 36 Introduction Place GV-Mount107 on the ceiling and mark the location for the center socket and the 3 screws. Drill the marks and secure the Pendant Bracket onto the ceiling. Figure 1-41 Attach one end of the Pendant Tube to the Pendant Bracket, and the other end to the Tube Connector.

  • Page 37: Gv-Abl / Tbl Series

    1.2 GV-ABL / TBL Series The Bullet IP Camera is an outdoor, fixed, network camera equipped with an automatic IR- cut filter and an IR LED for day and night surveillance. The camera supports H.265 video codec to achieve better compression ratio while maintaining high quality image at reduced network bandwidths.

  • Page 38: Packing List

    Introduction Motorized Fixed Iris, f: 2.8 ~ 12 mm, 8 MP, H.265, Super GV-TBL8810 varifocal lens F/1.6, Ø14 mm Lens Mount Low Lux, WDR Pro 1.2.1 Packing List   Bullet IP Camera Drill Template Paster   Screw Kit Waterproof Rubber Set ...
  • Page 39 Dimensions: 111.2 x 369.9 x GV-Mount310-2 Concave Corner Mount 210 mm (2.6” x 11.4” x 6.6”) Weight: 1.65 kg (3.64 lb) GV-Mount420 (must be Pole Mount Bracket Dimensions: Ø 120 x 120 x used with GV-Mount503) 53.4 mm (Ø 4.7” x 4.7” x 2.1”) Weight: 0.45 kg (0.99 lb) Steel Strap Diameter: Ø...

  • Page 40: Overview

    Introduction 1.2.3 Overview 1.2.3.1 GV-ABL2701 / 2703 / 4701 / 4703 & TBL2703 / 4703 / 8804 Figure 1-43 No. Description No. Description Power connector (DC 12 V) Ethernet connector / PoE Load Default Button (for GV-ABL2703 / 4703 & TBL2703 / 4703 / 8804 only) Figure 1-44 No.

  • Page 41: Gv-Abl2702 / 4711 / 4712 / 8712 & Tbl4700 / 4710 / 4711 / 8710 / 8810

    Note: 1. For safety precautions, it is recommended to connect a grounding wire to the grounding screw, and do not loosen or remove the grounding screw under any circumstances. 2. If the default button doesn’t respond after pressing for 15 seconds, reboot the camera and try again within 10 minutes of rebooting.

  • Page 42: Installation

    Introduction 1.2.4 Installation The Bullet IP Camera is designed for outdoors. With the standard package, you can install the camera on the wall or ceiling. Or, you can purchase optional mounting accessories to mount your camera on a wall. Below are the instructions for Wall Mount. There are two kinds of Wall Mount: Concealed Installation and Open Installation.
  • Page 43 Drill the holes according to the drill template. GV-ABL2702 / 4711 / 4712 / 8712 GV-TBL8804 TBL4700 / 4710 / 4711 / 8710 / 8810 Figure 1-48 Insert the screw anchors. GV-ABL2702 / 4711 / 4712 / 8712 GV-TBL8804 TBL4700 / 4710 / 4711 / 8710 / 8810 Figure 1-49 Screw the locknut and loosen the universal joint before attaching the camera to the wall.
  • Page 44 Introduction Secure the camera to the wall and connect all cables. Figure 1-51 To adjust the monitoring direction: GV-ABL2702 / 4711 / 4712 / 8712 & TBL4700 / 4710 / 4711 / 8710 / 8804 / 8810 Figure 1-52-1 GV-TBL8804 Figure 1-52-2 For Open Installation Lead the cables out from the open slot on the base before screwing the camera to the wall...

  • Page 45: Optional Installation

    1.2.5 Optional Installation For GV-ABL2701 Series / 2703 Series / 4701 Series / 4703 & TBL2703 Series / 4703, you can optionally purchase the following accessories to fit your mounting environment: GV-Mount502 for Wall Box Mount: see section 1.2.5.1.  For GV-ABL2702 / 4711 / 4712 / 8712 &...

  • Page 46: Gv-Mount502

    Introduction 1.2.5.1 GV-Mount502 GV-Mount502 Packing List   GV-Mount502 M3 25 mm Screw x 4   M3 12 mm Screw x 4 Screw Anchor x 4  Plastic PG21 Conduit Connector 1. Unscrew the box cover. Figure 1-56...
  • Page 47 2. Loosen the knob by turning it anticlockwise. Figure 1-57 3. Attach the box to the wall with the knob pointing down and use a marker to mark 4 dots. 4. Drill 4 holes according to the marks. 5. Insert the 4 screw anchors to the holes and secure the box to the wall with 4 long screws. 6.

  • Page 48: Gv-Mount503

    Introduction 1.2.5.2 GV-Mount503 GV-Mount503 Packing List   GV-Mount503 Long Screw x 4   Short Screw x 4 Screw Anchor x 4  Waterproof Rubber Plug Plastic PG21 Conduit Connector  1. 1. Unscrew the box cover. Figure 1-59...
  • Page 49 2. Loosen the knobs by turning it anticlockwise. Figure 1-60 3. Attach the box to the wall with the knobs pointing down and use a marker to mark 4 dots. 4. Drill 4 holes according to the marks. 5. Insert 4 screw anchors to the holes and secure the to the wall with 4 long screws. 6.

  • Page 50: Gv-Mount420 + Gv-Mount503

    Introduction Note: Alternatively, you can use the supplied waterproof rubber plug to seal the box cover by following the steps below. Thread the camera cable through the box cover, and then through the supplied waterproof rubber plug from the bottom side. Figure 1-62 Align the gap of the waterproof rubber plug to the direction of the “up ↑”...
  • Page 51 Note: For GV-ABL2702 / 4711 / 4712 / 8712 and GV-TBL4700 / 4710 / 4711 / 8710 / 8810, GV-Mount420 can only be used in conjunction with GV-Mount503. 1. Follow Step 1 & 2 in 1.2.5.2 GV-Mount503. 2. Align and attach the power box to the back plate using the 4 supplied M4 screws as indicated.

  • Page 52: Gv-Mount504

    Introduction 1.2.5.4 GV-Mount504 GV-Mount504 Packing List   GV-Mount504 Long Screw x 4   Short Screw x 3 Screw Anchor x 4   Drill Template Paster Waterproof Rubber Plug  Plastic PG21 Conduit Connector 1. Unscrew the box cover. 2.
  • Page 53 5. Position the power box on the wall with the “up ↑” indicator pointing up and align the screw holes indicated below to the 4 mounting holes on the wall. 6. Secure the wall box to the wall with the supplied long screws. 7.

  • Page 54: Gv-Adr / Tdr Series

    Introduction 1.3 GV-ADR / TDR Series The IR Mini Fixed Rugged IP Dome is an outdoor, fixed, network camera equipped with an automatic IR-cut filter and an IR LED for day and night surveillance. The camera supports H.265 video codec to achieve better compression ratio while maintaining high quality image at reduced network bandwidths.
  • Page 55 Fixed Iris, f: 4 mm, 2 MP, H.265, Low GV-TDR2702-1F Lux, WDR F/2.0, M12 Lens Mount Fixed Iris, f: 2.8 mm, GV-TDR4700-0F F/2.0, M12 Lens Mount 4 MP, H.265, Super Low Lux, WDR Pro Fixed Iris, f: 3.6 mm, GV-TDR4700-1F F/2.0, M12 Lens Mount Fixed Iris, f: 2.8 mm, GV-TDR4702-0F...

  • Page 56: Packing List

    Introduction 1.3.1 Packing List  IR Mini Fixed Rugged IP Dome  Waterproof Rubber Set   Screw Kit Drill Template Paster  Download Guide  Warranty Card 1.3.2 Optional Accessories Optional accessories can expand the capabilities and versatility of your camera. Contact your dealer for more information.
  • Page 57 GV-Mount300-2 Dimensions: 137 x 233 x 160 mm Convex Corner Mount (must be used with (5.4” x 9.17” x 6.3”) GV-Mount211P or Weight: 1.65 kg (3.64 lb) GV-Mount213 for GV-ADR2701 / 4701) GV-Mount310-2 Concave Corner Mount Dimensions: 111.2 x 369.9 x 210 (must be used with mm (2.6”...

  • Page 58: Overview

    Introduction 1.3.3 Overview Figure 1-65 Description Ethernet connector / PoE Power connector (DC 12 V) Transparent Dome Cover For GV-TDR2700 / 4700 / 4703 series only, see the table below. Wire Definition GV-TDR4703 series GV-TDR2700 series / 4700 series Wire Definition Wire Definition...

  • Page 59: Installation

    1.3.4 Installation The IR Mini Fixed Rugged IP Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Below are the instructions for Ceiling Mount. There are two kinds of Ceiling Mount: Concealed Installation and Open Installation. In Concealed Installation, the cables are hidden in the ceiling.
  • Page 60 Introduction Unscrew the transparent dome cover with the supplied torx wrench. Connect the cables and secure the camera. Figure 1-68 Adjust the monitoring direction and tighten the screws after vertically adjusting the lens. Figure 1-69...
  • Page 61 Secure the transparent dome cover with the supplied torx wrench. Figure 1-70 Note: Before securing the transparent dome cover, make sure the waterproof rubber strip is tightly held by the six retainers on the bottom ring. Figure 1-71 For Open Installation Lead the cables out from the open slot on the camera base before screwing the camera to the ceiling as shown in Figure 1-68.

  • Page 62: Optional Installation

    Introduction 1.3.5 Optional Installation You can optionally purchase the following accessories to fit your mounting environment: GV-Mount211P for Wall Mount: see section 1.1.5.1.  GV-Mount213 for Wall / Ceiling Box Mount: see section 1.3.5.1  GV-Mount420 + GV-Mount211P for Pole Box Mount: see section 1.1.5.3. ...
  • Page 63 1. Attach the GV-Mount213 to the wall / ceiling and use a marker to mark the location for the center socket and the 3 screws. Figure 1-73 Note: To prevent rain from getting into GV-ADR2701 / 2702 / 4701 / 4702 & TDR2702 / 4702 / 4703, ...
  • Page 64 Introduction 3. Insert 3 screw anchors to the screw locations and secure the GV-Mount213 to the wall / ceiling with 3 long screws. 4. Thread the Ethernet cable through the center socket and waterproof the Ethernet cable. For details, see 1.6 Waterproofing the Cable. Figure 1-75 5.
  • Page 65 GV-ADR2702 / ADR4702 / TDR2700 / TDR2702 / TDR4700 / TDR4702 / TDR4703 Figure 1-77 7. Secure the camera cover. Note: In addition to the Standard Installation, you can also choose to run the Ethernet cable through a corrugated tube. To do this, see Figure 1-34 and its related Note.

  • Page 66: Gv-Avd / Tvd Series

    Introduction 1.4 GV-AVD / TVD Series The Vandal Proof IP Dome is an outdoor camera designed with IK10 vandal resistance and IP67 ingress protection. The camera is equipped with an automatic IR-cut filter and IR LEDs for day and night surveillance. Adjustable in 3 axes (pan, tilt and rotate), it offers an entry- level surveillance solution with all the essential features and excellent image quality.

  • Page 67: Packing List

    1.4.1 Packing List 1.4.1.1 GV-TVD4711  IR Vandal Proof IP Dome  Screw Kit   Drill Template Paster Torx Wrench   Spare Waterproof Rubber Plug Cable Protection Connector   2-Pin Power Terminal Block Warranty Card  Download Guide...

  • Page 68: Gv-Avd / Tvd Series

    Introduction 1.4.1.2 GV-AVD / TVD Series   IR Vandal Proof IP Dome Waterproof Rubber Set   Screw Kit Drill Template Paster   Torx Wrench Warranty Card  Download Guide...

  • Page 69: Optional Accessories

    1.4.2 Optional Accessories Optional accessories can expand the capabilities and versatility of your camera. Contact your dealer for more information. Model Number Name Details GV-Mount107 Dimensions: Ø 120 x 334 mm (Ø Pendant Bracket (must be used with 4.72” x 13.15”) GV-Mount212P / Weight: 0.74 kg (1.63 lb) GV-Mount212-2)
  • Page 70 Introduction GV-Mount704 Extension Tube Dimensions: Ø 3.5 x 10 or 20 or 30 (must be used with or 50 cm (Ø 1.38 x 3.9 or 7.9 or GV-Mount107) 11.8 or 19.7”) Weight: 225g or 360g or 500g or 780g (0.5 lb or 0.79 lb or 1.1 lb or 1.72 lb) Power over Ethernet (PoE) GV-PA191 is a Power over...

  • Page 71: Overview

    1.4.3 Overview 1.4.3.1 GV-AVD2700 / 4710 / 8710, GV-TVD4700 / 4710 / 8710 / 8810 Figure 1-78 No. Description No. Description Power connector (DC 12 V) Default button Ethernet connector / PoE Micro SD card slot Video output Default button (For GV-TVD8810) (Not applicable to GV-TVD8810) Audio input / Audio output / GND (Not Micro SD card slot (For GV-TVD8810)
  • Page 72 Introduction 1.4.3.2 GV-TVD4711 Figure 1-79 No. Description No. Description Ethernet port Power port (2-Pin terminal block) Digital Input Micro SD card slot Default button Audio In Digital Output (N) Digital Output (P) Audio Out Note: There are two ways to supply power to the camera: Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and ...

  • Page 73: Installation

    1.4.4 Installation The Target Vandal Proof Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Alternatively, you can purchase optional mounting accessories to mount the camera on a wall. Below are the instructions for Ceiling Mount. There are two kinds of Ceiling Mount: Concealed Installation and Open Installation.
  • Page 74 Introduction 4. Connect the camera cables and secure the camera. Figure 1-83 5. Insert a SD card into the slot. 6. Adjust the monitoring direction and tighten the screws after vertically adjusting the lens. Figure 1-84 7. Secure the transparent dom e cover with the supplied torx wrench.
  • Page 75 1.4.4.2 GV-TVD4711 Follow steps 1 to 3 in 1.4.4.1 GV-AVD2700 / 4710 / 8710, GV-TVD4700 / 4710 / 8710 / 8810. To install an Ethernet / PoE cable: Remove the large waterproof rubber plug from the base of the camera. Cut a small opening on the tip of the large waterproof rubber plug.
  • Page 76 Introduction 10. Connect the 2-pin terminal block and I/O wires to the camera. Tip: When connecting the I/O wires to the camera, thread the I/O wires through the protruded loop. Figure 1-86 To finish the installation: 11. Secure the camera and insert a micro SD card to the slot. 12.

  • Page 77: Optional Installation

    1.4.5 Optional Installation You can optionally purchase the following accessories to fit your mounting environment: GV-Mount211P / GV-Mount212P for Wall Box Mount: see section 1.1.5.1 and 1.1.5.2.  GV-Mount420 + GV-Mount211P for Pole Box Mount: see section 1.1.5.3.  GV-Mount212P / GV-Mount212-2 + GV-Mount107 for Pendant Tube Mount: see ...

  • Page 78: Gv-Mount211-2

    Introduction 1.4.5.1 GV-Mount211-2 Figure 1-87 GV-Mount211-2 Packing List   GV-Mount211-2 Long Screw x 5   Short Screw x 4 Screw Anchor x 5   Plastic PG21 Conduit Connector Drill Template Paster...
  • Page 79 1. To install the power box from the wall mount bracket on the wall, follow steps 1 to 5 in 1.1.5.1 GV-Mount211P. 2. Unscrew the transparent dome cover with the supplied torx wrench. Figure 1-88 3. Optionally insert a SD card into the slot. 4.

  • Page 80: Gv-Mount212-2

    Introduction 1.4.5.2 GV-Mount212-2 GV-Mount212-2 Figure 1-91 GV-Mount212-2 Packing List   GV-Mount212-2 Long Screw x 3   Short Screw x 3 Screw Anchor x 3...
  • Page 81 1. Attach the ceiling box to the ceiling and use a marker to mark the location for the center socket and the screws. Make sure the knob points inwards. Figure 1-92 2. Drill 3 holes according to the screw location. Then, drill a bigger hole at the center socket location for the Ethernet cable.
  • Page 82 Introduction 6. Secure the camera to the ceiling box. Figure 1-94 Note: In addition to the Standard Installation, you can also choose to run the Ethernet cable through a corrugated tube. To do this, see Figure 1-34 and its related Note.

  • Page 83: Gv-Mount420 + Gv-Mount211-2

    1.4.5.3 GV-Mount420 + GV-Mount211-2 Figure 1-95 GV-Mount420 Packing List   GV-Mount420 M4 Screw x 4  Additional Screw Kit M6 Screw x 4 M6 Nut x 4 M6 Plain Washer x 4 M6 Split Washer x 4 Note: For GV-AVD Series, GV-Mount420 can only be used in conjunction with GV- Mount211-2.

  • Page 84: Gv-Mount606

    Introduction 1.4.5.4 GV-Mount606 Figure 1-96 GV-Mount606 Packing List   In-Ceiling Mount Bracket In-Ceiling Cover   In-Ceiling Plate Drill Template Paster  Screw Kit : M4 Screw (8 mm) x 3 M4 Screw (40 mm) x 2...
  • Page 85 Paste the drill template to the ceiling and drill the ceiling to the size of the drill template. Place the In-Ceiling Plate behind the ceiling with the flat side facing down. Loosen the knob on the side of the camera and thread the camera wires through. Thread the camera wires through the side of the In-Ceiling Mount Bracket and place the camera in the Mount Bracket.

  • Page 86: System Requirements

    Introduction 1.5 System Requirements Intel Core i5-4670, 3.40 GHz Memory DDR3 8 GB RAM On Board Graphics Intel HD Graphics 4600 (Versions of driver from year 2014 or later required)  Web Browsers Internet Explorer 11.0 or above  Google Chrome ...

  • Page 87: Waterproofing The Cable

    1.6 Waterproofing the Cable Waterproof the Ethernet cable by using the supplied waterproof rubber set. 1. Attach the seal ring to the RJ-45 plug. Seal ring Figure 1-100 2. Insert the waterproof components through the Ethernet cable as shown below. 2      Insert in order Figure 1-101 3.
  • Page 88 Introduction 4. Insert the cable into the RJ-45 plug and screw the waterproof bolt in. Figure 1-103 5. Screw in the waterproof bolt lid. Bolt lid Figure 1-104 6. Finish the waterproof installation. Figure 1-105 IMPORTANT: After installing the camera, it is required to use waterproof tapes to cover and protect any of the tail cables and connection points that are exposed, see Note for Installing Camera Outdoor at the beginning of the manual.

  • Page 89: Chapter 2 Accessing The Camera

    Chapter 2 Accessing the Camera Once installed, the IP camera is accessible on a network. Follow these steps to configure the network settings and access your surveillance images. 2.1 Installing on a Network These instructions describe the basic connections to install the camera on the network. 1.

  • Page 90: Looking Up The Dynamic Ip Address And Logging In

    Accessing the Camera 2.1.1 Looking Up the Dynamic IP Address and Logging In By default, when the device is connected to LAN with a DHCP server, it is automatically assigned with a dynamic IP address. Follow the steps below to look up its IP address and log in the Web interface.

  • Page 91: Configuring The Ip Address

    By default, when the device is connected to LAN without a DHCP server, it is assigned with a static IP address of 192.168.0.10. Follow the steps below to assign a new IP address to avoid IP conflict with other GeoVision devices. Open your Web browser and type the default IP address 192.168.0.10.

  • Page 92: Accessing Live View

    Accessing the Camera 2.2 Accessing Live View After logging into the camera, you will see the Home page as shown below: 10 11 12 13 14 15 Figure 2-4 No. Name Function Set the display ratio of the image.  Scale: display images by 16:9.
  • Page 93 Play/Stop Play or stop live video. Only for the audio-supporting models, adjust the audio output Video Volume volume on the PC. Only for audio-supporting models, enable or disable Microphone microphone. Only for audio-supporting models, adjust the microphone Microphone volume on the PC during audio communication between the PC Volume and the camera.

  • Page 94: Digital Zoom

    Accessing the Camera 2.2.1 Digital Zoom To use the digital zoom function, follow these steps: 1. Click (No. 13, Figure 2-4) on the toolbar. 2. Click and drag the mouse button in any direction to specify an area. 3. To restore the original image size, right click on the enlarged area. 4.

  • Page 95: Playing Back Recorded Videos

    2.3 Playing Back Recorded Videos Note this function is only applicable to models with SD card slot for local storage. To play back recorded videos from the camera’s local storage, click Playback at the top of the Web interface. Figure 2-6 No.

  • Page 96: Recording Download

    Accessing the Camera Note: To store and play back recorded videos to and from the camera’s local storage, make sure to configure the storage settings in Storage. For details, refer to 3.7.1 Formatting Storage. 2.3.1 Recording Download To download recorded videos from the local storage, follow the steps below: 1.

  • Page 97: Chapter 3 Administrator Mode

    Chapter 3 Administrator Mode The Administrator can access and configure the GV-IP Camera through the network. Click Setup at the top of the Web interface to access the following configuration tabs: Common, Network, Video & Audio, Image, Intelligent, Events, Storage, Security and System. Figure 3-1...
  • Page 99 List of Options See the table below for the settings available on the Web interface. Find the topic of interest by referring to the section number prefixed to each option. IMPORTANT: The available options may vary among camera models and firmware versions. 3.1.1 Basic Info 3.1 Common 3.1.2 Local Parameters...

  • Page 100: Common

    Administrator Mode 3.1 Common Under the Common tab, the Administrator can find the general settings of the camera, as well as shortcuts to the following setting pages.  Network: See 3.2.1 Network for details.  Time: See 3.9.1 Time for details. ...

  • Page 101: Local Parameters

    3.1.2 Local Parameters You can set the local parameters for your PC. Figure 3-3 [Intelligent Mark]  Untriggered Target: Displays the detection lines / areas defined by Smart Settings on Live View. You must set up Smart Settings first for this function to work, see 3.5.1 Smart Settings.
  • Page 102 Administrator Mode [Video]  Processing Mode  Real-Time Priority: Select this if the network is in good condition.  Fluency Priority: Select this if you want short time lag for live video.  Ultra-low Latency: Select this if you want the minimum time lag for live video. ...

  • Page 103: Network

    3.2 Network The network section allows you to configure the network settings, modify ports, configure FTP server, and set up e-mail for notification. 3.2.1 Network Figure 3-4  Obtain IP Address: Select Static IP or DHCP according to your network environment. ...

  • Page 104: Dns

    Administrator Mode  PPPoE: The network environment is xDSL connection. Type the Username and Password provided by ISP to establish the connection. If you use the xDSL connection with dynamic IP addresses, first use the DDNS function to obtain a domain name linking to the camera’s changing IP address.

  • Page 105: Port

    3.2.3 Port Port You can modify the default HTTP, HTTPS and RTSP ports if necessary. Figure 3-6 Port Mapping This function can automatically forward and open certain ports on your router, allowing connection to your camera from the Internet. 1. Enable Port Mapping, and select UPnP or Manual for Mapping Type. ...

  • Page 106: Ddns

    1. Click On to enable DDNS Service. 2. Select the DDNS service provider you have registered with. If you chose DynDNS, skip to Step 5. 3. Copy the website address http://ns.gvdip.com/register.aspx to a browser to access Geovision DDNS service. Figure 3-9...
  • Page 107 4. In the Geovision DDNS Server page, type a desired Hostname and Password. Re-type Password and type the verification letters shown in the image. Click Send. 5. In the Web interface of your camera, type Username. The username is the hostname registered in DDNS Server.

  • Page 108: E-Mail

    Administrator Mode 3.2.5 E-mail After the configuration of E-mail, you will be able to send messages to the specified E-mail addresses when alarms are triggered. 1. Type the Name and Address of the sender. 2. Type the SMTP Server. 3. Type the SMTP Port number. 4.

  • Page 109: Snmp

    3.2.6 SNMP Users can transfer the configurations of the device through SNMP protocol to communicate with and/or integrate it into a central server. Note this function is not supported by GV- ABL2701 series / 2703 series / 4703 / 4711, GV-ADR2701 / 2702 / 4702, GV-EBD4701 / 4712, GV-TBL2703 series / 4700 / 4703 / 4711, GV-TDR2702 / 4702 / 4703 series, and GV-TVD4700 / 4711.
  • Page 110 Administrator Mode 3.2.7 802.1x IEEE 802.1x is an IEEE standard for port-based Network Access Control. It provides an authentication mechanism to devices wishing to attach to a LAN or WLAN. Note this function is only applicable to GV-EBD2702 / 4700 / 4711 / 8700 / 8711 / 8800 / 8813, GV-ABL2702 / 4712 / 8712, GV-AVD2700 / 4710 / 8710, GV-TBL4710 / 8710 / 8804 / 8810, GV-TDR2700 / 4700 and GV-TVD4710 / 8710 / 8810.

  • Page 111: Qos

    3.2.8 QoS QoS is the prioritization of network traffic used to ensure resource reservation under abundant data flow. Note this function is not supported by GV-ABL2701 series, GV- ADR2701, GV-EBD4701 / 4712, and GV-TDR4703 series. Figure 3-13  Audio & Video: Optionally modify the priority of value of Audio & Video. The higher the value, the higher the priority.

  • Page 112: Video & Audio

    Administrator Mode 3.3 Video & Audio This section allows you to configure the three video streams and audio input. The audio function is only applicable to GV-EBD2702 / 4701 / 4711 / 4712 / 8711 / 8800 / 8813, GV- ABL2702 / 4711 / 4712 / 8712, GV-AVD2700 / 4710 / 8710, GV-TBL4710 / 4711 / 8710 / 8804 / 8810, GV-TDR4703 series, and GV-TVD4710 / 4711 / 8810.
  • Page 113 The following options are available for the main, sub and third streams.  Video Compression: Set the codec type to H.265, H.264 or MJPEG.  Resolution: Select different resolutions for each stream. Note: Changing the resolution in this option will not affect the Capture Mode. For GV-ABL4711, GV-EBD4701 / 4712, GV-TBL4700 / 4711, GV-TDR4703 series, and GV-TVD4700 / 4711, the resolution of the main stream cannot be modified.

  • Page 114: Snapshot

    Administrator Mode 3.3.2 Snapshot Using the Snapshot function, when an alarm is triggered, the camera will automatically upload the captured snapshots to the FTP server and/or send snapshots to the specified e- mail addresses. Note: If Upload Images is selected in Figure 3-49, 3.7.2 FTP, the captured snapshots will only be sent to the FTP server.

  • Page 115: Audio

    3.3.3 Audio Note this function is only applicable to audio-supporting models. You can configure the audio settings of the camera. Figure 3-16  Audio Input: Select On to enable audio input.  Input Gain: Set the audio signal amplification for sampling. The greater the gain, the greater amplification.

  • Page 116: Roi

    Administrator Mode 3.3.4 ROI When Region of Interest (ROI) is enabled, the system ensures image quality for ROI first if the bit rate is insufficient. Figure 3-17 Click to enable and add ROI. Click and drag on the image to specify an area. To add additional ROI areas, repeat steps 1 and 2.

  • Page 117: Media Stream

    3.3.5 Media Stream Media Stream By configuring media stream, you can set the camera to transmit code streams by UDP or TCP protocol to a specified IP address and port number. The settings can be saved and take effect after the camera is rebooted. Figure 3-18 1.
  • Page 118 Administrator Mode RTSP Multicast Address After an RTSP multicast address is configured, the third-party player can request for the RTSP multicast media stream from the camera through RTSP protocol. Figure 3-19 1. Type the Multicast Address (224.0.1.0 to 239.255.255.255) and Port number (0 to 65535).

  • Page 119: Image

    3.4 Image This section introduces the Image Settings, On-screen Display and Privacy Mask. 3.4.1 Image This page allows you to adjust image settings such as brightness, exposure, IR illumination and white balance. [Scene] Figure 3-20  Current: Indicates the scene that is being used. ...
  • Page 120 Administrator Mode [Image Enhancement] Figure 3-21  Brightness: Adjust the degree of brightness of the image.  Saturation: Adjust the amount of hue contained in a color.  Contrast: Set the degree of difference between the blackest pixel and the whitest pixel. ...
  • Page 121  Exposure Mode: Select the correct exposure mode to achieve the desired exposure effect. The default setting is Outdoor.  Low Motion Blur: Improve image quality by reducing motion blur in low light conditions.  Shutter(s): The length of time that allows light to enter into the lens. You can set a shutter speed when Exposure Mode is set to Manual (Custom).
  • Page 122 Administrator Mode  WDR Level: After enabling the WDR function, you can improve the image by adjusting the WDR level.  Suppress WDR Stripes: Enable Suppress WDR Stripes to automatically adjust shutter frequency based on the frequency of light measured. [Smart Illumination] Figure 3-23 ...
  • Page 123  Near / Far Illumination Level: For GV-TBL8804, you can set the intensity level of the IR light respectively for wide-angle scene (near illumination level) and telephoto view (far illumination level) when Illumination Mode is set to Dual Light and Control Mode to Manual.

  • Page 124: Osd

    Administrator Mode 3.4.2 OSD On Screen Display (OSD) is the text displayed on the screen of video images and may include the date and time and other customized contents. Note GV-ABL2703 series / 4703 / 4711, GV-ADR2702 / 4702, GV-EBD4701 / 4712, GV-TBL2703 series / 4700 / 4703 / 4711, GV-TDR2702 series / 4702 series / 4703 series, and GV-TVD4700 / 4711 only support up to 4 OSD.
  • Page 125 3.4.2.2 For GV-EBD2702 Figure 3-27 1. Click Overlay OSD Content to select the content or type a self-defined text to be displayed on the screen. 2. Click Position and select from Areas 1 to 8 to specify the position of the OSD on the image.

  • Page 126: Privacy Mask

    Administrator Mode 3.4.3 Privacy Mask On certain occasions, you may need to set a mask area to block out parts of the camera image to protect privacy, for example, the keyboard of an ATM machine. When PTZ changes its position or zooms, the Privacy Mask will be adjusted accordingly to protect the area all along.

  • Page 127: Intelligent

    3.5 Intelligent Under Intelligent, users can set the camera to detect for a number of video-analytic events, which can be used to send FTP and/or e-mail alerts, based on the parameters set. Note this function is not supported by GV-ABL2701 series / 2703 series / 4701 series / 4703, GV- ADR2701 / 2702 / 4701 / 4702, GV-TBL2703 series / 4703 and GV-TDR2702 / 4702.

  • Page 128: Cross Line

    Administrator Mode 3.5.1.1 Cross Line Cross line detection generates an alarm when an object moves past the detection threshold in the direction you defined. Up to 4 detection lines can be added. Note that when adding multiple detection lines, make sure they do NOT intersect as it may affect the detection results.
  • Page 129 5. Sensitivity: Drag the slider to adjust the detection sensitivity. 6. Snapshot Object: Select the type of object you want to take a snapshot of. 7. Filter Type: Select the of object you want to define a minimum or maximum size for detection.
  • Page 130 Administrator Mode  Select A -> 1 to trigger an output device upon cross line detection.  Select Recording Edge Storage or Image Edge Storage. Snapshots captured will automatically be stored in the selected storage(s). 15. Optionally select Enable Plan under Plan to set the start and end times during which the video analytic monitoring is enabled.

  • Page 131: Intrusion

    3.5.1.2 Intrusion With Intrusion Detection, an alarm is generated when an object enters the boundaries of the detection area. Up to 4 detection areas can be added. Note that it is recommended NOT to overlap the detection areas when adding multiple detection areas. Select the checkbox next to Intrusion to enable and click to configure.
  • Page 132 Administrator Mode 4. You can use the following functions to reduce false alarm.  Time Threshold: The minimum period of time for an object to stay within the detection area before an alarm is triggered.  Sensitivity: Move the slider to adjust the detection sensitivity. 5.

  • Page 133: Object Removed

    3.5.1.3 Object Removed Object Removed can generate an alarm when an object is removed from the specified area. Up to 4 detection areas can be added. Note that it is recommended NOT to overlap the detection areas when adding multiple detection areas. Select the checkbox next to Object Removed to enable and click to configure.

  • Page 134: Object Left Behind

    Administrator Mode 3.5.1.4 Object Left Behind With Object Left Behind, an alarm can be generated when an object which remained in the detection area for the specified period of time, leaves the specified region. Up to 4 detection areas can be added. Note that it is recommended NOT to overlap the detection areas when adding multiple detection areas.

  • Page 135: Defocus

    3.5.1.5 Defocus Defocus generates an alarm to be sent through e-mail whenever the camera’s image is out of focus. Select the checkbox next to Defocus to enable and click to configure. Figure 3-35 Once enabled, drag the slider to adjust the Sensitivity value. For Trigger Actions, follow Step 14, 3.5.1.1 Cross Line.

  • Page 136: Scene Change

    Administrator Mode 3.5.1.6 Scene Change Scene Change is able to generate an alarm whenever there is a drastic scene change to the image of the camera. Select the checkbox next to Scene Change to enable and click configure. Figure 3-36 Once enabled, drag the slider to adjust the Sensitivity value as desired.

  • Page 137: Face Detection

    3.5.1.7 Face Detection The Face function can detect for and capture face(s) in a specified area and send to an FTP server. Select the checkbox next to Face to enable and click to configure. Figure 3-37 1. Once enabled, define the detection area, either by drawing a desired area on the image or select Full Screen next to Specified Area to set the entire image as detection area.

  • Page 138: People Counting

    Administrator Mode 3.5.1.8 People Counting The People Counting function can count the number of person(s) entering and leaving the vicinity, which is useful at an entrance/exit setting. Select the checkbox next to People Counting to enable and click to configure. Figure 3-38 1.

  • Page 139: Human Body Detection

    3.5.1.9 Human Body Detection Human Body Detection is used to generate an alarm whenever a human figure appears in the specified area. Note this function is only applicable to GV-ABL4711, GV-EBD4701 / 4712, GV-TBL4700 / 4711, GV-TDR4703 series and GV-TVD4700 / 4711. Figure 3-39 In the Snapshot Area, click to add a new detection area.

  • Page 140: Enter Area / Leave Area

    Administrator Mode 3.5.2.0 Enter Area / Leave Area With Enter Area / Leave Area, an alarm is generated when a person or vehicle enters / leaves the boundaries of the detection area. Note this function is only applicable to GV- EBD8800 / 8813, GV-TBL8804 / 8810, and GV-TVD8810.

  • Page 141: Advanced Settings

    7. Under Trigger Actions, select Upload Image(Original) to automatically upload snapshots to the specified FTP server. Select A -> 1 to trigger an output device upon people / vehicle / no vehicle detection. 8. For Plan, follow Step 15, 3.5.1.1 Cross Line. Note: 1.
  • Page 142 Administrator Mode Figure 3-41  Detection Mode: You can choose between Normal Mode, which detects for moving targets continuously, and Filter Repeat Motion Mode, which ignores repeated motions.  Detection Scene: For GV-TBL8810 only, you can choose between Indoor, which only detects people, and Outdoor, which detects both people and vehicles.

  • Page 143: Events

    Events You can set the camera to generate an alarm upon motion detection, tampering alarm and audio detection. 3.6.1 Motion Detection Motion detection is used to generate an alarm whenever movement occurs in the specified area. Figure 3-42 1. In the Detection Area, click to create a new detection area.
  • Page 144 Administrator Mode  If the alarm is triggered within the set time, the alarm will not be cleared until the suppress alarm time expires. Then the alarm can be reported again. 6. For Trigger Actions and Plan, follow Step 14 ~ 15, 3.5.1.1 Cross Line. Note: 1.

  • Page 145: Tampering Alarm

    3.6.2 Tampering Alarm Note this function is only applicable to GV-EBD series, GV-ABL2702 / 2703 series / 4703 / 4711 / 4712 / 8712, GV-ADR2700 / 4710 / 8710, GV-AVD2700 / 4710 / 8710, GV-TBL series, GV-TDR series and GV-TVD series.

  • Page 146: Audio Detection

    Administrator Mode 3.6.3 Audio Detection Note this function is only applicable to audio-in-supporting models. Audio detection is used to detect abnormal audio volume. When the rise, fall, or change of volume exceeds the set limit, or when the input volume reaches the set threshold, an alarm is generated.

  • Page 147: Alarm Input

    3.6.4 Alarm Input Note this function is only applicable to GV-ABL2701 Series / 2702 / 4701 Series / 4711 / 4712 / 8712, AVD2700 / 4701 / 8710, GV-TBL4710 / 4711 / 8710 / 8810, GV-TDR2700 series / 4700 series / 4703 series, and GV-TVD4710 / 4711 / 8710 / 8810. The camera can receive alarm information from an input device.

  • Page 148: Alarm Output

    Administrator Mode 3.6.5 Alarm Output Note this function is only applicable to GV-ABL2701 Series / 2702 / 4701 Series / 4711 / 4712 / 8712, AVD2700 / 4701 / 8710, GV-TBL4710 / 4711 / 8710 / 8810, GV-TDR2700 series / 4700 series / 4703 series, and GV-TVD4710 / 4711 / 8710 / 8810. After alarm output is triggered by a motion detection alarm, temperature alarm or input alarm, the camera can trigger an output device.

  • Page 149: Formatting Storage

    3.7 Storage This section allows you to configure storage related settings and set up FTP server. 3.7.1 Formatting Storage Note this function is only applicable to GV-EBD2702 / 4701 / 4711 / 4712 / 8711 / 8800 / 8813, GV-ABL2702 / 4712 / 8712, GV-AVD2700 / 4710 / 8710, GV-TBL4700 / 4710 / 8710 / 8804 / 8810, GV-TDR2700 series / 4700 series / 4703 series and GV-TVD4700 / 4710 / 8710 / 8810.
  • Page 150 Administrator Mode Note: Face Snapshot is not supported by GV-ABL4711, GV-EBD4701 / 4712 / 8800 / 8813, GV-TBL4700 / 4711 / 8804 / 8810, GV-TDR4703 series, and GV-TVD4700 / 4711 / 8810. [Video Storage Info] Figure 3-49  Storage Policy: Choose the Storage Policy from the three options. ...

  • Page 151: Ftp

    3.7.2 FTP After the configuration of FTP, you will be able to upload snapshots from the camera to the specified FTP server. General Figure 3-50 1. Type the Server IP address. 2. Change the Port No. of the FTP server if needed. 3.

  • Page 152: Backing Up Storage

    Administrator Mode Face This function is used to store snapshots taken for smart functions such as face detection. For GV-EBD8800 / 8813, GV-TBL8804 / 8810, and GV-TVD8810, this function is named Intelligent to store captured snapshots of motor vehicle (cars, trucks, and buses), non-motor vehicle (bicycles and motorcycles), and people.

  • Page 153: Security

    1. Select Photo at the top of the Web interface and click Refresh. 2. Click Ascending Order or Descending Order to sort the folders. 3. Click to view more folders and select or deselect the folders to back up. 4. Click Export and select a destination to store the selected folders. 5.

  • Page 154: Network Security

    Administrator Mode 3.8.2 Network Security There are five types of network security settings: HTTPS, Authentication, ARP Protection, IP Address Filtering and Access Policy. HTTPS You can enable the Hypertext Transfer Protocol Secure (HTTPS) settings to access the camera through a secure protocol. Click On to enable, and optionally click Browse to locate an SSL certificate from your local computer and click Upload.
  • Page 155 ARP Protection This function can protect the camera from ARP attacks. When the camera visits an IP of another network segment via a gateway, it can only communicate with the MAC address binding to the gateway address in the same segment. Figure 3-56 1.
  • Page 156 Administrator Mode Access Policy Access Policy measures the strength of account passwords upon login. Figure 3-58 By enabling Illegal Login Lock, the camera will apply a 5-minute account lockout duration after 5 failed login attempts.

  • Page 157: System

    3.9 System This section allows you to set the camera time and update the firmware. 3.9.1 Time You can use the following methods to adjust the system time of your camera. Time Figure 3-59 Select a Sync Mode.  Sync with System Configuration: Select a Time Zone, manually set a time by clicking on the System Time, or synchronize with the computer time.
  • Page 158 Administrator Mode To adjust the camera’s time for daylight saving time: Click the DST tab at the top. Figure 3-60 Select On to enable DST. Set a Start Time and End Time for the Daylight Saving Time. Select a time period for DST Bias. Click Save.

  • Page 159: Maintenance

    3.9.2 Maintenance This section allows you to upgrade the firmware, restart the camera, and backup/import camera configurations. Figure 3-61 [Software Upgrade] For detailed instructions, refer to 4.1 Upgrading System Firmware and 4.1.1 Using the Web Interface. [Config Management] Export the current configurations of the camera and save them to the PC or an external storage medium.

  • Page 160: Chapter 4 Advanced Applications

    This chapter introduces more advanced applications. 4.1 Upgrading System Firmware GeoVision periodically releases updated firmware on the company website. The new firmware can be loaded into the camera using the Web interface or GV-IP Device Utility. Important Notes before You Start Before you start updating the firmware, please read these important notes: 1.

  • Page 161: Using The Web Interface

    4.1.1 Using the Web Interface Log into the Web interface and follow the steps below to update the firmware. 1. At the top, click Setup. 2. In the left menu, select System and select Maintenance. This page appears. Figure 4-1 3.

  • Page 162: Using Gv-Ip Device Utility

    Advanced Applications 4.1.2 Using GV-IP Device Utility You can upgrade the camera firmware using GV-IP Device Utility. Note the computer used to upgrade firmware must be under the same network as the camera. 1. Download GV-IP Device Utility from the company website.

  • Page 163: Restoring To Factory Default Settings

    4.2 Restoring to Factory Default Settings If for any reason the camera is not responding correctly, you can restore the camera back to its factory default settings using the Web interface or the Default Button. Note: 1. Only GV-EBD4711 / 4712 / 8711 / 8813, GV-ABL2703 series / 4703, GV-AVD2700 / 4710 / 8710, GV-TBL2703 series / 4703 / 8804 and GV-TVD4700 / 4710 / 4711 / 8710 / 8810 support a default button.

  • Page 164: Chapter 5 Dvr / Nvr / Vms

    40 Mbps in throughput and a maximum of 20 streams.  When an IP camera is connected to IE browser or any GeoVision CMS application, it takes up 1 stream; when it is connected to GV-VMS / DVR / NVR, it takes up 2 streams.
  • Page 165 Double-click your camera and type the camera’s User name and Password. Figure 5-2 Click OK. This dialog box appears. Figure 5-3...
  • Page 166 DVR /NVR / VMS Click OK. The IP camera is added to the connection list. Click the listed camera and select Display position to map the IP camera to a channel on the GV-DVR / NVR. Figure 5-4 The Statue column should display “Connected”. Click OK. After the camera is connected and assigned with a display position, you can configure the camera’s settings, such as frame rate, codec type and resolution.
  • Page 167  Live-view frame rate control (Sub / Main): Set the frame rate of the stream to help reduce the CPU usage. If the codec is set as MJPEG, select the number of frames to allow in a second. If the codec is H.265 or H.264, select one of the following options: ...

  • Page 168: Setting Up Ip Cameras On Gv-Vms

    DVR /NVR / VMS 5.2 Setting Up IP Cameras on GV-VMS Follow the steps below to manually connect your camera to GV-VMS. 1. To access the IP Device Setup page, click Home , select Toolbar , click Configure and select Camera Install. Figure 5-6 2.
  • Page 169 4. Click OK. This dialog box appears. Figure 5-8 5. Click OK to add the camera to the list. 6. To connect the added camera, click the box beside the ID column. Upon successful connection, the Status icon shows green, with the video resolution and bitrate being displayed in the correspondent columns.

  • Page 170: Appendix

    Appendix Appendix A. RTSP Multicast Protocol Support The camera can support RTSP multicast protocol for both video and audio streaming. You can use the following RTSP multicast command to access the camera image: Stream 1: rtsp://<IP of the camera>/multicast/video1 Stream 2: rtsp://<IP of the camera>/multicast/video2 For example, rtsp:// 192.168.4.115/multicast/video1 B.

  • Page 171: Compatible Versions Of Gv-Vms / Dvr / Nvr

    D. Compatible Versions of GV-VMS / DVR / NVR Compatible versions of GV-VMS / DVR / NVR based on camera models listed as follows: Camera Model Compatible GV-DVR / NVR Compatible GV-VMS GV-EBD2702 V8.7.4.0 with patch files or later V17.1 with patch files or later GV-EBD4700 V8.7.3.0 with patch files or later V16.11.0.0 with patch files or later...
  • Page 172 Appendix GV-TBL2703 Series V17.3.0 with patch files or later V17.3.0 with patch files or later GV-TBL4700 V18.1.1 with patch files or later V8.8.0 with patch files or later GV-TBL4703 V17.3.0 with patch files or later GV-TBL4710 V17.1.0.100 with patch files or later V17.3.0 with patch files or later GV-TBL4711 V18.1.1 with patch files or later...

  • Page 173: Gv-Mount Dimensions

    E. GV-Mount Dimensions Dimensions of various GV-Mount are illustrated below: GV-Mount Models Dimensions 1"NPT 20mm 20mm (0.3") (0.79") (0.79") GV-Mount107 25mm 15mm (0.98") (0.59") 120mm (4.72") 300mm (11.8") 16mm (0.63") GV-Mount211-2 GV-Mount211P GV-Mount212-2...
  • Page 174 Appendix GV-Mount212P GV-Mount213 160mm 233mm (9.17") (6.3") 7.5mm 20mm (0.3") (0.79") 15mm GV-Mount300-2 (0.59") 160mm (6.3") 160mm (6.3") 290mm (11.4") 20mm (0.79") GV-Mount310-2 15mm (0.59") 45mm 45mm (1.77") (1.77") 130mm (5.11") 160mm (6.3") GV-Mount502...
  • Page 175 GV-Mount503 GV-Mount504 GV-Mount606 40mm 100mm (3.94") (1.57") 200mm (7.87") GV-Mount704 300mm (11.8") 10 / 20 / 30 / 50 cm 500mm (19.7")
  • Page 176 Appendix F. GV-Mount300-2 / 310-2 GV-Mount300-2 / 310-2 Packing List   Mounting Bracket Convex Mounting Plate x 2 (for GV-Mount300-2)  Concave Mounting Plate x 2 (for GV-Mount310-2)   Carriage Bolt x 6 1/4” Plain W sher x 6 ...
  • Page 177 To install GV-EBD Series, GV-ABL / TBL Series, GV-ADR2702 / 4702, GV-TDR Series, or GV-AVD / TVD Series directly on GV-Mount300-2 / 310-2, follow the instructions below. Assemble the GV-Mount300-2 / 310-2, by attaching the two mounting plates onto the mounting bracket with the supplied carriage bolts, 1/4”...

  • Page 178: Screw Position Chart

    Appendix Secure your GV-IP Camera to the GV-Mount211P / 211-2 / 212-2 / 212P / 213 / 502 / 503 to complete the installation. Note: For details on attaching your GV-IP Camera to GV-Mount211P / 211-2 / 212-2 / 212P / 213 / 502 / 503, see optional installations in Chapter 1 Introduction. G.

This manual is also suitable for:

Gv-abl seriesGv-tbl seriesGv-adr seriesGv-tdr seriesGv-avd seriesGv-tvd series ... Show all

Table of Contents

Save PDF
