Chapter 2 — Installation
Media Supply Positions
10
Therearefoursetsofslotsandthreadedholesintheprinter's
centersectionforthemediasupplyrollpostorrotatinghub
(optional).Theseslotsallowthelargestpossiblerollsizetofit,
giventhelimitationsofanylinertakeupunitand/orthefull
enclosureprovidedbythelongsidedoororMegatop.The
positionsareindicatedbynumbersengravedinthecenter
section.Theprintercanalsouseanexternalmediasupplylocated
behindtheprinter,unlessithasanoptional8-inchMegatop
·Position1:Themediacompartmentisfullyenclosedbyalong
sidedoor,regardlessoftheexistenceofanyintegrallinertakeup
unit.Maximumrollsizeis152mm(6inches).
·Position2:Theshortsidedooronlyenclosestheprint
mechanismanddoesnothaveanintegrallinertakeupunit.
Maximumrollsizeis203mm(8.00inches).
·Position3L:Theshortsidedoorandanintegrallinertakeup
unit.Thispositionisalsousedwiththeoptional8-inch
Megatop.Formoreinformation,seeChapter7,"Options"on
page67.Maximumrollsizeis213mm(8.38inches).
·Position4isnotused.
2
Media Supply Positions
4
Position 1
Position 4
(not used)
