Interface Cable
Optional Interfaces
EasyCoder PF4i User's Guide (IPL Version)
*Theexternal+5Vislimitedto500mAandisautomatically
switchedoffatoverload.
Computerend:Dependsoncomputermodel
Printerend:DB-9plug
TheprintercanoptionallybefittedwithanIEEE1284Parallel
InterfaceBoardattheright-handsideoftheprinter'srearplate.
TheprintercanalsobefittedwithoneofthefollowingEasyLAN
interfaceboardsforconnectiontoaLocalAreaNetwork(LAN).
·EasyLANEthernetInterface
·EasyLANWirelessInterface
IEEE 1284 Parallel Interface Board
EasyLAN Ethernet Interface
Chapter C — Interfaces
Parallel interface connector
RJ-45 EasyLAN connector
