Chapter B — Media Specifications
Media Roll Size
Core
Media
110
Diameter(A),standard:38-40mm(1.5inches),withadapter:
76.2mm(3inches)
Width:Mustnotprotrudeoutsidethemedia.
Themediamustbewounduponthecoreinsuchawaythatthe
printercanpulltheendfree.
Diameter:
·Position1
·Position2
·Position3
Maximum:114.3mm/4.50inches
Minimum(standard):25mm/1.00inches
Minimum(Quick-Load):40mm/1.57inches
